2AFRH-TINTSmart LED light

Welcome to use our Tint light ---Bluetooth control Led bulb. Please use Android 4.3 (or above) and iPhone 4s (or newer) smart phone Scan the QR code below for free download All devices should enable Bluetooth 4.0. Quick Guide: 1.Turn on bulbs. 2.Launch the ‘Tintlink ’APP. 3.Click the bulb icon to control the bulbs. Function 1. Music Click “Music”, then bulb will change colors according to the music rhythm in phone. 2. Auto Link When turn on the new bulb, go to “HOME” and click the “Auto Link” icon to find the new bulb. 3. Rename Long time press the bulb icon. There will come out a dialog where can type its name. 4. Group Control Click ‘Add group’ to create a group, you may named it as living room, bedroom... Long time press the bulb icon, then put bulb into the created group. Long time press the ‘group’ icon can delete it. 5. Dimmable Color temperature and brightness can be adjust by move the dot on the line. Or press the +/- 7. Timer Set time: press the button “Timer”, enter the setting interface, set the time, click ok. Cancel time: press the button “Timer”, enter the setting interface, set the time to zero. 8. Wake up Set time: press the icon “Wake up “, enter the setting interface, set the time, click ok. Cancel time: press the icon “Wake up”, enter the setting interface, set the time to zero. 9. Sleep Press the icon “Sleep” , bulb will flash in blue once, then lamp will turn off in 20 minutes gradually . 10. RGB Mode Press the M+ , the color will change as below, if M- , then change in opposite direction A. Red B. Green C. Blue D. Yellow E. Pink F. Light blue G. White(rgb mixed) H. R-G-B changing I. 7 colors (from A to G) changing J. R-G-B gradually changing K. 7 colors (from A to G) gradually changing L. Blue-pink-red-yellow-green-light blue Warm Tips 1. Used in door. 2. Work Temperature: -20°C-60°C. 3. Don't touch bulbs when last hours working. 4. keep away from fire, liquid and explosion hazard. Tint-light User Manual 6. Color changing Click “RGB” and then touch the color ring ON/OFF Color temperature down 1 32 54 12 Color temperature up 3 4 5 Brightness down Brightness up TINT01 TINT02 TINT03TINT04TINT05TINT06TINT07 FCCSTATEMENT：This equipment has been tested and found to comply with the limitsfor a Class B digital device, pursuant to Part 15 of the FCC Rules. Theselimits are designed to provide reasonable protection against harmfulinterference in a residential installation. This equipment generates uses andcan radiate radio frequency energy and, if not installed and used in accordancewith the instructions, may cause harmful interference to radio communications.However, there is no guarantee that interference will not occur in a particularinstallation. If this equipment does cause harmful interference to radio ortelevision reception, which can be determined by turning the equipment off andon, the user is encouraged to try to correct the interference by one or more ofthe following measures:-- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment andreceiver. -- Connect the equipment into an outlet on a circuit differentfrom that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician forhelp. Changes or modifications not expressly approved by the partyresponsible for compliance could void the user's authority TINT08 to operate theequipment. This device complies withpart 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device mustaccept any interference received, including interference that may causeundesired operation. ICSTATEMENT：This device complies with IndustryCanadalicence-exempt RSS standard(s). Operation is subject to thefollowing two conditions: (1) this device may not cause interference, and (2)this device must accept any interference, including interference that may causeundesired operation of the device.Le présent appareil est conforme aux CNR d'IndustrieCanadaapplicables aux appareils radio exempts de licence. L'exploitation estautorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produirede brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillageradioélectrique subi, même si le brouillage est susceptible d'en compromettrele fonctionnement.

Differences Declaration To whom concern, We company Shenzhen Haipai Techanology Co.,Ltd hereby declares: The product model(s) Tint C4 is identical in the same PCB layout, interior structure and electrical circuits with the model Tint K4 which tested in Global Unit Technology Co., Ltd., the only differences are the model name for commercial purpose. The product model(s) Tint C4 is identical in components and electrical circuits with the model Tint K4 , the only differences are the model name and PCB layout .

