2AFGO-A990BLBLUETOOTH EARPHONE

A990 BL Wireless Sport Stereo Bluetooth Earphones USER MANUAL Introduction Thank you for purchasing the model AWEI-A990BL smart Bluetooth stereo Earphones. Pls read this manual before use. Bluetooth wireless communications Technology Introduction Bluetooth is a kind of wireless technology which support short distance communications (work normally within a distance of 10M) with it you can exchange information by wireless between many IT digital devices like mobile phones / wireless earphones / computers ect. Bluetooth technology effectively and simplify to the communications which makes device and data transmission quickly and off effectively. Function Introduction The latest technology of CSR,and backward compatibility V4.0, V3.0, V2.1, V2.0, V1.2, V1.1. Internal integrate 80MHz RISC MCU and 80MIPS Kalimba DSP, However Bluetooth 3.0 the maximum support to 64MHz RISC MCU and 64MIPS Kalimba DSP. This product supports Profiles: ■ HFP v1.6 wideband speech (HD voice ready) ■ HSP v1.2 ■ A2DP v1.2 ■ AVRCP v1.4 ■ CVC Version 6.0 Effective distance: 10metres Work frequency: 2.402-2.480GHz Support multi-point connection (simultaneous connection of two mobile phones) Two mobile phones, one headset, a key to answer the call. Support voice report number When phone call coming, automatic report telephone numbers to avoid important telephones. E.g.: “1”“0”“0”“8”“6” phone call coming. Support voice reminding function Real-time report to users the status of the Bluetooth earphone, handle skillfully. E.g.: “Bluetooth is turned on”, “Bluetooth is power off”. iPhone: power consumption display function: Display Bluetooth headset power on iPhone , In order to consider whether need to charge the headset. Take A Look A. Calls and streaming audio ◆ Take a call or end it (1 tap) ◆ Reject a call (2-second press) ◆ Hold first call and answer second call (1 tap) ◆ Switch between calls (2-second press) ◆ End second call and retrieve first call (1 tap) ◆ Transfer call from phone (1 tap) ◆ Redial (2 taps) ◆Use phone’s voice-control feature to make a call (2-second press unitil tone is heard) ◆ Reconnect lost Bluetooth® connection (1 tap if the earbuds can’t automatically reconnect) ◆ Play or pause audio (1 tap) B. Micro USB charging port (right earbud) ◆ 1 hour before first use (LED is red until fully charged) ◆ 2.5 hours for full charge C. Volume, tracking and mute ◆ Volume up or down (1 tap on + or - per level change) ◆ Track forward or back (3 second press on+ or- per track change) D. Power, pawing and battery check ◆ Turn on or off (2-seconds press) ◆ Activate pairing mode after initial set up (press until red/blue LED flashes) ◆ Check battery level (1 tap when power is on) Get Connected 1. Ready First time, right out of the box: With earbuds turned off, activate Bluetooth pairing mode by pressing Power/Pairing button on. The LED flashes red/blue to indicate pairing mode. Pairing new phone/reconnecting original: With earbuds turned off, Press Power/Pairing button until the LED flashes red/blue. 2. Set Activate the Bluetooth feature on your device, then use phone menus to “add,” search” or “scan” for new Bluetooth devices. Phones have different menus to select from: iPhone: Settings > Bluetooth > On (starts the search for devices) BlackBerry® smartphone: Settings/options >Bluetooth: On > Search for devices Android smartphone: Settings > Bluetooth: On > Scan for devices 3. Connect Select “AWEI-A990” from the list of Bluetooth devices shown on your device. If device asks for a passcode, enter four zeros (0000). You may see **** on screen. Some devices also ask to confirm connection after paring. The earbud’s LED will stop flashing red/blue once successfully paired/connected. You can now make a call using your device’s keypad or voice-dialing feature and enjoy audio listening from your device. Try It On The right fit = the best audio:] For the best sound performance and a secure, Comfortable fit, Be sure to adjust the earbuds to rest gently in your ear. And drape around the back of your neck, Use the provided fit kit to find the ear tip that works best for you. Learn More Stay near your device: Bluetooth has a working “range” of up to 33 feet between your phone and earbuds before audio degrades and the connection is lost. For best audio reception, keep your phone on the right side of your body. Learn how to reconnect: Your earbuds try to reconnect a lost connection. If they can’t, then tap the Call button once or manually reconnect via your phone’s Bluetooth menu. Decipher the beeps: If you have a call on hold, you will hear a beep every 5 seconds, If you are on mute, you will hear a beep every 30 seconds. In addition, if you long-press certain buttons (more than 2-seconds press), a feedback beep will be heard (example, accessing the Voice control feature on your phone). Juggle two calls: You can take a second call and place the first call on hold by tapping the call button to accept the new call. Switch between calls by pressing the Call button for a few seconds and you will hear a beep, indicating the switch is happening. Learn More You can end a call and return to the other call on hold by tapping the Call button. Some phones require tapping the Call button twice. Use your voice: Some smart phones allow you to use voice commands to activate their features, such as voice-dialing or playing music. To activate your smart phone’s voice controls, press the Call/Audio button until you hear your phone prompt you for a command. Never miss a call: You will hear an incoming call alert while listening to stored or streaming audio. When you take the call, you stored audio (downloaded tunes, video or podcast ) will pause. If you are listening to live streaming audio (Internet radio) then it will mute, not pause, during your call. Once you end your call, your playback or streaming will resume. Check the battery level: If you are on a call or listening to audio you will hear a tone when the battery is low. You can-check the batter…

