QuickStart Guide YoSmart Remote Controller Model: KT-LR-U01B Good Choice J The Remote controller enables you to control the controller by hand. Getting Started Correctly insert disk shape battery. Description of remote buttons’ function ： Shown in picture below QuickStart Guide LED All available colors ， Turning lights on and off ， To modify brightness of LED lights （ only work with a single color ） Number button functionality: 1. While linking choose the sections you want to link，or the sections you want to control simultaneously。 Selecting ALL will link all the sections. 2. Also used to set time for light to remain on, the maximum time is 9.9 hours. Used to set how long you want the light to stay on. Instructions： 1. Press Duration, then set however long you want with the number buttons, (maximum time is 9.9 hours, you must insert numbers after the decimal, not putting a time will be understood as maximum duration) 2. When the LED light is on, it will turn off when time is reached. If the LED light is turned off, timer will start the next time it is turned on, until time is reached. Set a timer Instructions： 1. Choose the mode LED lights 2. Press the Timer button, use the number buttons to insert time (maximum 9.99 hours, be sure to insert two numbers after the decimal point. For example if the time is 6 hours then put 6.00. ) When time is reached, the mode will return to standard mode. 3. If the LED light is turned off while setting time, when time is reached, LED will return to the mode before it was turned off. Starts the flashing Stop the flashing. Changes the way that LED lights flashes. Increases the speed in which LED lights flashes. Decreases the speed in which the LED lights flashes. LINK button： 1. LINK：hold button 4-8S，enter LINK process，green LED flashes，if successful LINK with device the green LED flash will go away，if fail to LINK within 4 minutes，will be forced out of LINK，LED light goes out. 2. UNLINK：hold for 10S，enters UNLINK process，red LED flashes, if successful UNLINK with device the red LED flash will go away，if fail to LINK within 4 minutes，will be forced out of LINK，LED light goes out. 3. While LINK or UNLINK is in process you can press it again to cancel. Support Visit: http://www.YoSmart.com/support for complete manual, online tech support and latest product documents. FCC Caution:Anychanges ormodifications not expressly approved bythe partyresponsible forcompliancecouldvoidthe user's authoritytooperate this equipment. This devicecomplieswithPart15 of theFCC Rules.Operationissubject tothefollowingtwo conditions:(1)This devicemaynotcause harmfulinterference,and(2)thisdevicemust accept anyinterferencereceived,includinginterference thatmaycauseundesiredoperation. NOTE:This equipment has been testedandfound to complywith thelimitsfor a ClassB digitaldevice,pursuant toPart15 of theFCC Rules. Theselimits are designedto providereasonable protectionagainstharmfulinterferencein a residentialinstallation.This equipment generates, uses and canradiateradiofrequency energyand,if notinstalledandusedin accordancewith theinstructions,maycause harmful interferencetoradiocommunications. However,thereis noguaranteethatinterferencewillnot occurin a particularinstallation. Ifthisequipmentdoescauseharmfulinterferencetoradioortelevisionreception,whichcanbe determinedbyturningthe equipment off and on, the useris encouraged to trytocorrect the interference byone ormore of the followingmeasures: FCC RF RadiationExposureStatement: This equipmentcomplieswithFCCradiationexposurelimitssetforthfor an uncontrolled environmentEndusersmustfollowthespecific operatinginstructionsforsatisfying RF exposurecompliance.This transmittermust not be collocatedor operatinginconjunctionwith anyother antenna or transmitter. The devicehas beenevaluatedtomeet general RF exposurerequirement.Thedevicecanbe usedinportableexposureconditionwithoutrestriction.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 KingTing Tech. Corporation 2015/9/14 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, KingTing Tech. Corporation hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product description: LED Strip Remote Controller model name: KT-LR-U01B, KT-LR-UXXY, 'XX' is 2 digit numbers which represents the software version, for example, 01 represents the software version 0.1. 'Y' is 1 character which represents the color of product, for example 'B' represents black. FCC ID: 2AFK9KT-LR-U01B Sincerely, Client’s signature Client’s name / title : Mx Xu / General Manager Contact information / address: 17165 Von Karman Avenue, Suite 105, Irvine CA, USA

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526- 1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (current) 3.0 4.0 March-26-2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 4.0 KingTing Tech. Corporation 2015/9/14 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AFK9KT-LR-U01B We hereby request confidential treatment of information accompanying this application as outlined below: - e.g. Block Diagram - e.g. Schematics - e.g. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Client’s name / title : Mx Xu / General Manager Contact information / address: 17165 Von Karman Avenue, Suite 105, Irvine CA, USA

KingTing Tech. Corporation Model Difference FCC ID: 2AFK9KT-LR-U01B Model : KT-LR-U01B,KT-LR-UXXY, 'XX' is 2 digit numbers which represents the software version, for example, 01 represents the software version 0.1. 'Y' is 1 character which represents the color of product, for example 'B' represents black. All the model are the same circuit and RF module,except color and software version. Regards Sincerely Client’s signature Client’s name / title : Mx Xu / General Manager Contact information / address: 17165 Von Karman Avenue, Suite 105, Irvine CA, USA

Shenzhen BCTC Technology Co., Ltd. FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page1 of 5 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Shenzhen BCTC Technology Co., Ltd. FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page2 of 5 Photo 3 Photo 4

Model: KT-LR-U01B FCC ID: 2AFK9KT-LR-U01B KingTing Tech. Corporation This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:(1)This device may not cause harmful interference, and (2) this dev ice must accept any interference received, including interference that may cause undesired operation.

