2AFHU-SR150FRadar-Based, Outdoor Perimeter Security Sensor

SR-Series User Manual Page 1 © Copyright 2017, Magos Systems. All Rights Reserved 1. INTRODUCTION ....................................................................................... 3 1.1 About Magos Systems ....................................................................... 3 1.1.1 Contacting Magos Systems ...................................................................... 3 1.1.2 Contacting Magos Support ....................................................................... 3 2. SCOPE ...................................................................................................... 4 2.1 Professional Installation Instructions .................................................. 4 2.1.1 Installation personnel .............................................................................. 4 2.1.2 INSTALLATION LOCATION .................................................................... 4 2.1.3 INSTALLATION procedure ....................................................................... 4 2.2 identification ....................................................................................... 4 2.3 system overview................................................................................. 4 3. SYSTEM DESCRIPTION ......................................................................... 6 4. MECHANICAL INSTALLATION .............................................................. 8 4.1 Installation Restrictions and Limitations ............................................. 8 4.2 general installation guidelines ............................................................ 9 5. ELECTRICAL INSTALLATION GUIDELINES ........................................ 18 5.1 Power Supply Interface ...................................................................... 18 6. COMMUNICATION INTERFACE ............................................................ 19 6.1 Radar Manager .................................................................................. 19 7. BIT ............................................................................................................. 22 7.1 BIT Mechanism .................................................................................. 22 7.2 BIT Description .................................................................................. 22 TABLE OF CONTENTS Page 2 © Copyright 2017, Magos Systems. All Rights Reserved 7.3 Handling Failed BIT Reports .............................................................. 23 8. WARNINGS AND DISCLAIMERS ........................................................... 24 8.1 General .............................................................................................. 24 8.2 FCC Compliance Statement .............................................................. 24 8.3 Industry Canada Compliance ............................................................. 25 8.4 Warranty ............................................................................................ 25 8.5 Limitation of Liability ........................................................................... 26 Figure 1 – SR sensor general view .................... Error! Bookmark not defined. Figure 2 – SR sensor outline and dimensions ................................................... 9 Figure 3 – SR Tripod Installation...................................................................... 10 Figure 4 – SR Tripod adapter .......................................................................... 10 Figure 5 – SR Wall Installation ......................................................................... 11 Figure 6 – Wall mount Bracket ......................................................................... 11 Figure 7 – Elevation angle Adjustable Bracket ................................................ 12 Figure 8 – Proper Installation on tripod ............................................................ 12 Figure 9– Proper Installation on fence ............................................................. 13 Figure 10 Angle Coverage ............................................................................... 13 Figure 11: Nominal detection ranges as a function of angle of approach ........ 14 Figure 12: Tilt Angle ......................................................................................... 14 Figure 13: Tilt Angle ............................... Error! Bookmark not defined. - Table Figure 14: SR External operation cable ............. Error! Bookmark not defined. Figure 15: Radar Manager Main Screen ............ Error! Bookmark not defined. Figure 16: Radar Manager - Choosing a fixed IPError! Bookmark not defined. TABLE OF FIGURES Page 3 © Copyright 2017, Magos Systems. All Rights Reserved 1. INTRODUCTION 1.1 ABOUT MAGOS SYSTEMS Magos was established in 2007 to realize its co-founders' vision of bringing advanced radar technology to the security and perimeter protection and detection market. We are Experts in Low cost, Low power consumption, High performance radars that can be easily integrated with existing VMS, PSIM and other control software and automatic PTZ slew-to-cue for an end-to-end cost effective and easily maintained solution of the customer’s security requirements. 1.1.1 CONTACTING MAGOS SYSTEMS Please contact us through the following channels: Medium Details Email [email protected] Mail Gad Feinstein 13 Office 225, Rehovot Israel 7638517 Website www.magosys.com 1.1.2 CONTACTING MAGOS SUPPORT Support is available to customers who have a trial version of a Magos product or who have purchased a Magos product and have a valid maintenance contract. To contact Magos support, send an email to [email protected]. Page 4 © Copyright 2017, Magos Systems. All Rights Reserved 2. SCOPE This document aims to provide a user manual for the setup and installation of the SR sensor by Magos Systems. The manual provides information on mechanical structure and interface, installation procedure and guidelines, interface to managing system. P…

Text truncated - open the document above for the full version.