Text truncated - open the document above for the full version.

SHENZHEN YALE ELECTRONICS CO., LTD 4 th Floor, Building 2, Huaxing Road 35, Yujingtai Industrial Park, Dalang, Longhua District, Shen zhen DATE :2015-08-19 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Kevin Yu of Shenzhen EBO Technology Co., Ltd. to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with SHENZHEN YALE ELECTRONICS CO., LTD and 4 th Floor, Building 2, Huaxing Road 35, Yujingtai Industrial Park, Dalang, Longhua District, Shenzhen Dated this / Day of 19/8/2015 / Agency agreement expiration date: 18/8/2016 By: Lu Han Xi Signature Printed Title: Manager On behalf of : SHENZHEN YALE ELECTRONICS CO., LTD Telephone: +86 0755-82999998

SHENZHEN YALE ELECTRONICS CO., LTD 4 th Floor, Building 2, Huaxing Road 35, Yujingtai Industrial Park, Dalang, Longhua District, Shenzhen DATE :2015-08-19 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AFGO-A990BL Product Name: BLUETOOTH EARPHONE Request for Long-term Confidentiality Pursuant to Sections 0.457 and 0.459 of the commission rules, we hereby request that the following documents be held confidential long term:  Block diagram  Schematics  Operational Description These documents contain detailed system and equipment description and related information about the product which SHENZHEN YALE ELECTRONICS CO., LTD. considers to be proprietary, confidential, and a custom design and, otherwise would not release to the general public. Since this design is a basis from which future technological products will evolve, SHENZHEN YALE ELECTRONICS CO., LTD. Considers this information to be of benefit to its competitors, and that the disclosure of information in these documents would give competitors an unfair advantage in the market Dated this / Day of 19/8/2015 / By: Lu Han Xi Signature Printed Title: Plant Manager On behalf of : SHENZHEN YALE ELECTRONICS CO., LTD Telephone: +86 0755-82999998

Differences Declaration To whom concern, We, SHENZHEN YALE ELECTRONICS CO., LTD hereby declares: The product model(s) A800BL, A810BL, A820BL, A830BL, A840BL, A850BL, A860BL, A870BL, A880BL, A890BL, A900BL, A910BL, A920BL, A930BL, A940BL, A950BL, A960BL, A970BL, A980BL are identical in the PCB layout, interior structure and electrical circuits with the product model A990BL, the only differences are the model name for commercial purpose and Colour. Authorized signature: Position: Manager Date: 2015/8/19

External Photos of EUT Sample

53mm 10.5mm

Internal Photos of EUT Sample

FCC ID: 2AFGO-A990BL According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where --f(GHz) is the RF channel transmit frequency in GHz --Power and distance are rounded to the nearest mW and mm before calculation --The result is rounded to one decimal place for comparison eirp = pt x gt = (EXd) 2 /30 where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, --- 10 ((dBuV/m)/20) /10 6 d = measurement distance in meters (m) ---3m So pt = (EXd) 2 /30 x gt Field strength = 97.84dBuV/m @3m Ant gain =0dBi, so Ant numeric gain= 1 So pt={ [10 (97.84/20) /10 6 x 3] 2 /30x1 }x1000 mW = 1.824mW So (1.824mW /5mm)x √2.480 = 0.575<3 Then SAR evaluation is not required
