2AFP4QB1801Mobile Phone

User Manual Model:QB1801 Brand:QUICK User Guide Contents 1 1. Preface ............................................................................................................................................................................... 2 2. Quick Start Guide ............................................................................................................................................................. 40 2.1 Insert SIM card and battery .............................................................................................................................................................. 40 2.2 Insert memory card ......................................................................................................................................................................... 40 2.3 Battery charging ............................................................................................................................................................................. 40 3. Call .................................................................................................................................................................................... 41 3.1 Dialpad .............................................................................................................................................................................................. 41 3.2 Making an overseas call. ....................................................................................................................................................................... 41 3.3 Dialing via Contacts............................................................................................................................................................................. 41 3.4 Calling an extension number ................................................................................................................................................................. 41 3.5 Making an emergency phone ................................................................................................................................................................. 41 3.6 Answer or reject incoming calls ............................................................................................................................................................. 41 3.7 Menu during a call ............................................................................................................................................................................... 42 4. Call Log ............................................................................................................................................................................ 43 5. Contacts ........................................................................................................................................................................... 44 5.1 Browsing contacts ........................................................................................................................................................................... 44 5.2 Quick search .................................................................................................................................................................................. 44 5.3 Creating contacts ............................................................................................................................................................................ 44 6. Message Service .............................................................................................................................................................. 45 6.1 SMS .............................................................................................................................................................................................. 45 6.2 MMS ............................................................................................................................................................................................ 45 7. Browser ............................................................................................................................................................................ 46 7.1 Open ............................................................................................................................................................................................. 46 7.2 Browser ......................................................................................................................................................................................... 46 8. Multimedia ........................................................................................................................................................................ 47 8.1 Audio Player .................................................................................................................................................................................. 47 8.2 Video Player ................................................................................................................................................................................... 47 8.3 Camera .......................................................................................................................................................................................... 47 8.4 FM Radio ...................................................................................................................................................................................... 47 9. Application ....................................................................................................................................................................... 48 9.1 Clock .....................................................................…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2Rev 5.0 JRG INVERSIONES SAS 2015.8.20 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, JRG INVERSIONES SAS hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): (Product description, model name): Product description: Mobile Phone model name: QB1801 FCC ID: 2AFP4QB1801 Sincerely, Client’s signature : GUSTAVO GAVIRIA VILLALBA Client’s name / title: Marketing Manager Applicant company: JRG INVERSIONES SAS address: Via 40 NO. 73-290 Local 14,Barranquilla,Colombia

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (current) 3.0 4.0 March-26-2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 4.0 JRG INVERSIONES SAS 2015.8.20 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AFP4QB1801 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description - Tune up Procedure - Part List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : GUSTAVO GAVIRIA VILLALBA Client’s name & title : Marketing Manager Contact information / address: Via 40 NO. 73-290 Local 14,Barranquilla,Colombia

ProjectNo:STS1508055 APPENDIX-PHOTOGRAPHSOFEUTCONSTRUCTIONALDETAILS Photo1 Photo2 ProjectNo:STS1508055 Photo3 Photo4 ProjectNo:STS1508055 Photo5 Photo6 ProjectNo:STS1508055 Photo7 Photo8

Label Mobile Phone Model name: QB1801 FCC ID: 2AFP4QB1801 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. label

ProjectNo:STS1508055 APPENDIX-PHOTOGRAPHSOFEUTCONSTRUCTIONALDETAILS Photo1 Photo2 GSMAntenna BTAntenna ProjectNo:STS1508055 Photo3 Photo4 ProjectNo:STS1508055 Photo5 Photo6 ProjectNo:STS1508055 Photo7 Photo8

