2AFOSWT51822Bluetooth Low Engergy 4.0 Module

Forum: bbs.wireless-tag.com WT51822-S4AT 1 / 16 Wireless-Tag Technology www.wireless-tag.com [email protected] Wireless-Tag WT51822-S4AT Bluetooth Low Energy 4.0 Module DATASHEET Description: WT51822-S4AT is a high performance ,low power radio transmit and receive system module use Nordic BLE 4.0 nRF51822 as the controller chips. It has the smallest volume package in the industry, the size is 18.5*9.1*2.0, suitable for most applications which pay more attention to the size. The module integrate the complete standard low energy Bluetooth 4.0 protocol stack S100 drive. Customer's MCU is connected to the module by UART port, it will automatically send a broadcast code after the module starts. As the master, APP device can scan and search the broadcast from module in order to establish the connection. After success, it can conduct two-way communication link with mobile device APP by serial port. Through UART interface, the user can exchange data or control the communication parameters of module. The meaning of data is defined by the upper application user. The mobile device can operate to the module through APP, the data will receive by the module and pushed through UART MCU. After the module received a data packet from the client MCU serial port, it will be automatically forwarded to the mobile device. Features ：  CPU : nRF51822-QFAA (ARM Cortex™-M0 32 bit processor)  Memory: 256KB flash + 16KB RAM memory  Transparent transmission (Bridged method) easy to use and fast, no Bluetooth protocol stack development experience can use too.  The user interface uses a standard UART (TTL) Interface, bidirectional data read, easy to operate  Supports serial AT commands, the user can modify the basic parameters like the serial port baud rate, name, MAC address of the module, etc.  Serial data packet length, single data packet can support data length up to 200byte；  Serial hardware enable control, low-power control applications  With the support under the test mode but not connect the serial mode, mutual communication between test module and bluetooth master devices  Operating distance: 0~45m，class II level  Support System: IOS & Android  Supply voltage:3.3V  Module comes with PCB antenna, optional external antenna  Size : 18.5*9.1*2.0mm Applications：  Electronic scales Forum: bbs.wireless-tag.com WT51822-S4AT 2 / 16 Wireless-Tag Technology www.wireless-tag.com [email protected]  Electronic cigarette  Smart cups  Smart bracelet  Smart Watch  Bluetooth toys  Intelligent hardware  Smart Home 1. Work Mode Image 2. Module Pin Definitions MCU Application circuit BLE 4.0 Module VCC UART-TX UART-RX ENABLE GND APP BLE Master BLE 4.0 Top View Bottom View Forum: bbs.wireless-tag.com WT51822-S4AT 3 / 16 Wireless-Tag Technology www.wireless-tag.com [email protected] 3. Pin Directions No. Chip pin Module pin Function Description pin1 VCC VCC DC 2.5~3.6V pin2 GND GND Ground pin3 P0.01 RXD UART--RX pin4 P0.02 TXD UART--TX pin5 P0.03 INT Interrupt output pin, the bluetooth will deliver output 100ushigh-level pulse signal tips after received the primary-side data pin6 P0.04 TEST Test mode control pin, high level is effective, the module will enter into the Bluetooth test mode after being set high, the module will send back the received data pin7 P0.09 ENABLE Serial Port Enable pin, low level is effective. .Activate module serial port function after set high, and the serial port will close after being set low, which result in module functions reduction. pin8 P0.10 RESET Serial port reset pin, low level restored, and the baud rate restored to the default setting pin9 P0.13 NC No need to connect pin10 SWDIO SWDIO Debug data input pin11 SWDCLK SWDCLK Debug clock signal input Pin12 GND GND Ground Pin13 GND GND Ground Forum: bbs.wireless-tag.com WT51822-S4AT 4 / 16 Wireless-Tag Technology www.wireless-tag.com [email protected] Pin14 NC NC No connection Pin15 NC NC No connection 4. Module package size 5. Reflow reference to FIG. 6. The Manual for The Serial Transparent Transmission Protocol Serial transparent transmission means that modules are connected with user MCU via a common serial interface to establish a two-way communication between user MCU and mobile devices. The module Top View Forum: bbs.wireless-tag.com WT51822-S4AT 5 / 16 Wireless-Tag Technology www.wireless-tag.com [email protected] can obtain at least 200bytes transmission data and automatically send the data by separated packets, each wireless packet maximum load is 20byte. The data packet, which is sent to the module by mobile device side, must send subcontracting automatically(1-20byte/package), the module will forward to the MCU serial receiving port after receiving the data packet. Users can modify the module basic Bluetooth parameters serial AT commands. For details, please check "serial AT command" description. 6-1、 Serial hardware protocol: default 9600bps. 8, No verify bit 1, Stop bit 6-2、 “Enable” serial ports enable control, low level enable module serial port function making data communication with the client host MCU properly; high level close s the serial port function. At this time, the module Bluetooth can still transmit broadcast code, and can be paired connection, but you can not use the serial port functions; 6-3、 In order to save the size, the module uses the TXD / RXD double wire serial methods, without increasing the data flow control. So it is not recommended to set the serial rate too high, in caseof packet loss or error code, recommend to use 9600bps or other baud rates like no higher than 38400bps; 6-4、 Bluetooth module default connection interval is 20ms, if you need to save power and adopt low-speed forwarding mode, you can adjust Bluetooth connection interval via the AT command, the longest interval Bluetooth connectivity is 2000ms; 7. Serial AT commands Description: Module will automatically recognize and distinguish serial data, the data packet began with AT charact…

