2AFKA36060069Wireless Earmuff

Wireless Earmuff User Manual FEATURES 1. V3.0+EDR Bluetooth version, a vailable for most of devices wi th Bluetooth function. 2. Fashion and keep warm with ans wer the phone in winter, enjoy music freely. 3. Set-in mic, available for cell phone to transmit the speakin g phone to your audio devices directly so that the user can hand free answering phone up via the device. 4. set-in Li-ion chargeable batte ry. Charge via USB cable, long stand-by time. 5. Support power display on IPhone. SPECIFICATIONS 1.Bluetooth: V3.0+EDR 2.Frequency response:100Hz~20KHz 3.Transmission distance: 10M 4.Transmission distance of mic: <1M 5. Mini USB Charge,5V/0.5A 6.Rechargeable Lithium Battery:180mAH, 3.7V 7.Continuous Working time:4-6 hours 8.Speaker Sensitivity :110dB 9.Bluetooth pairing name: BT music Function Button and cable Function specification Plug USB port of micro into ear phone, then connect the USB port of USB cable into computer, at the time the LED light will turn red, when th e LED light is off, it means the speaker is fu lly charged, please pull out the cable. How to use 1. Press the on/off button (pla y icon button )about 5 seconds u ntil the LED light blinks from blue-red. 2. Turn on the Bluetooth on your mobile device and connect with "BT-music" 3. If you are playing an audio file from your mobile device you can play or pause by pressing the on/off button (play icon). 4. To select the next audio file from your mobile simply press the “ back button ” 5. To select the previous audio file from your mobile simply pr ess the “ forward button ” 6. To attend a call press t he on/off button (play icon) 7. Press on/off button fo r 2-3 seconds to retail. 8. Press on/off button to hang off . 9. To increase the volume k eep hold of the back button 10. To decrease the volume keep hold of t he forward button 11. To charge the device simply p lug the charging cable supplie d with the product in to the Bluetooth round port thr ough the small opening hide o n one earmuff . 12. The red light indicator will stay on wilts on charge and wi ll turn off when fully charged. Power save mode The device will be off automatically after 3 minutes no working device pairing it. Low power warning The device alarming as “do” while is working seems the power no t enough, need to be charged. Using the USB Cable. Notes 1.Please use and store the device far away acidic, alkaline and cuspidal things 2.Please keep t he device dry 3.Please keep the devic e clean and put desiccant in it after us ing 4.Please remove the earphone before wash 5.Please do not disassemble, a mend or alter device alone. 6.Please do not throw or drop Accessories Bluetooth earmuff 1set User manual 1pc USB Charging cable 1pc FCC Statement This equipment has been tested and found to comply with the lim its for a Class B digital device, pursuant to Part 15 of the FCC Ru les. These limits are designed to prov ide reasonable protection agai nst harmful interference in a reside ntial installation. This equipm ent generates uses and can radiate radio frequency energy and, if n ot installed and used in accordance with the instructions, may cau se harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular inst allation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate t he receiving antenna. -- Increase the separation betwee n the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. This device complies with part 1 5 of the FCC Rules. Operation i s subject to the follo wing two conditions: (1) This device may not cause harmful interference, and (2) thi s device must accept any interfere nce received, including interfe rence that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to o perate the equipment.

Magic Move International Limited FCC Authorization Letter Number: CF304 Version: V03 Date: 01-08-2011 We, (the approval holder) Company name Magic Move International Limited Address #418,Guanghui Blding ,Shangkeng Street,Changping Town, City Dongguan city, Guangdong Country China declare that the following representative (agent): Name (person) Amy Liu Company name Magic Move International Limited Address #418,Guanghui Blding ,Shangkeng Street,Changping Town, City Dongguan city, Guangdong Country China is hereby authorized to apply the following equipment for certification on our behalf: Product Description Wireless Earmuff Type or Model(s) 36060069, BT-309 Tradename or Brand(s) N/A We also authorize Teleconformity (Mr. M. Koop, Manager Certification, Address: Rietven 31, 7534NH Enschede, the Netherlands) to apply and sign this application for certification, registration or filing on our behalf (as representative agent or certifier). Attestation: City and Country: Date: Name: (this must be a person) Function:Signature: (or official company stamp) Dongguan city, Guangdong 2015-8-10 Amy Liu Manager

Magic Move International Limited FCC Confidentiality Request Number: CF303 Version: V05 Date: 21-05-2012 (Permanent or also called long term confidentiality is the normal method to keep certain docuements confidential, and may apply to schematics, block diagrams, operational description and bill of materials.) To: Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Pursuant to 47 CFR Section 0.459(a) & (b), we, (the applicant / grantee) Company name Magic Move International Limited Address #418,Guanghui Blding ,Shangkeng Street,Changping Town, City Dongguan city, Dongguan Country China request for this certification filing under: Grantee Code Product Number FCC ID: 2AFKA 36060069 to maintain permanent confidentiality for the following documents submitted within this application: (please cross what is applicable, or add other documents, provide the file name and description) Exhibit File Name Description x Operational Description explaining the functioning of the block diagram x Block Diagrams showing the systematic building blocks of the EUT x Schematics Diagrams showing components, their values and interconnection Above materials crossed contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. We understand that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. The documents indicated as confidential above, are not publicly available elsewhere. Attestation: City and Country: Date: Name: (this must be a person) Function:Signature: (or official company stamp) Dongguan city, Dongguan 2015-8-10 Amy Liu Manager

