1 QUAD CORE BOX User’s Guide 2 1. Safety Information Read and understand all instructions before using this product. If damage is caused by failure to follow the instructions, the warranty does not apply. 1.1 FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on. The user is encouraged to try to correct the interference by one or more of the following measures. - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. -Connect the equipment into and outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cmbetween the radiator & your body. You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. The distance between user and products should be no less than 20cm This device complies with Part 15 of the FCC Rules; Operation is subject to the following two conditions: 1). this device may not cause harmful interference, and 2). this device must accept any interference received, including interference that may cause undesired operation. 1.2 Precautions Important Safety Instructions Read these operating instructions carefully before using the unit. Follow all the safety instructions listed below. Keep these operating instructions handy for future reference. 1.2.1 Read these instructions. 1.2.2 Keep these instructions. 1.2.3 Heed all warnings. 1.2.4 Follow all instructions. 1.2.5 DO NOT use this apparatus near water. 1.2.6 DO NOT clean with any chemical detergent. Clean only with a dry cloth. 3 1.2.7 DO NOT block any ventilation openings. Install in accordance with the manufacturer’s instructions. 1.2.8 DO NOT install near any heat sources such as radiators, heat registers, stoves, or other apparatus that produce heat. 1.2.9 Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where it exits the apparatus. 1.2.10 Only use attachments/accessories specified by the manufacturer. 1.2.11 Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used , use caution when moving the cart/apparatus combination to avoid injury from tip-over. 1.2.12 Unplug this apparatus during lightning storms or when unused for long period of time. 1.2.13 Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as when the power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. 1.3 Handling Cautions 1.3.1 DO NOT expose this apparatus to dripping or splashing. Do not put objects filled with liquids, such as vases on the apparatus. 1.3.2 To turn this apparatus off completely, you must pull the power plug out of the wall socket. Consequently, the power plug must be easily and readily accessible at all times. 1.3.3 DO NOT plug multiple electric devices into the same wall socket. Overloading a socket can cause it to overheat, resulting in a fire. 1.3.4 Before connecting other components to this player, be sure to turn them off. 1.3.5 If the product makes an abnormal noise or produces a burning smell or smoke, turn off the power switch immediately and disconnect the power plug from the wall outlet. Then, contact the nearest customer service center for technical assistance. Do not use the product. Using the product as it is may cause a fire or an electric shock. 4 2. Introduction 2.1 Package Contents LifeShare TV User’s Guide HDMI Cable Optional Cable CVBS Cable IR Remote Controller (IR RC) Power Adapter, Input: AC100 ~ 240V, 50/60Hz, Output: 5V/2A 2.2 Product Features  A9, 1.6~2.0GHz, RAM 2G , ROM built in 8G EMMC  Powered by Android 4.x OS  Built in 802.11 ac a/b/g/n WiFi module, wireless Internet access  2 USB interface, support mobile HDD, wired/wireless mouse and keyboard operation  RJ45 10/100M Ethernet interface  Support 1080P video playback  HDMI video output, connect to HDTV for HD video playback  Support weather, calendar, and desktop clock gadgets  Support 2.4G wireless motion Remote Controller  Support music player, picture player and more family entertainment  Support SD card and Google Chrome browser and virtual private network access  App Installer for application installation from USB/SD card 2.3Remote Controller 5 Note: Button Battery 2025 3V insert with correct polarity (+/-). 6 2.4 Setup Connection Place APC380 on a flat platform near the TV, and make sure nothing block the remote control signal. 2.5 Display when Power Up 2.6.1 After power up, the TV will first show a green robot during loading. When loading is finished, it will go to Home screen. 2.6.2 Home Screen display. 3. Settings Using Navigation (4 directions), OK, EXIT, and Menu keys of Remote Controller to select the options, the option selected will be highlighted and confirmed by pressing OK key. Same operation for text input if needed. Select icon then press OK key. Select icon and select icon to settings interface. 7 3.1 WiFi 3.1.1 It will automatically scan ambient WiFi networks when select “ON”. 3.1.2 Connec…

Text truncated - open the document above for the full version.