Text truncated - open the document above for the full version.

SCS-F26 Modular Approval Letter Page 1 of 2 Rev 7.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Modular Approval Declaration Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (Obsolete) 1.0 1.0 Dec-04-2006 Added IC Modular Letter (Obsolete) 1.0 2.0 Feb 16 2009 Add LMA and MA option (Obsolete) 2.0 3.0 April 14 2010 Revised per RSS Gen issue 3.0 (Obsolete) 3.0 4.0 Jan 12 2011 Removed Foot(2) (obsolete) 4.0 5.0 July 19 2011 Adding New note per KDB996369 D01 V01R03 (obsolete) 5.0 6.0 August 29 2011 Updated company template & Added text box (current) 6.0 7.0 Jan-31-2012 SCS-F26 Modular Approval Letter Page 2 of 2 Rev 7.0 WIRELESS-TAG TECHNOLOGY CO., LIMITED (Date) 2015/8/28 (Product name) Bluetooth Low Engergy 4.0 Module FCC ID : 2AFOSWT51822 , is seeking FCC Authorization as a Single Modular transmitter / Single Limited Modular Approval (Please check one). The EUT meets the requirements for Single Modular approval / Single Limited Modular Approval (please check one) as detailed in FCC public Notice DA00-1407. Compliance to each of the requirements is described below : Questions are: * Please provide a detailed explanation if the answer is “No.” 1. “The modular transmitter must have its own RF shielding.” Yes / No the product haven't RF shielding. 2. “The modular transmitter must have buffered modulation/data inputs.” Yes / No 3. “The modular transmitter must have its own power supply regulation.” Yes / No The product's power provide by host. it's didn't have own power supply. 4. “The modular transmitter must comply with the antenna requirements of section 15.203 and 15.204(c).” Yes / No 5. “The modular transmitter must be tested in a stand-alone configuration.” Yes / No 6. “The modular transmitter must be labeled with its own FCC ID number.” Yes / No 7. “The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacture must provide adequate instruction along with the module to explain any such requirements.” Yes / No 8. “The modular transmitter must comply with any applicable RF exposure requirements.” Yes / No Note: (1) LMA may be granted when one or more of the requirements in the table above cannot be demonstrated. LMA will also be issued in those instances where applicants can demonstrate that they will retain control over the final installation of the device, such that compliance of the end product is assured. In such cases, an operating condition on the LMA for the module must state that the module is only approved for use when installed in devices produced by a specific manufacturer. When LMA is sought, the application for equipment certification must specifically state how control of the end product into which the module will be installed, and will be maintained, such that full compliance of the end product is always ensured. (2) Please provide Clear and specific instructions describing the conditions, limitations and procedures for third-parties to use and/or integrate the module into a host device. (3) For non-Software Defined Radio transmitter modules where software is used to ensure compliance of the device, technical description of how such control is implemented to ensure prevention of third party modification must be provided (see KDB 594280). Note 1: Compliance of a module in its final configuration is the responsibility of the applicant. A host device will not be considered certified if the instructions regarding antenna configuration provided in the original description, of one or more separately certified modules it contains, were not followed. Example: A separately certified low-power transceiver module using Bluetooth technology which is housed in a desktop computer, laptop or peripheral does not require the overall system to be recertified, if the desktop computer, laptop or peripheral, as a stand-alone unit, complies with all applicable technical standards. Client’s name / title : Ming Li / manager Contact information / address: 4/F., BAK Sci & Tech Building, No. 9 Keyan Road, Science & Technology Park Central, Nanshan District, Shenzhen, China(Post Code:518057)