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. 1/F., Building B, Zhuoke Science Park, No.190,Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] FCC SAR TEST REPORT Report No: STS1508055H01 Issued for JRG INVERSIONES SAS Vía 40 NO.73-290 Local 14,Barranquilla,Colombia Product Name: Mobile Phone Brand Name: QUICK Model No.: QB1801 Series Model: N/A FCC ID: 2AFP4QB1801 Test Standard: ANSI/IEEE Std. C95.1 FCC 47 CFR Part 2 ( 2.1093) IEEE 1528: 2013 Max. SAR (1g): Head:1.208 W/kg Body:1.299 W/kg S T L A B S Page 2 of 65 Report No.: STS1508055H01 Test Report Certification Applicant’s name ................. : JRG INVERSIONES SAS Address ................................. : Vía 40 NO.73-290 Local 14,Barranquilla,Colombia Manufacture's Name ............ : Shenzhen Hongkaijiawei Technology Co.,Ltd Address ................................. : Room 7C, Block A, Hongsong Building, Tairan Six Road, Chegongmiao, Futian District, Shenzhen, China Product description Product name ........................ : Mobile Phone Trademark ........................... : QUICK Model and/or type reference : QB1801 Serial Model： N/A Standards ............................. : ANSI/IEEE Std. C95.1-1992 FCC 47 CFR Part 2 ( 2.1093) IEEE 1528: 2013 The device was tested by Shenzhen STS Test Services Co., Ltd. in accordance with the measurement methods and procedures specified in KDB 865664 The test results in this report apply only to the tested sample of the stated device/equipment. Other similar device/equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Date of Test ........................................... : Date (s) of performance of tests ............. : 26 Aug. 2015 Date of Issue .......................................... : 28 Aug. 2015 Test Result.............................................. : Pass Testing Engineer : (Allen Chen) Technical Manager : (John Zou) Authorized Signatory : (Bovey Yang) Page 3 of 65 Report No.: STS1508055H01 TABLE OF CONTENS 1. General Information 4 1.1 EUT Description 4 1.2 Test Environment 5 1.3 Test Facility 5 2. Test Standards And Limits 6 3. SAR Measurement System 7 3.1 Definition Of Specific Absorption Rate (SAR) 7 3.2 SAR System 7 3.2.1 Probe 8 3.2.2 Phantom 9 3.2.3 Device Holder 9 4. Tissue Simulating Liquids 10 4.1 Simulating Liquids Parameter Check 10 5. SAR System Validation 11 5.1 Validation System 11 5.2 Validation Result 11 6. SAR Evaluation Procedures 12 7. EUT Test Position 13 7.1 Define Two Imaginary Lines On The Handset 13 8. Uncertainty 15 8.1 Measurement Uncertainty 15 8.2 System validation Uncertainty 17 9. Conducted Power Measurement 19 11. EUT And Test Setup Photo 22 11.1 EUT Photo 22 11.2 Setup Photo 25 12. SAR Result Summary 29 12.1 Head SAR 29 12.2 Body SAR And Hotspot 29 12.3 repeated SAR measurement 30 13. Equipment List 32 Appendix A. System Validation Plots 33 Appendix B. SAR Test Plots 41 Appendix C. Probe Calibration And Dipole Calibration Report 65 Page 4 of 65 Report No.: STS1508055H01 1. General Information 1.1 EUT Description Equipment Mobile Phone Brand Name QUICK Model No. QB1801 Serial Model N/A FCC ID 2AFP4QB1801 Model Difference N/A Adapter Input: AC100-240V, 0.5A, 50/60 Hz Output: DC 5V, 500mA Battery Rated Voltage: 3.7V Charge Limit: 4.2V Capacity: 600mAh Hardware Version S8 v3.1 Software Version S8_HXBC_S103_EHAS_WELCOME_V13_20150130.R.pac Frequency Range GSM 850: 824.2 ~ 848.8 MHz PCS1900: 1850.2 ~ 1909.8 MHz Bluetooth：2402~2480MHz Transmit Power(MAX): GSM 850: 31.91dBm GSM 1900: 31.25dBm Bluetooth: -5.605dBm Max. Reported SAR(1g): Head: GSM 850: 1.175 W/kg GSM 1900: 1.208 W/kg Body: GSM 850: 1.299 W/kg GSM 1900: 0.397 W/kg Operating Mode: GSM: GSM Voice, GPRS, EGPRS Class 12; Bluetooth: V2.1 + EDR (GFSK +π/4DQPSK+8DPSK) Antenna Specification: GSM: PIFA Antenna BT: Dipole Antenna SIM Card Support dual-SIM, dual standby, the multiple SIM card with two lines can not transmitting at the same time Hotspot Mode: Not Support DTM Mode: Not Support Page 5 of 65 Report No.: STS1508055H01 1.2 Test Environment Ambient conditions in the SAR laboratory: Items Required Actual Temperature (°C) 18-25 22~23 Humidity (%RH) 30-70 55~65 1.3 Test Facility Shenzhen STS Test Services Co., Ltd. Add. : 1/F, Building B, Zhuoke Science Park,No.190, Chongqing Road, Fuyong, Baoan District, Shenzhen, Guangdong, China CNAS Registration No.: L7649 FCC Registration No.: 842334; IC Registration No.: 12108A-1 Page 6 of 65 Report No.: STS1508055H01 2. Test Standards And Limits No. Identity Document Title 1 47 CFR Part 2 Frequency Allocations and Radio Treaty Matters; General Rules and Regulations 2 ANSI/IEEE Std. C95.1-1992 IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz 3 IEEE Std. 1528-2013 Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques 4 FCC KDB 447498 D01 v05r02 Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Policies 5 FCC KDB 865664 D01 v01r03 SAR Measurement 100 MHz to 6 GHz 6 FCC KDB 865664 D02 v01r01 RF Exposure Reporting This device belongs to portable device category because its radiating structure is allowed to be used within 20 centimeters of the body of the user. According to EN 50360 and 1999/519/EC the limit for General Population/Uncontrolled exposure should be applied for this device, it is 2.0 W/kg as averaged over any 10 gram of tissue. (A). Limits for Occupational/Controlled Exposure (W/kg) Whole-Body Partial-Body Hands, Wrists, Feet and Ankles 0.4 8.0 20.0 (B). Limits for General …

