AFP1 - SmartTool SHORT INSTRUCTION MANUAL General description Congratulations on your purchase of a ROTRONIC AFP1 probe. Please read this short operating instructions carefully before putting the unit into operation. The document is limited to the description of the main features and the installation of the device. The AFP1 probe measures along with humidity and temperature also wind speeds of 0.5 to 20 m/s. Dimensions Energy supply The AFP1 is powered by two CR2032 button batteries. When inserting or replacing the batteries, place them on top of each other in the battery compartment slide (observe polarity). Device Operation via multifunction key The AFP1 features a multifunction button, which is located on the front, below the sensor head. The following functions are controlled via the button: - Switch on with auto-power-off after 5 minutes - Switch on - Switch off - Calibration mode humidity 32.8 %RH (green LED blinking) 32.8 %RH OK! (green and red LED on) 75.2 %RH (red LED blinking) Measure mode (auto-power-off after 5 min) Power OFF Measure mode 2s < PRESS < 8s PRESS < 1s PRESS > 2s PRESS > 2s After 30min PRESS < 1s PRESS > 10s After 30min PRESS > 2s Humidity adjustment mode AFP1 on the Smart Device After commissioning of AFP1 the LED should light up green. The device is now switched on and ready to perform measurements. To measure wind speeds ensure that the wind turbine rotates freely and the sign “AIR IN" points in the direction of the measured air flow. Operation of AFP1 sensor via the ROTRONIC smartphone application “ROTRONIC" which is available in the App Store (iOS) or in Play Store (Android) for free. Use the app to display, log and send the desired measurement values by email. Furthermore, among other things, measurement-specific settings and options can be set. The “ROTRONIC" APP Bluetooth To connect the AFP1 with the app, please ensure that the Bluetooth function of your smartphone is enabled. Home The current measured values are displayed on the home screen of the AFP1. Furthermore, you can reach further sub-menus or features: - Device overview - Menu - Picture mode - Graphical mode - Parameter settings - Parameter units Data recording Device overview Connected devices appear in the “Device Overview”. Features: - Rename devices - Select displayed device Menu Home View current measuring values Data export Export saved data Feedback Send feedback to ROTRONIC About TOTRONIC contact information Parameter settings To make alarms or parameters specific settings, just click the appropriate parameter on the home screen. Features: - Set high and low alarms - Parameter-specific settings Picture mode The “Picture Mode” has been implemented to photograph specific measuring points at which the measurements are saved directly on the photo. Graphical mode In the “Graphical Mode” the current measured values can be graphically displayed and viewed. To toggle the visibility of a certain curve click on the corresponding parameter symbol. Data export Stored data will be saved in the “Data Export” menu and can be renamed, deleted, or sent via e-mail. About The menu "About" includes contact information of all ROTRONIC AG offices. - Street address - Phone number - Website - E-mail address FCC Caution Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Technical specifications General Sensor type Vane anemometer ROTRONIC HYGROMER® IN-1 NTC Measuring range 0.5...20 m/s 0...100 %RH -20...60 °C Accuracy ±(3 %reading + 0.2 m/s) ±3 %RH (at 25°C) ±0,3 K (at -20...50°C) Log interval 1 s LED 1 dual color LED Red: Battery level too low to maintain proper operation Green: Battery and communication normal Power supply 2 x 3 V CR2032 batteries Power consumption <5.3 mA Dimensions measuring head 150 x ø18 mm or 150 x ø28 mm Dimensions telescopic stick Retracted: 0,55 m Withdrawn: 1,2 m Weight xxx Software „ROTRONIC“ App (iOS, Android) Delivery Factory certificate Short manual instructions APP (online) Soft case Batteries 2 x 3 V (CR2032) ROTRONIC AG, CH-8303 Bassersdorf Tel. +41 44 838 11 44, www.rotronic.com ROTRONIC Messgeräte GmbH, D-76275 Ettlingen Tel. +49 7243 383 250, www.rotronic.de ROTRONIC SARL, 56, F - 77183 Croissy Beaubourg Tél. +33 1 60 95 07 10, www.rotronic.fr ROTRONIC Italia srl, I- 20157 Milano Tel. +39 2 39 00 71 90, www.rotronic.it ROTRONIC Instruments (UK) Ltd, West Sussex RH10 9EE Phone +44 1293 571000, www.rotronic.co.uk ROTRONIC Instrument Corp, NY 11788, USA Phone +1 631 427-3898, www.rotronic-usa.com ROTRONIC Canada Inc.,Canada L8W 3P7 Phone + 1 416-848-7524, www.rotronic.ca ROTRONIC Instruments Pte. Ltd., Singapore 159836 Phone +65 6376 2107, www.rotronic.sg ROTRONIC Shanghai Rep. Office, Shanghai 200233, China Phone +86 40 08162018, www.rotronic.cn Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: -Reorient or relocate the receiving antenna. …
