P ortable Thermal Printer User Manual P lease read this manual carefully before using it, and keep it for future reference Portable Thermal Printer User Manual I About this manual Thank you for your purchase of our company's 58MM thermal printer. This manual can help you learn to use this product. Please read this manual before use, and safekeeping, so that all the use of this product can read it. Note Due to our constant efforts to improve and upgrade the product's function and performance, our company reserves the right to change the hardware and software specifications in the manual without prior notice. If you find any errors or missions in the contents of this manual, please tell us or our agent,thank you very much. Without the prior written permission of our company, the contents of the relevant manual attached to the product shall not be reproduced, transmitted, transcribed, stored, etc.. Portable Thermal Printer User Manual II Statement This product is type A product, may cause the radio interference in the living environment , in this case,the user need to protect the interference with effective protection measure Safety tips Please follow the following notes when using the printer ●Do not disassemble the printer personally, pls read this manual before use. ●Please shut off the power supply when the failure occurs. When you find that the printer power adapter or battery smoke or has bad smell, please unplug the power adapter immediately, and take out the battery, pls note to avoid being burned. ●Please do not use the printer at the gas station, fuel warehouse, etc. ●When charging, please put the printer and the power adapter on the ventilation place with environment temperature -5°C~40°C, and use the manufacturers standard power adapter. The use of unauthorized power adapters may cause danger, and violation of the manufacturer's warranty terms. Portable Thermal Printer User Manual III ●When the printer is printing, please do not open the paper cover, otherwise it may appear unexpected situation, and even damage the printer. ●After printing, print head is still at high temperature, do not touch, so as not to burn. ●Pls do not use dissolved substances, such as: benzene, thinner or alcohol wipe to clean the printer casing. At the same time, please do not use corrosive chemicals and detergent to contact printer. To avoid damage to the printer. ●Pls use our company approved or regular factory produced printing paper, otherwise it may lead to poor print quality, and even damage the printer core. ●If you have to store the printer for a long time, please be sure to remove the battery in the printer and for separate storage, otherwise may cause the battery failure, and even leakage, and then damage the printer. ●Before replacing the battery, please make sure that the printer has been shut off. If you use the power adapter, please confirm that the power supply has been cut off. Portable Thermal Printer User Manual IV ●Thermal printing paper printing letter save time is related to thermal printing paper quality, if you want to print the long-term preservation bills, please choose a long-term thermal paper. ●The printer is only suitable for using in the altitude below 2000M. ●The printer is only suitable for use in non tropical climates. Please follow the following precautions when using the battery ●Before use, please read this manual and battery surface identification. ●Pls charge the battery indoor in the appropriate emperature, if charging temperature is too high, will cause the battery heat, smoke, burning or deformation, and even explosion. ●There are special protection circuit and device inside the battery, please do not disassemble the battery, otherwise it will cause short circuit or electrolyte leakage. it has the risk of blindness if electrolyte into the eyes , if accidentally into the eyes, please rinse immediately, and immediately rushed to the hospital for treatment. Portable Thermal Printer User Manual V ●Please do not squeeze, mechanical vibration or shaking the battery, is strictly prohibited to make the battery positive and negative shortcircuit. ●Please do not put the battery into water or other liquid, to cause the battery short circuit, which causes the battery to heat, smoke, or even explode. ●Please do not expose the battery to the sun. Please do not use in the high humidity environment, such as the bathroom, sauna room, etc.. Please replace the battery when the performance requirements can not be met. ●Please put the battery in a place where children can not reach, and prevent the occurrence of danger. ●Once the battery is found deformed, leakage, fever or has other abnormal conditions, please stop using. Please follow the following precautions when using the power adapter ●Before use, please read this manual and the surface of the power adapter. ●If the power adapter is exposed to water or other conductive liquid, please cut off the power immediately. Portable Thermal Printer User Manual VI ●Do not remove or modify the power adapter, it is strictly prohibited to use the power adaptor with damage the power supply line , otherwise it will cause damage to the power adapter and even lead to electric shock, fire and other hazards. ●Please do not short-circuit the power adapter, or violent shaking the power adapter, as to avoid dangerous situations. ●Please do not use the power adapter in the bathroom, sauna and other high humidity environment, no rain. ●Please put the battery in a place where children can not reach,and prevent the occurrence of danger. Application area Water and electricity meter reading Transport, logistics bill printing Mobile government, police bill printing Taxi bill printing Portable Thermal Printer User Manual VII Package Printer 1 PC Standard power adapter 1 SET Standard battery 1PC Paper roll 1 ROLL USB data line 1 PC user manual 1 PC optional accessories standard COM line 1 PC standard holster 1 PC Portable Thermal Printer User Manual VIII Print…

Text truncated - open the document above for the full version.