LifeShareTechnologiesLLC 2177IntelliplexDr.,Suite150 Shelbyville,IN46176 FederalCommunicationCommission EquipmentAuthorizationDivision,ApplicationProcessingBranch 7435OaklandMillsRoad Columbia,MD21048 DATE:2015-10-14 Attn:OfficeofEngineeringandTechnology Subject:AttestationLetterregardingUNIIdevices FCCID:2AFNK-D2C315 SoftwaresecurityquestionsandanswersperKDB594280D02: SoftwareSecuritydescription–GeneralDescription 1Describehowanysoftware/firmwareupdatewill beobtained,downloaded,andinstalled.Software thatisaccessedthroughmanufacturer’swebsite ordevice’smanagementsystem,mustdescribe thedifferentlevelsofsecurity. Wedonotreleasethe firmwareonourwebsite fordownloading.Our directhostmanufacturer (OEM)canrequestthe firmwarefromusandit willbemadeavailablevia secureserver. 2Describealltheradiofrequencyparametersthat aremodifiedbyanysoftware/firmwarewithout anyhardwarechanges.Aretheseparametersin somewaylimited,suchthat,itwillnotexceed theauthorizedparameters? Radiofrequency parametersarelimitedby USregulatorydomainand countrycodetolimit frequencyandtransmit powerlevels.Theselimits arestoredinnon-volatile memorybythemodule manufactureratthetimeof production.Theywillnot exceedtheauthorized values. 3Describeindetailtheauthenticationprotocols thatareinplacetoensurethatthesourceofthe software/firmwareislegitimate.Describein detailhowthesoftwareisprotectedagainst modification Thefirmwareisinstalled oneachsinglemodule duringmanufacturing process.Thecorrect firmwareisverifiedand installedbythemodule manufacturer. Inaddition,thefirmware LifeShareTechnologiesLLC 2177IntelliplexDr.,Suite150 Shelbyville,IN46176 binaryisencryptedusing openSSLencryptionand thefirmwareupdatescan onlybestoredin non-volatilememorywhen thefirmwareis authenticated. Theencryptionkeyis knownbythemodule manufactureronly. 4Describeindetailtheverificationprotocolsin placetoensurethatinstalledsoftware/firmwareis legitimate Thefirmwarebinaryis encrypted.Theprocessto flashanewfirmwareis usingasecretkeyto decryptthefirmware,only correctdecryptedfirmware isstoredinnon-volatile memory(see#3). 5Describeindetailtheverificationprotocolsin placetoensurethatinstalledsoftware/firmwareis legitimate StandardopenSSL encryptionisused(see #3). 6Foradevicethatcanbeconfiguredasamaster andclient(withactiveorpassivescanning), explainhowthedeviceensurescompliancefor eachmode?Inparticularifthedeviceactsas masterinsomebandofoperationandclientin another;howiscomplianceensuredineachband ofoperation? Thedeviceensuresthe compliancebychecking theconfiguredparameter andoperationvalues accordingtotheregulatory domainandcountrycode ineachband. SoftwareSecuritydescription–Third-PartyAccessControl 1Howisunauthorizedsoftware/firmwarechanges prevented? Unauthorizedfirmwareis notacceptedbythe firmwareupdateprocess. SeeGeneralDescription #5,#3 2Isitpossibleforthirdpartiestoloaddevice driversthatcouldmodifytheRFparameters, countryofoperationorotherparameterswhich impactdevicecompliance?Ifso,describe procedurestoensurethatonlyapproveddrivers areloaded. Theembeddedsoftwareis protectedviathemeasures explainedintheprevious section.Distributionsof hostoperatingsoftwareare encryptedwithakey. 