2AFJVHZ-PL5UV Sterilizer Box with Wireless Charging

UVSterilizerBoxwithWirelessChargingmanual Tips: Pleasereadtheinstructionmanualofthisproductcarefullybeforeuseandkeepitproperly. Precautions: 1.Whenturningonthegermicidallamp,donotlookdirectlyatthegermicidallamp,otherwiseit willcauseaslightburnthantheeyes. 2.Pleaseplaceitmorethan1Mawayfromthecomputerandelectronicequipmenttoprevent signalinterferencefromtheintegratedmodule. 3.Donotopentherepairormodificationequipmentbyyourself,tearthewarrantylabel,and consideritasman-madedamagenotcoveredbythewarranty. 4.Thisdeviceisnotwaterproof,avoidliquidsplashing,pleasedonotstoretheproductina humidenvironment. 5.Donotchargetheproductnearorneartheheatsource. 6.Whencharging,acertainamountofheatwillbegenerated.Thisisnormalandwillnotaffect theperformanceoftheproduct.However,ifyoufeelthatthecellphonebatteryorsterilization boxistoohot,disconnectthepowersupplytothesterilizationboxandwaitforittocoolbefore attemptingtochargeit. Duringthewarrantyperiod,duetothefailureordamagecausedbythequalityofthisproduct, freemaintenanceserviceisprovided;iftheproductisdamagedduetoaccidents,unstable voltageandirresistiblefactors,itisnotcoveredbythewarranty. TechnicalParameters: 1.Productmodel:P16 2.Aromatherapypower:1W 3.Wirelesschargingpower:10W 4.Disinfectionpower:LED-2W 5.UVlampbeadpower:2W 6.NumberofUVlampbeads:6 7.Inputvoltage/current:5V/2A9V/2A 8.Outputvoltage/current:9V/1.1A 9.Transmissiondistance:2-6mm 10.Chargingefficiency80% 11.Packingsize:23.2*13*5.6cm 12.Productweight:0.42kg 13.Powersupplymethod:USBpowersupply 14.Chargingstatusindication:Whenstandby,bluelightisalwayson;whencharging,bluelightis breathingandbluelightisoffafterfully-charged;Whenit’sabnormal,bluelightflashesquickly. 15.Wavelength:270-280NM Mobilephonewirelesscharginginstructions: 1.AfterconnectingtheUVSterilizerBoxwithWirelessChargingtothepoweradapterand energizing,theblueindicatorlightbreathes. 2.TochargeaQI-compatiblesmartphone,pleaseputthephoneonthelid. 3.Aftercharging,removethesmartphonefromtheUVSterilizerBoxwithWirelessCharging. Instructionsfordisinfectionfunction: Shortpressthedisinfectionswitchbuttontostartthedisinfectionmode. Shortpressthebutton,thegreenlightison,indicatingthatthedisinfectionmodeisinprogress, youwillhearabeep.(Cankill99.9%ofStaphylococcusaureusandE.coli). 3.Duringdisinfection,whenthelidisopened,inordertopreventslightburnstotheeyes,the disinfectionlampwillgoout.Whenthelidisclosed,thedisinfectionprocesswillresume. 4.Whenthedisinfectiontimereaches5minutes,youwillhearthree"beep"sounds,the indicatorlightflashesthreetimesandthengoesout,indicatingthatdisinfectioniscomplete. Aromatherapyfunctioninstructions: Ifyouwanttoaddapleasantfragrancetotheitem,youcanaddadropofliquidaromatothe aromadistributionpointinthewirelesschargingsterilizationboxbeforedisinfection.(Liquid aromatherapymustbepurchasedseparately) Features: 1.Sterilizationeffect:99.99% 2.Theproducthaslonglifeandstrongdurability 3.Exquisiteandcompact,easytocarry,doesnotoccupyspace 4.Aviationaluminumindustrydesign,strongsenseoftechnology 5.Comprehensivedisinfectionandsterilization,sidecrossultravioletdisinfectionandsterilization, 360degreescirculationwithoutdeadangle 6.Optionalmobilephonewirelesschargingfunction,whichcanbesterilizedatthesametime duringthechargingprocess. 7.Aromatherapyfunction. 8.Largecapacityandmulti-function,cansterilizemobilephones,masks,jewelrywatches,etc. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The device has been evaluated to meet general RF exposure requirement. The distance between user and products should be no less than 20cm.

2020.07.22 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AFJVHZ-PL5 Product Name: UV Sterilizer Box with Wireless Charging Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: Schematics Long-term confidential Block diagram Long-term confidential Operation description Long-term confidential These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Signature: Data: 2020.07.22 Name Zhang Wenyuan Position Manager Company Name ShenZhen HuaZeng Technology Co., Ltd Address Floor 8th, Building 6, 3rd Industrial Zone, Tangwei District, Gongming Street, Guangming, Shenzhen, Guangdong, China Tel 0755-27671506 Fax 0755-27671814 Email [email protected] ShenZhen HuaZeng Technology Co., Ltd

FCC ID: 2AFJVHZ-PL5

3cm 1.5cm Label Location FCC ID: 2AFJVHZ-PL5 ShenZhen HuaZeng Technology Co., Ltd Model name: UV Sterilizer Box with Wireless Charging Model No.: HZ-PL5