Date: 6 December 2022 To Whom It May Concern We hereby authorize Mr. Moshe Zohar of I.T.L. Product Testing Ltd. to act on our behalf regarding the FCC grant process, for the following application: FCC ID: 2AFHU-SR150F Thank you,

Date: 6 December 2022 To Whom It May Concern We hereby authorize Mr. Moshe Zohar of I.T.L. Product Testing Ltd. to sign Form 731 on our behalf, for the following application: FCC ID: 2AFHU-SR150F Thank you,

Date: 5 January 2023 To: Federal Communications Commission Authorization and Evaluation Division Confidentiality request regarding the application for the certification of FCC ID: 2AFHU-SR150F Pursuant to Sections 0.457 and 0.459 of the Commission’s rules, we hereby request permanent confidential treatment of information accompanying this application as outlined below: 1. CONF APPENDIX 2AFHU-SR150F Schem1.pdf 2. CONF APPENDIX 2AFHU-SR150F Schem2.pdf 3. CONF APPENDIX 2AFHU-SR150F BlkDia.pdf 4. CONF APPENDIX 2AFHU-SR150F OpDes.pdf 5. CONF APPENDIX 2AFHU-SR150F PartsLst1.pdf 6. CONF APPENDIX 2AFHU-SR150F PartsLst2.pdf Additionally, we request short term confidentiality for 180 days from the issuance of the grant, for the following: 7. 2AFHU-SR150F IntPht.pdf 8. 2AFHU-SR150F ExtPht.pdf 9. 2AFHUSR150F TSup.pdf 10. 2AFHUSR150F UseMan.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely,

FCC ID: 2AFHU-SR150F

FCC ID: 2AFHU-SR150F

FCC ID: 2AFHU-SR150F

p. 1 of 3 FCC RF Exposure report 1. Product information FCC ID 2AFHU-SR150F Product Radar-Based, Outdoor Perimeter Security Sensor Model No. SR150F Power supply 48V (via POE) Antenna gain 9.0dBi (max.) Assigned frequency range 5725-5780MHz Operating frequency range 5726-5749MHz Transmit power (max EIRP) 9.3dBm RF Exposure considerations A worst-case test separation distance of 20cm=200mm 2. Evaluation Method and Limit FCC: Part 1, Subpart I, Section 1.1310(e)(1), RSS 102, Issue 5, Section 2.5.2 (Table 4 requirements), KDB447498 D01 V06 (October 23, 2015) IC: RSS-102, Issue 5, March 2015 According to KDB447498 D01 General RF Exposure Guidance v06 Section 4.3.1, the standalone SAR test exclusion considerations are: “Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied. The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander (see 5) of section 4.1)." According to RSS-102, Section 3, “Devices that have a radiating element normally operating at or below 6 GHz, with a separation distance of up to 20 cm between the user and/or bystander and the device, shall undergo a SAR evaluation. Devices that have a radiating element normally operating at or below 6 GHz, with a separation distance greater than 20 cm between the user and/or bystander and the device shall undergo an RF exposure evaluation. However, a SAR evaluation may be performed in lieu of an RF exposure evaluation for devices operating below 6 GHz with a separation distance of greater than 20 cm between the user and/or p. 2 of 3 2 4R GP S tt   bystander and the device. Devices operating above 6 GHz regardless of the separation distance shall undergo an RF exposure evaluation.” For MPE evaluation we take the following E.U.T values: 3. Max. power (conducted)=0.3 dBm = 1.1mW 4. Antenna gain = 9 dBi = 8 5. Minimum distance from human body: 20cm=200 mm 6. The power density was calculated using the following formula: Where: S: Power density (mW/cm 2 ) P t : Conducted Transmitted Power (mW ) G t : Antenna Gain (numeric) R: Distance from Transmitter (cm) 3. FCC Test Limit Limits for General Population/Uncontrolled Exposure: Frequency range (MHz) Power density (mW/cm 2 ) Averaging time (min) 1,500.0-100,000.0 1.0 ˂ 30 4. Test Results Frequency FCC calculation FCC limit calculation Verdict (MHz) (mW/cm 2 ) (mW/cm 2 ) 5726
      = [1.1*9]/[4*3.16*(20 2 )]=0.002 ˂1.0 Pass Figure 1 Test Results 5. Conclusion p. 3 of 3 The measurement results comply with the Limit per FCC, Part 1, Subpart I, Section 1.1310(e)(1), RSS 102, Issue 5, Section 2.5.2( table 4 requirements) KDB447498 D01 V06 (October 23, 2015) End of Report