3Explainifanythirdpartieshavethecapabilityto operateaUSsolddeviceonanyotherregulatory domain,frequencies,orinanymannerthatisin No,thirdpartiesdon’t havethecapabilityto accessandchangeradio LifeShareTechnologiesLLC 2177IntelliplexDr.,Suite150 Shelbyville,IN46176 violationofthecertification.parameters.USsold modulesarefactory configuredtoUS. 4Whatpreventsthirdpartiesfromloadingnon-US versionsofthesoftware/firmwareonthedevice? Onlyencryptedand verifiedfirmwareis appliedandstoredinthe non-volatilememory. 5Formodulardevices,describehowauthentication isachievedwhenusedwithdifferenthosts. Themoduleisnot availableforsaleor installationoutsideof companylicensing agreements.Modulesare alwaysinstalledinhost systemsinafactorybyend integrators(OEM) responsibleforloading authorizedsoftware. SoftwareSecuritydescription–USERCONFIGURATIONGUID 1TowhomistheUIaccessible?(Professional installer,enduser,other.) TheUIisaccessibleto anyoneusingthedevice. a.Whatparametersareviewabletothe professionalinstaller/enduser? Variousdevicestatus informationismade availablelikelog information,connection status,operationmode, operationfrequency,etc. Radioparametersare describedinc.i b.Whatparametersareaccessibleormodifiable totheprofessionalinstaller? i.Aretheparametersinsomeway limited,sothattheinstallerswillnot enterparametersthatexceedthose authorized? ii.Whatcontrolsexistthattheuser cannotoperatethedeviceoutsideits authorizationintheU.S.? Thisdeviceisnotsubject toprofessionalinstallation c.Whatconfigurationoptionsareavailableto theend-user? Theenduserisableto configuretheoperation frequency,modulation, reducetheoutputpower levelsetc.Theenduser cannotchangetheantenna LifeShareTechnologiesLLC 2177IntelliplexDr.,Suite150 Shelbyville,IN46176 i.Aretheparametersinsomeway limited,sothattheinstallerswillnot enterparametersthatexceedthose authorized? ii.Whatcontrolsexistthattheuser cannotoperatethedeviceoutsideits authorizationintheU.S.? gainandcountrycode, thosesettingsare programmedatfactory productiontime. Yes,theparameterscan onlybechangedwithinthe limitsofcountrycodeUS. Thecountrycodeand regulatorydomaincontrol dolimitalltheparameters setbyUI d.Isthecountrycodefactoryset?Canitbe changedintheUI? i.Ifso,whatcontrolsexisttoensure thatthedevicecanonlyoperate withinitsauthorizationintheU.S.? Thecountrycodeis factorysetandisnever changedbyUI. Thecountrycodeis factorysetandisnever changedbyUI e.Whatarethedefaultparameterswhenthe deviceisrestarted? Ateachbootupthe countrycodeandthe antennagainarereadfrom thenon-volatilememory, thosevaluesare configuredduringmodule production. 2Cantheradiobeconfiguredinbridgeormesh mode?Ifyes,anattestationmayberequired. FurtherinformationisavailableinKDB Publication905462D02. Notsupported 3Foradevicethatcanbeconfiguredasamaster andclient(withactiveorpassivescanning),if thisisuserconfigurable,describewh…

Text truncated - open the document above for the full version.

CONFIDENTIALITYREQUEST forCertificationServiceinUSA FederalCommunicationCommission EquipmentAuthorizationDivision,ApplicationProcessingBranch 7435OaklandMillsRoad Columbia,MD21048 DATE:2015-10-14 TOWHOMITMAYCONCERN PursuanttoParagraphs§0.457and0.459oftheCommission’sRules(47C.F.R.)and Section§552(b)(4)oftheFreedomofInformationAct,werequestsconfidentialityforthe followingproducts: FCCIDModelname 2AFNK-D2C315LifeShareTV Fortheproductstatedabove,werequestpermanentconfidentialityforexhibitswhich containOperationalDescription,BlockDiagram,Schematics,PartsListsorTuneUp Information. Theaboveexhibitscontainourtradesecretsandproprietaryinformationthatcouldbeof benefittoourcompetitors. Ifyouhaveanyquestions,pleasefeelfreetocontactmeattheaddressshownbelow. Sincerely, (signed) Name:doug.stevens Company:LifeShareTechnologiesLLC Address:2177IntelliplexDr.,Suite150 Shelbyville,IN46176 Phone:+317825-0320 Fax:+317825-0320 Email:[email protected]