FCC ID: 2AFJVHZ-PL5 Antenna

FCC TEST REPORT FCC ID: 2AFJVHZ-PL5 On Behalf of ShenZhen HuaZeng Technology Co., Ltd UV Sterilizer Box with Wireless Charging Model No.: HZ-PL5 Prepared for : ShenZhen HuaZeng Technology Co., Ltd Address : Floor 8th, Building 6, 3rd Industrial Zone, Tangwei District, Gongming Street, Guangming, Shenzhen, Guangdong, China Prepared By : Shenzhen Alpha Product Testing Co., Ltd. Address : Building i, No.2, Lixin Road, Fuyong Street, Bao'an District, 518103, Shenzhen, Guangdong, China Report Number : A2006325-C01-R12 Date of Receipt : July 9, 2020 Date of Test : July 9-16, 2020 Date of Report : July 16, 2020 Version Number : V0 Page 2 of 14 Report No.: A2006325-C01-R12 TABLE OF CONTENTS 1. Test Result Summary .............................................................................. 5 2. EUT Description ....................................................................................... 6 2.1. DESCRIPTION OF DEVICE (EUT) ............................................................................................................. 6 2.2. ACCESSORIES OF DEVICE (EUT) ............................................................................................................ 8 2.3. TESTED SUPPORTING SYSTEM DETAILS ................................................................................................. 8 2.4. BLOCK DIAGRAM OF CONNECTION BETWEEN EUT AND SIMULATORS ....................................................... 8 2.5. DESCRIPTION OF TEST MODES ............................................................................................................... 8 2.6. TEST CONDITIONS ................................................................................................................................. 8 2.7. TEST FACILITY ...................................................................................................................................... 9 2.8. MEASUREMENT UNCERTAINTY ............................................................................................................... 9 3. Test Results and Measurement Data ................................................... 10 3.1. RF EXPOSURE TEST ....................................................................................................................... 10 4. Photos of test setup .............................................................................. 13 5. Photographs of EUT .............................................................................. 14 Page 3 of 14 Report No.: A2006325-C01-R12 TEST REPORT DECLARATION Applicant : ShenZhen HuaZeng Technology Co., Ltd Address : Floor 8th, Building 6, 3rd Industrial Zone, Tangwei District, Gongming Street, Guangming, Shenzhen, Guangdong, China Manufacturer : ShenZhen HuaZeng Technology Co., Ltd Address : Floor 8th, Building 6, 3rd Industrial Zone, Tangwei District, Gongming Street, Guangming, Shenzhen, Guangdong, China EUT Description : UV Sterilizer Box with Wireless Charging (A) Model No. : HZ-PL5 (B) Trademark : N/A Measurement Standard Used: FCC KDB 680106 D01 RF Exposure Wireless Charging Apps v03 The device described above is tested by Shenzhen Alpha Product Testing Co., Ltd. to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The test results are contained in this test report and Shenzhen Alpha Product Testing Co., Ltd. is assumed full responsibility for the accuracy and completeness test. Also, this report shows that the EUT is technically compliant with the KDB 680106 D01 requirements. This report applies to above tested sample only. This report shall not be reproduced in parts without written approval of Shenzhen Alpha Product Testing Co., Ltd. Tested by (name + signature).............: Lucas Pang Project Engineer Approved by (name + signature).......: Simple Guan Project Manager Date of issue...... .......................: July 16, 2020 Page 4 of 14 Report No.: A2006325-C01-R12 Revision History Revision Issue Date Revisions Revised By V0 July 16, 2020 Initial released Issue Lucas Pang Page 5 of 14 Report No.: A2006325-C01-R12 1. Test Result Summary Requirement CFR 47 Section Result RF EXPOSURE §1.1307(b)(1) & KDB680106 PASS Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. Page 6 of 14 Report No.: A2006325-C01-R12 2. EUT Description 2.1. Description of Device (EUT) EUT Name : UV Sterilizer Box with Wireless Charging Model No. : HZ-PL5 DIFF. : N/A Power supply : Wireless Output: 10W(max) USB Input: 5V/2A, 9V/2A Test voltage : DC 5V or DC 9V from adapter. Operation frequency : 125-205KHz Modulation : MSK Antenna Type : Coil Antenna, Maximum Gain is 4dBi Software version : V1.0 Hardware version : V1.0 Intend use environment : Residential, commercial and light industrial environment Page 7 of 14 Report No.: A2006325-C01-R12 Conditions requirement Answers Power transfer frequency is less that 1 MHz After measuring the product the transfer frequency is 125-205KHz Output power from each primary coil is less than 15 watts After measuring the product the each primary coil power is 10 watts The transfer system includes only single primary and secondary coils. This includes charging systems that may have multiple primary coils and clients that are able to detect and allow coupling only between individual pairs of oils The wireless charger has a primary coil. It can only detect and allow coupling between single coil pairs. Client device is inserted in or placed directly in contact with the transmitter Client device is placed directly in contact with the transmitter Mobile exposure conditions only (portable exposure conditions are not covered by this exclusion). Mobile exposure conditions only. The aggregate H-field strengths at 15 cm surrounding the device and 20 cm above the top surfac…
