2AG32EG7010AM11LTE Outdoor CPE

01 All rights reserved © Baicells Technologies Co., Ltd. Baicells EG7010A-M11 User Manual V100R001C00 About This Document This document introduces the specifications of Baicells EG7010A-M11 CPE and guides users to install and configure it. Copyright Notice Baicells copyrights this specification. No part of this specification may be reproduced in any form or means, without the prior written consent of Baicells. Disclaimer This specification is preliminary and is subject to change at any time without notice. Baicells assumes no responsibility for any errors contained herein. For more information, please consult our technical engineers. Revision Record Date Version Description 24 Jan,2017 V1.0 Initial released. Contact Us Baicells Technologies Co., Ltd.North America Address: 555 Republic Drive, Suite 200 Plano, TX 75074 E-mail: [email protected] Phone: +1-972-800-1157 Website: http://www.baicells.com/ Contents 1. Product Overview ....................................................................................................... 1 1.1 Introduction .......................................................................................................... 1 1.2 Features ................................................................................................................ 1 1.3 Appearance ........................................................................................................... 2 2. Technical Specifications ............................................................................................... 5 2.1 Basic Specification ................................................................................................ 5 2.2 RF Specification ..................................................................................................... 5 2.3 SW Specification ................................................................................................... 5 2.4 Device Management ............................................................................................... 6 2.5 Environment Specification ...................................................................................... 6 3. Installation Guide.......................................................................................................... 8 3.1 Support Materials ................................................................................................... 8 3.2 Install USIM Card and Ethernet Cable ..................................................................... 8 3.3 Install on Pole ......................................................................................................... 9 3.4 Install on Wall ....................................................................................................... 10 3.5 Grounding ............................................................................................................ 10 3.6 Regulatory Compliance ......................................................................................... 11 4. Configuration Guide ................................................................................................... 13 4.1 Log in .................................................................................................................... 13 4.2 View Status ........................................................................................................... 13 4.3 Basic Configuration ............................................................................................... 14 4.3.1 LTE Setting .................................................................................................... 14 4.3.2 Set Connection Method................................................................................. 14 4.3.3 Set Scan Mode .............................................................................................. 15 4.3.4 Lock Frequency (Earfcn) ................................................................................ 15 4.3.5 Lock PCI ......................................................................................................... 16 Appendix A FAQs ......................................................................................................... 19 Appendix B Shipping List ............................................................................................. 20 Figures Figure 1-1 EG7010A-M11 Appearance ........................................................................ 2 Figure 1-2 Interface and Button of EG7010A-M11 ....................................................... 2 Figure 1-3 LED Indicators of EG7010A-M11 ................................................................ 3 Figure 3-1 Install Ethernet Cable and USIM Card ....................................................... 8 Figure 3-2 Connection Diagram ................................................................................... 9 Figure 3-3 Install the Bracket ....................................................................................... 9 Figure 3-4 Install on Pole............................................................................................ 10 Figure 3-5 Install on Wall ............................................................................................ 10 Figure 3-6 Grounding ................................................................................................. 11 Figure 4-1 Login Page ................................................................................................ 13 Figure 4-2 View Status ............................................................................................... 14 Figure 4-3 Set Connection Method ............................................................................ 14 Figure 4-4 Set Scan Mode ......................................................................................... 15 Figure 4-5 Lock Frequency ................................................................................…

Text truncated - open the document above for the full version.

Baicells Technologies Co., Ltd. Date: Dec. 30, 2019 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2AG32EG7010AM11 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Schematics Block Diagram Operational Description Schematics.pdf Block Diagram.pdf Operational Description.pdf Part List Tune-up Procedure Part List.pdf Tune-up Procedure.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Baicells Technologies Co., Ltd. Signature Back Huang/ Manager Typed name and Title

Baicells Technologies Co., Ltd. Date: 12/30/2019 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD To Whom It May Concern: We, Baicells Technologies Co., Ltd., state that our device, FCC ID: 2AG32EG7010AM11, has a non-removable rear cover. The label will be placed on the rear cover. And the label will be visible to the end users when they purchase the product. The back cover can not be moved away, so the FCC ID label has to be placed on the surface of product. Sincerely, Signature [Back Huang (Name)] [Manager(Title)] [Baicells Technologies Co., Ltd. (Company name)]