Test Report Ra233690.01 Magos Systems Ltd. Page 31 of 56 FCC ACC M Ver 1.2 28 February 2011 Peak Output Power E.U.T Description Radar-Based, Outdoor Perimeter Security Sensor Type SR150F Serial Number: Not designated Figure 29 Low, Vertical Figure 30 Low, Horizontal Test Report Ra233690.01 Magos Systems Ltd. Page 32 of 56 FCC ACC M Ver 1.2 28 February 2011 Peak Output Power E.U.T Description Radar-Based, Outdoor Perimeter Security Sensor Type SR150F Serial Number: Not designated Figure 31 Mid, Vertical Figure 32 Mid, Horizontal Test Report Ra233690.01 Magos Systems Ltd. Page 33 of 56 FCC ACC M Ver 1.2 28 February 2011 Peak Output Power E.U.T Description Radar-Based, Outdoor Perimeter Security Sensor Type SR150F Serial Number: Not designated Figure 33 High, Vertical Figure 34 High, Horizontal Test Report Ra233690.01 Magos Systems Ltd. Page 34 of 56 FCC ACC M Ver 1.2 28 February 2011 9.5 Test Equipment Used, Peak Output Power Instrument Manufacturer Model Serial No. Last Calibration Date Next Calibration Due EMI Receiver R&S ESCI7 100724 February 20, 2022 February 20, 2023 Horn Antenna ETS 3115 6142 May 25, 2021 May 25, 2024 RF Cable Commscope ORS 0623 WBC-400 G020133 May 16, 2022 May 16, 2023 full Anechoic Civil Chamber ETS S81 SL 11643 NCR NCR Figure 35 Test Equipment Used Test Report Ra233690.01 Magos Systems Ltd. Page 35 of 56 FCC ACC M Ver 1.2 28 February 2011 10 Dwell Time on Each Channel 10.1 Test Specification FCC Part 15, sub part C, Section 15.247(a)(1)(ii) 10.2 Test Procedure (Temperature (22°C)/ Humidity (55%RH)) The E.U.T operation mode and test set-up are as described in Section 2 of this report. The E.U.T was tested in the chamber, and placed on a remote-controlled turntable. The E.U.T was placed on a non-metallic table, 1.5 meters above the ground and 3-meter distance from testing antenna. The spectrum analyzer was set to the following parameters:  Span = zero span, centered on a hopping channel, RBW≥ 1MHz  Detector Function: Peak, Trace: Maximum Hold 10.3 Test Limit The average time of occupancy on any frequency shall not be greater than 0.4 seconds within a 30 second period. 10.4 Test Results JUDGEMENT: Passed The E.U.T met the requirements of the FCC Part 15, Section 15.247(a)(1)(ii) and RSS 247, Issue 2, clause 5.1(e). Additional information of the results is given in Figure 36 to Figure 37. Test Report Ra233690.01 Magos Systems Ltd. Page 36 of 56 FCC ACC M Ver 1.2 28 February 2011 Figure 36 Number of Bursts in 1sec=4, in 30sec=120 Figure 37 Burst Duration1 =0.3ms Dwell Time = 0.3msec*120= 36msec<0.4s Test Report Ra233690.01 Magos Systems Ltd. Page 37 of 56 FCC ACC M Ver 1.2 28 February 2011 10.5 Test Equipment Used, Dwell Time on Each Channel Instrument Manufacturer Model Serial No. Last Calibration Date Next Calibration Due EMI Receiver R&S ESCI7 100724 February 20, 2022 February 20, 2023 Horn Antenna ETS 3115 6142 May 25, 2021 May 25, 2024 RF Cable Commscope ORS 0623 WBC-400 G020133 May 16, 2022 May 16, 2023 Full Anechoic Civil Chamber ETS S81 SL 11643 NCR NCR Figure 38 Test Equipment Used Test Report Ra233690.01 Magos Systems Ltd. Page 38 of 56 FCC ACC M Ver 1.2 28 February 2011 11 Band Edge 11.1 Test Specification FCC Part 15, Section 15.247(d) 11.2 Test Procedure (Temperature (22°C)/ Humidity (55%RH)) The E.U.T operation mode and test set-up are as described in Section 2 of this report. The E.U.T was tested in the chamber, placed on a remote-controlled turntable. The E.U.T was placed on a non-metallic table, 1.5 meters above the ground and a 3 meter distance from testing antenna. The transmitter unit operated in 2 modes: hopping enabled and hopping disabled. The RBW was set to 100 kHz. The display line was set to 20 dBc The E.U.T. was tested at the lower and the upper channels. 11.3 Test Limit In any 100 kHz bandwidth outside the frequency band in which the spread spectrum or digitally modulated intentional radiator is operating, the radio frequency power that is produced by the intentional radiator shall be at least 20dB below that in the 100 kHz bandwidth within the band that contains the highest level of the desired power. 11.4 Test Results Mode Operation Frequency Band Edge Frequency Spectrum Level Limit Margin (MHz) (MHz) (dBm) (dBm) (dB) Hopping 5726.0 5725.0 -89.2 -74.9 5849.0 5850.0 -89.0 -76.2 Non- Hopping 5726.0 5725.0 -70.0 -49.0 5849.0 5850.0 -73.0 -49.0 Figure 39 Band Edge Test Results JUDGEMENT: Passed by 3.4 dB For additional information see Figure 40 to Figure 43. Test Report Ra233690.01 Magos Systems Ltd. Page 39 of 56 FCC ACC M Ver 1.2 28 February 2011 Figure 40 Hopping, Lower Band Edge Figure 41 Hopping, Higher Band Edge Test Report Ra233690.01 Magos Systems Ltd. Page 40 of 56 FCC ACC M Ver 1.2 28 February 2011 Figure 42 Non-Hopping, Lower Band Edge Figure 43 Non-Hopping, Higher Band Edge Test Report Ra233690.01 Magos Systems Ltd. Page 41 of 56 FCC ACC M Ver 1.2 28 February 2011 11.5 Test Equipment Used, Band Edge Instrument Manufacturer Model Serial No. Last Calibration Date Next Calibration Due EMI Receiver R&S ESCI7 100724 February 20, 2022 February 20, 2023 Horn Antenna ETS 3115 6142 May 25, 2021 May 25, 2024 RF Cable Commscope ORS 0623 WBC-400 G020133 May 16, 2022 May 16, 2023 Full Anechoic Civil Chamber ETS S81 SL 11643 NCR NCR Figure 44 Test Equipment Used Test Report Ra233690.01 Magos Systems Ltd. Page 42 of 56 FCC ACC M Ver 1.2 28 February 2011 12 Emissions in non-Restricted Frequency Bands 12.1 Test Specification FCC, Part 15, Subpart C, Section 247(d) 12.2 Test Procedure (Temperature (22°C)/ Humidity (55%RH)) The E.U.T. operation mode and test set-up are as described in Section 2 of this report. For measurements between 0.009MHz-30MHz: The E.U.T was tested inside the shielded room and placed on a non-metallic table, 0.8 meters above the ground. The emissions were measured at a distance of 3 meters. The readings were maximized by the turntable azimuth between 0-360°, and the antenna polarization. The frequency range 0.009MHz-30MHz wa…

