2AFQD-SY4050-LMUHF Transceiver

SamYoungTech. co., Ltd.
UHF Transceiver - FCC ID 2AFQD-SY4050-LM - SamYoungTech. co., Ltd.
Click to zoom

Application Details

Equipment Class
TNF - Licensed Non-Broadcast Transmitter Held to Face
Date of Grant
Nov 08, 2015
Application Purpose
Original Equipment
Date of Application
Nov 08, 2015
Equipment Note
UHF Transceiver
Frequency Range
406.10000000 - 440.00000000
Company
SamYoungTech. co., Ltd.
Country
South Korea

Documents & Files

Select a file to view

Users Manual

↗

Attestation Statements

↗
↗

Cover Letter(s)

↗
↗
↗

External Photos

↗

ID Label/Location Info

↗
↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗

Test Setup Photos

↗
↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

1 Copyright ⓒ 2015 SAMYOUNG TECH.CO.,LTD SY4050-LM DMR/FM Terminal User Manual Date Prepared by Checked by Approved by 04-Mar-2015 SAMYOUNG TECH. CO.,LTD 110 Gumdan-ro, Seo-gu, Incheon 404-300 Korea TEL : +82-32-561-6700 FAX : +82-70-4694-9646 http:/ www.sytcl.co.kr 2 Copyright ⓒ 2015 SAMYOUNG TECH.CO.,LTD Revision History Revision Date Author Status/Comments 1.0 04-Mar-2015 Initial Release 1.1 01-June-2015 Minor update 1.2 17-June-2015 Add specification CONTENTS ============================================================== 1. Radio Overview ............................................................................................................ 3 2. Status Indication ............................................................................................................ 4 3. Menu Navigation ......................................................................................................... 6 4. Basic Operation ............................................................................................................ 7 5. Call Services ................................................................................................................... 7 6. Features and Operations ............................................................................................... 9 ============================================================== 3 Copyright ⓒ 2015 SAMYOUNG TECH.CO.,LTD 1. Radio Overview ⑯ ⑰⑱ No. Part Name No. Part Name No.Part Name No. Part Name 1 PTT Key 6 Speaker 11Back Key 16 Belt Clip 2 Soft Key-1 7 LCD 12 Microphone 17 Battery 3 Soft Key-2 8 Menu/Enter/OK Key 13 Power/Volume Control Knob 18 Battery Latch 4 Antenna 9 Down Key 14 Emergency Alarm Key 5 LED Indicator 10 Up Key 15 Accessory Jack ① ⑤ ② ③ ④ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ ⑮ ⑯ ⑰ ⑱ 4 Copyright ⓒ 2015 SAMYOUNG TECH.CO.,LTD 2. Status Indication 2.1 LED Indicator The top LED indicator will help you easily identify the current radio status. LED Indicator Radio Status Blinks YELLOW Receiving, Carrier detected Glows YELLOW Receiving, Call match Blinks ORANGE Channel scanning Glows RED Transmitting 5 Copyright ⓒ 2015 SAMYOUNG TECH.CO.,LTD 2.2 LCD Icons Icon Name Icon Radio Status RSSI The number of bars represents the radio signal strength Tx Power Level Low power level of the current channel High power level of the current channel Operation Mode Direct Mode(Talkaround) operation: Radios communicates with each other directly Repeater Mode operation: Radios communicates with each other via a repeater Scan Radio is under scanning channels Radio detects activity on a channel Unread Message Indicate the unread incoming message in Inbox Secure Privacy feature is enabled Battery The number of bars represents the charge remaining in battery Zone Indicates the current zone number Channel Indicates the current channel number of Dual-mode  Digital DMR channel is displayed with D(ex, D009)  Analog channel is displayed with A(ex, A001)  Digital and Analog mixed channel is displayed with M(ex, M003) Call Indicates Outgoing Individual Call Indicates Incoming Individual Call Indicates Outgoing Group Call Indicates Incoming Group Call Indicates Outgoing All Call Indicates Incoming All Call 6 Copyright ⓒ 2015 SAMYOUNG TECH.CO.,LTD 3. Menu Navigation The following menu list shows all the menus of the radio. To select and confirm the options shown in the menu, press Menu/Enter key and then press Up or Down key to select your needed option, finally press Menu/Enter key. To move back the path of menu, press Back key 1 st 2 nd 3 rd Remarks Contacts List of Contacts Max 32 Messages Quick Text Message list in Quick Text Max 10 Inbox Message list in Inbox Max 10 Delete All Outbox Message list in Outbox Max 10 Delete All Call Log Outgoing Call logs in Outgoing Max 10 Delete All Incoming Call logs in Incoming Max 10 Delete All Scan Scan on/off On Off Scan List Scan list Max 10 Zone List of Zones Max 32 Settings Radio settings Power Level High/Low SQ Level Normal/Open/Tight Keypad Lock On/Off Backlight Off/On/Timed LED Off/On Tone Off/On Language English/Chinese Radio Info Radio Id Serial Number Model Name Model Number Freq Range SW Ver BB Ver Last Pro Date 7 Copyright ⓒ 2015 SAMYOUNG TECH.CO.,LTD 4. Basic Operation 4.1 Power On/Off Rotate the Radio On-Off/Volume Control knob clockwise until a click is heard to turn on the radio. The LED lights up solid red and the beeper indication is played To turn off the radio, rotate the same knob counterclockwise until a click is heard 4.2 Adjust Volume After turning on the radio, rotate the Radio On-Off/Volume Control knob clockwise to increase the volume, or counterclockwise to decrease the volume. 4.3 Selecting a zone A zone is a group of channels. User can include a group of channels into a zone. The radio supports 32 zones, each of which consists of up to 16 channels. User can select a zone via one of the following ways;  Via Menu: Go to Menu > Zone, press Up/Down key to select an appropriate zone, and then press the Menu/OK key to confirm the selection  Via Programmable key: User can toggle the appropriate zone by pressing the programmed Zone key preset by your dealer 4.4 Selecting a Channel Once the zone is selected, press Up/Down key to select a desired channel. Note: “A” character prior on channel number indicates a conventional Analog channel and “D” character indicates a conventional Digital channel 5. Call Services After the radio is powered on, you can make and receive calls. To ensure optimal volume of the receiving radio, keep the microphone about 2.5 to 5 centimeters away from your mouth when transmitting.  Individual call It is a voice call between an individual user and another individual user. 8 Copyright ⓒ 2015 SAMYOUNG TECH.CO.,LTD  Group call It is a voice call between one individual user and a predefined group of users. All parties in the group can communicate with each other.  All call It is a one-way voice call from any user to all users on a channel. User can initiate an individu…