Shenzhen Hoin Electronic Technology Co., Ltd Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: SUBJECT: FCC Application for (FCC ID: 2AFWHHOP-E200) To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite device. We understand that devices subject to the DoC procedure are required to be tested to show compliance with the FCC technical regulations by a recognized accredited testing laboratory. The testing laboratory must be accredited by a Commission approved accreditation body or designated under the terms of a government-to-government Mutual Recognition Agreement (MRA). A listing of those accredited testing laboratories that have been recognized by the Commission is published on the FCC Webpage: https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm Select the "accredited" option to search for FCC recognized accredited test firms. Test facilities located in countries, where the U.S. does not have an operational Telcom MRA are not recognized by the FCC to test for the DoC procedure. Testing laboratory: The Hong Kong Standards and Testing Centre Ltd.( 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong FCC registration number: 607756 Name: Wilson Wong Tel: 852-2666-1888) Regards, Signatory City and Country: Date: Name: (this must be a person) Function:Signature: (or official company stamp) Yan Chuan Community,Songgang Street,Baoan.Shenzhen 2015-9-11 Haitao Li Manager

Shenzhen Hoin Electronic Technology Co., Ltd Agent Authorization Letter 2015/9/21 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen BCTC Technology Co., Ltd to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Client’s name / title : Haitao Li / Manager Contact informations: Area C,3rd floor 7# Bei Fang Yong Fa Science and Technology Park,Area A,Chao Yang Yan Chuan Industrial Park,Yan Chuan Community,Songgang Street,Baoan,Shenzhen,China

Shenzhen Hoin Electronic Technology Co., Ltd Long Term Confidentiality Request Letter 2015/9/21 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR EUT NAME: Thermal Receipt Printer MODEL : HOP-E200, E200,HOP-E200II,E200II,HOP-H200,H200,HOP-H200II,H200II,DC- 58BTIII,58BTIII,HOP-E300,E300,HOP-E300II,E300II,HOP-H300,H300,HOP- H300II,H300II,DC-80IIBT,80BTII FCC ID: 2AFWHHOP-E200 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - Block Diagram - Schematics - Operational Description required to be submitted with this application be permanently withheld from public review. SPECIFY REASON FOR REQUEST (i.e. the above documents are company proprietary information that could never get into the possession of your competition). Please contact me if there is any information you may need. Sincerely, Client’s name / title : Haitao Li / Manager Contact informations: Area C,3rd floor 7# Bei Fang Yong Fa Science and Technology Park,Area A,Chao Yang Yan Chuan Industrial Park,Yan Chuan Community,Songgang Street,Baoan,Shenzhen,China

HANTAT TECHNOLOGY LTD. Model Difference FCC ID: 2AFWHHOP-E200 Product description: Thermal Receipt Printer Model : HOP-E200, E200,HOP-E200II,E200II,HOP-H200,H200,HOP- H200II,H200II,DC-58BTIII,58BTIII,HOP-E300,E300,HOP-E300II,E300II,HOP- H300,H300,HOP-H300II,H300II,DC-80IIBT,80BTII All the models are the same circuit and RF module, except the mode names and outlook color. Regards Sincerely Client’s signature City and Country: Date: Name: (this must be a person) Function:Signature: (or official company stamp) Yan Chuan Community,Songgang Street,Baoan.Shenzhen 2015-9-10 Haitao Li Manager

M/N: HOP-E200 FCC ID: 2AFWHHOP-E200 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Label location