Baicells Technologies Co., Ltd. FCC ID: 2AG32EG7010AM11 POWER OF ATTORNEY Date: Dec. 30, 2019 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: We, the undersigned, hereby authorize Waltek Services (ShenZhen) Co., Ltd. (Philo Zhong) on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Waltek Services (ShenZhen) Co., Ltd. (Philo Zhong) on our behalf shall have the same effect as acts of our own. This authorization expires on Dec. 29, 2020. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. We, Baicells Technologies Co., Ltd. are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Sincerely, Baicells Technologies Co., Ltd. Signature Back Huang / Manager Typed name and Title

Appendix-EG7010A-M11_Photo Page 3 of 14 EUT – External View Model EG7010A-M11 FCC ID: 2AG32EG7010AM11 Appendix-EG7010A-M11_Photo Page 4 of 14 Appendix-EG7010A-M11_Photo Page 5 of 14 Appendix-EG7010A-M11_Photo Page 6 of 14 Appendix-EG7010A-M11_Photo Page 7 of 14

EG7010C-M11 _Label Sample and Label Location

Appendix-EG7010A-M11_Photo Page 8 of 14 EUT – Internal View Model EG7010A-M11 FCC ID: 2AG32EG7010AM11 ANT Appendix-EG7010A-M11_Photo Page 9 of 14 Appendix-EG7010A-M11_Photo Page 10 of 14 Appendix-EG7010A-M11_Photo Page 11 of 14 Appendix-EG7010A-M11_Photo Page 12 of 14 Appendix-EG7010A-M11_Photo Page 13 of 14 Appendix-EG7010A-M11_Photo Page 14 of 14 ======End======

Waltek Services (Shenzhen) Co.,Ltd. http://www.waltek.com.cn Page 1 of 7 TEST REPORT Reference No. .................... : WTS19S10068895W002 FCC ID ................................ : 2AG32EG7010AM11 Applicant ............................ : Baicells Technologies Co., Ltd. Address .............................. : 3F, Hui Yuan Development Building, No.1 Shangdi Information Industr y Base, Haidian Dist., Beijing, China Manufacturer .................... : Baicells Technologies Co., Ltd. Address .............................. : 3F, Hui Yuan Development Building, No.1 Shangdi Information Industry Base, Haidian Dist., Beijing, China Product ............................... : LTE Outdoor CPE Model(s). ............................ : EG7010A-M11 Brand Name ....................... : BaiCells Standards........................... : FCC 1.1307 Date of Receipt sample .... : 2019-10-08 Date of Test ....................... : 2019-10-09 to 2019-11-10 Date of Issue ...................... : 2019-11-11 Test Result ......................... : Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Prepared By: Waltek Services (Shenzhen) Co., Ltd. Address: 1/F., Fukangtai Building, West Baima Road, Songgang Street, Baoan District, Shenzhen, Guangdong, China Tel :+86-755-83551033 Fax:+86-755-83552400 Compiled by: Approved by: Ford Wang / Project Engineer Philo Zhong / Manager Reference No.: WTS19S10068895W002 Page 2 of 7 Waltek Services (Shenzhen) Co.,Ltd. http://www.waltek.com.cn 2 Contents Page 1 COVER PAGE ........................................................................................................................................... 1 2 CONTENTS ............................................................................................................................................................ 2 3 REVISION HISTORY ............................................................................................................................................ 3 4 GENERAL INFORMATION .................................................................................................................................. 4 4.1 GENERAL DESCRIPTION OF E.U.T. ................................................................................................................ 4 4.2 DETAILS OF E.U.T. ......................................................................................................................................... 4 5 TEST SUMMARY .................................................................................................................................................. 5 6 RF EXPOSURE ...................................................................................................................................................... 6 6.1 REQUIREMENTS ............................................................................................................................................... 6 6.2 THE PROCEDURES / LIMIT ................................................................................................................................ 6 6.3 MPE CALCULATION METHOD ......................................................................................................................... 7 Reference No.: WTS19S10068895W002 Page 3 of 7 Waltek Services (Shenzhen) Co.,Ltd. http://www.waltek.com.cn 3 Revision History Test report No. Date of Receipt sample Date of Test Date of Issue Purpose Comment Approved WTS19S10068 895W002 2019-10-08 2019-10-09 to 2019-11-10 2019-11-11 original - Valid Reference No.: WTS19S10068895W002 Page 4 of 7 Waltek Services (Shenzhen) Co.,Ltd. http://www.waltek.com.cn 4 General Information 4.1 General Description of E.U.T. Product: LTE Outdoor CPE Model(s): EG7010A-M11 Model Description: NA Storage Location: Internal Storage 4.2 Details of E.U.T. Operation Frequency: LTE Band 48:3550MHz-3700MHz Type of Modulation: LTE: Uplink:QPSK, 16QAM;Downlink: QPSK，16QAM，64QAM Antenna installation: LTE: Internal antenna Antenna Gain: 14dbi Ratings: DC 24V 0.5A Reference No.: WTS19S10068895W002 Page 5 of 7 Waltek Services (Shenzhen) Co.,Ltd. http://www.waltek.com.cn 5 Test Summary Test Items Test Requirement Result Maximum Permissible Exposure (Exposure of Humans to RF Fields) 1.1307(b)(1) PASS Reference No.: WTS19S10068895W002 Page 6 of 7 Waltek Services (Shenzhen) Co.,Ltd. http://www.waltek.com.cn 6 RF Exposure Test Requirement: FCC Part 1.1307 Test Mode: The EUT work in test mode(Tx). 6.1 Requirements Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.2m normally can be maintained between the user and the device. 6.2 The procedures / limit FCC Part 1.1307: (A) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 (B) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz ; *Plane-wave equivalent power density Reference No.: WTS19S10068895W002 Page 7 of 7 Walt…