Text truncated - open the document above for the full version.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. 1/F., Building B, Zhuoke Science Park, No.190,Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No: STS1508055F01 Issued for JRG INVERSIONES SAS Via 40 NO. 73-290 Local 14,Barranquilla,Colombia Product Name: Mobile Phone Brand Name: QUICK Model No.: QB1801 Series Model: N/A FCC ID: 2AFP4QB1801 Test Standard: FCC Part 22H and 24E S T L A B S 2 of 70 Report No.: STS1508055F01 Testing Engineer : (Jin Ming) Technical Manager : (Vita Li) Authorized Signatory : (Bovey Yang) TEST RESULT CERTIFICATION Applicant’s name ................. : JRG INVERSIONES SAS Address ................................. : Via 40 NO. 73-290 Local 14,Barranquilla,Colombia Manufacture's Name............ : Shenzhen Hongkaijiawei Technology Co.,Ltd Address ................................. : Room 7C,Block A,Hongsong Building,Tairan Six Road, Chegongmiao, Futian District,Shenzhen,China Product name ........................ : Mobile Phone Brand name ......................... : QUICK Model and/or type reference .. : QB1801 Standards ............................. : FCC Part 22H and 24E Test procedure ............................ : TIA 603 C This device described above has been tested by STS and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document may be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ........................................... : Date of performance of tests .................. : 15 Aug. 2015 ~21 Aug. 2015 Date of Issue.......................................... : 24 Aug. 2015 Test Result ............................................. : Pass 3 of 70 Report No.: STS1508055F01 TABLE OF CONTENTS Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 6 1.2 MEASUREMENT UNCERTAINTY 6 2. GENERAL INFORMATION 7 2.1 PRODUCT DESCRIPTION 7 2.2 RELATED SUBMITTAL(S) / GRANT (S) 8 2.3 SPECIAL ACCESSORIES 8 2.4 EUT CONFIGURATION 8 2.5 EUT EXERCISE 8 2.6 CONFIGURATION OF EUT SYSTEM 8 2.7 MEASUREMENT INSTRUMENTS 9 3. DESCRIPTION OF TEST MODES 10 4. OUTPUT POWER 11 4.1 CONDUCTED OUTPUT POWER 11 4.2 PEAK-TO-AVERAGE RADIO (PAR) OF TRANSMITTER 14 4.3 RADIATED OUTPUT POWER 17 5. SPURIOUS EMISSION 20 5.1 SPURIOUS EMISSION 20 5.2 RADIATED SPURIOUS EMISSION 22 6. FREQUENCY STABILITY 26 6.1 MEASUREMENT METHOD 26 6.2 PROVISIONS APPLICABLE 27 6.3 MEASUREMENT RESULT 28 7. OCCUPIED BANDWIDTH 32 7.1 MEASUREMENT METHOD 32 7.2 PROVISIONS APPLICABLE 32 7.3 MEASUREMENT RESULT 32 8. EMISSION BANDWIDTH 34 8.1 MEASUREMENT METHOD 34 8.2 PROVISIONS APPLICABLE 34 8.3 MEASUREMENT RESULT 34 9. BAND EDGE 36 9.1 MEASUREMENT METHOD 36 4 of 70 Report No.: STS1508055F01 