Text truncated - open the document above for the full version.

Test Report Ra233690.01 Magos Systems Ltd. Page 1 of 56 FCC ACC M Ver 1.2 28 February 2011 Date: 02 November 2022 I.T.L. Product Testing Ltd. FCC Part 15.247 Test Report for Magos Systems Ltd. Equipment under test: Radar-Based, Outdoor Perimeter Security Sensor SR150F Tested by: M. Zohar Approved by: I. Mansky pp. I. Cohen: This report must not be reproduced, except in full, without the written permission of I.T.L. Product Testing Ltd. This report relates only to items tested. Test Report Ra233690.01 Magos Systems Ltd. Page 2 of 56 FCC ACC M Ver 1.2 28 February 2011 Measurement/Technical Report for Magos Systems Ltd. Radar-Based, Outdoor Perimeter Security Sensor SR150F FCC ID: 2AFHU-SR150F This report concerns: Original Grant Equipment type: FCC: DSS Part 15 Spread Spectrum Transmitter Limits used: 47CFR15 Section 15.247 Measurement procedures used are KDB 558074 D01 v05, and ANSI C63.10: 2013. Prepared by: Applicant: R. Ezrah I.T.L. Product Testing Ltd. 1 Bat Sheva St., Lod 7116002, Israel Email: [email protected] Amit Isseroff Magos Systems Ltd. 13 Gad Feinstein St., Rehovot 7638517, Israel Email: [email protected] Test Report Ra233690.01 Magos Systems Ltd. Page 3 of 56 FCC ACC M Ver 1.2 28 February 2011 Table of Contents 1 GENERAL INFORMATION --------------------------------------------------------------------------- 5 1.1 Administrative Information ........................................................................................ 5 1.2 List of Accreditations ................................................................................................. 5 1.3 Product Description .................................................................................................. 6 1.4 Test Methodology ..................................................................................................... 6 1.5 Test Facility ............................................................................................................... 6 1.6 Measurement Uncertainty......................................................................................... 7 2 SYSTEM TEST CONFIGURATION ----------------------------------------------------------------- 8 2.1 Justification ............................................................................................................... 8 2.2 EUT Exercise Software ............................................................................................. 8 2.3 Special Accessories .................................................................................................. 8 2.4 Equipment Modifications........................................................................................... 8 2.5 Configuration of Tested System ............................................................................... 8 3 TEST SETUP PHOTOS -------------------------------------------------------------------------------- 9 4 CONDUCTED EMISSION FROM AC MAINS ---------------------------------------------------- 9 4.1 Test Specification ..................................................................................................... 9 4.2 Test Procedure ......................................................................................................... 9 4.3 Test Limit ................................................................................................................ 10 4.4 Test Results ............................................................................................................ 10 4.5 Test Equipment Used; Conducted Emission from AC Mains ................................. 15 5 20DB MINIMUM BANDWIDTH -------------------------------------------------------------------- 16 5.1 Test Specification ................................................................................................... 16 5.2 Test Procedure ....................................................................................................... 16 5.3 Test Limit ................................................................................................................ 16 5.4 Test Results ............................................................................................................ 16 5.5 Test Equipment Used, 20 dB Minimum Bandwidth ................................................ 18 6 OCCUPIED BANDWIDTH -------------------------------------------------------------------------- 19 6.1 Test Specification ................................................................................................... 19 6.2 Test Procedure ....................................................................................................... 19 6.3 Test Limit ................................................................................................................ 19 6.4 Test Results ............................................................................................................ 19 6.5 Test Equipment Used, Occupied Bandwidth .......................................................... 21 7 HOPPING FREQUENCIES NUMBER ----------------------------------------------------------- 22 7.1 Test Specification ................................................................................................... 22 7.2 Test Procedure ....................................................................................................... 22 7.3 Test Limit ................................................................................................................ 22 7.4 Test Results ............................................................................................................ 22 7.5 Test Equipment Used, Number of Hopping Frequencies ....................................... 26 8 CHANNEL FREQUENCY SEPARATION ------------------------------------------------------- 27 8.1 Test Specification ................................................................................................... 27 8.2 Test Procedure ..........................…

