2AFN5-B020768Bluetooth speaker

User manual of Amp Cooler Case with Bluetooth Speakers This device includes aluminum liner inside MDF case, silver Bluetooth dial panel, speakers at 3W, 4 Ohm, rechargeable Lithium battery (D.C.4.7V, 1200mA) and A.C. adaptor (D.C. 5V, 1A) with UL approval. The silver square dial panel has functions of Bluetooth playing, F.M.( via help of antenna ) ,SD, USB and Line-in. The black OFF/ON switch button is used to switch OFF/ON the circuit whether it is driven by D.C. rechargeable battery or A.C. adaptor supply. When the button is switched on, LED screen is lightened with displays. The function button MODE can be selected in sequence of Bluetooth-Radio-USB. To select music while playing, press NEXT/VOL+ button to go forward or press PRE/VOL- button to go backward. To increase volume of music played, just press NEXT/VOL+ button long time or PRE/VOL- long time to decrease music volume. Press the middle button to pause music playing. To achieve Bluetooth playing, search this Bluetooth unit with I.D. Sweety via your cell phone. When Bluetooth is connected, there will be a warning voice to advise. just operate the cell phone connected to play music. Produce name Amp cooler case with Bluetooth speaker Model nr. ST-202DHF-G Operation frequency 50~60Hz Rated current 1A Rated voltage D.C. 5V Note: Changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

DATE : 2015-8-18 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint below company and person: Name Kevin Feng Position Manager Company Name Dongguan Dongdian Testing Service Co.,Ltd. Address 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808 Tel / Fax Tel: +86-0769-22891499 fax:+86-0769-22895596 E-Mail [email protected] to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with: Applicant name 4 Sizzle Inc Address 17315 Studebaker Rd, ste 300C Cerritos, CA 90703 Yours sincerely, Signatory Name Neil Henderson Position President Company Name 4 Sizzle Inc Address 17315 Studebaker Rd, ste 300C Cerritos, CA 90703 Tel / Fax 480 557 0291/ 602 926 2552 E-Mail Neil@ 4sizzle.com

DATE: 2015-8-20 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AFN5-B020768 Product Name: Bluetooth speaker Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...)  Schematics  Block diagram  Operation description  BOM (Parts List) These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Yours sincerely, Signatory Name Neil Henderson Position President Company Name 4 Sizzle Inc Address 17315 Studebaker Rd, ste 300C Cerritos, CA 90703 Tel / Fax 480 557 0291/ 602 926 2552 E-Mail Neil@ 4sizzle.com

Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R15Q0805-3E2 Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R15Q0805-3E2 Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R15Q0805-3E2 Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R15Q0805-3E2

FCC ID: 2AFN5-B020768 Model: ST-202DHF-G SIG: B020768 Rated Voltage: D.C. 5V Rated Current: 1000 mA Speaker: 3W/4 Ohm This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R15Q0805-3E2 Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R15Q0805-3E2 Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R15Q0805-3E2 Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R15Q0805-3E2

RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Worse case is as below: [2441MHz, -2.72dBm (0.535mW) output power] (0.535/5)·[√2.441(GHz)]= 0.167 <3.0 for 1-g SAR Then SAR evaluation is not required Leo Liu 2015/8/27

Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R15Q0805-3E2 Page 1 of 68 FCC CERTIFICATION TEST REPORT FOR Issued By: Dongguan Dongdian Testing Service Co., Ltd. Add: No. 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808 Tel: +86-0769-22891499 Http://www.dgddt.com Applicant : 4 Sizzle Inc. Address : 17315 Studebaker Rd, ste 300C Cerritos, CA 90703 Equipment under Test : Bluetooth Speaker Model No. : ST-202DHF-G Trade Mark : / FCC ID : 2AFN5-B020768 Manufacturer : 4 Sizzle Inc. Address : 17315 Studebaker Rd, ste 300C Cerritos, CA 90703 Report No.: DDT-R15Q0805-3E2 Issued Date: Aug. 12, 2015 Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R15Q0805-3E2 Page 2 of 68 TABLE OF CONTENTS Test report declares......................................................................................................................4 1. Summary of test results ............................................................................................................... 5 2. General test information .............................................................................................................. 6 2.1. Description of EUT ..................................................................................................................... 6 2.2. Accessories of EUT..................................................................................................................... 6 2.3. Assistant equipment used for test ................................................................................................ 6 2.4. Block diagram of EUT configuration for test ............................................................................. 7 2.5. Test environment conditions ....................................................................................................... 7 2.6. Test laboratory............................................................................................................................. 7 2.7. Measurement uncertainty ............................................................................................................ 8 3. Maximum Peak Output Power ....................................................................................................9 3.1. Test equipment ............................................................................................................................ 9 3.2. Block diagram of test setup ......................................................................................................... 9 3.3. Limits .......................................................................................................................................... 9 3.4. Test Procedure............................................................................................................................. 9 3.5. Test Result................................................................................................................................... 9 4. 20dB Bandwidth and 99% Bandwidth ...................................................................................... 10 4.1. Test equipment .......................................................................................................................... 10 4.2. Block diagram of test setup ....................................................................................................... 10 4.3. Limits ........................................................................................................................................ 10 4.4. Test Procedure........................................................................................................................... 10 4.5. Test Result................................................................................................................................. 10 4.6. Original test data ....................................................................................................................... 11 5. Carrier Frequency Separation.................................................................................................... 14 5.1. Test equipment .......................................................................................................................... 14 5.2. Block diagram of test setup ....................................................................................................... 14 5.3. Limits ........................................................................................................................................ 14 5.4. Test Procedure........................................................................................................................... 14 5.5. Test Result................................................................................................................................. 14 5.6. Original test data ....................................................................................................................... 15 6. Number Of Hopping Channel ...................................................................................................16 6.1. Test equipment .......................................................................................................................... 16 6.2. Block diagram of test setup ....................................................................................................... 16 6.3. Limits ........................................................................................................................................ 16 6.4. Test Procedure........................................................................................................................... 16 6.5. Test Result................................................................................................................................. 16 6.6. Original test data ..................................................…

Text truncated - open the document above for the full version.

Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R15Q0805-3E2 Page 60 of 68 13. Test setup photograph Dongguan Dongdian Testing Service Co., Ltd Report No.: DDT-R15Q0805-3E2 Page 61 of 68