9.2 PROVISIONS APPLICABLE 36 9.3 MEASUREMENT RESULT 36 APPENDIX I 37 TEST PLOTS FOR CONDUCTED SPURIOUS EMISSION 37 APPENDIX II 52 TEST PLOTS FOR OCCUPIED BANDWIDTH (99%) 52 EMISSION BANDWIDTH (-26DBC) 52 APPENDIX III 64 TEST PLOTS FOR BAND EDGES 64 APPENDIX IV 70 PHOTOS OF TEST SETUP 70 5 of 70 Report No.: STS1508055F01 Revision History Rev. Issue Date Report NO. Effect Page Contents 00 24 Aug. 2015 STS1508055F01 ALL Initial Issue 6 of 70 Report No.: STS1508055F01 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: The radiated emission testing was performed according to the procedures of ansi C63.10: 2009; TIA 603 C and fcc cfr 47 rules of 2.1046, 2.1047, 2.1049, 2.1051, 2.1053, 2.1055, 2.1057 Item Number Item Description FCC Rules 1 Output Power Conducted output power 22.913(a) / 24.232 (b) Radiated output power 2 Spurious Emission Conducted spurious emission 2.1051 / 22.917 / 24.238 Radiated spurious emission 3 Frequency Stability 2.1055 /24.235 4 Occupied Bandwidth 2.1049 (h)(i) 5 Emission Bandwidth 22.917(b) / 24.238 (b) 6 Band Edge 22.917(b) / 24.238 (b) NOTE: (1)” N/A” denotes test is not applicable in this Test Report 1.1 TEST FACTORY Shenzhen STS Test Services Co., Ltd. Add. : 1/F., Building B, Zhuoke Science Park, No.190,Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China CNAS Registration No.: L7649; FCC Registration No.: 842334; IC Registration No.: 12108A-1 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission (9KHz-150KHz) ±2.88dB 2 Conducted Emission (150KHz-30MHz) ±2.67dB 3 RF power,conducted ±0.70dB 4 Spurious emissions,conducted ±1.19dB 5 All emissions,radiated(<1G) 30MHz-200MHz ±2.83dB 6 All emissions,radiated(<1G) 200MHz-1000MHz ±2.94dB 7 All emissions,radiated(>1G) ±3.03dB 8 Temperature ±0.5°C 9 Humidity ±2% 7 of 70 Report No.: STS1508055F01 2. GENERAL INFORMATION 2.1 PRODUCT DESCRIPTION A major technical description of EUT is described as following: Product Designation: Mobile Phone Hardware version: S8 v3.1 Software version: S8_HXBC_S103_EHAS_WELCOME_V13_20150130.R.pac FCC ID: 2AFP4QB1801 Frequency Bands: GSM 850 PCS 1900 (U.S. Bands) GSM 900 DCS 1800 (Non-U.S. Bands) U.S. Bands: UMTS FDD Band II UMTS FDD Band V Non-U.S. Bands: UMTS FDD Band I UMTS FDD Band VIII Max RF Output Power: GSM850:32.12dBm,GSM1900:31.59dBm Type of Emission: GSM(850):253KGXW: GSM(1900):256KGXW GPRS(850):247KGXW; GPRS(1900):257KGXW EDGE(850):256KG7W: EDGE(1900):254KG7W Description test modes (worst case) SIM 1 and SIM 2 is a chipset unit and tested as single chipset, SIM 1 is used to tested An…

Text truncated - open the document above for the full version.

PCE Setup photo PCEradiation L PCEradiation H
