INSYTE PRODUCT OPERATION DESCRIPTIONS Page 1 of 8 Female Male InSyte Product Operation Descriptions Part I: The Product InSyte 1 is a product designed with the intention of providing a secure measure to prevent any misuse, whether intentional or unintentional, of firearms, to deter weapon theft, and ensure security within the home. InSyte 1 is a revolutionary solution that satisfies both the gun control and gun rights activists. It is designed to fit 95% of the firearms in the market, both historic and modern, without altering the firearm. InSyte 1 simple design and user-friendly mechanism offers a product that is within reach of any customer. 1.1. Product Physiognomy InSyte 1 exhibits a two-piece assembly device that is composed by a main enclosure assembly (Male part) and the slide lock assembly (Female part). 1.1.1. Main Enclosure Assembly The Main Enclosure Assembly (Male part) consists of a housing structure that holds the electronics, the batteries, the alarm (15), the universal trigger lock (17) and an adjustable tapered lock element (16) that will connect the Male part to the Female part. 1.1.2. Slide Lock Assembly The Slide Lock Assembly (Female part) consists of a housing (18), defining sockets for receiving tapered lock (16), and a pair of pawl elements mounted in the housing for unlocking the assembly. Each one of the pawls is on opposing sides, including a latch end and a release. 1.2. Unlocking Mechanism The Unlocking Mechanism showcases two pawl elements, which are buttons that must be depressed simultaneously to enable the system to become unlocked. The morphology of the buttons is made in a way that a certain amount of pressure has to be applied to enable the release procedure to occur. The mechanism’s ultimate purpose is to provide a childproof device that will prevent misuse of the weapon. An elastomeric band will cover the pawl mechanism to enhance the stealth effectiveness of the unlocking system. This amplifies the same ideology as pharmaceutical locking devices for caps on prescriptions drug containers. 1.3. Power System The device is designed to function with three (3) VDC power coin batteries that will be placed in the main Male enclosure assembly. The expected battery life is minimum one (1) year, up to 18 months, depending on number of alarms set off during that period. There will be a battery decay alarm that will indicate when the batteries need to be replaced. 1.4. Alarm System The Alarm System is located in the Male part of the device. It is designed to alert the gun owner of an unauthorized movement of the firearm. The device will produce a distinct alarm that will sound for 10 seconds and reset after 5 seconds for an additional period of 10 seconds. The alarm system cycle will continue to sound until the weapon is settled, disarmed and/or there is no further movement of the firearm. An additional alert system is released when the device has been unlocked; producing a higher and more defined alert sound to inform the gun owner that the InSyte 1 device has INSYTE PRODUCT OPERATION DESCRIPTIONS Page 2 of 8 been disassembled. The alarm may be switched off by depressing, for a period of 3 seconds, the stealth Multifunction Tact Switch, located on the Male component of the device. The motion movement alarm is triggered through the warning circuit within the device. Utilizing an Omni-directional Motion Sensor, sending a signal to an Oscillator, driving a Piezoelectric Transducer, producing a minimum of 85db @ 3.5kHz warning sound for a duration of 10 seconds, then resets. 1.5. Trigger Lock The Trigger Lock represents a universal system that prevents the unauthorized use of a firearm. It exhibits an adjustable locking cam that extends through the trigger guard and behind the trigger. In this manner, the firearm is rendered inoperative until the InSyte 1 complete mechanism is removed by an authorized user. This will also prevent possible accidents derived from an inappropriate handling of the firearm by an unauthorized person. 1.6. The 6-button Keypad controls The 6-button Keypad will establish the system control, enabling the following qualities: Six-button (Four-numeric keys) keypad design: There are six keys on the keypad for user input. We name them as “ ”, “
”, “”, “”, “”, and “”. For easier document writing, we use the following symbols “
” for the keys respectively.. The meaning of each key is defines as follows:  “ ”: Command Button: This is a special button (we also call it the “wake up button”). No matter the InSyte device at what status mode, once this button is pressed, it will take the InSyte device into the Wakeup Mode.  “
”, “”, “”, and “”: Numeric keys: These keys are used to instruct the actions defined be the key sequence combinations. The following document will explain them in details.  “ ”: Control Button: This is another special button (we also call it the “confirm button”). This key is used to start an option command, or to end an action command sequence, or to confirm user key input action. A: SPECIAL Commands: 1) “ ”: “TO ARM” the devices: once this key combination is pressed, the InSyte device will be armed immediately, and a reminder message will be played. 2) “ ####”: “TO DISARM” the devices: if the “####” is the correct password, then this InSyte device will be disarmed immediately, and a reminder message will be played. If the “####” is NOT the correct password, then device will play a reminder message and then this command is void. User can ONLY try this command 5 times with incorrect passwords. B: GENERAL Commands: The command key sequence “ #”: We have to define the actions for this InSyte command key similar to these keys on the remote control. So, here is what I think it will do. The definitions of general commands are as follows: INSYTE PRODUCT OPERATION DESCRIPTIONS Page 3 of 8 a) “
”: to change password; b) “”: to change the alarm sounds; c) “”: to check the battery usage; d) “ ”: to perform coupling between InS…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 Advanced Warning Systems, LLC 2015/9/19 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, Advanced Warning Systems, LLC hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product description: AWS-SC model name: AWS-EC, AWS-RC, AWS-SC. FCC ID: 2AFCJAWS-SC Sincerely, Client’s signature Client’s name / title : Richard YuSu / Manager Contact information / address: 2690 Paseo Verde, Lake Havasu City, AZ 86406, USA

