2AG6N-P2RAPayment Terminal

1 User Guide P20-R Payment Terminal Model:P20R01 2 Disclaimer - This guide is the sole property of Fujian LANDI Commercial Equipment Co., Ltd. (“LANDI”). Unauthorized reproduction, distribution, transfer, or sale of this document or any part thereof is strictly prohibited without explicit authorization from LANDI. LANDI reserves the right to take legal action for any infringement according to law. - Every effort has been made to ensure the accuracy and completeness of the information in this user guide. However, errors or omissions may exist. - LANDI reserves the right to modify product software, hardware or documentation without notice. - Product details in this guide may differ from the actual product due to updates. Refer to the physical product for authoritative information. - LANDI shall not be held liable for damages, malfunctions, data loss or accessory loss caused by operations not complying with instructions in this guide. 3 Use this Manual Legend Danger Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury. Warning Indicates a potentially hazardous situation which, if not avoided, may result in equipment damage, data loss, performance degradation, or unexpected results. Notes Indicates important information that helps make better use of the device and features. 4 Important Safety Information Safety Rules ⚫ Power Supply - Use only provided LANDI power adapter. - Maintenance restricted to authorized LANDI technicians. - Connect to properly rated electrical outlet. - Ensure outlet is easily accessible and meets local regulations. - Disconnect adapter from electrical mains network to power off. - Shut down terminal after daily operations to save energy. - Avoid connecting or disconnecting components while powered on. ⚫ Battery Safety - Use only LANDI-approved batteries and chargers. - Internal lithium button battery: service by qualified technician only. - Avoid short-circuiting, crushing, puncturing, or dismantling the battery. - Replacing the battery with an incorrect type can defeat its safeguards and risk explosion. - Disposing of a battery in fire or a hot oven can cause an explosion. - Leaving a battery in extreme heat may cause an explosion or leakage of flammable substances. - Subjecting a battery to extremely low air pressure may cause an explosion or leakage. - Properly dispose of used batteries according to local environmental regulations. 5 ⚫ Environmental Restrictions - Avoid use in explosion-risk areas (chemical plants, fuel depots). - Suspend use during thunderstorms. - Use certified protective cover near fuel pumps. - Remove battery when on aircraft. - Avoid harsh environments with direct sunlight, high temperatures, humidity, or dust. - Operate and store the terminal only within the specified environmental limits: ◼ Operating Temperature:  Non-Battery Version (Without PSU): -10°C to +50°C (14°F to 122°F)  Non-Battery Version (With PSU): 0°C to +40°C (32°F to 104°F)  Battery Version: -10°C to +50°C (14°F to 122°F) for discharging; 0°C to +45°C (32°F to 113°F) for charging ◼ Storage Temperature:  Without PSU: -20°C to +70°C (-4°F to 158°F)  With PSU: -20°C to +60°C (-4°F to 140°F) ◼ Operating Humidity: 10% to 90% non-condensing ⚫ Health and Safety - Radio transmission may interfere with medical devices. - Consult healthcare providers regarding potential interference. Usage Instructions ⚫ Terminal Security - Verify PCI PTS security compliance. - Regular inspection for tampering signs: ◼ Keypad integrity ◼ Unauthorized wire connections 6 ◼ Card reader condition - Report "Warning Detected" messages immediately. - Restrict access to verified trustworthy staff. ⚫ Customer Protection - Never request PIN disclosure. - Advise customers on PIN privacy. - Maintain terminal visibility at all times. - Secure terminal against theft or replacement. ⚫ Component Guidelines - Keep SAM/SIM reader compartment cover in place. ⚫ Network Compliance - Follow cellular network regulations. - Non-compliance may result in service ban or legal action. ⚫ Abnormal Conditions If any of the following phenomena occur during work: - Stop operation immediately. - Cut off power supply. - Promptly report to service provider when: 1. Hearing sharp noises during operation 2. Impurities or water enter terminal 3. Unpleasant odors emit during operation 7 Contents Disclaimer ....................................................................................................... 2 Use this Manual .............................................................................................. 3 Legend ........................................................................................................................... 3 Important Safety Information ........................................................................ 4 Safety Rules .................................................................................................................. 4 Usage Instructions ......................................................................................................... 5 1. Product Profile ................................................................................... 8 1.1. Introduction ........................................................................................................ 8 1.2. Unboxing Inspection .......................................................................................... 8 1.3. Overview ............................................................................................................ 9 2. Product Technical Features ............................................................ 14 3. Product Installation ......................................................................... 16 3.1. Power Connection ........................................................................................... 16 3.2. SAM/SIM Cards ..........................................................................................…

Text truncated - open the document above for the full version.

