2AFRR-010304Guitar effect stomp-boxes

1 USER MANUAL EKKO EK-­‐1 User Manual rev. 1.0.8, September, 2015 CONGRATULATIONS! You are now the owner of an EKKO EK-­‐1 delay pedal! EKKO is a high-­‐quality aluminum, standard semi-­‐analog delay pedal with true bypass. Semi-­‐analog means that the direct signal from your guitar is always direct through, whether the pedal is in bypass mode or not. It can be controlled like a stand-­‐alone effects pedal or using the AERO TM AE-­‐1 wireless controller (optional): 2 FCC Statements 15.19 (a)(3): This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 15.21: Unauthorized changes or modifications not expressly approved by Aalberg Audio could void the user's authority to operate the equipment. 15.105(b): Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. 3 Table of Contents FCC Statements ........................................................................................................................................... 2 1. GETTING STARTED ............................................................................................................................... 4 2. CONTROLS ................................................................................................................................................ 4 3. OVERVIEW ............................................................................................................................................... 5 4. SPECIFICATIONS .................................................................................................................................... 6 5. SOFTWARE UPDATE ............................................................................................................................. 7 6. WIRELESS CONTROL – PAIRING ....................................................................................................... 9 7. INPUT/OUTPUT SETUPS .................................................................................................................. 11 8. DISCLAIMERS ....................................................................................................................................... 13 9. WARRANTY .......................................................................................................................................... 13 10. HISTORY .............................................................................................................................................. 15 11. IPR-­‐RELATED .................................................................................................................................... 16 12. COMPLIANCE ..................................................................................................................................... 16 4 1. GETTING STARTED To get your pedal up and running you need a standard 9V DC, 2.1 mm plug, center negative power supply (minimum 250 mA). You will find the connector at the back of your pedal. The pedal supports both mono and stereo connections. Combinations of these will lead to different properties in the output signal. See the input/output setups section for further explanations. 2. CONTROLS TIME Time between echoes LEVEL Adjusts the output level of your echo signal relative to the level of the direct signal (0-­‐100%) FEEDBACK Controls the number of echoes FX SELECT/TAP TEMPO Two modes: -­‐ TAP – tap the desired delay time using footswitch (TAP) -­‐ FX-­‐SELECT – Choose active effect parameter (TIME, LEVEL or FEEDBACK) for wireless control with AERO controller (optional) ON/OFF Set the pedal to ON (activated) or OFF (true bypass). 5 3. OVERVIEW *Set active parameter for AERO TM AE-­‐1 Wireless Controller 6 4. SPECIFICATIONS Power supply 9V DC, 2.1 mm plug (center negative) Current draw 250 mA Input impedance@1kHz ~1M Ohm Output impedance@1kHz < 1k Ohm Maximum input signal 3.22 Vp-­‐p (2.28 Vrms) Delay time 0 ms – 2000 ms Sound Quality (sample-­‐/bit rate) 48 kHz/24-­‐bits Connectors -­‐ INPUT (mono/stereo) -­‐ OUTPUT (mono/stereo) -­‐ DC power jack Controls TIME, LEVEL, F.BACK, ON/OFF (true bypass), FX SELECT (TAP) Parameter level indicators LED bar indicators for TIME, LEVEL and F.BACK Dimensions incl. knobs (W x H x D) 93 x 57 x 142 mm / 3.7 x 2.2 x 5.6 inches Weight (excl. packaging) 0.372 kg / 13.0 oz Weight (incl. packaging) 0.442 kg / 15.6 oz 7 5. SOFTWARE UPDATE UPDATE APP ESTIMATED READY: AFTER SUMMER 2015 Performing software updates on your wireless Aalberg Audio product is easy: 1. To set your device in software update mode: • For AERO: i. Turn off the AERO (slide switch set to ‘0’) ii. Press and hold rotary knob button and preset button 3 (marked: ’III ’) simultaneously, then turn the AERO on (slide switch set to ‘I’) iii. The AERO LED will light up (…

Text truncated - open the document above for the full version.

