2AG5U-BIS6380EEmbedded computer

BIS-6380E USER' Manual V1.0 SZ HQ: 0755-27331166 Beijing Office: 010-82671166 Shanghai Office: 021-61212081 Chengdu Office: 028-85259319 Shenyang Office: 024-23960846 Xi’an Office: 029-88338386 Nanjing Office: 025-58015489 Wuhan Office: 027-87858983 Tianjin Office: 022-23727100 Singapore: 65-68530809 Netherland: 31-040-2668554 For more information, please visit www.norco-group.com BIS-6380E USER' Manual V1.0 Disclaimer Except for the accessories attached to the product as specified herein, what is contained in this user manual does not represent the commitments of NORCO Company. NORCO Company reserves the right to revise this User Manual, without prior notice, and will not be held liable for any direct, indirect, intended or unintended losses and/or hidden dangers due to installation or improper operation. Before ordering products, please learn about the product performance from the distributors to see if it is in line with your needs. NORCO is a registered trademark of Shenzhen NORCO Intelligent Technology CO., LTD. The ownership of other trademarks involved in this manual is owned by its respective owners. The contents of this manual are protected by copyright law. All rights are strictly reserved. Any form of unauthorized reproduction including but not limited to carbon copy, facsimile transmission and electronic copy or email is prohibited. Safety Instructions 1. Please read the product manual carefully before using this product. 2．Put all the unused or uninstalled boards or electronic components in a static dissipative surface or static shielding bag. 3．Always ground yourself to remove any static discharge before touching the board, to place your hands on grounding metal object for a while or wear a anti-static wrist strap at all times. 4．When taking or fetching the boards or cards, please wear antistatic gloves and have the habit of holding the boards by its edges. 5．Make sure that your power supply is set to the correct voltage in your area. Incorrect voltage may cause personal injuries and damage the system. 6．To prevent electronic shock hazard or any damage to the product, please ensure that all power cables for the devices are unplugged when adding or removing any devices or reconfiguring the system. 7．To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. 8．When adding or removing devices to or from the system, ensure that all the power cables for the devices are unplugged in advance. 9．To prevent any unnecessary damage to the products due to frequent power on/off, please wait at least 30 seconds to restart the unit after the shutdown. 10．If system goes wrong during the operation, do not try to fix it by yourself. Contact a qualified service technician or your retailer. 11．This product is classified as Class A product, which may cause radio interference in our living environment. On this occasion, users need to take measures to handle the interference. CONTENT Chapter 1 Product Introduction ................................................................................................ 1 1.1 Overview .................................................................................................................... 1 1.2 Specifications ............................................................................................................. 1 1.3 Product Structure Size ................................................................................................ 1 Chapter 2 Hardware Introduction ............................................................................................. 3 2.1 External Interfaces Location ....................................................................................... 3 2.2 Front Panel I/O Connectors ........................................................................................ 4 2.2.1 Audio（Speak-out, Mic-in） .............................................................................. 4 2.2.2 LED .................................................................................................................. 4 2.2.3 Serial Ports（COM1-COM8） .......................................................................... 5 2.2.4 USB .................................................................................................................. 5 2.2.5 Ethernet（LAN） .............................................................................................. 6 2.3 Jumper Setting ........................................................................................................... 6 2.3.1 Jumper Function Setting（JP1） ...................................................................... 6 2.4 Inner Interface Instruction ........................................................................................... 7 2.4.1 Serial Port（COM_DB） ................................................................................... 8 2.4.2 SATA Interface（SATA、J16） ......................................................................... 8 2.4.3 USB Interface（USB5-7，USB_HDMI，USB_LAN, USB89） ......................... 9 2.4.4 Ethernet Interface（LAN） ............................................................................. 10 2.4.5 Audio Interface（ AUDIO、J18）................................................................... 11 2.4.6 Display Interface（LVDS、 HDMI、VGA） .................................................... 12 2.4.7 Power Interface（PWR、PWR1、PW2） ...................................................... 14 2.4.8 Power and System LED (LED2、LED3）： ..................................................... 14 2.4.9 Four-wire Resistive Touch（J4） .................................................................... 15 2.4.10 GPIO Expansion Slot（J10）： ...................................................................... 16 4.4.11 Front Panel Interface (PWRSW、RSTSW): .................................................. 16 2.4.12 EXP_CON Interface ...........................…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 ShenZhen NORCO Intelligent Technology Co.,LTD. 2015-12-31 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, ____ ShenZhen NORCO Intelligent Technology Co.,LTD.__ _hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product： Embedded computer Trade Name： NORCO Model Name： BIS-6380E Serial Model： HR-6566 FCC ID： 2AG5U-BIS6380E Sincerely, Signature Client’s name / title : Zhang Bing / Engineer Contact information / address : 6th Fl., Blg A,Taohuayuan Hi-tech Innovation Park, XiXiang, Shenzhen 518102,China