Sporton International Inc. (Kunshan) Page Number : 1 of 20 TEL : +86-512-57900158 Report Issued Date : Nov. 29, 2024 FCC ID : XMR2024SC200EAU Report Version : Rev. 01 FCC DFS Test Report Report No. : FZ480203 DYNAMIC FREQUENCY SELECTION DFS Test Report APPLICANT : Quectel Wireless Solutions Co., Ltd. EQUIPMENT : Smart LTE Module BRAND NAME : Quectel MODEL NAME : SC200E-AU FCC ID : XMR2024SC200EAU STANDARD : FCC Part 15 Subpart E CLASSIFICATION : (NII) Unlicensed National Information Infrastructure TEST DATE(S) : Nov. 26, 2024 We, Sporton International Inc. (Kunshan), would like to declare that the tested sample has been evaluated in accordance with the procedures and shown to be compliant with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of Sporton International Inc. (Kunshan), the test report shall not be reproduced except in full. Approved by: Jason Jia Sporton International Inc. (Kunshan) No. 1098, Pengxi North Road, Kunshan Economic Development Zone Jiangsu Province 215300 People’s Republic of China Sporton International Inc. (Kunshan) Page Number : 2 of 20 TEL : +86-512-57900158 Report Issued Date : Nov. 29, 2024 FCC ID : XMR2024SC200EAU Report Version : Rev. 01 FCC DFS Test Report Report No. : FZ480203 TABLE OF CONTENTS REVISION HISTORY .......................................................................................................................................... 3 SUMMARY OF DYNAMIC FREQUENCY SELECTION TEST .......................................................................... 4 1 GENERAL DESCRIPTION .......................................................................................................................... 5 1.1 Applicant ........................................................................................................................................... 5 1.2 Manufacturer ..................................................................................................................................... 5 1.3 Feature of Equipment Under Test .................................................................................................... 5 1.4 Product Specification of Equipment Under Test ............................................................................... 5 1.5 Modification of EUT .......................................................................................................................... 6 1.6 Testing Site ....................................................................................................................................... 6 1.7 Applied Standards ............................................................................................................................ 6 1.8 Support Unit used in test configuration and system ......................................................................... 6 2 REQUIREMENTS AND PARAMETERS FOR DFS TEST .......................................................................... 7 2.1 Summary of Dynamic Frequency Selection Test ............................................................................. 7 2.2 Applicability of DFS Requirements ................................................................................................... 8 2.3 Interference Threshold values, Master or Client incorporating In-Service Monitoring ..................... 9 2.4 DFS Response requirement values .................................................................................................. 9 2.5 Short Pulse Radar Test Waveforms ............................................................................................... 10 3 CALIBRATION SETUP AND DFS TEST RESULTS ................................................................................ 11 3.1 Calibration of Radar Waveform ...................................................................................................... 11 3.2 In-Service Monitoring: Channel Move Time, Channel Closing Transmission Time and Non-Occupancy Period ................................................................................................................... 13 4 LIST OF MEASURING EQUIPMENT ........................................................................................................ 19 5 MEASUREMENT UNCERTAINTY ............................................................................................................ 20 APPENDIX A. SETUP PHOTOGRAPHS Sporton International Inc. (Kunshan) Page Number : 3 of 20 TEL : +86-512-57900158 Report Issued Date : Nov. 29, 2024 FCC ID : XMR2024SC200EAU Report Version : Rev. 01 FCC DFS Test Report Report No. : FZ480203 REVISION HISTORY REPORT NO. VERSION DESCRIPTION ISSUED DATE FZ480203 Rev. 01 Initial issue of report Nov. 29, 2024 Sporton International Inc. (Kunshan) Page Number : 4 of 20 TEL : +86-512-57900158 Report Issued Date : Nov. 29, 2024 FCC ID : XMR2024SC200EAU Report Version : Rev. 01 FCC DFS Test Report Report No. : FZ480203 SUMMARY OF DYNAMIC FREQUENCY SELECTION TEST UNII Bandwidth and Channel Description Measured Limit Result UNII Band 2-A 5250-5350MHz & UNII Band 2-C 5470-5725MHz 80MHz (CH106) 5530MHz Channel Move Time 878.029ms 10 sec Pass Channel Closing Transmission time <200ms + 8.4ms (aggregate) 200 ms + aggregate of 60 ms over remaining 10 s period Pass Non-Occupancy Period and Client Beacon Test No transmission or Beacons occurred 30 minutes Pass Note: Since the product is client without radar detection function, only Channel Move Time, Channel Closing Transmission Time and Non-Occupancy Period Test are required to be performed. Conformity Assessment Condition: 1. The test results (PASS/FAIL) with all measurement uncertainty excluded are presented against the regulation limits or in accordance with the requirements stipulated by the applicant/manufacturer who shall bear all the risks of non-compliance that may potentially occur if measurement uncertainty is taken …