LifeShareTechnologiesLLC 2177IntelliplexDr.,Suite150 Shelbyville,IN46176 UNIIDeviceDeclarationLetter Towhomitmayconcern: WehavedeclaredbelowfeaturedforFCCequipmentauthorization, DeviceFCCID:2AFNK-D2C315 (1)DFSDevice:  Master  ClientwithRadardetectioncapability N/AClientwithoutradardetectioncapability, (2)Active/PassiveScanning,adhocmodeaccesspointcapability Frequency Band(MHz) ActiveScanning (thedevicecan transmitaprobe (beacon)) passivescanning (wherethedevice iscanlistenonly withnoprobes) AdHocMode Capability Accesspoint Capability 2412-2462YesNoYesNoYesNoYesNo 5745-5825YesNoYesNoYesNoYesNo 5755-5795YesNoYesNoYesNoYesNo 5180-5240 YesNoYesNoYes No YesNo 5190-5230YesNoYesNoYesNoYesNo 5260-5320  YesNoYes  No  YesNo  YesNo 5270-5310  YesNoYes  No  YesNo  YesNo 5500-5700  YesNoYes  No  YesNo  YesNo 5510-5670  YesNoYes  No  YesNo  YesNo (3)CountrycodeselectionabilityYesNo Ifyes,plsexplainhowitwasimplemented: (4)Meet15.202requirement  Yes  No plscheckbelow: Amasterdeviceisdefinedasadeviceoperatinginamodeinwhichithasthecapabilityto transmitwithoutreceivinganenablingsignal.Inthismodeitisabletoselectachanneland initiateanetworkbysendingenablingsignalstootherdevices Aclientdeviceisdefinedasadeviceoperatinginamodeinwhichthetransmissionsofthe deviceareundercontrolofthemaster.Adeviceinclientmodeisnotabletoinitiateanetwork. (5)Forclientdevicesthathavesoftwareconfigurationcontroltooperateindifferentmodes(active scanninginsomeandpassivescanninginothers)indifferentbands(deviceswithmultiple equipmentclassesorthosethatoperateonnon-DFSfrequencies)ormodulardeviceswhich configurethemodesofoperationsthroughsoftware,theapplicationmustprovidesoftwareand operationsdescriptiononhowthesoftwareand/orhardwareisimplementedtoensurethat properoperationsmodescannotbemodifiedbyenduseroraninstaller. ApplyDoesnotapply (Ifapply,plshelptoprovideexplanationonitwasimplement,andhowsoftwarewascontrolled)

LifeShareTechnologiesLLC 2177IntelliplexDr.,Suite150 Shelbyville,IN46176 Date:2015-10-21 To: FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD We,LifeShareTechnologiesLLC,declarethatthissample(FCCID:2AFNK-D2C315)doesn’thave AdHocmodefunctionon“non-US/Canadafrequencies”.Inaddition,thefrequencyselection featureisdisabledbyfirmwarefordevicesmarkedtotheUS/Canada.ForDTSpartofthisdevice, onlychannels1-11willbeusedinNorthAmerica,Countrycodeselectionisdisabled. Shouldyouhaveanyquestionsorcommentsregardingthismatter,pleasehavemybest attention. Sincerely, (signature) NameandTitle:doug.stevens /PM Company:LifeShareTechnologiesLLC Address:2177IntelliplexDr.,Suite150Shelbyville,IN46176 Phone:+317825-0320 Fax:+317825-0320 Email:[email protected]