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (obsolete) 3.0 4.0 March-26-2015 Corrections to STC form. Added reference to KDB (current) 4.0 5.0 Nov 19 2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 5.0 ShenZhen NORCO Intelligent Technology Co.,LTD. 2015-12-31 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AG5U-BIS6380E Pursuant to sections 0.457 and 0.459 of CFR 47, we respectfully request permanent confidential treatment of the following Exhibits accompanying this application as: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Signature Client’s name / title : Zhang Bing / Engineer Contact information / address : 6th Fl., Blg A,Taohuayuan Hi-tech Innovation Park, XiXiang, Shenzhen 518102,China

ShenZhen NORCO Intelligent Technology Co.,LTD. Model Difference FCC ID: 2AG5U-BIS6380E Model : BIS-6380E, HR-6566 All the model are the same circuit and RF module, except the model name. Regards, Client’s signature Signature Client’s name / title : Zhang Bing / Engineer Contact information / address : 6th Fl., Blg A,Taohuayuan Hi-tech Innovation Park, XiXiang, Shenzhen 518102,China

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Photo 8

FCC ID LABELING AND LOCATION FCC ID Label Embedded computer Model NO.: BIS-6380E FCC ID: 2AG5U-BIS6380E This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Wifi ANT Photo 3 Photo 4 Photo 5 Photo 6