M/N: WT51822 FCC ID: 2AFOSWT51822 Label location

Antenna location

Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15080232 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 1 of 27 FCC Part 15C Test Report FCC ID: 2AFOSWT51822 Product Name: Bluetooth Low Engergy 4.0 Module Trademark: N/A Model Name : WT51822 Prepared For : WIRELESS-TAG TECHNOLOGY CO., LIMITED Address : 4/F., BAK Sci & Tech Building, No. 9 Keyan Road, Science & Technology Park Central, Nanshan District, Shenzhen, China(Post Code:518057) Prepared By : Shenzhen BCTC Technology Co., Ltd. Address : No.101,Yousong Road,Longhua New District, Shenzhen,China Test Date: Aug. 6- Aug. 20, 2015 Date of Report : Aug. 21, 2015 Report No.: BCTC-15080232 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15080232 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 2 of 27 VERIFICATION OF COMPLIANCE Applicant’s name ................. : WIRELESS-TAG TECHNOLOGY CO., LIMITED Address ................................. : 4/F., BAK Sci & Tech Building, No. 9 Keyan Road, Science & Technology Park Central, Nanshan District, Shenzhen, China(Pos t Code:518057) Manufacture's Name ............ : WIRELESS-TAG TECHNOLOGY CO., LIMITED Address ................................. : 4/F., BAK Sci & Tech Building, No. 9 Keyan Road, Science & Technology Park Central, Nanshan District, Shenzhen, China(Pos t Code:518057) Product description Product name ........................... : Bluetooth Low Engergy 4.0 Module Trademark: N/A Model Name: WT51822 Test procedure FCC Part15.249 Standards ANSI C63.10-2013 This device described above has been tested by BCTC, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BCTC, this document may be altered or revised by BCTC, personal only, and shall be noted in the revision of the document. Test Result ............................................... : Pass Testing Engineer : (Eric Yang) Technical Manager : (Sophia Lee) Authorized Signatory : (Carson. Zhang) Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15080232 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 3 of 27 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 5 1.2 MEASUREMENT UNCERTAINTY 5 2 . GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 DESCRIPTION OF TEST MODES 7 2.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 7 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 7 2.5 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 8 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 9 3 . EMC EMISSION TEST 10 3.1 CONDUCTED EMISSION MEASUREMENT 10 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 10 3.1.2 TEST PROCEDURE 11 3.1.3 DEVIATION FROM TEST STANDARD 11 3.1.4 TEST SETUP 11 3.1.5 EUT OPERATING CONDITIONS 11 3.1.6 TEST RESULTS 11 3.2 RADIATED EMISSION MEASUREMENT 12 3.2.1 RADIATED EMISSION LIMITS 12 3.2.2 TEST PROCEDURE 13 3.2.3 DEVIATION FROM TEST STANDARD 13 3.2.4 TEST SETUP 14 3.2.5 EUT OPERATING CONDITIONS 15 3.2.6 TEST RESULTS 16 4 . BANDWIDTH TEST 20 4.1 APPLIED PROCEDURES / LIMIT 20 4.1.1 TEST PROCEDURE 20 4.1.2 DEVIATION FROM STANDARD 20 4.1.3 TEST SETUP 20 4.1.4 EUT OPERATION CONDITIONS 20 4.1.5 TEST RESULTS 20 5 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 23 5.1 DEVIATION FROM STANDARD 24 5.2 TEST SETUP 24 5.3 EUT OPERATION CONDITIONS 24 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15080232 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 4 of 27 Table of Contents Page 5.4 TEST RESULTS 24 6 . ANTENNA REQUIREMENT 25 6.1 STANDARD REQUIREMENT 25 6.2 EUT ANTENNA 25 7 . EUT TEST PHOTO 26 8 . EUT PHOTO 27 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15080232 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 5 of 27 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.249) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission N/A 15.249 Radiated Spurious Emission PASS 15.249 Bandwidth PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report 1.1 TEST FACILITY Shenzhen BCTC Technology Co., Ltd. Add.:No.101,Yousong Road,Longhua New District, Shenzhen,China FCC Registration No.:187086 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15080232 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 6 of 27 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Bluetooth Low Engergy 4.0 Module Trade Name N/A Model Name WT51822 Model different N/A Product Description Operation Frequency: 2402~2480 MHz Modulation Type: GFSK Bit Rate of Transmitter 2Mbps Number Of Channel 40 CH Antenna Designation: Please see Note 3. Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an ITE/Computing Device. More details of EUT technical specification, please refer to the User's Manual. Channel List Please refer to the Note 2. Adapter DC 3.3V from Host Connecting I/O Port(s) Please refer to the User's Manual hardware version V01 Software version S01 Serial number 01 Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. 2. Channel List Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 00 2402 11 2424 31 2464 01 240…

Text truncated - open the document above for the full version.

Radiated Emission
