2AFVA-FD1102Voice-Controller

[Voice-Controller] User Guide Don’t underestimate button battery. It can be used for 6 months! As the case with battery inside is fitted well, the small light will give out 5 flashes, see? Great first step! (1) Remove the battery case. (2) Put the battery into the attached case with the positive pole facing down. (3) Plug it into the battery jar, 5 flashes of blue lights indicate a success. The designers have racked their brains just for your convenience. You can replace the battery by pulling your little finger gently. It is so capricious with talents. (4) Hold the bottom of batter case and pull it out. (5) Remove the battery case to replace the battery. Step 1 Is your phone Fashion(able) enough? It support 4.3 or higher OS version for Android phone and IOS7.0 or higher for Apple phone with iPhone4s or newer. Dear, if your phone version is too low, hurry up to upgrade it. Search the "ijiazu" in the App Store or scan the QR code below to download and install it. By the way, please give us praise. (6) App Store (7) QR code of ijiazu App Step 2 Open ijiazu APP. There is no need of Bluetooth pairing, it will be automatically connected! 1. When you open the mobile APP, it might remind you to "Turn on Bluetooth" or prompt you to use privileges such as sound recording, location, phone calls etc. Please do make a choice. 2. It is recommended that ijiazu App should be on for automatic connection next time. 3. The App on Android phone may be killed automatically after a long time run. Just open it again. (8) Main Interface of Android APP Bluetooth is connected successfully. Welcome to use Voice-Controller It is connecting to Bluetooth now and can be used after the successful connection Bluetooth is connected successfully. Voice-Controller is in low battery Bluetooth connection is failed. Please make sure the phone is close to Jingling is in low battery Step 3 Come to your car and buckle up the strap just like wearing a watch. Fix it to the inside of the steering wheel (Note that you should install Voice-Controller to steering wheel firstly when a handle grip need to be installed moreover). Now the Voice-Controller will fit with your car. However bumpy the road is, they will not be separated. (9) Fasten the strap in the metal card buckle (10) Installation is complete Step 4 Single-click: Voice input Sing-click: option moves one step upward Long press: switch the applications Sing-click: option moves one step downward Long press: switch the applications Back to upper level Exit Navigation(during navigation) Decline a call(phone rings) Hang up the phone(in a call) Confirm your selection Answer the phone(phone rings) [Note]Voice command parsing / navigation / playing network content require network support. Step 5 Operating environment • Do not place the device near a heat source or fires such as electric heaters, microwave, oven, water heater, fire or other places that may generate heat. Battery Safety • Do not expose the battery to high temperature or heat-producing devices such as heaters, microwave, oven, water heater. The overheating Battery may cause an explosion • When replacing the battery, only the same type battery or equivalent type of battery can be used. • Dispose the batteries according to local regulations. Do not deal with them as household waste • The battery cannot be charged to reused. Part Names Hazardous Substance Pb Hg Cd Cr6+ PBB PBDE Structural parts ○ ○ ○ ○ ○ ○ Circuit Modules × ○ ○ ○ ○ ○ Battery ○ ○ ○ ○ ○ ○ Label ○ ○ ○ ○ ○ ○ Other parts ○ ○ ○ ○ ○ ○ ○: shows the hazardous substance content in all homogeneous materials of this part is below the limitation requirement specified in SJ / T 11363-2006 “Hazardous Substance Limitation requirements for Electronic Information Products ". ×: shows the hazardous substance content is above the limitation requirement specified in SJ / T 11363-2006 in at least one of the homogeneous materials of this part. The environmentally friendly use period is 10 years, and its logo is as shown on the left. This environmentally friendly use period is only applicable when the product is under the conditions specified in the product manuals. Security Information ijiazu • Voice-Controller has made the service commitment: carry out the Three Guarantees strictly according to “Customers ‘Rights and Interests Law of People's Republic Law”, “Product Quality Law of People's Republic of China”. The service content is as follows: You can enjoy the rights of return, replacement and repair according to this provisions with the warranty period. The rights of return and replacement need to be done against the invoice. 1. If there is a product quality problem arising within 7 days since the date of your purchase, you can choose to return, change or repair. But the following situations do not enjoy the return service: Product is artificially damaged; Product damage is caused by the force majeure; There are scratches, paint loss and fracture on the product appearance; Accessories cannot be fully provided; Product features and performance changes; Product that has experienced replacement; Affect the Secondary sales; 2. Within 90 days since the date of your purchase, if there are product quality problems arising under normal operating conditions (without artificial damage), we will provide you free replacement or repair service. 3. Within 90 days since the date of your purchase, there are product quality problems arising under normal operating conditions (without overhauling), we will provide you free replacement or repair service. After-sales Service and Three Guarantees Fault Indications Solutions Indicator light is invalid. Examine if the battery is fitted reversely, or change it into a new battery. Voice recognition has no reaction. Examine if the phone is connected to the internet, or change it into high speed network. Voice recognition error Begin to speak after hearing the prompt tone, or slow down the speed. Prompt “not hearing your words” Voice recognition requi…

Text truncated - open the document above for the full version.