Text truncated - open the document above for the full version.

Attestation Statements

Office of Engineering and Technology Laboratory Division Equipment Authorization Branch Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Product: UHF Transceiver Applicant: SamYoungTech. co., Ltd. Model: SY4050-LM Address: 110, Geomdan-ro, Seo-gu, Incheon, South Korea FCC ID: 2AFQD-SY4050-LM SUBJECT: Verification for Transmitter with FCC ID: 2AFQD-SY4050-LM Dear Sir or Madam: We, the undersigned, hereby attest to the fact that we has been apply the verification procedure to the class B, according to the Other Class B digital devices & Peripherals and receiver portion of this filing. Sincerely, Date: 2015. 11. 02 Choi sung-jun / Director

Attestation Statements

Office of Engineering and Technology Laboratory Division Equipment Authorization Branch Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Product: UHF Transceiver Applicant: SamYoungTech. co., Ltd. Model: SY4050-LM Address: 110, Geomdan-ro, Seo-gu, Incheon, South Korea FCC ID: 2AFQD-SY4050-LM SUBJECT: Application for Certification of Transmitter with FCC ID: 2AFQD-SY4050-LM Dear Sir or Madam: SamYoungTech. co., Ltd. herein submits application for certification of the subject transmitter. This transmitter is intended for use in a Mobile Radio environment and is capable of operating at the frequency range and power listed below: Frequency 400 - 440 ㎒ Rated Power 2 - 5 W FCC Rule Parts 90 The subject transmitter complies with Section 90.203 of the Rules in that the operator cannot directly program transmit frequencies using the unit's normally accessible external controls. Enclosed is a complete Certification Application. Please contact me if you require any additional information. Sincerely, Date: 2015. 09. 30 Choi sung-jun / Director

