2AFVPQKS6Bluetooth Speaker

User Manual Please read this user manual before using this speaker Button Function: 1. Bluetooth switch 2. Next /volume up 3. Previous/ volume down 4. Pause answer/ hang up 5. Mic 6. TF card slot 7. USB micro jack 8. AUX audio jack Specification: 1.Name: waterproof Bluetooth speaker. 2.Bluetooth: RDA 2.1+EDR 3.Waterproof: Ipx6 4.Charging Input: DC5V----1000mA 5.Battery capacity: Ployer Lithium Battery. 3.7V/2200mAh 6.Charging time: 3~4hours 7.Speaker specification:5W×2 8.Frequency Range:2.4-2.48GHz 9.Distortion:<0.5% 10.Whole signal to noise Radio: >65dB 11.Main material: ABS+Silicone 12.Size: L170 x ∅6cm 13.Weight: 170g 14.Playing time: 8hours Speaker Function: Bluetooth mode: First Press and hold the Bluetooth switch button for 3 seconds to enter Bluetooth detect mode. Then you can connect the Bluetooth speaker to your Bluetooth enabled device. Bluetooth connection Step 1: open the Bluetooth setting on your phone or tablet and click “ search device”. Iphones will search for Bluetooth devices automatically. Step 2: You have found the Bluetooth speaker when the screen displays the character “WYT-S01”, click on it your device to pair the connection. Step 3: The phone or tablet will indicate when the pairing is successful. Music playing Open the player device when the connection is successful. Click to lay music, and the Bluetooth speaker will play music. You can operate the player with buttons on the Bluetooth Speaker. Short press to play/pause. Short press “+” to play next, Long press “+” to volume up. Short press “-” to play previous, Long press “-” to volume down. Bluetooth Hands free call Answer and hang up the phone: There will be an alert sound from the speaker when there is a phone call. Click to answer the call. And click again to hang up. In Bluetooth mode, when you shorty press , it will be switched to the TF card mode. TF Card mode Insert the TF card when the speaker is turned on. The speaker will enter itself into the TF card mode. It can play the music (MP3/WMA/APE FORMAT) from your CARD. You can operate with the buttons on the Bluetooth speaker： Short press to play/pause. Short press “+” to play next, Long press “+” to volume up. Short press “-” to play previous, Long press “-” to volume down. Bluetooth pairing and connection 1. If the speaker has been connected with Bluetooth devices before, it will connect with the last Bluetooth device automatically once it is turned on. 2. Other phones or tablets cant be connected with the Bluetooth speaker when the speaker is being connected with a phone or tablet. 3. The phone or tablet can not be connected with the Bluetooth speaker if it is connected with other Bluetooth devices. You should turn off your Bluetooth connection and connect your phone with the Bluetooth speaker again. Frequently Asked Questions Question Solution Unsuccessful pairing and connection 1. Check the speaker and make sure it is the searching state or reboot the speaker. 2. Connection is difficult when there are too many Bluetooth devices nearby. Turn off other Bluetooth devices. Turn off the Bluetooth device that was connected with the Bluetooth speaker last time, and reconnect the speaker. Muted or distorted sound 1. Click the volume of your phone or the speaker, and adjust the volume. 2. The battery is low. Please charge it. Choppy music play 1. Check if the device is beyond the effective connection distance. 2. Check if there is any obstacle between the speaker and your device. The indicator not shinning in Bluetooth mode 1. The battery is low. Please charge it. 2. Please reboot the speaker. Charging Please make sure the speaker is fully charged in first use. The light and display will flash, indicating that the speaker needs to be recharged. Charge the speaker with the provided USB cable which is compatible with any computer or cell phone charger. The charge indicator light will be red while charging, then when the battery is fully charged it will turn off. The USB port is only used for Charging. Precautions 1. Please store and use the product in room temperature environment. 2. Do not disassemble, repair, or modify the product. 3. Plz use the power charge with rated voltage for the speaker. 4. It may cause hearing damage if playing music in high volume for a long time. Consider avoiding excessively high volume when playing music for a long time. 5. Disassemble this product will invalidate the warranty.

