  1 MobileComputer CFON640  UserManual Corewise Smart Technology Inc Trade Mark: Corewise   2  Introduction ThanksforappreciationforCFON640. Beforeusingproduct,plscarefullyreadintroduction.                (Statement) CFON640(Classproduct)maycauseradiointerferenceintheliving environment,inwhichcasetheusermightberequiredtotake adequatemeasures. Corewise Smart Technology Inc BB   3  Overview    Mainperformanceindicators OS:Android4.1 *Networks: GSM(GPRS/EDGE)/WCDMA Screen: 7inchHDLCD(Resolution600*1024) Processor: 1.2G(Quadcore) *Bluetooth: BluetoothV2.1+EDR *Wifi: b/g/n(HT20);11channels Camera: 5MˈAutofocusˈflashlight USB: USB2.0 *FingerprintSensor: 508DPI RFID:13.56MHz  Corewise Smart Technology Inc   4  *BarcodeScanner: 1Dand2D(Professionalreadinghead) Temperature: 0 ~50ćć˗Humidity: 20%~90%RH Dimensions: 220*132*26.5mm Weight: 650g                  Corewise Smart Technology Inc   5  Catalogue 1ǃAppearanceIntroduction.............................................................6 2ǃStatusbarIcons ............................................................................7 3ǃGettingStarted ............................................................................8 ImportantNotification.................................................................8 BatteryCharging ..........................................................................8 ConnectDevicetoComputer.......................................................9 4ǃBasicFunction..............................................................................9 UnlockandLockScreen ...............................................................9 UsingApplication.........................................................................9 ViewNotification .......................................................................10 InputText...................................................................................10 5ǃFunctionIntroductioninDetail .................................................11 RFIDApplication.........................................................................11 *FingerprintCollectingApplication ...........................................12 BarcodeScanner........................................................................13 TakePhotosorVideo.................................................................14 CopyingFile................................................................................14 ConvenientTools .......................................................................14 6ǃSimpleTroubleshootingInstructions.........................................15 Corewise Smart Technology Inc   6  1 ǃ AppearanceIntroduction HeadphoneUSBCharging  VolumeResetPower FrontCamera Fingerprint RFID IndicatorLight SD Slot Corewise Smart Technology Inc   7 Powerkey:Longpresstoturnon/off. Volumekey:Adjustvolume. Reset:Restartdevice Chargerinterface:Connectcharger. USBinterface:ConnectUSBcabletocomputor. *Fingerprintsensor:Pressthisarea. RFIDarea:PutRFIDcardhere. Indicatorlight:display deviceinacertainstate˗ Fromlefttoright: їChargingindicator:Chargingstateisred,chargingsaturationstateturnsgreen. їPowerͲonlight:Devicewillbepoweredonbeforefingerprintfunction,indicator turnsblue. ї*Fingerprintlight:Bluelightflashesinprocessofcollecting. їRFIDlight:Lightflashes inbluewhenreadingRFIDcard.      Barcodescanner:Putbarcodeinscanningarea.  2.StatusbarIcons Thestatusbardisplaystime,batterystatus,signalstrength,operatornameor notificationicon. Statusbariconinformationatthetopofscreen:        Flashlight Barcode BackCamera  Corewise Smart Technology Inc   8    3. Gettingstarted  їImportantNotification  ͼToavoidunnecessaryharm,plsnotefollowinginformationbeforeusing: ͼPlsdon’tturnondevicewherewirelessdeviceisprohibited.Suchasaircraft,medical placesandnearbymedicalequipment. ͼPlsdon’tturnondevicesintheplacewherecouldcauseinterferenceor danger.Suchasnearbygasstation,fuelorchemicals,blasting point. ͼPlsuseoriginalaccessoriesandbatteryinsteadofincompatibleones. ͼPlskeepphonedry. ͼPlsfindqualifiedpersonnaltorepairit. ͼWhenconnectingotherdevices,pleaserefertotheusermanual,don'tconnect incompatibledevicesarbitrarily.  їBatterycharging Poweroffstate,charginglightshowsbatterylevel. Poweronstate,batterydisplaysbatterylevelorchargingstateinthelowerright cornerofscreen. PlsconnecttopoweroutletwithsuppliedchargerorconnectUSBcabletocomputer.  Corewise Smart Technology Inc   9  їConnectdevicetocomputer  ConnectdevicetocomputerwithUSBcable,ifsucceed,”USBConnected"appears inDeviceͲside. Ifproblemsappearwhencomputerconnectsthedevice,plsoperateaccordingto guide:Accordingtotheguide,installdevicedriversandtoolsinthecomputer.  4.BasicFunction  їUnlockscreenandlockscreen Tounlockthescreen,plsclickanddragtheunlockbuttononthescreentounlockthe iconandentersintofunctionmodule.Tolockthescreen,plssimplypressthepower buttonatanyinterface,thephoneentersintosleepmode.  їUsingApplication Plsclicktheicontoopenapplication. Returntomainscreen:pressthehomekeybelowthedisplay. Switchtootherscreen:swiftfingeronleftorright,orbottomdotpaddlingarea. Switchrecentlyusedapplications:longpressthehomekey. LongpressseldomͲusedfunctionicontodelete. Corewise Smart Technology Inc   10 їViewNotification Plsslidedownthestatusbartoviewthedetailso…
