2AFKK99378THE GOAL LIGHT 30 HORN SOUND

External Photos

Label Artwork and Location SIZE: 20.5mm (W) x 1.5mm (H) FCC ID ： 2AFKK99378

Internal Photos

1 INTERTEK TESTING SERVICES RF Exposure The Equipment under Test (EUT) is a control unit for THE GOAL LIGHT 30 HORN SOUND operating at 2.4GHz band. It is powered by DC 3.0V (2 x 1.5V AAA batteries). For more detail information pls. refer to the user manual. Antenna Type: Integral antenna. Antenna Gain: 2dBi. The normal radiated output power (e.i.r.p) is: 1.0dBm (tolerance: +/- 3dB). The normal conducted output power is: -1.0dBm (tolerance: +/- 3dB). Mo dulation Type: GFSK. According to the KDB 447498: Th e Maximum peak radiated emission for the EUT is 95.7dBμV/m at 3m in the frequency 2427MHz The EIRP = [(FS*D) ^2 / 30] mW = 0.47dBm which is within the production variation. The maximum conducted output power specified is 2. 0dBm = 1.6mW Th e source- based time-averaging conducted output power = 1.6* Duty cycle mW <1.6 mW(Duty cycle <100%) Th e SAR Exclusion Threshold Level: = 3 .0 * (min. test separation distance, mm) / sqrt(freq. in GHz) = 3.0 * 5 / sqrt (2.427) mW = 9.6 mW Since the source-based time-averaging conducted output power is well below the SAR low threshold level, so the EUT is considered to comply with SAR requirement without testing. The duty cycle is simply the on-time divided by the period: The duration of one cycle = 2.0000 ms Effective period of the cycle = 144.9 μs =0.1449 ms DC = 0.1449ms / 2.0000 ms = 0.0725 or 7.25% FCC ID: 2AFKK99378
