User's Manual Slim Wireless Charger CWC-TT051xyz Series (CWC-TT051BK2, CWC-TT051BL2, CWC-TT051YE2 CWC-TT051WH2, CWC-TT051RE2, CWC-TT051GE2 CWC-TT051GD2, CWC-TT051SL2, CWC-TT051VI2) Please read this manual thoroughly before use to ensure that ∙ you use the product safely and properly. The images in this manual may be different from the actual∙ product, and the contents are subject to change without notice for performance improvement. This device is a device suitable for electromagnetic waves and ∙ mainly intended for home use (Class B) in any region. How to use ∙Connect a Micro USB 5-Pin Adaptor to the Slim Wireless Charger. (Micro USB 5-Pin Adaptor is not included, and the adaptor must be certified for DC 5V/2.1A.) ∙Place a wireless device on top of the Slim Wireless Charger, and charging begins when the LED light flashes in green The wireless device should be placed on the right position for ∙ optimum performance. LED Status Display ※ In case of insufficient power: Use a certified DC 5V/2.1A adaptor. ※ In case of abnormal status: Adjust the position of wireless device. ※ In case of impurities (metal): Please check if there is an impurity (metal) between the wireless device and Slim Wireless Charger. Status LED Display GreenRed StandbyOff ChargingFlashing- Charging CompleteOn- Insufficient PowerFlashing in Orange Abnormal-On Impurities (Metal)-Flashing Fast Suitability for Electromagnetic Waves under Electromagnetic Waves Act Product Name: Slim Wireless Charger∙ Model Name: CWC-TT051xyz Series∙ Dimensions: 68 x 83 x 6.7mm ∙ Rated Power Input: DC 5.0V∙ 2.1A Name of Equipment: Wireless Device with Minor Electric ∙ Field Strength Identification: ∙ Company: THEDREAMTECH CO.,LTD.∙ Manufacturer/Place of Origin: THEDREAMTECH CO.,LTD./Korea∙ Retail &A/S: THEDREAMTECH CO.,LTD. (+)82-31-222-4735∙ Considerations Please read the included user’s manual thoroughly before using ∙ this product. Please use to ∙the adaptor must be certified for DC 5V/2.1A. ∙The wireless device should be placed on the right position ∙The receiver pad required to use this product, besides the wireless device with Qi feature, is not included. Do not touch the product with wet hands. ∙ ∙Protect the product from severe impact, e.g. dropping the product. ∙Use the product between 5C~35C, and avoid temperatures that ̊ ̊ are too low or too high when storing the product. ∙Protect the connection parts (connection port and plug) from conductive impurities (liquid, dust, metal powder, lead, etc). Keep out of the reach of children or pets as they may suck or∙ chew the product. Do not randomly renovate, disassemble, or repair the product. ∙ Items that contain information in magnetic strips such as credit ∙ cards, phone cards, bank books, and tickets may be damaged by the product’s magnetic force. Product Warranty Caution : Any changes or modifications in construction of this device which are not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment Note : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications, However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increasetheseparationbetweentheequipmentandreceiver. - Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiverisconnected. - Consultthedealeroranexperiencedradio/TVtechnicianforhelp. This device complies with Part 15 of the FCC`s Rules. Operation is subject to the following two Conditions: - 1. This device may not cause harmful interference, and - 2. This device must acc ept ant interference received, including interference that may cause undesirable operation. Product Name Slim Wireless Charger Place of Purchase Model Name CWC-TT051xyz Series Date of Purchase S / N Name of Customer Warranty Period 1 year Customer’s Contact Info

THEDREAMTECH CO.LTD. To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD FCC ID: 2AFOVTHEDRTCWCTT051 To Whom It May Concern: This letter is to ascertain that THEDREAMTECH CO.LTD. Product Slim Wireless Charger, 2AFOVTHEDRTCWCTT051, has been the units used for conducting FCC compliance testing, and it meets KDB 680106 Clause 5(2) all 6 conditions as stated below hence PBA is not required. 1 Power transfer frequency is less that 1 MHz  The power transfer frequency of DUT(Device Under Test) is between 110 kHz and 205 kHz. 2 Output power from each primary coil is less than 5 watts Output power from each coils are Max. 5 watts. 3 The transfer system includes only single primary and secondary coils. This includes charging systems that may have multiple primary coils and clients that are able to detect and allow coupling only between individual pairs of coils  The DUT(Device Under Test) are consist of one charging coil use. So the DUT can detect and allow coupling only between TX and RX Coil. 4 Client device is inserted in or placed directly in contact with the transmitter When the client device is placed directly in contact with transmitter, then charging is able to start. 5 The maximum coupling surface area of the transmit (charging) device is between 60 cm2 and 400 cm2.  The Maximum coupling surface area of the charging transmit is 54.76 cm 2 . 6 Aggregate leakage fields at 10 cm surrounding the device from all simultaneous transmitting coils are demonstrated to be less than 30% of the MPE limit.  The highest leakage filed is less than 30 % of the MPE(Maximum Permissible Exposure) limit. If you have any question or concerns, pls. contact us. Sincerely, Client’s signature Name: Song Hee-Jun Address: 603ho, B Dong, Dontankiseong-ro 316, Hwaseong-si, Gyeonggi-do, Korea