Text truncated - open the document above for the full version.

DEKRA Certification, Inc 405 Glenn Drive, Suite 12 Sterling · VA 20164 · United States of America Report No: (NIE) 2515bRCB.001 09-12-2019 Test report No: NIE: 2515bRCB.001 Test report Citizen Broadband Radio Service Test report Identification of item tested Citizens Based Category A and B Devices Trademark Baicells Model and /or type reference EG7010A-M11 Other identification of the product FCC ID: 2AG32EG7010AM11 Features ---- Manufacturer Baicells Technologies Co., Ltd. 3F, Hui Yuan Development Building, No.1 Shangdi Information Industry Base, Haidian Dist., Beijing, PR China, 100085. Final HW version A Final SW version CPE: BaiCE_BG_1.2.1 Domain Proxy: BaiOMC Rev-18822 Summary IN COMPLIANCE Approved by (name / position & signature) Domingo Gálvez Dueñas (Lab Manager) Date of issue 09-12-2019 Report template No FDT08_22 DEKRA Certification, Inc 405 Glenn Drive, Suite 12 Sterling · VA 20164 · United States of America Report No: (NIE) 2515bRCB.001 Page 2 of 14 09-12-2019 Index Competences and guarantees .................................................................................................... 3 General conditions ...................................................................................................................... 3 Uncertainty ................................................................................................................................. 4 Data provided by the client .......................................................................................................... 4 Usage of samples ....................................................................................................................... 4 Identification of the client............................................................................................................. 4 Testing period and place ............................................................................................................. 4 Document history ........................................................................................................................ 4 Remarks and comments ............................................................................................................. 5 Testing verdicts ........................................................................................................................... 5 Summary .................................................................................................................................... 5 Appendix A: Test Results ............................................................................................................ 6 Appendix B: Test Systems .......................................................................................................... 9 Appendix C: DUT Photographs ................................................................................................. 10 Appendix D: CBSD/ DP Supported Features ............................................................................ 11 Appendix E: Reference Standards and Procedures .................................................................. 12 Appendix F: Test case descriptions, parameters and test steps ................................................ 14 DEKRA Certification, Inc 405 Glenn Drive, Suite 12 Sterling · VA 20164 · United States of America Report No: (NIE) 2515bRCB.001 Page 3 of 14 09-12-2019 Competences and guarantees DEKRA Certification Inc. is a testing laboratory accredited by A2LA (The American Association for Laboratory Accreditation), to perform the tests indicated in the Certificate 2764.01. DEKRA Certification, Inc. is a CBRS Alliance authorized test laboratory. DEKRA Certification, Inc. is a WInnForum Approved CBSD test laboratory. In order to assure the traceability to other national and international laboratories, DEKRA Certification, Inc. has a calibration and maintenance program for its measurement equipment. DEKRA Certification, Inc. guarantees the reliability of the data presented in this report, which is the result of the measurements and the tests performed to the item under test on the date and under the conditions stated on the report and, it is based on the knowledge and technical facilities available at DEKRA Certification, Inc. at the time of performance of the test. DEKRA Certification, Inc. is liable to the client for the maintenance of the confidentiality of all information related to the item under test and the results of the test. The results presented in this Test Report apply only to the particular item under test established in this document. IMPORTANT: No parts of this report may be reproduced or quoted out of context, in any form or by any means, except in full, without the previous written permission of DEKRA Certification, Inc. General conditions 1. This report is only referred to the item that has undergone the test. 2. This report does not constitute or imply on its own an approval of the product by the Certification Bodies or competent Authorities. 3. This document is only valid if complete; no partial reproduction can be made without previous written permission of DEKRA Certification, Inc. 4. This test report cannot be used partially or in full for publicity and/or promotional purposes without previous written permission of DEKRA Certification, Inc and the Accreditation Bodies. DEKRA Certification, Inc 405 Glenn Drive, Suite 12 Sterling · VA 20164 · United States of America Report No: (NIE) 2515bRCB.001 Page 4 of 14 09-12-2019 Uncertainty Uncertainty (factor k=2) was calculated according to the DEKRA Certification, Inc internal document PODT000. Data provided by the client DEKRA declines any responsibility with respect to the information provided by the client and that may affect the validity of results. Usage of samples Samples undergoing test have been selected by: Baicells Technologies, Inc. Sample M/01 is composed of the following elements: Control Nº Descripti on Model Serial Nº…