LifeShareTechnologiesLLC 2177IntelliplexDr., Suite150 Shelbyville,IN 46176 Attestationfor FCCDeclarationof Conformity FCCID: 2AFNK-D2C315 ModelName:LifeShareTV DATE: 2015-10-14 Pleasebe notifiedthat we, the undersigned,LifeShareTechnologiesLLCdeclarethat the productwhichbearsthe aboveFCCID is also compliantwiththe FCCrequirementsfor DoC.Testingin regardsto this reportwas doneby Com pliance Certification ServicesInc. (Tainan Lab.) located at No. 8,Jiucengling,Xinhua Dist., Tainan City 712,Taiwan(R.O.C), whichhas beenaccreditedin accordanceto all of the requirementsof 47CFR2.948(d)and (e) of the FCCrulesand KDB349827 BestRegards! (signed) Company:LifeShareTechnologiesLLC ContactPerson:doug.stevens Title:PM Telephone: +317825-0320 Fax:+317825-0320 EMAIL:[email protected]

Report No: C150727Z04 Page 1 / 7 External Photos of EUT Report No: C150727Z04 Page 2 / 7 Report No: C150727Z04 Page 3 / 7 Report No: C150727Z04 Page 4 / 7 Report No: C150727Z04 Page 5 / 7 Report No: C150727Z04 Page 6 / 7 Report No: C150727Z04 Page 7 / 7

Label Location

Compliance Certification Services (Shenzhen) Inc. Report No: C150727Z04-RP1_MPE FCC ID: 2AFNK-D2C315 Date of Issue: September 29, 2015 MPE Report Exposure category: General population/uncontrolled environment EUT Type: Production Unit Device Type: Mobile Device Refer Standard: KDB 447498 D01 General RF Exposure Guidance v05r02 FCC Part 2 §2.1091 1. Evaluation method Systems operating under the provisions of FCC 47 CFR section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as mobile device whereby a distance of 0.2m normally can be maintained between the user and the device, and below RF Permissible Exposure limit shall comply with. In accordance with KDB447498D01 for Simultaneous transmission MPE test exclusion applies when the sum of the MPE ratios for all simultaneous transmitting antennas incorporated in a host device, based on the calculated/estimated, numerically modeled or measured field strengths or power density, is ≤ 1.0. The MPE ratio of each antenna is determined at the minimum test separation distance required by the operating configurations and exposure conditions of the host device, according to the ratio of field strengths or power density to MPE limit, at the test frequency. Either the maximum peak or spatially averaged results from measurements or numerical simulations may be used to determine the MPE ratios. Spatial averaging does not apply when MPE is estimated using simple calculations based on far-field plane-wave equivalent conditions. The antenna installation and operating requirements for the host device must meet the minimum test separation distances required by all antennas, in both standalone and simultaneous transmission operations, to satisfy compliance. 2. Limits for General Population/Uncontrolled Exposure 3. Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density Compliance Certification Services (Shenzhen) Inc. Report No: C150727Z04-RP1_MPE FCC ID: 2AFNK-D2C315 Date of Issue: September 29, 2015 P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna From the peak EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the maximum gain of the used antenna is 2dBi, the RF power density can be obtained. 