2AG4FPOS88VBTFReceipt Printer

SPRT ® SP-POS88VThermal Receipt Printer User’s Manual （Ver 1.00） Beijing Spirit Technology Development Co., Ltd Address: No.26,Ave 4,Chuangye Middle Road, Shangdi Information Industry Park , Beijing, China Post Code:100085 Tel:+861051661178 Fax:+861051661178-190 E-mail: [email protected] Content Introduction ...................................................................................................................................... 3 Chapter 1 Feature and Performance ........................................................................................... 3 1.1 Print Performance ............................................................................................................... 3 1.2 Print Paper ........................................................................................................................... 4 1.3 Print Font ............................................................................................................................ 4 1.4 Interface .............................................................................................................................. 5 1.5 Print Control Commands..................................................................................................... 5 1.6 Power Supply ...................................................................................................................... 6 1.7 Operation Environment ....................................................................................................... 6 1.8 Outline Dimension .............................................................................................................. 6 1.9 Model classification ............................................................................................................ 6 Chapter 2 Operation Specification ............................................................................................... 7 2.1 Printer Appearance .............................................................................................................. 7 2.2 Paper Installation ................................................................................................................. 8 2.2.1 Paper Loading ....................................................................................................... 8 2.2.2 Solution to Paper Jam ......................................................................................... 8 2.3 Interface .............................................................................................................................. 9 2.3.1 Serial Interface ...................................................................................................... 9 2.3.2 Parallel Interface ................................................................................................. 11 2.3.3 BLUETOOH interface connection .................................................................... 14 2.3.4 BLUETOOH binding address ............................................................................ 15 2.3.5 Cash Drawer Interface ....................................................................................... 16 2.3.6 Power Connection .............................................................................................. 17 2.4 Buttons and Indicators ...................................................................................................... 18 2.5 Self-test ............................................................................................................................. 18 2.6 Hexadecimal Printing ........................................................................................................ 19 Introduction POS88Vprinter is a new type line thermal printer, it features in fast speed print, low print noise, high reliability, perfect print quality and ribbon needless, avoiding the vexation of regular maintenance. POS88Vprinter: small in outline dimension, simple operation, and extensive application, especially suitable for commercial cash register, PC-POS, bank POS and all kinds of receipts print. Chapter 1 Feature and Performance 1.1 Print Performance ● Print method: direct thermal ● Print paper width: 79.5±0.5mm ● Print density: 8 dots/mm, 576 dots/line ● Print speed: approx.250mm／sec. ● Reliability (1)Print head life: 100km Warning This is a class A product. In a domestic environment this produ ct may cause radio interference in which case the user may be required to take adequate measures. Using condition: ＊Print 12 × 24 ASCII characters, print 50 lines each time, intermittent print repeatedly ＊Each dot-line printing at the same time should not exceed 25%, each character line and one dot vertical printing repeatedly should not exceed 11 times ＊Use specified thermal paper （2）Cutter life: 500,000 cuts Using condition: less than 30 cuts/minute ● Valid print width: 72mm 1.2 Print Paper ● Thermal paper roll model: TF50KS－E（Japan paper co.ltd） AF50KS-E (JUJO THERMAL) ● Thermal paper roll: Width－－－ 79.5±0.5mm Outer Diameter －－－ 80mm（max.） Inner Diameter－－－ 13mm（min.） Thickness －－－ 0.06mm～0.08mm 1.3 Print Font ● ANK Character Set 12×24 dots，1.5（W）×3.00（H）mm ● GB GB2312-80(Chinese): 24×24 dots，3.00（W）×3.00（H）mm. 1.4 Interface ● RS－232C Serial Interface： DB-25 socket (female), supports XON/XOFF and TR/DSR protocols. Baudrate: 2400, 4800, 9600, 19200, 38400, 57600, 115200bps adjustable. Data structure: 1start bit + (7 or 8) data bits + 1 stop bit. Parity checking: no parity or odd, even parity optional. ● Parallel Interface 36-pin，8-bit parallel interface，BUSY/ACK handshaking protocol, TTL signal level. ● Ethernet Interface: Normal ethernet interface. ● USB Interface：USB interface ● Cash Drawer Control DC24V，1A，6-pin RJ-11 socket. 1.5 Print Control Commands ● Character print commands: support double-width, double height print of ANK characters, user-defined characters and Chinese characters, the character line spacing is adjustab…

Text truncated - open the document above for the full version.