Beijing JINGLING Network Science & Technology Co., Ltd Room1021, Bldg.2, No.15 Taiyanggong South Street, Chaoyang Dist., Beijing 2015-09-10 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AFVA-FD1102 Product Name: Voice-Controller Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: • Schematics • Block diagram • Operational Description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 09/10/2015

Label Location

FCC ID: 2AFVA-FD1102

FCC ID: 2AFVA-FD1102 According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where --f(GHz) is the RF channel transmit frequency in GHz --Power and distance are rounded to the nearest mW and mm before calculation --The result is rounded to one decimal place for comparison eirp = pt x gt = (EXd) 2 /30 where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, --- 10 ((dBuV/m)/20) /10 6 d = measurement distance in meters (m) ---3m So pt = (EXd) 2 /30 x gt Field strength = 90.30dBuV/m @3m Ant gain =0dBi, so Ant numeric gain= 1.0 So pt={ [10 (90.30/20) /10 6 x 3] 2 /30x1.0 }x1000 mW = 0.321mW So (0.321mW /5mm)x √2.440 = 0.1<3 Then SAR evaluation is not required

Global United Technology Services Co., Ltd. Report No.: GTSE15090172301 Authorized Signature: Robinson Lo Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the GTS product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of GTS or testing done by GTS in connection with, distribution or use of the product described in this report must be approved by GTS in writing. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. FCC REPORT Applicant: Beijing JINGLING Network Science & Technology Co., Ltd Address of Applicant: Room 1021, Bldg. 2, No.15 Taiyanggong South Street, Chaoyang Dist., Beijing Equipment Under Test (EUT) Product Name: Voice-Controller Model No.: FD1102, FD1106 FCC ID: 2AFVA-FD1102 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.249:2014 Date of sample receipt: September 01, 2015 Date of Test: September 02-07, 2015 Date of report issued: September 08, 2015 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTSE15090172301 Global United Technology Services Co., Ltd. Project No.: GTSE150901723RF Room 301-309, 3th Floor, Block A, Huafeng Jinyuan Business Building, No. 300 Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, China Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 25 2 Version Version No. Date Description 00 September 08, 2015 Original Prepared By: Date: September 08, 2015 Project Engineer Check By: Date: September 08, 2015 Reviewer Tested By: Report No.: GTSE15090172301 Global United Technology Services Co., Ltd. Project No.: GTSE150901723RF Room 301-309, 3th Floor, Block A, Huafeng Jinyuan Business Building, No. 300 Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, China Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 25 3 Contents Page 1 COVER PAGE ............................................................................................................................................ 1 2 VERSION .................................................................................................................................................. 2 3CONTENTS .............................................................................................................................................. 3 4TEST SUMMARY ..................................................................................................................................... 4 4.1MEASUREMENT UNCERTAINTY ............................................................................................................ 4 5GENERAL INFORMATION ...................................................................................................................... 5 5.1CLIENT INFORMATION ......................................................................................................................... 5 5.2GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.3TEST MODE ........................................................................................................................................ 7 5.4DESCRIPTION OF SUPPORT UNITS ....................................................................................................... 7 5.5TEST FACILITY .................................................................................................................................... 7 5.6TEST LOCATION ................................................................................................................................. 7 5.7DESCRIPTION OF SUPPORT UNITS ....................................................................................................... 7 5.8OTHER INFORMATION REQUESTED BY THE CUSTOMER ......................................................................... 7 6TEST INSTRUMENTS LIST ..................................................................................................................... 8 7TEST RESULTS AND MEASUREMENT DATA ...................................................................................... 9 7.1ANTENNA REQUIREMENT ..................................................................................................................... 9 7.2RADIATED EMISSION METHOD ........................................................................................................... 10 7.2.1Field Strength of The Fundamental Signal ................................................................................ 12 7.2.2Spurious emissions .................................................................................................................... 13 7.2.3Bandedge emissions.................................................................................................................. 17 7.320DB OCCUPY BANDWIDTH .............................................................................................................. 18 8TEST SETUP PHOTO ...........................................................…

Text truncated - open the document above for the full version.

Radiated Emission