Text truncated - open the document above for the full version.

Sporton International Inc. (Kunshan) Page Number : 1 of 26 TEL : +86-512-57900158 Report Issued Date : Nov. 29, 2024 FCC ID: XMR2024SC200EAU Report Version : Rev. 01 Report Template No.: BU5-FR15CBT Version 2.0 FCC RF Test Report Report No. : FR480203A FCC RF Test Report APPLICANT : Quectel Wireless Solutions Co., Ltd. EQUIPMENT : Smart LTE Module BRAND NAME : Quectel MODEL NAME : SC200E-AU FCC ID : XMR2024SC200EAU STANDARD : FCC Part 15 Subpart C §15.247 CLASSIFICATION : (DSS) Spread Spectrum Transmitter TEST DATE(S) : Aug. 05, 2024 ~ Nov. 25, 2024 We, Sporton International Inc. (Kunshan), would like to declare that the tested sample has been evaluated in accordance with the test procedures and has been in compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of Sporton International Inc. (Kunshan), the test report shall not be reproduced except in full. Approved by: Jason Jia Sporton International Inc. (Kunshan) No. 1098, Pengxi North Road, Kunshan Economic Development Zone Jiangsu Province 215300 People’s Republic of China Sporton International Inc. (Kunshan) Page Number : 2 of 26 TEL : +86-512-57900158 Report Issued Date : Nov. 29, 2024 FCC ID: XMR2024SC200EAU Report Version : Rev. 01 Report Template No.: BU5-FR15CBT Version 2.0 FCC RF Test Report Report No. : FR480203A TABLE OF CONTENTS REVISION HISTORY .......................................................................................................................................... 3 SUMMARY OF TEST RESULT ......................................................................................................................... 4 1 GENERAL DESCRIPTION .......................................................................................................................... 5 1.1 Applicant ............................................................................................................................................ 5 1.2 Manufacturer ...................................................................................................................................... 5 1.3 Product Feature of Equipment Under Test ........................................................................................ 5 1.4 Product Specification of Equipment Under Test ................................................................................ 5 1.5 Modification of EUT ........................................................................................................................... 6 1.6 Testing Location ................................................................................................................................ 6 1.7 Test Software ..................................................................................................................................... 6 1.8 Applicable Standards ......................................................................................................................... 6 2 TEST CONFIGURATION OF EQUIPMENT UNDER TEST ........................................................................ 7 2.1 Carrier Frequency Channel ............................................................................................................... 7 2.2 Test Mode .......................................................................................................................................... 8 2.3 Connection Diagram of Test System ................................................................................................. 9 2.4 Support Unit used in test configuration and system .......................................................................... 9 2.5 EUT Operation Test Setup .............................................................................................................. 10 2.6 Measurement Results Explanation Example ................................................................................... 10 3 TEST RESULT .......................................................................................................................................... 11 3.1 Number of Channel Measurement .................................................................................................. 11 3.2 Hopping Channel Separation Measurement ................................................................................... 12 3.3 Dwell Time Measurement ................................................................................................................ 13 3.4 20dB and 99% Bandwidth Measurement ........................................................................................ 