This report contains a total of 80 pages and may be reproduced in full only. Partial reproduction may only be done with the written consent of CKC Laboratories, Inc. Aalberg Audio EMC TEST REPORT FOR Wireless Guitar Equipment Models: EKKO EK-1 and AERO AE-1 Tested To The Following Standards: FCC Part 15 Subpart C Sections 15.207 & 15.249 Report No.: 96887-5 Date of issue: August 11, 2015 This test report bears the accreditation symbol indicating that the testing performed herein meets the test and reporting requirements of ISO/IEC 17025 under the applicable scope of EMC testing for CKC Laboratories, Inc. We strive to create long-term, trust based relationships by providing sound, adaptive, customer first testing services. We embrace each of our customers’ unique EMC challenges, not as an interruption to set processes, but rather as the reason we are in business. Page 2 of 80 Report No.: 96887-5 TABLE OF CONTENTS Administrative Information .......................................................................................................................... 3 Test Report Information ............................................................................................................................................ 3 Report Authorization ................................................................................................................................................. 3 Test Facility Information ............................................................................................................................................ 4 Software Versions ...................................................................................................................................................... 4 Site Registration & Accreditation Information .......................................................................................................... 4 Summary of Results ................................................................................................................................................... 5 Modifications During Testing ..................................................................................................................................... 5 Conditions During Testing.......................................................................................................................................... 5 Equipment Under Test ............................................................................................................................................... 6 FCC Part 15 Subpart C ................................................................................................................................... 7 15.207 AC Conducted Emissions ................................................................................................................................ 7 15.215(c) -20dB Bandwidth ..................................................................................................................................... 25 15.249(a) Field Strength of Fundamental ................................................................................................................ 35 15.31(e) Voltage Variation ....................................................................................................................................... 47 15.249(a)&(d) Radiated Spurious Emissions / Band Edge ....................................................................................... 54 Supplemental Information .......................................................................................................................... 79 Emissions Test Details .............................................................................................................................................. 79 Page 3 of 80 Report No.: 96887-5 ADMINISTRATIVE INFORMATION Test Report Information REPORT PREPARED FOR: REPORT PREPARED BY: Aalberg Audio Postboks 645 Norway Terri Rayle CKC Laboratories, Inc. 5046 Sierra Pines Drive Mariposa, CA 95338 REPRESENTATIVE: Rune Aalberg Alstad Project Number: 96887 DATE OF EQUIPMENT RECEIPT: August 4, 2015 DATE(S) OF TESTING: August 4-5, 2015 Report Authorization The test data contained in this report documents the observed testing parameters pertaining to and are relevant for only the sample equipment tested in the agreed upon operational mode(s) and configuration(s) as identified herein. Compliance assessment remains the client’s responsibility. This report may not be used to claim product endorsement by A2LA or any government agencies. This test report has been authorized for release under quality control from CKC Laboratories, Inc. Steve Behm Director of Quality Assurance & Engineering Services CKC Laboratories, Inc. Page 4 of 80 Report No.: 96887-5 Test Facility Information Our laboratories are configured to effectively test a wide variety of product types. CKC utilizes first class test equipment, anechoic chambers, data acquisition and information services to create accurate, repeatable and affordable test results. TEST LOCATION(S): CKC Laboratories, Inc. 110 Olinda Place Brea, CA 92823 Software Versions CKC Laboratories Proprietary Software Version EMITest Emissions 5.02.00 EMITest Immunity 5.02.00 Site Registration & Accreditation Information Location CB # TAIWAN CANADA FCC JAPAN Brea D US0060 SL2-IN-E-1146R 3082D-2 100638 A-0147 Page 5 of 80 Report No.: 96887-5 SUMMARY OF RESULTS Standard / Specification: FCC Part 15 Subpart C Test Procedure Description Modifications Results 15.207 AC Conducted Emissions NA Pass 15.215(c) -20dB Bandwidth NA Pass 15.249(a) Field Strength of Fundamental NA Pass 15.31(e) Voltage Variation NA Pass 15.249(a)&(d) Field Strength of Spurious Emissions / Band Edge NA Pass NA = Not applicable. Modifications During Testing This list is a summary of the modifications made to the equipment during testing. Summary of Conditions No modifications were made during t…