Cover Letter(s)

SUBJECT: Product Certification Representative Authorization Letter Date: 2015. 11. 06 To: Kostec Co., Ltd. 28(175-20,Annyeong-dong) 406-gil sejaro, Hwaseong-si Gyeonggi-do, Korea Dear Sir or Madam: We, SamYoungTech. co., Ltd., the undersigned, hereby authorize Mi-young,Lee in Kostec Co., Ltd to act on our behalf, as our agent, in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by Mi-young,Lee in Kostec Co., Ltd within the scope of this authorization shall have the same effects as our own. We, SamYoungTech. co., Ltd. , the undersigned, hereby authorize Kostec Co., Ltd. to act as a agent for certifying for the following project(s): Product: UHF Transceiver Model: SY4050-LM FCC ID: 2AFQD-SY4050-LM Sincerely, Client’s name / title : Choi sung-jun / Director Address: 110, Geomdan-ro, Seo-gu, Incheon, South Korea

Cover Letter(s)

Office of Engineering and Technology Laboratory Division Equipment Authorization Branch Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Product: UHF Transceiver Applicant: SamYoungTech. co., Ltd. Model: SY4050-LM Address: 110, Geomdan-ro, Seo-gu, Incheon, South Korea FCC ID: 2AFQD-SY4050-LM SUBJECT: Extended Frequencies Justification of Transmitter with FCC ID: 2AFQD-SY4050-LM Dear Sir or Madam: This transmitter was design to operate in the frequency range of 400-406MHz, 406.1-440MHz. To aid equipment authorization in other countries that accept the United States FCC Grant for Certification, SamYoungTech. co., Ltd. is requesting that the FCC list the above frequency/frequencies under FCC Rule Part 90 on the Grant. For the FCC’s Rule Part 90 applications, this radio is used in systems by Federal and Public Safety agencies including Police, Fire, and Emergency Medical Services, etc. as indicated in the table below. Equipment programming is the responsibility of Authorized Service Personnel. Also, the radio complies with 47 CFR Part 90.203(e), in that the operator cannot directly program the transmit frequencies using the normally accessible external controls. Per the FCC’s KDB634817 guidance, as an alternative to listing the exact frequencies, we acknowledge that it’s a violation of the FCC Rules if this device operates on unauthorized frequencies. Frequency Range (MHz) Part 90 Federal Emission Designator 400 - 406 √ 11K0F3E 7K70F1D 7K70F1E 406.1 - 440 √ Please contact us if you have any additional information. Sincerely, Date: 2015. 11. 06 Choi sung-jun / Director

Cover Letter(s)

Office of Engineering and Technology Laboratory Division Equipment Authorization Branch Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Confidentiality Request regarding application for certification of FCC ID: 2AFQD-SY4050-LM Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type Block diagram Schematic diagram Part List Operation description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 and 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Date: 2015. 09. 30 Choi sung-jun / Director

