2AFRO-TINTAGWPCTintag (charger)

SCS-F18:ProjectandProductCertificationRepresentativeAuthorizationLetterPage1of2Rev5.0 775MontagueExpressway Milpitas,CA95035 Tel:408-526-1188 Fax:408-526-1088 Email:[email protected] ProjectandProduct CertificationRepresentative AuthorizationLetter ReasonforAmendment(current/obsolete) RevisionHistory ApprovedDate FromTo InitialRelease(obsolete)1.01.0Nov-14-2006 Revisedwording(obsolete)1.02.0Sept–25-2007 Updatedcompanytemplate(obsolete)2.03.0Jan-31-2012 Updatedletterinformation(obsolete)3.04.0May-23-2014 AddedFCCIDfield(current)4.05.0Sept162014 SCS-F18:ProjectandProductCertificationRepresentativeAuthorizationLetterPage2of2Rev5.0 (TintagElectronics) (CurrentDate)Sep29,2015 To:SIEMIC,INC. 775MontagueExpressway, Milpitas,CA95035 USA DearSir/Madam, Re:ProductCertificationRepresentativeAuthorizationLetter We,TintagElectronicsherebyauthorizeSIEMIC,Inc.toactasaCertificationBodyforcertifying forthefollowingproject(s): (Productdescription,modelname)：Tintag(charger)/Tintag FCCID:2AFRO-TINTAGWPC Sincerely, Client’ssignature: Client’sname/title：AlexandruChis/Manager Contactinformation/address：+40748227768

SCS-F19:ConfidentialityRequestLetterPage 1 of 2 Rev4.0 775MontagueExpressway Milpitas,CA95035 Tel:408-526-1188 Fax:408-526-1088 Email:[email protected] Confidentiality RequestLetter ReasonforAmendment(current/obsolete) RevisionHistory ApprovedDate FromTo InitialRelease(obsolete)1.01.0Nov-14-2006 AddingCFR2.459(obsolete)1.02.0August–11-2008 Updatedcompanytemplate&Addedtextbox (obsolete) 2.03.0Jan-31-2012 AddedICconfidentialityletterform(current)3.04.0March-26-2015 SCS-F19:ConfidentialityRequestLetterPage 2 of 2 Rev4.0 TintagElectronics Date:Sep.29,2015 To: FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD Subject:PermanentConfidentialityRequestforFCCID:2AFRO-TINTAGWPC Weherebyrequestconfidentialtreatmentofinformationaccompanyingthisapplicationasoutlinedbelow: -BlockDiagram -Schematics -OperationalDescription Theabovematerialscontaintradesecretsandproprietaryinformationnotcustomarilyreleasedtothepublic.The publicdisclosureofthesematerialsmaybeharmfultotheapplicantandprovideunjustifiedbenefitstoits competitors. TheapplicantunderstandsthatpursuanttoSection0.457&0.459oftheRules,disclosureofthisapplicationand allaccompanyingdocumentationwillnotbemadebeforethedateoftheGrantforthisapplication. Sincerely, Client’ssignature: Client’sname/title:AlexandruChis/manager Contactinformation/address: Address: StradaTraiannr9ap19,ClujNapoca,Romania

WirelessChargerDeclaration TintagElectronics Date:Sep.29,2015 To:FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD FCCID:2AFRO-TINTAGWPC ToWhomItMayConcern: ThisletteristoascertainthatTintagElectronics,ProductTintag(charger),hasbeen theunitsusedforconductingFCCcompliancetesting,anditmeetsKDB680106Clause 5(2)all6conditionsasstatedbelowhencePBAisnotrequired. 1 Powertransferfrequencyislessthat1MHz 2 Outputpowerfromeachprimarycoilislessthan5watts 3 Thetransfersystemincludesonlysingleprimaryandsecondarycoils.Thisincludeschargingsystems thatmayhavemultipleprimarycoilsandclientsthatareabletodetectandallowcouplingonly betweenindividualpairsofcoils 4 Clientdeviceisinsertedinorplaceddirectlyincontactwiththetransmitter 5 Themaximumcouplingsurfaceareaofthetransmit(charging)deviceisbetween60cm2and400 cm2. 6 Aggregateleakagefieldsat10cmsurroundingthedevicefromallsimultaneoustransmittingcoilsare demonstratedtobelessthan30%oftheMPElimit. Ifyouhaveanyquestionorconcerns,pls.contactus. Sincerely, Client’ssignature: Name:AlexandruChis Address: StradaTraiannr9ap19,ClujNapoca,Romania