4. Estimation Result 4.1 Conducted Power Results Bluetooth ModeChannelFrequency(MHz) Peak Conducted Output Power (dBm) GFSK-BLE 0024024.30 1924405.60 3924805.89 GFSK 002402-4.96 392441-3.72 782480-3.16 8DPSK 002402-6.87 392441-5.31 782480-4.37 π/4DQPSK 002402-6.63 392441-5.18 782480-4.22 2.4GHz WIFI AntennaModeFrequency(MHz) Peak Conducted Output Power (dBm) Antenna 1 IEEE 802.11b 24129.51 24379.05 24628.34 Antenna 2 24129.43 24379.01 24629.07 Antenna 1 IEEE 802.11g 241214.40 243713.70 246212.84 Antenna 2 241214.65 243714.09 246213.77 Antenna 1 IEEE 802.11n HT20 241212.53 243712.00 246211.57 Antenna 2241212.34 Compliance Certification Services (Shenzhen) Inc. Report No: C150727Z04-RP1_MPE FCC ID: 2AFNK-D2C315 Date of Issue: September 29, 2015 243711.40 246210.67 Antenna 1 IEEE 802.11n HT40 242212.37 243712.07 245211.77 Antenna 2 242211.73 243711.72 245211.87 5GHz WIFI AntennaModeFrequency(MHz) Peak Conducted Output Power (dBm) Antenna 1 IEEE 802.11a 518015.79 520015.79 524015.51 526015.49 530015.15 532015.20 574515.26 578515.32 582514.90 Antenna 2 518014.32 520015.50 524014.45 526014.33 530014.46 532014.20 574514.41 578515.22 582514.91 Antenna 1 IEEE 802.11n HT20 518015.56 520015.42 524015.46 526015.34 530015.04 532015.16 574514.07 578515.12 582514.63 Antenna 2518014.39 520014.43 524013.34 526014.36 530014.26 532014.22 574515.39 578515.04 582514.54 Antenna 1 IEEE 802.11n HT40 519016.21 523015.94 527015.76 531015.70 575515.75 579515.54 Antenna 2 519014.90 523014.98 527014.71 531014.86 575516.00 579515.77 Antenna 1 IEEE 802.11ac 80 521015.46 529015.17 577514.90 Antenna 2 521013.83 529013.89 577515.14 4.2 Manufacturing tolerance Bluetooth GFSK -BLE(Peak) ChannelChannel 00Channel 19Channel 39 Target (dBm)4.05.05.0 Tolerance ±(dB)1.01.01.0 GFSK (Peak) ChannelChannel 00Channel 39Channel 78 Target (dBm)-4.0-3.0-3.0 Tolerance ±(dB)1.01.01.0 8DPSK (Peak) ChannelChannel 00Channel 39Channel 78 Target (dBm)-6.0-5.0-4.0 Tolerance ±(dB)1.01.01.0 π/4DQPSK (Peak) ChannelChannel 00Channel 39Channel 78 Target (dBm)-6.0-5.0-4.0 Tolerance ±(dB)1.01.01.0 2.4GHz WIFI IEEE 802.11 b (Peak) Frequency (MHz) Antenna 1Antenna 2 241224372462241224372462 Target (dBm) 9.09.08.09.09.09.0 Tolerance ±(dB)1.01.01.01.01.01.0 IEEE 802.11 g ( Average) Frequency (MHz) Antenna 1Antenna 2 241224372462241224372462 Target (dBm)14.013.012.014.014.013.0 Tolerance ±(dB)1.01.01.01.01.01.0 IEEE 802.11 n HT20 (Peak) Frequency (MHz) Antenna 1Antenna 2 241224372462241224372462 Target (dBm)12.012.011.012.011.010.0 Tolerance ±(dB)1.01.01.01.01.01.0 IEEE 802.11 n HT40 (Peak) Frequency (MHz) Antenna 1Antenna 2 242224372452242224372452 Target (dBm)12.012.012.011.011.011.0 Tolerance ±(dB)1.01.01.01.01.01.0 5GHz WIFI IEEE 802.11 a (Peak) Frequency (MHz) Antenna 1Antenna 2 518052005240518052005240 Target (dBm) 15.015.015.014.015.015.0 Tolerance ±(dB)1.01.01.01.01.01.0 Frequency (MHz) Antenna 1Antenna 2 526053005320526053005320 Target (dBm) 15.015.015.014.014.014.0 Tolerance ±(dB)1.01.01.01.01.01.0 Frequency (MHz) Antenna 1Antenna 2 574557855825574557855825 Target (dBm) 15.015.014.014.015.014.0 Tolerance ±(dB)1.01.01.01.01.01.0 IEEE 802.11n HT20 (Peak) Frequency (MHz) Antenna 1Antenna 2 518052005240518052005240 Target (dBm) 15.015.015.014.014.013.0 Tolerance ±(dB)1.01.01.01.01.01.0 Frequency (MHz) Antenna 1Antenna 2 526053005320526053005320 Target (dBm) 15.015.015.014.014.014.0 Tolerance ±(dB)1.01.0…

Text truncated - open the document above for the full version.