External Photos

Head office & Test Lab: 28(175-20,Annyeong-dong) 406-gil sejaro, Hwaseong-si Gyeonggi-do, Korea Tel: +82-31-222-4251 / Fax: +82-31-222-4252 Report No: KST-FCR-150003 Page: 1 / 6 Appendix 2. Photographs of EUT [External View] [Front] [Rear] Head office & Test Lab: 28(175-20,Annyeong-dong) 406-gil sejaro, Hwaseong-si Gyeonggi-do, Korea Tel: +82-31-222-4251 / Fax: +82-31-222-4252 Report No: KST-FCR-150003 Page: 2 / 6 [ Right ] [ Left View ] Head office & Test Lab: 28(175-20,Annyeong-dong) 406-gil sejaro, Hwaseong-si Gyeonggi-do, Korea Tel: +82-31-222-4251 / Fax: +82-31-222-4252 Report No: KST-FCR-150003 Page: 3 / 6 [ Top ] [ Bottom ] Head office & Test Lab: 28(175-20,Annyeong-dong) 406-gil sejaro, Hwaseong-si Gyeonggi-do, Korea Tel: +82-31-222-4251 / Fax: +82-31-222-4252 Report No: KST-FCR-150003 Page: 4 / 6 [Antenna (HW-423W-CT405)] [Antenna (HW-423H-CT405)] Head office & Test Lab: 28(175-20,Annyeong-dong) 406-gil sejaro, Hwaseong-si Gyeonggi-do, Korea Tel: +82-31-222-4251 / Fax: +82-31-222-4252 Report No: KST-FCR-150003 Page: 5 / 6 [Belt Clip] [Ear-mic set(WEP-100)] Head office & Test Lab: 28(175-20,Annyeong-dong) 406-gil sejaro, Hwaseong-si Gyeonggi-do, Korea Tel: +82-31-222-4251 / Fax: +82-31-222-4252 Report No: KST-FCR-150003 Page: 6 / 6 [Charger Front] [Charger Rear]

ID Label/Location Info

Head office & Test Lab: 180-254, Annyeong-dong, Hwaseong-si, Gyeonggi-do, South korea 445-380 Tel: +82-31-222-4251 / Fax: +82-31-222-4252 Report No: KST-FCR-150003 Page: 1 / 1 Appendix 4. Sample Label & Location Label Information The following is a sample copy of the label that will be placed on Bottom side of the product. The FCC ID is marked in the product label with model No. and below information is visible printed on the label. Label location The label shown above shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase. The label is located here.

ID Label/Location Info

Office of Engineering and Technology Laboratory Division Equipment Authorization Branch Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Product: UHF Transceiver Applicant: SamYoungTech. co., Ltd. Model: SY4050-LM Address: 110, Geomdan-ro, Seo-gu, Incheon, South Korea FCC ID: 2AFQD-SY4050-LM SUBJECT: Label Statement Dear Sir or Madam: We hereby provide the label statement letter for the above-mentioned device by a new label statement policy of FCC Rule Part 2.925. The label statement is as follows: The FCC ID label is located in the battery compartment. While the battery cover is installed when the unit is shipped from the factory, the battery is never installed prior to sale, so the user must remove the cover in order to install the battery and operate the device. At this time the FCC ID is readily visible to the user. The label is permanently attached by acrylic glue and not easily removed from the device. This statement could not be included in the label. So we inform you of it through this letter. Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely, Date: 2015. 11. 02 Choi sung-jun / Director

Internal Photos

Head office & Test Lab: 28(175-20,Annyeong-dong) 406-gil sejaro, Hwaseong-si Gyeonggi-do, Korea Tel: +82-31-222-4251 / Fax: +82-31-222-4252 Report No: KST-FCR-150003 Page: 1 / 8 Appendix 3. Photographs of EUT [Internal View] [ Inside View ] Head office & Test Lab: 28(175-20,Annyeong-dong) 406-gil sejaro, Hwaseong-si Gyeonggi-do, Korea Tel: +82-31-222-4251 / Fax: +82-31-222-4252 Report No: KST-FCR-150003 Page: 2 / 8 [Main board Front] Head office & Test Lab: 28(175-20,Annyeong-dong) 406-gil sejaro, Hwaseong-si Gyeonggi-do, Korea Tel: +82-31-222-4251 / Fax: +82-31-222-4252 Report No: KST-FCR-150003 Page: 3 / 8 [Main board Rear] Head office & Test Lab: 28(175-20,Annyeong-dong) 406-gil sejaro, Hwaseong-si Gyeonggi-do, Korea Tel: +82-31-222-4251 / Fax: +82-31-222-4252 Report No: KST-FCR-150003 Page: 4 / 8 [Main board Rear without shield] Head office & Test Lab: 28(175-20,Annyeong-dong) 406-gil sejaro, Hwaseong-si Gyeonggi-do, Korea Tel: +82-31-222-4251 / Fax: +82-31-222-4252 Report No: KST-FCR-150003 Page: 5 / 8 [Sub board Front] Head office & Test Lab: 28(175-20,Annyeong-dong) 406-gil sejaro, Hwaseong-si Gyeonggi-do, Korea Tel: +82-31-222-4251 / Fax: +82-31-222-4252 Report No: KST-FCR-150003 Page: 6 / 8 [Sub board Rear] Head office & Test Lab: 28(175-20,Annyeong-dong) 406-gil sejaro, Hwaseong-si Gyeonggi-do, Korea Tel: +82-31-222-4251 / Fax: +82-31-222-4252 Report No: KST-FCR-150003 Page: 7 / 8 [Charger board Front] Head office & Test Lab: 28(175-20,Annyeong-dong) 406-gil sejaro, Hwaseong-si Gyeonggi-do, Korea Tel: +82-31-222-4251 / Fax: +82-31-222-4252 Report No: KST-FCR-150003 Page: 8 / 8 [Charger board Rear]

