REMOTE CONTROL DC-IN SPREAD SIZE 54.5CM X11.3CM FOLDED SIZE 7.8 CM X11.3CM EN DC-IN FR DC-IN DE Package Contents: Aurora User Manual Remote control Type-C Charging cable Application: Bluetooth devices,etc. Contenu de l'emballage: Haut-parleur Bluetooth Manuel de l'utilisateur Télécommande Câble de charge de type C Application: Appareils Bluetooth,etc Packungsinhalt: Bluetooth-Lautsprecher Benutzerhandbuch Fernbedienung Typ-C-Ladekabel Anwendung: Bluetooth - Geräte usw.

External Photos ALL VIEW OF EUT TOP VIEW OF EUT BOTTOM VIEW OF EUT FRONT VIEW OF EUT BACK VIEW OF EUT LEFT VIEW OF EUT RIGHT VIEW OF EUT

FCC ID Label Location FCC ID:2AG5A-AURORA This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Internal Photos OPEN VIEW OF EUT-1 INTERNAL VIEW OF EUT-1 INTERNAL VIEW OF EUT-2 Antenna INTERNAL VIEW OF EUT-3 INTERNAL VIEW OF EUT-4 INTERNAL VIEW OF EUT-5 INTERNAL VIEW OF EUT-6

Declaration concerning Antenna Specification It is hereby declared that the product Model No.: Aurora FCC ID: 2AG5A-AURORA fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for internal antenna type(s) described below: Type of antenna: PCB Antenna Gain of the antenna: 2.3 dBi Frequency range: 2.402 GHz to 2.480GHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: BrandCharger Ltd Address: Flat H, 7/F, Mai Luen Industrial Building, 23 Kung Yip Street, Kwai Chung, Hong Kong Place: Hong Kong Date: 2020-01-08 Signature:

RF EXPOSURE EVALUATION 1. PRODUCT INFORMATION Product Description Wireless Speaker Model Name Aurora FCC ID 2AG5A-AURORA 2. EVALUATION METHOD According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR. Where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation 3. CALCULATION P t =5.722dBm=3.73mW The value of the Maximum output power P t is referred to the test report of the CFR47 §15.247. The result for RF exposure evaluation SAR=(3.73mW /5mm) .[√2.48(GHz)]= 1.17<3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR. 4. CONCLUSION The SAR evaluation is not required.