FCCID:2AFRO-TINTAGWPC label

1/3 RFEXPOSUREREPORT Environmental evaluation and exposure limit according to FCC CFR 47 Part 1.1307(b), 1.1310 1.Limits for Maximum Permissible Exposure (MPE) 2. Test mode ModeDescription Charging mode with load Using Max. load Using Mid. load Using Min. load 3. Test equipment EquipmentManufacturerModelSerial No.Due Date 3M Chamber & Accessory Equipment TDKSAC-3---06/01/2016 Magnetic field probeNarda2304/03M-001809/04/2016 4.Test setup 1. The test was performed on 360 degree turn table in anechoic chamber. 2. The probe was placed at distance 10 cm which is between the edge of the charger and the geometric centre of the probe. 3. The highest emission level was recorded and compared with limit as soon as measurement of each point; A, B, C, D were completed. 4. The EUT was measured according to the KDB 680106 D01v02. 2/3 5. Test results 5.1 E-Field Strength at 10 cm from each edges the EUT Test mode Frequency range (kHz) Position A (V/m) Position B (V/m) Position C (V/m) Position D (V/m) Limits (V/m) Charging mode with load (Max.) 205kHz0.340.510.410.41614 Charging mode with load (Mid.) 205kHz0.310.520.590.43614 Charging mode with load (Min.) 205kHz0.380.510.390.43614 Remark: Max. = <1% battery status Mid. = 50% battery status Min. = >95% battery status 5.2 H-Field Strength at 10 cm from each edges the EUT Test mode Frequency range (kHz) Position A (A/m) Position B (A/m) Position C (A/m) Position D (A/m) Limits (A/m) Charging mode with load (Max.) 205kHz0.180.140.150.161.43 Charging mode with load (Mid.) 205kHz0.190.120.170.151.29 Charging mode with load (Min.) 205kHz0.200.140.150.171.33 Remark: Max. = <1% battery status Mid. = 50% battery status Min. = >95% battery status 3/3 Test setup photo Charging Mode with load