Page 1 of 23 Report No.: NTEK-2015NT11173139E FCC EMC Test Report FCC ID:2AG5U-BIS6380E Product: Embedded computer Trade Name: NORCO Model Number: BIS-6380E, HR-6566 Prepared for ShenZhen NORCO Intelligent Technology Co.,LTD. 6th Fl., Blg A,Taohuayuan Hi-tech Innovation Park, XiXiang, Shenzhen 518102,China Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website: www.ntek.org.cn Page 2 of 23 Report No.: NTEK-2015NT11173139E TEST RESULT CERTIFICATION Applicant’s name ................. : ShenZhen NORCO Intelligent Technology Co.,LTD Address ................................. : 6th Fl., Blg A, Taohuayuan Hi-tech Innovation Park, XiXiang, Shenzhen 518102, China Manufacturer's Name .......... : ShenZhen NORCO Intelligent Technology Co.,LTD Address ................................. : 6th Fl., Blg A, Taohuayuan Hi-tech Innovation Park, XiXiang, Shenzhen 518102, China Product description Product name ........................... : Embedded computer Model and/or type reference : BIS-6380E, HR-6566 Standards ............................. : 47 CFR FCC part15 subpart B, 10-1-2015 ANSI C63.4:2014 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with Part 15 of FCC Rules. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personal only, and shall be noted in the revision of the document. Date of Test ............................................ : Date (s) of performance of tests ............. : 19 Nov. 2015~08 Dec. 2015 Date of Issue ........................................... : 08 Dec. 2015 Test Result ............................................... : Pass Testing Engineer : (Bing He) Technical Manager : (Jane Lv) Authorized Signatory : (Sam Chen) Page 3 of 23 Report No.: NTEK-2015NT11173139E Table of Contents Page 1 . TEST SUMMARY 4 1.1 TEST FACILITY 5 1.2 MEASUREMENT UNCERTAINTY 5 2 . GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 DESCRIPTION OF TEST MODES 7 2.3 DESCRIPTION OF TEST SETUP 8 2.4 DESCRIPTION TEST PERIPHERAL AND EUT PERIPHERAL 9 2.5 MEASUREMENT INSTRUMENTS LIST 10 3 . EMC EMISSION TEST 11 3.1 CONDUCTED EMISSION MEASUREMENT 11 3.1.1 POWER LINE CONDUCTED EMISSION 11 3.1.2 TEST PROCEDURE 12 3.1.3 TEST SETUP 12 3.1.4 EUT OPERATING CONDITIONS 12 3.1.5 TEST RESULTS 13 3.2 RADIATED EMISSION MEASUREMENT 17 3.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT 17 3.2.2 TEST PROCEDURE 17 3.2.3 TEST SETUP 18 3.2.4 EUT OPERATING CONDITIONS 18 3.2.5 TEST RESULTS 19 3.2.6 TEST RESULTS(Above 1GHz) 21 4 . EUT TEST PHOTO 22 Page 4 of 23 Report No.: NTEK-2015NT11173139E 1. TEST SUMMARY Test procedures according to the technical standards: EMC Emission Standard Test Item Limit Judgment Remark FCC part15 subpart B, 10-1-2015 ANSI C63.4: 2014 Conducted Emission Class B PASS Radiated Emission Class B PASS NOTE: (1) ’N/A’ denotes test is not applicable in this Test Report (2) For client’s request and manual description, the test will not be executed. Page 5 of 23 Report No.: NTEK-2015NT11173139E 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration Number:238937; IC Registration Number:9270A-1 CNAS Registration Number:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %. A. Conducted Measurement : Test Site Method Measurement Frequency Range U，(dB) NOTE NTEKC01 ANSI 150 kHz ~ 30MHz 3.6 B. Radiated Measurement : Test Site Method Measurement Frequency Range U，(dB) NOTE NTEKA01ANSI 30MHz ~ 1000MHz 4.8 1GHz ~13GHz 4.5 Page 6 of 23 Report No.: NTEK-2015NT11173139E 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Embedded computer Model Name BIS-6380E Additional Model Number(s) HR-6566 Model Difference All the model are the same circuit and RF module, except the model name. Product Description The EUT is an Embedded compute r. Operating f requency:2.462GHz Connecting I/O port:COM, USB, OTG, LAN, MIC, VGA, HDMI Based on the application, features, or specification exhibited in User's Manual, the EUT is considered as an ITE/Computing Device. More details of EUT technical specification, please refer to the User's Manual. Power Source AC Voltage Power Rating Input: AC 100-240V, 50/60Hz, 2A Output: DC 12V, 5A Page 7 of 23 Report No.: NTEK-2015NT11173139E 2.2 DESCRIPTION OF TEST MODES To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-scanning tested base on the consideration of following EUT operation mode or test configuration mode which possible have effect on EMI emission level. Each of these EUT operation mode(s) or test configuration mode(s) mentioned above was evaluated respectively. Pretest Mode Description Mode 1 Working For Conducted Test Final Test Mode Description Mode 1 Working For Radiated Test Final Test Mode Description Mode 1 Working Page 8 of 23 Report No.: NTEK-2015NT11173139E 2.3 DESCRIPTION OF TEST SETUP Mode CE: Working C-2 0.8m 0.1m 0.1m 1.5m AC Line E-3 Monitor Table E-1 EUT E-2 Adapter LISN C-1 0.1m E-4 Printer C-3 E-5 Earphone E-6 KB E-7 Mouse C-4 C-5C-6 Page 9 of 23 Report No.: NTEK-2015NT11173139E 2.4 DESCRIPTION TEST PERIPHERAL AND EUT PERIPHERAL The EUT has been tested as an independent unit together with other necessary accessories or support units. The following support units or accessories were used to form a representative test configuration during the tests. Item Equipment Brand Model/Type No. Series No. Note E-1 Em…

Text truncated - open the document above for the full version.

Page 23 of 23 Report No.: NTEK-2015NT11173139E 4. EUT TEST PHOTO Radiated Measurement Photos Conducted Measurement Photos