Antenna location

Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15090256 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 1 of 34 FCC Part 15C Test Report FCC ID: 2AFWHHOP-E200 Product Name: Thermal Receipt Printer Trademark: N/A Model Name : HOP-E200, E200,HOP-E200II,E200II,HOP-H200,H200,HOP-H200II,H200II,DC-58BT III,58BTIII,HOP-E300,E300,HOP-E300II,E300II,HOP-H300,H300,HOP-H 300II,H300II,DC-80IIBT,80BTII Prepared For : Shenzhen Hoin Electronic Technology Co., Ltd Address : Area C,3rd floor 7# Bei Fang Yong Fa Science and Technology Park,Area A,Chao Yang Yan Chuan Industrial Park,Yan Chuan Community,Songgang Street,Baoan,Shenzhen,China Prepared By : Shenzhen BCTC Technology Co., Ltd. Address : No.101,Yousong Road,Longhua New District, Shenzhen,China Test Date: Sept. 7 – Sept. 11, 2015 Date of Report : Sept. 11, 2015 Report No.: BCTC-15090256 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15090256 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 2 of 34 VERIFICATION OF COMPLIANCE Applicant’s name ....... Shenzhen Hoin Electronic Technology Co., Ltd Address ....................... Area C,3rd floor 7# Bei Fang Yong Fa Science and Technology Park,Area A,Chao Yang Yan Chuan Industrial Park,Yan Chuan Community,Songgang Street,Baoan,Shenzhen,China Manufacture's Name . Shenzhen Hoin Electronic Technology Co., Ltd Address ....................... Area C,3rd floor 7# Bei Fang Yong Fa Science and Technology Park,Area A,Chao Yang Yan Chuan Industrial Park,Yan Chuan Community,Songgang Street,Baoan,Shenzhen,China Product description Product name ...............Thermal Receipt Printer Trademark: N/A Model Name: HOP-E200, E200,HOP-E200II,E200II,HOP-H200,H200,HOP-H200II,H200II, DC-58BTIII,58BTIII,HOP-E300,E300,HOP-E300II,E300II,HOP-H300,H300, HOP-H300II,H300II,DC-80IIBT,80BTII Test procedure FCC Part15.249 Standards ANSI C63.10-2013 This device described above has been tested by BCTC, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BCTC, this document may be altered or revised by BCTC, personal only, and shall be noted in the revision of the document. Test Result ....................................... Pass Testing Engineer : (Eric Yang) Technical Manager : (Sophia Lee) Authorized Signatory : (Carson. Zhang) Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15090256 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 3 of 34 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 5 1.2 MEASUREMENT UNCERTAINTY 5 2 . GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 DESCRIPTION OF TEST MODES 7 2.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 8 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 8 2.5 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 8 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 9 3 . EMC EMISSION TEST 10 3.1 CONDUCTED EMISSION MEASUREMENT 10 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 10 3.1.2 TEST PROCEDURE 11 3.1.3 DEVIATION FROM TEST STANDARD 11 3.1.4 TEST SETUP 11 3.1.5 EUT OPERATING CONDITIONS 11 3.1.6 TEST RESULTS 12 3.2 RADIATED EMISSION MEASUREMENT 14 3.2.1 RADIATED EMISSION LIMITS 14 3.2.2 TEST PROCEDURE 15 3.2.3 DEVIATION FROM TEST STANDARD 15 3.2.4 TEST SETUP 16 3.2.5 EUT OPERATING CONDITIONS 17 3.2.6 TEST RESULTS 18 4 . BANDWIDTH TEST 24 4.1 APPLIED PROCEDURES / LIMIT 24 4.1.1 TEST PROCEDURE 24 4.1.2 DEVIATION FROM STANDARD 24 4.1.3 TEST SETUP 24 4.1.4 EUT OPERATION CONDITIONS 24 4.1.5 TEST RESULTS 25 5 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 29 5.1 DEVIATION FROM STANDARD 29 5.2 TEST SETUP 29 5.3 EUT OPERATION CONDITIONS 29 5.4 TEST RESULTS 30 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15090256 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 4 of 34 Table of Contents Page 6 . ANTENNA REQUIREMENT 31 6.1 STANDARD REQUIREMENT 31 6.2 EUT ANTENNA 31 7 . EUT TEST PHOTO 32 8 . PHOTO OF THE EUT 34 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15090256 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 5 of 34 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.249) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.249 Radiated Spurious Emission PASS 15.249 Bandwidth PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report 1.1 TEST FACILITY Shenzhen BCTC Technology Co., Ltd. Add.:No.101,Yousong Road,Longhua New District, Shenzhen,China FCC Registration No.:187086 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-15090256 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 6 of 34 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Thermal Receipt Printer Trade Name N/A Model Name HOP-E200, E200,HOP-E200II,E200II,HOP-H200,H200,HOP-H200II,H 200II,DC-58BTIII,58BTIII,HOP-E300,E300,HOP-E300II,E 300II,HOP-H300,H300,HOP-H300II,H300II,DC-80IIBT,80 BTII Product Description Operation Frequency: 2402~2480 MHz Modulation Type: GFSK,PI/4 DPSK,8DPSK Bit Rate of Transmitter 1M/2M/3Mbps Number Of Channel 79 CH Antenna Designation: Please see Note 3. Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an ITE/Computing Device. M…