RF Exposure Info

Head office & Test Lab: 28(175-20,Annyeong-dong) 406-gil sejaro, Hwaseong-si Gyeonggi-do, Korea Tel: +82-31-222-4251 / Fax: +82-31-222-4252 Report No: KST-FCS-150001 Page: 1 / 76 KST-FCS-SRS-Rev.0.1 This report shall not be reproduced except in full without the written approval of KOSTEC Co., Ltd. FCC SAR TEST REPORT Report No: KST-FCS-150001 Applicant : SamYoungTech. co., Ltd. Manufacturer : SamYoungTech. co., Ltd. Equipment : UHF Transceiver Brand Name : - Model Name : SY4050-LM Standard : FCC 47 CFR Parts 1 & 2 KDB 447498 D01 v05r02 KDB 865664 D01 v01r04 KDB 643646 D01 v01r02 Test Date(s) : 2015. 09. 30 Issue Date : 2015. 10. 01 Test Result : Compliance Note : - Supplementary Information The measurements shown in this test report were found to be in accordance with the requirements given in each KDB Guidance Publications and Rule References and in accordance with the procedure given in standard FCC KDB 865664. The test results in this report apply exclusively to tested model / sample. Without written approval of KOSTEC Co., Ltd., the test report shall not be reproduced except in full. Tested by Mi Young, Lee / Engineer Approved by Gyeong Hyeon, Park / Manager Signature Signature Head office & Test Lab: 28(175-20,Annyeong-dong) 406-gil sejaro, Hwaseong-si Gyeonggi-do, Korea Tel: +82-31-222-4251 / Fax: +82-31-222-4252 Report No: KST-FCS-150001 Page: 2 / 76 KST-FCS-SRS-Rev.0.1 This report shall not be reproduced except in full without the written approval of KOSTEC Co., Ltd. Table of Contents 1. Statement of Compliance .................................................................................................. 3 1-1 Test Method List ...................................................................................................................... 3 2. Administration Data ........................................................................................................... 4 2.1 Test Laboratory ........................................................................................................................... 4 2.2 Location ...................................................................................................................................... 4 2.3 Applicant ..................................................................................................................................... 4 2.4 Manufacturer .............................................................................................................................. 4 2.5 Application Details ...................................................................................................................... 4 3. GENERAL INFORMATION ................................................................................................. 6 3.1 Description of DUT ..................................................................................................................... 6 3.2 Photographs of EUT ................................................................................................................... 8 3.3 Accessories .............................................................................................................................. 11 3.4 Test Condition ........................................................................................................................... 13 3.5 Requirements for compliance testing defined by FCC ............................................................. 13 4. Specific Absorption Rate (SAR) ..................................................................................... 14 4.1 Introduction ............................................................................................................................... 14 4.2 SAR Definition .......................................................................................................................... 14 4.3 SAR Measurement Procedure ................................................................................................. 14 5. SAR Measurement System ............................................................................................. 15 5.1 E-field Probe ............................................................................................................................. 16 5.2 Device Positioner ..................................................................................................................... 17 5.3 6 Axis Articulated Robot ALS-F3 .............................................................................................. 18 5.4 SAM Phantoms......................................................................................................................... 19 5.5 Flat Phantoms .......................................................................................................................... 20 5.6 DAQ-PAQ (Analog to Digital Electronics) ................................................................................. 21 5.7 Validation Dipoles ..................................................................................................................... 22 5.8 Test Equipment List .................................................................................................................. 23 6. Measurement Results ...................................................................................................... 24 6.1 Tissue Simulating Liquids ......................................................................................................... 24 6.2 System Verification ................................................................................................................... 27 6.3 DUT Testing Position ................................................................................................................ 29 6.4 SAR measurement procedure .................................................................................................. 29 6.5 SAR Exposure Limits .....................…