Beijing Spirit Technology Development Co., Ltd Agent Authorization Letter 2015/12/26 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen BCTC Technology Co., Ltd to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Client’s name / title : David Peng / Manager Contact information / address: No.26 Ave.4, Chuangye Middle Road, Shangdi Information Industry Park, Beijing, China

Beijing Spirit Technology Development Co., Ltd Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: SUBJECT: FCC Application for (FCC ID: 2AG4FPOS88VBTF) To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite device. We understand that devices subject to the DoC procedure are required to be tested to show compliance with the FCC technical regulations by a recognized accredited testing laboratory. The testing laboratory must be accredited by a Commission approved accreditation body or designated under the terms of a government-to-government Mutual Recognition Agreement (MRA). A listing of those accredited testing laboratories that have been recognized by the Commission is published on the FCC Webpage: https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm Select the "accredited" option to search for FCC recognized accredited test firms. Test facilities located in countries, where the U.S. does not have an operational Telcom MRA are not recognized by the FCC to test for the DoC procedure. Testing laboratory: The Hong Kong Standards and Testing Centre Ltd.( 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong FCC registration number: 607756 Name: Wilson Wong Tel: 852-2666-1888) Regards, Signatory Client’s name / title : David Peng / Manager Contact information / address: No.26 Ave.4, Chuangye Middle Road, Shangdi Information Industry Park, Beijing, China

Beijing Spirit Technology Development Co., Ltd Long Term Confidentiality Request Letter 2015/12/26 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR EUT NAME: Receipt Printer MODEL : SP-POS88VBTF, SP-POS88VIBTF FCC ID: 2AG4FPOS88VBTF To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - Block Diagram - Schematics - Operational Description required to be submitted with this application be permanently withheld from public review. SPECIFY REASON FOR REQUEST (i.e. the above documents are company proprietary information that could never get into the possession of your competition). Please contact me if there is any information you may need. Sincerely, Client’s name / title : David Peng / Manager Contact information / address: No.26 Ave.4, Chuangye Middle Road, Shangdi Information Industry Park, Beijing, China

Beijing Spirit Technology Development Co., Ltd Model Difference FCC ID: 2AG4FPOS88VBTF Model : SP-POS88VBTF SP-POS88VIBTF All the models are the same circuit and RF module, except the model names and outlook color. Regards Sincerely Client’s signature Client’s name / title : David Peng / Manager Contact information / address: No.26 Ave.4, Chuangye Middle Road, Shangdi Information Industry Park, Beijing, China

M/N: SP-POS88VBTF FCC ID: 2AG4FPOS88VBTF This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Label location