SHENZHEN KUKASHI TECHNOLOGY CO.,LTD. FCC Authorization Letter Number: CF304 Version: V03 Date: 01-08-2011 We, (the approval holder) Company name SHENZHEN KUKASHI TECHNOLOGY CO.,LTD. Address F2, Block B, First Industry Park, Fenghuang, Fuyong, Baoan District, City Shenzhen, Country China declare that the following representative (agent): Name (person) [email protected] Company name Shenzhen BCTC Technology Co., Ltd. Address No.101,Yousong Road,Longhua New District, City Shenzhen Country China is hereby authorized to apply the following equipment for certification on our behalf: Product Description Bluetooth Speaker Type or Model(s) QKS6, QKS7，QKS8，QKS9，QKS11，QKS71,QKS72,QKS73, QKS75, QKS76, QKS78, QKS79, QKS91, QKS92, QKS93, QKS95 Tradename or Brand(s) We also authorize Teleconformity (Mr. M. Koop, Manager Certification, Address: Rietven 31, 7534NH Enschede, the Netherlands) to apply and sign this application for certification, registration or filing on our behalf (as representative agent or certifier). Attestation: City and Country: Date: Name: (this must be a person) Function:Signature: (or official company stamp) Shenzhen, 2015-9-10 Chen Xiaoning Manager

SHENZHEN KUKASHI TECHNOLOGY CO.,LTD. FCC Confidentiality Request Number: CF303 Version: V05 Date: 21-05-2012 (Permanent or also called long term confidentiality is the normal method to keep certain docuements confidential, and may apply to schematics, block diagrams, operational description and bill of materials.) To: Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Pursuant to 47 CFR Section 0.459(a) & (b), we, (the applicant / grantee) Company name SHENZHEN KUKASHI TECHNOLOGY CO.,LTD. Address F2, Block B, First Industry Park, Fenghuang, Fuyong, Baoan District, City Shenzhen, Country China request for this certification filing under: Grantee Code Product Number FCC ID: 2AFVP QKS6 to maintain permanent confidentiality for the following documents submitted within this application: (please cross what is applicable, or add other documents, provide the file name and description) Exhibit File Name Description x Operational Description explaining the functioning of the block diagram x Block Diagrams showing the systematic building blocks of the EUT x Schematics Diagrams showing components, their values and interconnection Above materials crossed contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. We understand that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. The documents indicated as confidential above, are not publicly available elsewhere. Attestation: City and Country: Date: Name: (this must be a person) Function:Signature: (or official company stamp) Shenzhen, 2015-9-10 Chen Xiaoning Manager

M/N: QKS6 FCC ID: 2AFVPQKS6 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Label location