Text truncated - open the document above for the full version.

Test Report

Head office & Test Lab: 28(175-20,Annyeong-dong) 406-gil sejaro, Hwaseong-si Gyeonggi-do, Korea Tel: +82-31-222-4251 / Fax: +82-31-222-4252 Report No: KST-FCR-150003 Page: 1 / 39 KST-FCR-RFS-Rev.0.2 This report shall not be reproduced except in full without the written approval of KOSTEC Co., Ltd. TEST REPORT Report No: KST-FCR-150003 Applicant Name SamYoungTech. co., Ltd. Address 110, Geomdan-ro, Seo-gu, Incheon, South Korea Manufacturer Name SamYoungTech. co., Ltd. Address 110, Geomdan-ro, Seo-gu, Incheon, South Korea Equipment Name UHF Transceiver Model No SY4050-LM Brand None FCC ID 2AFQD-SY4050-LM Test Standard FCC CFR 47, Part 90 ANSI/TIA-603-D-2010 Received Date 2015. 08. 19 Test Date(s) 2015. 09. 23 - 2015. 09. 25 Issue Date 2015. 09. 30 Test Result Compliance Note - Supplementary Information The device bearing the brand name and FCC ID specified above has been shown to comply with the applicable technical standards as indicated in the measurement report and was tested in accordance with measurement procedures specified in ANSI/TIA-603-D-2010. We attest to the accuracy of data and all measurements reported herein were performed by KOSTEC Co., Ltd. and were made under Chief Engineer’s supervision. We assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Tested by Mi Young, Lee Approved by Gyeong Hyeon, Park Signature Signature Head office & Test Lab: 28(175-20,Annyeong-dong) 406-gil sejaro, Hwaseong-si Gyeonggi-do, Korea Tel: +82-31-222-4251 / Fax: +82-31-222-4252 Report No: KST-FCR-150003 Page: 2 / 39 KST-FCR-RFS-Rev.0.2 This report shall not be reproduced except in full without the written approval of KOSTEC Co., Ltd. Table of Contents 1. GENERAL INFORMATION .............................................................................................................. 4 1.1 Test Facility ............................................................................................................................................... 4 1.2 Location .................................................................................................................................................... 4 2. EQUIPMENT DESCRIPTION ........................................................................................................... 5 3. SYSTEM CONFIGURATION FOR TEST ......................................................................................... 6 3.1 Characteristics of equipment .................................................................................................................... 6 3.2 Used peripherals list ................................................................................................................................. 6 3.3 Product Modification ................................................................................................................................. 6 3.4 Operating Mode ........................................................................................................................................ 6 3.5 Test Setup of EUT .................................................................................................................................... 6 3.6 Table for Carrier Frequencies ................................................................................................................... 7 3.7 Modulation ................................................................................................................................................ 7 3.8 Used Test Equipment List ......................................................................................................................... 8 4. SUMMARY TEST RESULTS .......................................................................................................... 10 5. MEASUREMENT RESULTS .......................................................................................................... 11 5.1 RF Output Power .................................................................................................................................... 11 5.2 Modulation Characteristecs .................................................................................................................... 12 5.3 Occupied Bandwidth & 26 ㏈ Bandwidth .............................................................................................. 15 5.4 Emission Mask ....................................................................................................................................... 24 5.5 Spurious Emission On Antenna Port ...................................................................................................... 30 5.6 Transmitter Radiated Unwanted Emissions ........................................................................................... 33 5.7 Frequency Stability ................................................................................................................................. 36 5.8 Transmitter Frequency Behavior ............................................................................................................ 38 Head office & Test Lab: 28(175-20,Annyeong-dong) 406-gil sejaro, Hwaseong-si Gyeonggi-do, Korea Tel: +82-31-222-4251 / Fax: +82-31-222-4252 Report No: KST-FCR-150003 Page: 3 / 39 KST-FCR-RFS-Rev.0.2 This report shall not be reproduced except in full without the written approval of KOSTEC Co., Ltd. Revision History of test report Rev. Revisions Effect page Reviewed Date - Initial issue All Gyeong Hyeon, Park 2015. 09. 30 1 Retest low frequency All Gyeong Hyeon, Park 2015. 11. 02 2 Revised section 5.2.1 and 5.3.6 12, 16 - 23 Gyeong Hyeon, Park 2015. 11. 06 3 Correct the value of emission designator for digital. 5,7 Gyeong Hyeon, Park 2015. 11. 09 Head office & Test Lab: 28(175-20,Annyeong-dong) 406-gil sejaro, Hwaseong-si Gyeonggi-do, Korea Tel: +82-31-222-4251 / Fax: +82-31-222-4252 Report No: KST-FCR-150003 Pa…