14 3.5 Output Power Measurement ............................................................................................................ 15 3.6 Conducted Band Edges Measurement............................................................................................ 16 3.7 Conducted Spurious Emission Measurement ................................................................................. 17 3.8 Radiated Band Edges and Spurious Emission Measurement ........................................................ 18 3.9 AC Conducted Emission Measurement........................................................................................... 22 3.10 Antenna Requirements .................................................................................................................... 24 4 LIST OF MEASURING EQUIPMENT ........................................................................................................ 25 5 MEASUREMENT UNCERTAINTY ............................................................................................................ 26 APPENDIX A. CONDUCTED TEST RESULTS APPENDIX B. AC CONDUCTED EMISSION TEST RESULT APPENDIX C. RADIATED SPURIOUS EMISSION APPENDIX D. DUTY CYCLE PLOTS APPENDIX E. SETUP PHOTOGRAPHS Sporton International Inc. (Kunshan)…

Text truncated - open the document above for the full version.

Sporton International Inc. (Kunshan) Page Number : 1 of 23 TEL : +86-512-57900158 Report Issued Date : Nov. 29, 2024 FCC ID: XMR2024SC200EAU Report Version : Rev. 01 Report Template No.: BU5-FR15CBT4.0 Version 2.0 FCC RF Test Report Report No. : FR480203B FCC RF Test Report APPLICANT : Quectel Wireless Solutions Co., Ltd. EQUIPMENT : Smart LTE Module BRAND NAME : Quectel MODEL NAME : SC200E-AU FCC ID : XMR2024SC200EAU STANDARD : FCC Part 15 Subpart C §15.247 CLASSIFICATION : (DTS) Digital Transmission System TEST DATE(S) : Aug. 08, 2024 ~ Nov. 25, 2024 We, Sporton International Inc. (Kunshan), would like to declare that the tested sample has been evaluated in accordance with the test procedures and has been in compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of Sporton International Inc. (Kunshan), the test report shall not be reproduced except in full. Approved by: Jason Jia Sporton International Inc. (Kunshan) No. 1098, Pengxi North Road, Kunshan Economic Development Zone Jiangsu Province 215300 People’s Republic of China Sporton International Inc. (Kunshan) Page Number : 2 of 23 TEL : +86-512-57900158 Report Issued Date : Nov. 29, 2024 FCC ID: XMR2024SC200EAU Report Version : Rev. 01 Report Template No.: BU5-FR15CBT4.0 Version 2.0 FCC RF Test Report Report No. : FR480203B TABLE OF CONTENTS REVISION HISTORY .......................................................................................................................................... 3 SUMMARY OF TEST RESULT ......................................................................................................................... 4 1 GENERAL DESCRIPTION .......................................................................................................................... 5 1.1 Applicant ............................................................................................................................................ 5 1.2 Manufacturer ...................................................................................................................................... 5 1.3 Product Feature of Equipment Under Test ........................................................................................ 5 1.4 Product Specification of Equipment Under Test ................................................................................ 5 1.5 Modification of EUT ........................................................................................................................... 6 1.6 Testing Location ................................................................................................................................ 6 1.7 Test Software ..................................................................................................................................... 6 1.8 Applicable Standards ......................................................................................................................... 6 2 TEST CONFIGURATION OF EQUIPMENT UNDER TEST ........................................................................ 7 2.1 Carrier Frequency Channel ............................................................................................................... 7 2.2 Test Mode .......................................................................................................................................... 8 2.3 Connection Diagram of Test System ................................................................................................. 9 2.4 Support Unit used in test configuration and system .......................................................................... 9 2.6 EUT Operation Test Setup ................................................................................................................ 9 2.7 Measurement Results Explanation Example ................................................................................... 