Magic Move International Limited Model Difference FCC ID: 2AFKA36060069 Product description: Wireless Earmuff Model : 36060069, BT-309 All the models are the same circuit and RF module, except the mode names and outlook color. Regards Sincerely Client’s signature City and Country: Date: Name: (this must be a person) Function:Signature: (or official company stamp) Dongguan city, Guangdong 2015-8-10 Amy Liu Manager

M/N: 36060069 FCC ID: 2AFKA36060069 Label location

Antenna location

Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15070127 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 1 of 33 FCC Part 15C Test Report FCC ID: 2AFKA36060069 Product Name: Wireless Earmuff Trademark: N/A Model Name : 36060069, BT-309 Prepared For : Magic Move International Limited Address : #418,Guanghui Blding ,Shangkeng Street,Changping Town, Dongguan city , Guangdong,China Prepared By : Shenzhen BCTC Technology Co., Ltd. Address : No.101,Yousong Road,Longhua New District, Shenzhen,China Test Date: Aug. 4– Aug. 10, 2015 Date of Report : Aug. 10, 2015 Report No.: BCTC-15070127 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15070127 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 2 of 33 VERIFICATION OF COMPLIANCE Applicant’s name ................. : Magic Move International Limited Address ................................. : #418,Guanghui Blding ,Shangkeng Street,Changping Town, Dongguan city , Guangdong,China Manufacture's Name ............ : Magic Move International Limited Address ................................. : #418,Guanghui Blding ,Shangkeng Street,Changping Town, Dongguan city , Guangdong,China Product description Product name ........................... : Wireless Earmuff Trademark: N/A Model Name: 36060069, BT-309 Test procedure FCC Part15.249 Standards ANSI C63.10-2013 This device described above has been tested by BCTC, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BCTC, this document may be altered or revised by BCTC, personal only, and shall be noted in the revision of the document. Test Result ............................................... : Pass Testing Engineer : (Eric Yang) Technical Manager : (Sophia Lee) Authorized Signatory : (Carson. Zhang) Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15070127 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 3 of 33 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 4 1.1 TEST FACILITY 4 1.2 MEASUREMENT UNCERTAINTY 4 2 . GENERAL INFORMATION 5 2.1 GENERAL DESCRIPTION OF EUT 5 2.2 DESCRIPTION OF TEST MODES 6 2.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 7 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 7 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 8 3 . EMC EMISSION TEST 9 3.1 RADIATED EMISSION MEASUREMENT 13 3.1.1 RADIATED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 15 3.1.5 EUT OPERATING CONDITIONS 16 3.1.6 TEST RESULTS 17 4 . BANDWIDTH TEST 22 4.1 APPLIED PROCEDURES / LIMIT 22 4.1.1 TEST PROCEDURE 22 4.1.2 DEVIATION FROM STANDARD 22 4.1.3 TEST SETUP 22 4.1.4 EUT OPERATION CONDITIONS 22 4.1.5 TEST RESULTS 23 5 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 27 5.1 DEVIATION FROM STANDARD 28 5.2 TEST SETUP 28 5.3 EUT OPERATION CONDITIONS 28 5.4 TEST RESULTS 28 6 . ANTENNA REQUIREMENT 29 6.1 STANDARD REQUIREMENT 29 6.2 EUT ANTENNA 29 7 . EUT TEST PHOTO 30 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15070127 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 4 of 33 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.249) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.249 Radiated Spurious Emission PASS 15.249 Bandwidth PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report 1.1 TEST FACILITY Shenzhen BCTC Technology Co., Ltd. Add.:No.101,Yousong Road,Longhua New District, Shenzhen,China FCC Registration No.:187086 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15070127 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 5 of 33 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Wireless Earmuff Trade Name N/A Model Name 36060069, BT-309 Model Difference All the same, is different for mode names and outlook color Product Description Operation Frequency: 2402~2480 MHz Modulation Type: GFSK,PI/4 DPSK,8DPSK Bit Rate of Transmitter 1M/2M/3Mbps Number Of Channel 79 CH Antenna Designation: Please see Note 3. Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an ITE/Computing Device. More details of EUT technical specification, please refer to the User's Manual. Channel List Please refer to the Note 2. Adapter N/A Battery DC 3.7V DC 5V from adapter Connecting I/O Port(s) Please refer to the User's Manual hardware version V1.0 Software version V1.1 Serial number 01 Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. 2. Channel List Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 00 2402 27 2429 54 2456 01 2403 28 2430 55 2457 02 2404 29 2431 56 2458 03 2405 30 2432 57 2459 04 2406 31 2433 58 2460 05 2407 32 2434 59 2461 06 2408 33 2435 60 2462 07 2409 34 2436 61 2463 08 2410 35 2437 62 2464 09 2411 36 2438 63 2465 10 2412 37 2439 64 2466 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15070127 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 6 of 33 11 2413 38 2440 65 2467 12 2414 39 2441 66 2468 13 2415 40 2442 67 2469 14 2416 41 2443 68 2470 15 2417 42 2444 69 2471 16 2418 43 2445 70 2472 17 2419 44 2…

Text truncated - open the document above for the full version.

Radiated Emission Conducted Emission