Text truncated - open the document above for the full version.

DEKRA Certification, Inc 405 Glenn Drive, Suite 12 Sterling · VA 20164 · United States of America Report No: (NIE) 02515BRCB.003 2019-Dec-26 Test report No: NIE: 02515BRCB.003 Test report Test and Certification for Citizens Broadband Radio Service ( CBRS): 940660 D02 CPE-CBSD Handshake Procedures Identification of item tested CBRS CPE-CBSD Trademark Baicells Model and /or type reference EG7010A-M11 Other identification of the product FCC ID: 2AG32EG7010AM11 Features CPE-CBSD with Domain Proxy Final HW Version: A Final SW Version: Domain Proxy:BaiOMC Rev-18822 CPE-CBSD: BaiCE_BG_1.2.1 Manufacturer Baicells Technologies Co., Ltd. 3F, Hui Yuan Development Building, No.1 Shangdi Information Industry Base, Haidian Dist., Beijing, PR China, 100085. Test method requested, standard 940660 D02 CPE-CBSD Handshake Procedures Approved by (name / position & signature) Gonzalo Casado (Lab Manager) Date of issue 2019-Dec-26 Report template No FDT08_22 DEKRA Certification, Inc 405 Glenn Drive, Suite 12 Sterling · VA 20164 · United States of America Report No: (NIE) 02515BRCB.003 Page 2 of 31 2019-Dec-26 Index Competences and guarantees ............................................................................................................ 3 General conditions ........................................................................................................................... 3 Abbreviations .................................................................................................................................. 4 Data provided by the client ............................................................................................................... 4 Usage of samples ............................................................................................................................. 4 Identification of the client ................................................................................................................. 4 Testing period and place ................................................................................................................... 4 Document history ............................................................................................................................ 4 Remarks and comments ................................................................................................................... 5 List of equipment used during the test ............................................................................................... 6 Test Setup Diagram ......................................................................................................................... 7 Testing verdicts ............................................................................................................................... 7 Test Results Summary ..................................................................................................................... 7 Appendix A: Test results .................................................................................................................. 8 Appendix B: Photographs ................................................................................................................. 9 Appendix C: Test Cases Details ........................................................................................................ 9 Appendix D: Spectrum Analyzer Screenshots .................................................................................. 11 DEKRA Certification, Inc 405 Glenn Drive, Suite 12 Sterling · VA 20164 · United States of America Report No: (NIE) 02515BRCB.003 Page 3 of 31 2019-Dec-26 Competences and guarantees DEKRA Certification Inc. is a testing laboratory competent to carry out the tests described in this report. In order to assure the traceability to other national and international laboratories, DEKRA Certification has a calibration and maintenance program for its measurement equipment. DEKRA Certification guarantees the reliability of the data presented in this report, which is the result of the measurements and the tests performed to the item under test on the date and under the conditions stated on the report and, it is based on the knowledge and technical facilities available at DEKRA Certification at the time of performance of the test. DEKRA Certification is liable to the client for the maintenance of the confidentiality of all information related to the item under test and the results of the test. The results presented in this Test Report apply only to the particular item under test established in this document. IMPORTANT: No parts of this report may be reproduced or quoted out of context, in any form or by any means, except in full, without the previous written permission of DEKRA Certification. General conditions 1. This report is only referred to the item that has undergone the test. 2. This report does not constitute or imply on its own an approval of the product by the Certification Bodies or competent Authorities. 3. This document is only valid if complete; no partial reproduction can be made without previous written permission of DEKRA Certification. 4. This test report cannot be used partially or in full for publicity and/or promotional purposes without previous written permission of DEKRA Certification and the Accreditation Bodies. DEKRA Certification, Inc 405 Glenn Drive, Suite 12 Sterling · VA 20164 · United States of America Report No: (NIE) 02515BRCB.003 Page 4 of 31 2019-Dec-26 Abbreviations Abbreviation Meaning CBRS Citizens Broadband Radio Services CBSD Citizens Broadband Radio Service Device DP Domain Proxy DUT Device Under Test SAS Spectrum Access System UUT Unit Under Test CPI Certified Professional Installer N/A Not Applicable SA Spectrum Analyzer Data provided by the client DEKRA declines any responsibility with respect to the information provided by the client and that may affect the validity of results. Information provided by the clie…