Report No.: C150727Z04-RP1-5 FCC ID: 2AFNK-D2C315 Page 1 / 31 FCC 47 CFR PART 15 SUBPART E & INDUSTRY CANADA RSS-247 for LifeShare TV Model: LifeShareTV-Pro-1.0 Brand: N/A Test Report Number: C150727Z04-RP1-5 Issued Date: October 16, 2015 Issued for LifeShare Technologies LLC 2177 Intelliplex Dr., Suite 150 Shelbyville, IN 46176 Issued by: Compliance Certification Services (Shenzhen) Inc. No.10-1 Mingkeda Logistics park, No.18, Huanguan South Rd., Guan Lan Town, Baoan District, Shenzhen, China TEL: 86-755-28055000 FAX: 86-755-28055221 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services (Shenzhen) Inc. This document may be altered or revised by Compliance Certification Services (Shenzhen) Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by TAF, A2LA, NVLAP, NIST or any government agencies. The TEST RESULTS in the report only apply to the tested sample. 检 测 CNAS L4818 Report No.: C150727Z04-RP1-5 FCC ID: 2AFNK-D2C315 Page 2 / 31 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Revision History Rev. Issue Date Revisions Effect Page Revised By 00 October 16, 2015 Initial Issue ALL Sabrina Wang Report No.: C150727Z04-RP1-5 FCC ID: 2AFNK-D2C315 Page 3 / 31 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. TABLE OF CONTENTS 1. TEST CERTIFICATION .................................................................................................. 4 2. EUT DESCRIPTION ....................................................................................................... 5 3. TEST METHODOLOGY ................................................................................................. 7 3.1 EUT CONFIGURATION ....................................................................................................... 7 3.2 EUT EXERCISE ................................................................................................................... 7 3.3 GENERAL TEST PROCEDURES ....................................................................................... 7 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS ........................................... 8 3.5 DESCRIPTION OF TEST MODES ...................................................................................... 9 4. SETUP OF EQUIPMENT UNDER TEST ...................................................................... 10 4.1 MEASURING INSTRUMENT CALIBRATION .................................................................... 10 4.2 MEASUREMENT EQUIPMENT USED .............................................................................. 10 4.3 DESCRIPTION OF SUPPORT UNITS............................................................................... 10 4.4 MEASUREMENT UNCERTAINTY ..................................................................................... 10 5. FACILITIES AND ACCREDITATIONS ........................................................................ 11 5.1 FACILITIES ........................................................................................................................ 11 5.2 EQUIPMENT ...................................................................................................................... 11 5.3 ACCREDITATIONS ........................................................................................................... 11 6. DYNAMIC FREQUENCY SELECTION ........................................................................ 12 Report No.: C150727Z04-RP1-5 FCC ID: 2AFNK-D2C315 Page 4 / 31 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 1. TEST CERTIFICATION Product LifeShare TV Model LifeShareTV-Pro-1.0 Brand N/A Tested July 27~ October 10, 2015 Applicant LifeShare Technologies LLC 2177 Intelliplex Dr., Suite 150 Shelbyville, IN 46176 Manufacturer LifeShare Technologies LLC 2177 Intelliplex Dr., Suite 150 Shelbyville, IN 46176 APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart E & IC RSS-247 ISSUE 1 with amendment May 2015 No non-compliance noted We hereby certify that: Compliance Certification Services (Shenzhen) Inc. tested the above equipment. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4: 2009 and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.407 and IC RSS-247. The TEST RESULTS of this report relate only to the tested sample identified in this report. Approved by: Reviewed by: Sunday Hu Supervisor of EMC Dept. Compliance Certification Services (Shenzhen) Inc. Ruby Zhang Supervisor of Report Dept. Compliance Certification Services (Shenzhen) Inc. Report No.: C150727Z04-RP1-5 FCC ID: 2AFNK-D2C315 Page 5 / 31 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 2. EUT DESCRIPTION Product LifeShare TV Model Number LifeShareTV-Pro-1.0 Brand N/A Model Discrepancy N/A Serial Number C150727Z04-RP1-5 Received Date July 27, 2015 Power Supply DC5V supplied by the Adapter Adapter Manufacturer /Model No. SHENZHEN FUJIA APPLIANCE CO., LTD. / FJ-SW0502000U I/P: 100-240Vac, 50/60Hz, 0.35A O/P: 5Vdc, 2000mA Operating Frequency Range & Number of Channels Mode Frequency Range(MHz) Number of channel UNII Band I: IEEE 802.11a 5180-5240 4 IEEE 802.11n HT20 5180-5240 4 IEEE 802.11n HT40 5190-5230 2 IEEE 802.11ac 80 5210 1 UNII Band II: IEEE 802.11a 5260-5320 4 IEEE 802.11n HT20 5260-5320 4 IEEE 802.11n HT40 5270-5310 2 IEEE 802.11ac 80 5290 1 UNII Band IV: IEEE 802.11a 5745-5825 5 IEEE 802.11n HT20 5745-5825 5 IEEE 802.11n HT40 5755-5795 2 IEE…