Text truncated - open the document above for the full version.

Test Setup Photos

Head office & Test Lab: 28(175-20,Annyeong-dong) 406-gil sejaro, Hwaseong-si Gyeonggi-do, Korea Tel: +82-31-222-4251 / Fax: +82-31-222-4252 Page: 1 / 1 Appendix 1-1. Photographs of test setup(SAR) Face held configration Body worn configuration 25 mm Separation distance

Test Setup Photos

Head office & Test Lab: 28(175-20,Annyeong-dong) 406-gil sejaro, Hwaseong-si Gyeonggi-do, Korea Tel: +82-31-222-4251 / Fax: +82-31-222-4252 Report No: KST-FCR-150003 Page: 1 / 2 Appendix 1. Photographs of test setup Radiated RF measurement ( Below 30 ㎒) Radiated RF measurement (30 ㎒ - 1 ㎓) Head office & Test Lab: 28(175-20,Annyeong-dong) 406-gil sejaro, Hwaseong-si Gyeonggi-do, Korea Tel: +82-31-222-4251 / Fax: +82-31-222-4252 Report No: KST-FCR-150003 Page: 2 / 2 Radiated RF measurement (Above 1 ㎓) BLANK

Contact Information

Applicant

sung-jun Choi(Director)
[email protected]82-32-561-6700Fax: 82-70-4694-9646

Test Firm

KOSTEC Co., LtdLee Chang-Ho
[email protected]82-31-222-4251Fax: 82-31-222-4252

Technical Specifications

#Rule PartsFrequency RangePower OutputEmissionTolerance
129406.1 MHz - 440 MHz5 W7K95F1E2.5 ppm
Confidentiality
Long Term
Grant Notes
Power listed is conducted. This device has high power level and low power level. This device contains functions that are not operational in U.S Territories except as noted in the filing. This filing is only applicable for US operations. This device must be restricted to work related operations in an Occupational/Controlled RF exposure Environment, not exceeding a maximum transmitting duty factor of 50% for analog voice, maximum transmitting duty factor of 100% for digital voice and data. All qualified end-users of this device must have the knowledge to control their exposure conditions and/or duration to comply with the Occupational/Controlled MPE limit and requirements. A label, as described in this filing, must be displayed on the device to direct users to specific training information for meeting Occupational Exposure Requirements. SAR compliance for body-worn operating configurations is limited to the specific belt-clip/holster/accessories tested for this filing. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR levels are: Head: 1.73 W/kg for 50% Duty Cycle; Body: 2.07 W/kg for 50% Duty Cycle. The highest reported SAR levels are: Head: 6.06 W/kg for 100% Duty Cycle; Body: 6.35W/kg for 100% Duty Cycle.