Text truncated - open the document above for the full version.

Magos Systems Gad Feinstein 13 225 floor, Office nd 2 Rehovot 7638517, Israel T: (972) 77-4140155 | F: (972) 77-4140165 www.magossystems.com ©Copyright 2022 Magos Systems. All rights reserved. Specification for Embedded Antenna SR150-Series Vertical Polarization 5.2-5.9 GHz, 10.0dBi Magos Systems ©Copyright 2022 Magos Systems. All rights reserved. SPECIFICATION Flat Panel Subscriber Antenna Dual Pole Note : - Antenna will be integrated into the radio PCB. MAGOS PART NUMBER MS9734 Regulatory Compliance UL, RoHS , CE 0682, 1. ELECTRICAL Frequency Range 5.2-5.9 GHz Gain 10.0±1.0 dBi VSWR 2.0 : 1 (max) 3 dB Beam width Azimuth 90° (typ) 3 dB Beam width Elevation 30° (typ) Polarization Linear ,Vertical Cross Polarization -15 dB (typ) Port To Port Isolation -14 dB (max) @ 5.2-5.7 GHz -17 dB (max) @ 5.7-5.9 GHz F/B Ratio -25 dB (typ) Input Impedance 50 (ohm) Input Power 6 W (max) Lightning Protection DC Grounded 2. MECHANICAL Dimensions (LxWxD) 90 x 190 x 3.5mm (max) Not include connector Weight 0.2 (kg) (max) Connector integrated Radome 2mm Polycarbonate Case Base Plate Embedded ground plane Outline Drawing Attached 3. ENVIRONMENTAL TEST STANDARD DURATION TEMPERTURE NOTES Low Temperature IEC 68-2-1 72 h -55°C - High Temperature IEC 68-2-2 72 h +71°C - Temp. Cycling IEC 68-2-14 1 h -45°C +70°C 3 Cycles Flammability UL 94 - - CLASS HB Magos Systems ©Copyright 2022 Magos Systems. All rights reserved. Drawing: Description: 7 Element array. Each element is composed of 3 connected patches. Magos Systems ©Copyright 2022 Magos Systems. All rights reserved. Performance:

Test Setup Photos FCC: 2AFHU-SR150F Figure 1. Conducted Emission from AC Mains Figure 2. Radiated Emission Test, 0.009-30MHz band Figure 3. Radiated Emission Test, 30-200MHz band Figure 4. Radiated Emission Test, 200-1000MHz band Figure 5. Radiated Emission Test, 1000-18,000MHz band Figure 6. Radiated Emission Test, 18,000-26,500MHz band Figure 7. Radiated Emission Test, 26,500-40,000MHz band