Antenna location

Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15090249 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 1 of 31 FCC Part 15C Test Report FCC ID: 2AFVPQKS6 Product Name: Bluetooth Speaker Trademark: Model Name : QKS6, QKS7, QKS8, QKS9, QKS11, QKS71,QKS72,QKS73,QKS75, QKS76, QKS78, QKS79, QKS91, QKS92, QKS93, QKS95 Prepared For : Shenzhen KUKASHI Technology Co., Ltd. Address : F2, Block B, First Industry Park, Fenghuang, Fuyong, Baoan District,ShenZhen,China. Prepared By : Shenzhen BCTC Technology Co., Ltd. Address : No.101,Yousong Road,Longhua New District, Shenzhen,China Test Date: Sept. 3 – Sept. 9, 2015 Date of Report : Sept. 10, 2015 Report No.: BCTC-15090249 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15090249 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 2 of 31 VERIFICATION OF COMPLIANCE Applicant’s name ................. : Shenzhen KUKASHI Technology Co., Ltd. Address ................................. : F2, Block B, First Industry Park, Fenghuang, Fuyong, Baoan District,ShenZhen,China. Manufacture's Name ............ : Shenzhen KUKASHI Technology Co., Ltd. Address ................................. : F2, Block B, First Industry Park, Fenghuang, Fuyong, Baoan District,ShenZhen,China. Product description Product name ........................... : Bluetooth Speaker Trademark: Model Name: QKS6, QKS7, QKS8, QKS9, QKS11, QKS71,QKS72,QKS73,QKS75, QKS76, QKS78, QKS79, QKS91, QKS92, QKS93, QKS95 Test procedure FCC Part15.249 Standards ANSI C63.10-2013 This device described above has been tested by BCTC, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BCTC, this document may be altered or revised by BCTC, personal only, and shall be noted in the revision of the document. Test Result ............................................... : Pass Testing Engineer : (Eric Yang) Technical Manager : (Sophia Lee) Authorized Signatory : (Carson. Zhang) Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15090249 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 3 of 31 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 4 1.1 TEST FACILITY 4 1.2 MEASUREMENT UNCERTAINTY 4 2 . GENERAL INFORMATION 5 2.1 GENERAL DESCRIPTION OF EUT 5 2.2 DESCRIPTION OF TEST MODES 6 2.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 7 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 7 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 8 3 . EMC EMISSION TEST 9 3.1 RADIATED EMISSION MEASUREMENT 13 3.1.1 RADIATED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 15 3.1.5 EUT OPERATING CONDITIONS 16 3.1.6 TEST RESULTS 17 4 . BANDWIDTH TEST 22 4.1 APPLIED PROCEDURES / LIMIT 22 4.1.1 TEST PROCEDURE 22 4.1.2 DEVIATION FROM STANDARD 22 4.1.3 TEST SETUP 22 4.1.4 EUT OPERATION CONDITIONS 22 4.1.5 TEST RESULTS 23 5 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 27 5.1 DEVIATION FROM STANDARD 28 5.2 TEST SETUP 28 5.3 EUT OPERATION CONDITIONS 28 5.4 TEST RESULTS 28 6 . ANTENNA REQUIREMENT 29 6.1 STANDARD REQUIREMENT 29 6.2 EUT ANTENNA 29 7 . EUT TEST PHOTO 30 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15090249 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 4 of 31 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.249) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.249 Radiated Spurious Emission PASS 15.249 Bandwidth PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report 1.1 TEST FACILITY Shenzhen BCTC Technology Co., Ltd. Add.:No.101,Yousong Road,Longhua New District, Shenzhen,China FCC Registration No.:187086 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15090249 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 5 of 31 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Bluetooth Speaker Trade Name Model Name QKS6, QKS7, QKS8, QKS9, QKS11, QKS71,QKS72,QKS73,QKS75, QKS76, QKS78, QKS79, QKS91, QKS92, QKS93, QKS95 Product Description Operation Frequency: 2402~2480 MHz Modulation Type: GFSK,PI/4 DPSK,8DPSK Bit Rate of Transmitter 1M/2M/3Mbps Number Of Channel 79 CH Antenna Designation: Please see Note 3. Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an ITE/Computing Device. More details of EUT technical specification, please refer to the User's Manual. Channel List Please refer to the Note 2. Adapter DC 5V from adapter input AC 120V/60Hz Battery DC 3.7V Connecting I/O Port(s) Please refer to the User's Manual hardware version -- Software version -- Serial number -- Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. 2. Channel List Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 00 2402 27 2429 54 2456 01 2403 28 2430 55 2457 02 2404 29 2431 56 2458 03 2405 30 2432 57 2459 04 2406 31 2433 58 2460 05 2407 32 2434 59 2461 06 2408 33 2435 60 2462 07 2409 34 2436 61 2463 08 2410 35 2437 62 2464 09 2411 36 2438 63 2465 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15090249 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Pa…

Text truncated - open the document above for the full version.

Radiated Emission conducted Emission