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526- 1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (current) 3.0 4.0 March-26-2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 4.0 Advanced Warning Systems, LLC 2015/9/19 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AFCJAWS-SC We hereby request confidential treatment of information accompanying this application as outlined below: - e.g. Block Diagram - e.g. Schematics - e.g. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Client’s name / title : Richard YuSu / Manager Contact information / address: 2690 Paseo Verde, Lake Havasu City, AZ 86406, USA

Advanced Warning Systems, LLC Model Difference FCC ID: 2AFCJAWS-SC Model : AWS-EC, AWS-RC, AWS-SC. All the same,Only model name is different. Regards Sincerely Client’s signature Client’s name / title : Richard YuSu / Manager Contact information / address: 2690 Paseo Verde, Lake Havasu City, AZ 86406, USA

Shenzhen BCTC Technology Co., Ltd. FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page1 of 8 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Shenzhen BCTC Technology Co., Ltd. FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page2 of 8 Photo 3 Photo 4 Shenzhen BCTC Technology Co., Ltd. FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page3 of 8 Photo 5 Photo 6 Shenzhen BCTC Technology Co., Ltd. FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page4 of 8 Photo 7 Lab provides adapter

Model: AWS-EC FCC ID: 2AFCJAWS-SC Advanced Warning Systems, LLC This device complies with Part 15 of the FCC Rules. Operationis subject to the following two conditions:(1)This device may not cause harmful int erference, and (2) this device must accept anyinterference received, incl uding interference that may cause undesired operation.

Shenzhen BCTC Technology Co., Ltd. FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page5 of 8 Photo 8 Photo 9 Shenzhen BCTC Technology Co., Ltd. FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page6 of 8 Photo 10 Photo 11 Shenzhen BCTC Technology Co., Ltd. FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page7 of 8 Photo 12 Photo 13 RF ANT Shenzhen BCTC Technology Co., Ltd. FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page8 of 8 Photo 14

Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15090268 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 1 of 31 FCC Part 15C Test Report FCC ID: 2AFCJAWS-SC Product Name: AWS-SC Trademark: , Model Name : AWS-EC AWS-RC, AWS-SC. Prepared For : Advanced Warning Systems, LLC Address : 2690 Paseo Verde, Lake Havasu City, AZ 86406, USA Prepared By : Shenzhen BCTC Technology Co., Ltd. Address : No.101,Yousong Road,Longhua New District, Shenzhen,China Test Date: Sep. 16 – Sep. 21, 2015 Date of Report : Sep. 21, 2015 Report No.: BCTC-15090268 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15090268 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 2 of 31 VERIFICATION OF COMPLIANCE Applicant’s name ................. : Advanced Warning Systems, LLC Address ................................. : 2690 Paseo Verde, Lake Havasu City, AZ 86406, USA Manufacture's Name ............ : Shanghai JiuSheng Intelligence Device Limited Address ................................. : 101 Room, E block, Long Wu Road, No.1500,Shanghai, China Product description Product name ............................ : AWS-SC Trademark: , Model Name: AWS-EC Test procedure FCC Part15.249 Standards ANSI C63.10-2013 This device described above has been tested by BCTC, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BCTC, this document may be altered or revised by BCTC, personal only, and shall be noted in the revision of the document. Test Result.............................................. : Pass Testing Engineer : (Eric Yang) Technical Manager : (Sophia Lee) Authorized Signatory : (Carson. Zhang) Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15090268 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 3 of 31 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 5 1.2 MEASUREMENT UNCERTAINTY 5 2 . GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 DESCRIPTION OF TEST MODES 7 2.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 8 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 8 2.5 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 8 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 9 3 . EMC EMISSION TEST 10 3.1 CONDUCTED EMISSION MEASUREMENT 10 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 10 3.1.2 TEST PROCEDURE 11 3.1.3 DEVIATION FROM TEST STANDARD 11 3.1.4 TEST SETUP 11 3.1.5 EUT OPERATING CONDITIONS 11 3.1.6 TEST RESULTS 12 3.2 RADIATED EMISSION MEASUREMENT 14 3.2.1 RADIATED EMISSION LIMITS 14 3.2.2 TEST PROCEDURE 15 3.2.3 DEVIATION FROM TEST STANDARD 15 3.2.4 TEST SETUP 16 3.2.5 EUT OPERATING CONDITIONS 17 3.2.6 TEST RESULTS 18 4 . BANDWIDTH TEST 22 4.1 APPLIED PROCEDURES / LIMIT 22 4.1.1 TEST PROCEDURE 22 4.1.2 DEVIATION FROM STANDARD 22 4.1.3 TEST SETUP 22 4.1.4 EUT OPERATION CONDITIONS 22 4.1.5 TEST RESULTS 23 5 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 26 5.1 DEVIATION FROM STANDARD 27 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15090268 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 4 of 31 Table of Contents Page 5.2 TEST SETUP 27 5.3 EUT OPERATION CONDITIONS 27 5.4 TEST RESULTS 27 6 . ANTENNA REQUIREMENT 28 6.1 STANDARD REQUIREMENT 28 6.2 EUT ANTENNA 28 7 . EUT TEST PHOTO 29 8 . EUT PHOTO 31 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15090268 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 5 of 31 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.249) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.249 Fundamental &Radiated Spurious Emission Measurement PASS 15.249 Bandwidth PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report 1.1 TEST FACILITY Shenzhen BCTC Technology Co., Ltd. Add.:No.101,Yousong Road,Longhua New District, Shenzhen,China FCC Registration No.:187086 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15090268 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 6 of 31 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment AWS-SC Trade Name , Model Name AWS-EC Serial Model AWS-RC, AWS-SC. Model Difference All the same, Only model name is different. Product Description Operation Frequency: 2402~2480 MHz Modulation Type: GFSK Bit Rate of Transmitter 1M Number Of Channel 79 CH Antenna Designation: Please see Note 3. Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an ITE/Computing Device. More details of EUT technical specification, please refer to the User's Manual. Channel List Please refer to the Note 2. Adapter N/A Battery DC 3.7V Connecting I/O Port(s) Please refer to the User's Manual hardware version -- Software version -- Serial number -- Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. 2. Channel List Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 00 2402 27 2429 54 2456 01 2403 28 2430 55 2457 02 2404 29 2431 56 2458 03 2405 30 2432 57 2459 04 2406 31 2433 58 2460 05 2407 32 2434 59 2461 06 2408 33 2435 60 2462 07 2409 34 2436 61 2463 08 2410 35 2437 62 2464 09 2411 36 2438 63 2465 Shenzhen BCTC Technology…