Shenzhen BCTC Technology Co., Ltd. FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page3 of 5 Photo 5 Photo 6 Shenzhen BCTC Technology Co., Ltd. FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page4 of 5 Photo 7 Photo 8 ANT Shenzhen BCTC Technology Co., Ltd. FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page5 of 5 Photo 9

Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15090267 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page1 of 28 FCC Part 15C Test Report FCC ID: 2AFK9KT-LR-U01B Product Name: LED Strip Remote Controller Trademark: N/A Model Name : KT-LR-U01B KT-LR-UXXY, 'XX' is 2 digit numbers which represents the software version, for example, 01 represents the software version 0.1. 'Y' is 1 character which represents the color of product, for example 'B' represents black. Prepared For : KingTing Tech. Corporation Address : 17165 Von Karman Avenue, Suite 105, Irvine CA, US Prepared By : Shenzhen BCTC Technology Co., Ltd. Address : No.101,Yousong Road,Longhua New District, Shenzhen,China Test Date: Sep. 12 - Sep. 17, 2015 Date of Report : Sep. 17, 2015 Report No.: BCTC-15090267 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15090267 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 2 of 28 TEST RESULT CERTIFICATION Applicant’s name ................. : KingTing Tech. Corporation Address ................................. : 17165 Von Karman Avenue, Suite 105, Irvine CA, US Manufacture's Name ............ : Guangdong KingTing Technology Co., Ltd. Address ................................. : 2B-2101 Hecheng century, Bantian Street, Longgang District, Shenzhen City, China Product description Product name ............................ : LED Strip Remote Controller Model and/or type reference : KT-LR-U01B Serial Model ............................... : KT-LR-UXXY, 'XX' is 2 digit numbers which represents the software version, for example, 01 represents the software version 0.1. 'Y' is 1 character which represents the color of product, for example 'B' represents black. Standards ............................. : FCC Part15.249 Test procedure ................................ ANSI C63.10-2013 This device described above has been tested by BCTC, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BCTC, this document may be altered or revised by BCTC, personal only, and shall be noted in the revision of the document. Testing Engineer : (Eric Yang) Technical Manager : (Sophia Lee) Authorized Signatory : (Casey Wang) Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15090267 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 3 of 28 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 8 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 9 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 9 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 10 3 . EMC EMISSION TEST 11 3.1 CONDUCTED EMISSION MEASUREMENT 11 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 11 3.1.2 TEST PROCEDURE 11 3.1.3 DEVIATION FROM TEST STANDARD 11 3.1.4 TEST SETUP 12 3.1.5 EUT OPERATING CONDITIONS 12 3.1.6 TEST RESULTS 13 3.2 RADIATED EMISSION MEASUREMENT 14 3.2.1 RADIATED EMISSION LIMITS 14 3.2.2 TEST PROCEDURE 15 3.2.3 DEVIATION FROM TEST STANDARD 15 3.2.4 TEST SETUP 16 3.2.5 EUT OPERATING CONDITIONS 17 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 18 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 19 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 21 4 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 22 4.1 DEVIATION FROM STANDARD 23 4.2 TEST SETUP 23 4.3 EUT OPERATION CONDITIONS 23 4.4 TEST RESULTS 23 5 . BANDWIDTH TEST 24 5.1 APPLIED PROCEDURES / LIMIT 24 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15090267 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 4 of 28 Table of Contents Page 5.1.1 TEST PROCEDURE 24 5.1.2 DEVIATION FROM STANDARD 24 5.1.3 TEST SETUP 24 5.1.4 EUT OPERATION CONDITIONS 24 5.1.5 TEST RESULTS 25 6 . ANTENNA REQUIREMENT 26 6.1 STANDARD REQUIREMENT 26 6.2 EUT ANTENNA 26 7 . EUT TEST PHOTO 27 8 . PHOTO OF THE EUT 28 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15090267 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 5 of 28 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.249) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.249 (a)(2) 20dB Bandwidth PASS 15.249 Fundamental &Radiated Spurious Emission Measurement PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15090267 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 6 of 28 1.1 TEST FACILITY Shenzhen BCTC Technology Co., Ltd. Add. : No.101,Yousong Road,Longhua New District, Shenzhen,China FCC Registered No.: 187086 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15090267 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 7 of 28 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment LED Strip Remote Controller Trade Name N/A Model Name KT-LR-U01B Serial Model KT-LC-UXXY('XX' is 2 digit numbers which represents the software version, for example, 01 represents the software version 0.1. 'Y' is 1 character which represents the color of product, for example 'B' represents black.) Model Difference All the model are the same circuit and RF module,except color and software version. Product…