T int K4: T int C4:

MADE IN CHINA LED LAMP 100-240VAC, 50/60Hz,70mA,4W Input ratings: CAUTION: Risk of Electric Shock DOUBLE INSULATED USE IN DRY LOCATION ONLY E468490 MMYYYY Model:Tint K4 Model:Tint K4 FCC ID:2AFRH-TINT ,HPF MADE IN CHINA LED LAMP 100-240VAC, 50/60Hz,70mA,4W Input ratings: CAUTION: Risk of Electric Shock DOUBLE INSULATED USE IN DRY LOCATION ONLY E468490 MMYYYY Model:Tint C4 Model:Tint C4 FCC ID:2AFRH-TINT ,HPF

Label Location Tint K4: Tint C4:

T int K4: T int C4:

FCC ID: 2AFRH-TINT According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation          [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,     !-" #$%  &  ! -g extremity SAR, where --f(GHz) is the RF channel transmit frequency in GHz --Power and distance are rounded to the nearest mW and mm before calculation --The result is rounded to one decimal place for comparison eirp = pt x gt = (EXd) 2 /30 where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, ---10 ((dBuV/m)/20) /10 6 d = measurement distance in meters (m) ---3m So pt = (EXd) 2 /30 x gt Field strength = 91.27dBuV/m @3m Ant gain =0dBi, so Ant numeric gain= 1 So pt={ [10 (91.27/20) /10 6 x 3] 2 /30x1.58 }x1000 mW = 0.402mW So (0.402mW /5mm)x 2.480 = 0.127<3 Then SAR evaluation is not required

Global United Technology Services Co., Ltd. Report No.: GTSE15080159701 FCC REPORT Applicant: Shenzhen Haipai Techanology Co.,Ltd Address of Applicant: Rm. 1,2,4, 10/F, Blk. A, Kelu Bldg., Baoshen Rd., Nanshan Dist., Shenzhen, China Equipment Under Test (EUT) Product Name:Smart LED light Model No.:Tint K4, Tint C4 FCC ID: 2AFRH-TINT Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.249:2014 Date of sample receipt: August 24, 2015 Date of Test: August 25-28, 2015 Date of report issued: August 31, 2015 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Authorized Signature: Robinson Lo Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the GTS product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of GTS or testing done by GTS in connection with, distribution or use of the product described in this report must be approved by GTS in writing. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. Robinsono Lo Report No.: GTSE15080159701 2Version Version No.DateDescription 00August 31, 2015Original Prepared By: Date: August 31, 2015 Project Engineer Check By:Date: August 31, 2015 Reviewer Global United Technology Services Co., Ltd.Project No.: GTSE150801597RF Room 301-309, 3th Floor, Block A, Huafeng Jinyuan Business Building, No. 300 Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, China Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960Page 2 of 33 Tested By: Report No.: GTSE15080159701 3Contents Page 1 COVER PAGE............................................................................................................................................ 1 2 VERSION .................................................................................................................................................. 2 3 CONTENTS .............................................................................................................................................. 3 4 TEST SUMMARY ..................................................................................................................................... 4 5 GENERAL INFORMATION ...................................................................................................................... 5 5.1 CLIENT INFORMATION......................................................................................................................... 5 5.2 GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.3 TEST MODE........................................................................................................................................ 7 5.4 DESCRIPTION OF SUPPORT UNITS....................................................................................................... 7 5.5 TEST FACILITY.................................................................................................................................... 7 5.6 TEST LOCATION................................................................................................................................. 7 5.7 DESCRIPTION OF SUPPORT UNITS....................................................................................................... 7 5.8 OTHER INFORMATION REQUESTED BY THE CUSTOMER......................................................................... 7 6 TEST INSTRUMENTS LIST ..................................................................................................................... 8 7 TEST RESULTS AND MEASUREMENT DATA...................................................................................... 9 7.1 ANTENNA REQUIREMENT..................................................................................................................... 9 7.2 CONDUCTED EMISSIONS................................................................................................................... 10 7.3 RADIATED EMISSION METHOD........................................................................................................... 13 7.3.1 Field Strength of The Fundamental Signal ................................................................................ 15 7.3.2 Spurious emissions.................................................................................................................... 16 7.3.3 Bandedge emissions.................................................................................................................. 20 7.4 20DBOCCUPY BANDWIDTH.............................................................................................................. 21 8 TEST SETUP PHOTO ............................................................................................................................ 23 9 EUT CONSTRUCTIONAL DETAILS .....................................................................................................25 Global United Technology Services Co., Ltd.Project No.: GTSE150801597RF Room 301-309, 3th Floor, Block A, Huafeng Jinyuan Business Building, No. 300 Laodong…