Text truncated - open the document above for the full version.

Waltek Services (Shenzhen) Co.,Ltd. http://www.waltek.com.cn Page 1 of 78 TEST REPORT Reference No. .................... : WTS19S10068895W001 V1 FCC ID ................................ : 2AG32EG7010AM11 Applicant ............................ : Baicells Technologies Co., Ltd. Address .............................. : 3F, Hui Yuan Development Building, No.1 Shangdi Information Industry Base, Haidian Dist., Beijing, China Manufacturer .................... : Baicells Technologies Co., Ltd. Address .............................. : 3F, Hui Yuan Development Building, No.1 Shangdi Information Industry Base, Haidian Dist., Beijing, China Product ............................... : LTE Outdoor CPE Model(s). ............................ : EG7010A-M11 Brand Name ....................... : BaiCells Standards........................... : FCC CFR Title 47 Part 2 FCC CFR Title 47 Part 96 Date of Receipt sample .... : 2019-10-08 Date of Test ....................... : 2019-10-09 to 2019-11-10 Date of Issue ...................... : 2020-01-14 Test Result ......................... : Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Prepared By: Waltek Services (Shenzhen) Co., Ltd. Address: 1/F., Fukangtai Building, West Baima Road, Songgang Street, Baoan District, Shenzhen, Guangdong, China Tel :+86-755-83551033 Fax:+86-755-83552400 Compiled by: Approved by: Ford Wang / Project Engineer Philo Zhong / Manager Reference No.: WTS19S10068895W001 V1 Page 2 of 78 Waltek Services (Shenzhen) Co.,Ltd. http://www.waltek.com.cn 2 Contents Page 1 COVER PAGE ...................................................................................................................................... 1 2 CONTENTS ............................................................................................................................................................ 2 3 REVISION HISTORY ............................................................................................................................................ 4 4 GENERAL INFORMATION .................................................................................................................................. 5 4.1 GENERAL DESCRIPTION OF E.U.T. ............................................................................................................... 5 4.2 DETAILS OF E.U.T. .…

Text truncated - open the document above for the full version.