Report No. :EED32H000910-2Page 1 of 19 TEST REPORT Product:Tintag (charger) Trade mark: Model/Type reference :Tintag Serial number:N/A Ratings:Input: 5V FCC ID:2AFRO-TINTAGWPC Report number:EED32H000910-2 Date:Jun. 15, 2015 Regulations:See below Test StandardsResults 47 CFR FCC Part 15 Subpart C: 2014PASS Prepared for: Tintag Electronics Strada Traian nr 9 ap 19 Cluj Napoca, Romania Prepared by: Centre Testing International Group Co., Ltd. Hongwei Industrial Zone, Bao’an 70 District, Shenzhen, Guangdong, China TEL: +86-755-3368 3668 FAX: +86-755-3368 3385 Tested by:Reviewed by: Approved by:Date:Aug. 14, 2015 Sheek Luo Lab supervisor Check No.: 1996258675 Report No. :EED32H000910-2Page 2 of 19 TABLE OF CONTENTS 1. GENERAL INFORMATION ...................................................................................................................................... 3 2. TEST SUMMARY ....................................................................................................................................................... 3 3. PRODUCT INFORMATION ...................................................................................................................................... 3 4. TEST EQUIPMENT LIST .......................................................................................................................................... 4 5. MEASUREMENT UNCERTAINTY .......................................................................................................................... 5 6. SUPPORT EQUIPMENT LIST ................................................................................................................................. 5 7. AC CONDUCTED EMISSION TEST ....................................................................................................................... 6 7.1. LIMITS ................................................................................................................................................................. 6 7.2. BLOCK DIAGRAM OF TEST SETUP ........................................................................................................... 6 7.3. PROCEDURE OF CONDUCTED EMISSION TEST ................................................................................... 6 7.4. GRAPHS AND DATA ....................................................................................................................................... 7 8. RADIATED EMISSION MEASUREMENT ............................................................................................................. 9 8.1. LIMITS ................................................................................................................................................................. 9 8.2. BLOCK DIAGRAM OF TEST SETUP ........................................................................................................... 9 8.3. TEST PROCEDURE ...................................................................................................................................... 10 8.4. TEST RESULT ................................................................................................................................................ 11 APPENDIX 1 PHOTOGRAPHS OF TEST SETUP ...................................................................................................... 15 APPENDIX 2 PHOTOGRAPHS OF PRODUCT ........................................................................................................... 17 Report No. :EED32H000910-2Page 3 of 19 1. GENERAL INFORMATION Applicant:Tintag Electronics Strada Traian nr 9 ap 19 Cluj Napoca, Romania Manufacturer:Cicor Systronics Zona Industriala Arad Vest, nr 10 Arad Romania Factory:Cicor Systronics Zona Industriala Arad Vest, nr 10 Arad Romania FCC ID: Product:Tintag (charger) Trade mark: Model/Type reference:Tintag Serial Number:N/A Report Number:EED32H000910-2 Sample Received Date:Jul.10, 2015 Sample tested Date:Jul. 10, 2015 to Aug. 14, 2015 The above equipment was tested by Centre Testing International (Shenzhen) Corporation for compliance with the requirements set forth in the FCC Rules and the measurement procedure according to ANSI C63.10-2013. 2. TEST SUMMARY No.Test ItemRuleTest Result 1Conducted EmissionFCC 15.207PASS 2Radiated EmissionFCC 15.209PASS 3. PRODUCT INFORMATION ItemsDescription RatingInput: 5V Antenna TypeCoil antenna Operated frequency 205kHz Report No. :EED32H000910-2Page 4 of 19 4. TEST EQUIPMENT LIST 3M Semi/full-anechoic Chamber EquipmentManufacturerMode No. Serial Number Cal. date (mm-dd-yyyy) Cal. Due date (mm-dd-yyyy) 3M ChamberTDKSAC-3---06-02-201306-01-2016 TRILOG Broadband Antenna schwarzbeckVULB91639163-61707-14-201507-13-2016 Microwave Preamplifier Agilent8449B3008A0242502-05-201502-04-2016 Horn AntennaETS-LINDGREN31170005741007-08-201507-07-2016 Loop AntennaETS65020007173007-23-201507-22-2016 Spectrum AnalyzerR&SFSP4010041607-09-201507-08-2016 ReceiverR&SESCI10043507-09-201507-08-2016 Multi device Controller maturo NCD/070/107111 12 ---01-13-201501-12-2016 LISNschwarzbeckNNBM81258125154707-09-201507-08-2016 LISNschwarzbeckNNBM81258125154607-09-201507-08-2016 Signal GeneratorAgilentE4438CMY4509574404-19-201504-18-2016 Signal GeneratorKeysightE8257DMY5340110604-14-201504-13-2016 Temperature/ Humidity Indicator TAYLOR1451519007-10-201507-09-2016 Communication test set AgilentE5515CGB4705053301-13-201501-12-2016 Cable lineFulai(7M)SF1065219/6A01-13-201501-12-2016 Cable lineFulai(6M)SF1065220/6A01-13-201501-12-2016 Cable lineFulai(3M)SF1065216/6A01-13-201501-12-2016 Cable lineFulai(3M)SF1065217/6A01-13-201501-12-2016 Communication test set R&SCMW50015239404-19-201504-18-2016 High-pass filter(3-18GHz) Sinoscite FL3CX03WG18N M12-0398-002 ---01-13-201501-12-2016 High-pass filter(5-18GHz) MICRO-TRONICS SPA-F-63029-4---01-13-201501-12-2016 band rejection filterSinoscite FL5CX01CA09CL 12-0395-001 ---01-13-201501-12-2016 band rejection filterSinoscite FL5CX01CA08CL 12-0393-00…