Antenna location

Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-151216003 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http://www.bctc-lab.com.cn Page 1 of 35 FCC Part 15C Test Report FCC ID: 2AG4FPOS88VBTF Product Name: Receipt Printer Trademark: SPRT Model Name : SP-POS88VBTF SP-POS88VIBTF Prepared For : Beijing Spirit Technology Development Co., Ltd Address : No.26 Ave.4, Chuangye Middle Road, Shangdi Information Industry Park, Beijing, China Prepared By : Shenzhen BCTC Technology Co., Ltd. Address : No.101,Yousong Road,Longhua New District, Shenzhen,China Test Date: Dec. 21 – Dec. 25, 2015 Date of Report : Dec. 25, 2015 Report No.: BCTC-151216003 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-151216003 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http://www.bctc-lab.com.cn Page 2 of 35 VERIFICATION OF COMPLIANCE Applicant’s name ................. : Beijing Spirit Technology Development Co., Ltd Address ................................. : No.26 Ave.4, Chuangye Middle Road, Shangdi Information Industry Park, Beijing, China Manufacture's Name ............ : Beijing Spirit Technology Development Co., Ltd Address ................................. : No.26 Ave.4, Chuangye Middle Road, Shangdi Information Industry Park, Beijing, China Product description Product name ........................... : Receipt Printer Trademark: SPRT Model Name: SP-POS88VBTF SP-POS88VIBTF Test procedure FCC Part15.249 Standards ANSI C63.10-2013 This device described above has been tested by BCTC, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BCTC, this document may be altered or revised by BCTC, personal only, and shall be noted in the revision of the document. Test Result ............................................... : Pass Testing Engineer : (Eric Yang) Technical Manager : (Sophia Lee) Authorized Signatory : (Carson. Zhang) Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-151216003 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http://www.bctc-lab.com.cn Page 3 of 35 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 4 1.1 TEST FACILITY 4 1.2 MEASUREMENT UNCERTAINTY 4 2 . GENERAL INFORMATION 5 2.1 GENERAL DESCRIPTION OF EUT 5 2.2 DESCRIPTION OF TEST MODES 6 2.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 7 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 7 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 8 3 . EMC EMISSION TEST 9 3.1 RADIATED EMISSION MEASUREMENT 13 3.1.1 RADIATED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 15 3.1.5 EUT OPERATING CONDITIONS 16 3.1.6 TEST RESULTS 17 4 . BANDWIDTH TEST 23 4.1 APPLIED PROCEDURES / LIMIT 23 4.1.1 TEST PROCEDURE 23 4.1.2 DEVIATION FROM STANDARD 23 4.1.3 TEST SETUP 23 4.1.4 EUT OPERATION CONDITIONS 23 4.1.5 TEST RESULTS 24 5 . BANDWIDTH OF FREQUENCY BAND EDGE 30 5.1 DEVIATION FROM STANDARD 30 5.2 TEST SETUP 30 5.3 EUT OPERATION CONDITIONS 30 5.4 TEST RESULTS 31 6 . ANTENNA REQUIREMENT 32 6.1 STANDARD REQUIREMENT 32 6.2 EUT ANTENNA 32 7 . EUT TEST PHOTO 33 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-151216003 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http://www.bctc-lab.com.cn Page 4 of 35 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.249) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.249 Radiated Spurious Emission PASS 15.249 Bandwidth PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report 1.1 TEST FACILITY Shenzhen BCTC Technology Co., Ltd. Add.:No.101,Yousong Road,Longhua New District, Shenzhen,China FCC Registration No.:187086 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-151216003 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http://www.bctc-lab.com.cn Page 5 of 35 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Receipt Printer Trade Name SPRT Model Name SP-POS88VBTF SP-POS88VIBTF Product Description Operation Frequency: 2402~2480 MHz Modulation Type: GFSK,PI/4 DPSK,8DPSK Bit Rate of Transmitter 1M/2M/3Mbps Number Of Channel 79 CH Antenna Designation: Please see Note 3. Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an ITE/Computing Device. More details of EUT technical specification, please refer to the User's Manual. Channel List Please refer to the Note 2. Adapter DC 24V from adapter input AC 120V/60Hz Battery N/A Connecting I/O Port(s) Please refer to the User's Manual hardware version -- Software version -- Serial number -- Note: 1. For a more detailed features description, please re fer to the manufacturer’s specifications or the User's Manual. 2. Channel List Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 00 2402 27 2429 54 2456 01 2403 28 2430 55 2457 02 2404 29 2431 56 2458 03 2405 30 2432 57 2459 04 2406 31 2433 58 2460 05 2407 32 2434 59 2461 06 2408 33 2435 60 2462 07 2409 34 2436 61 2463 08 2410 35 2437 62 2464 09 2411 36 2438 63 2465 10 2412 37 2439 64 2466 11 2413 38 2440 65 2467 12 2414 39 2441 66 2468 13 2415 40 2442 67 2469 Shenzhen BCTC Technology Co., Ltd. Report No.: BCTC-151216003 FCC Report Tel: 400-788-9558 0755-33019988 Web:Http://www.bctc-lab.com.cn Page 6 of 35 14 2416 41 2443 68 2470 15 2417 42 2444 69 2471 16 2418 43 244…

Text truncated - open the document above for the full version.

Radiated Emission Conducted Emission