10 3 TEST RESULT .......................................................................................................................................... 11 3.1 6dB and 99% Bandwidth Measurement .......................................................................................... 11 3.2 Output Power Measurement ............................................................................................................ 12 3.3 Power Spectral Density Measurement ............................................................................................ 13 3.4 Conducted Band Edges and Spurious Emission Measurement ..................................................... 14 3.5 Radiated Band Edges and Spurious Emission Measurement ........................................................ 15 3.6 AC Conducted Emission Measurement........................................................................................... 19 3.7 Antenna Requirements .................................................................................................................... 21 4 LIST OF MEASURING EQUIPMENT ........................................................................................................ 22 5 MEASUREMENT UNCERTAINTY ............................................................................................................ 23 APPENDIX A. CONDUCTED TEST RESULTS APPENDIX B. AC CONDUCTED EMISSION TEST RESULT APPENDIX C. RADIATED SPURIOUS EMISSION APPENDIX D. DUTY CYCLE PLOTS APPENDIX E. SETUP PHOTOGRAPHS Sporton International Inc. (Kunshan) Page Number : 3 of 23 TEL : +86-512-57900158 Report Issued Date : Nov. 29, 2024 FCC ID: XMR2024SC200EAU Report Version : Rev. 01 Report Template No.: BU5-FR15CBT4.0 Version 2.0 FCC RF Test Report Report No. : FR480203B REVISION HISTORY REPORT NO. VERSION DESCRIPTION ISSUED DATE FR480203B Rev. 01 Initial issue of report Nov. 29, 2024 Sporton International Inc. (Kunshan) Page Number : 4 of 23 TEL : +86-512-579…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01-A04 Rev.A/1 Page: 1 of 3 Appendix BT/Wi-Fi Test Setup Photos for SZCR2512005587AT FCC ID: 2AG6N-P2RA SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01-A04 Rev.A/1 Page: 2 of 3 Test Setup Photo Conducted Emissions at AC Power Line (150kHz-30MHz) Radiated Emissions which fall in the restricted bands SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01-A04 Rev.A/1 Page: 3 of 3 Radiated Spurious Emissions Below 1GHz Radiated Spurious Emissions Above 1GHz - End of the Appendix -

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/2 Report No.: SZCR251200558710 Page: 1 of 17 Keny Xu EMC Laboratory Manager TEST REPORT Application No.: SZCR2512005587AT Applicant: Fujian Landi Commercial Equipment Co.,Ltd. Address of Applicant: Building 17, Area A, Software Park, No.89 Software Road, Gulou District, Fuzhou, 350003, Fujian, China Equipment Under Test (EUT): EUT Name: Payment Terminal Model No.: P20R01 Trade Mark: Landi FCC ID: 2AG6N-P2RA Standard(s) : FCC Rules 47 CFR §2.1091 KDB 447498 D04 interim General RF Exposure Guidance v01 Date of Receipt: 2025-12-17 Date of Evaluation: 2025-12-27 to 2026-01-09 Date of Issue: 2026-01-14 Evaluation Result: Pass* * In the configuration evaluated, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/2 Report No.: SZCR251200558710 Page: 2 of 17 Revision Record Version Chapter Date Modifier Remark 01 2026-01-14 Original Authorized for issue by: Calvin Weng/Project Engineer Eric Fu/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/2 Report No.: SZCR251200558710 Page: 3 of 17 2 Contents Page 1 Cover Page ................................................................................................................................................ 1 2 Contents .................................................................................................................................................... 3 3 General Information .................................................................................................................................. 4 3.1 General Description of E.U.T. ............................................................................................................ 4 3.2 Details of E.U.T. ................................................................................................................................. 4 3.3 Separation Distance ........................................................................................................................... 8 3.4 Test Location ...................................................................................................................................... 9 3.5 Test Facility ........................................................................................................................................ 9 3.6 Deviation from Standards ................................................................................................................... 9 3.7 Abnormalities from Standard Conditions ........................................................................................... 9 4 FCC Radiofrequency radiation exposure limits .................................................................................. 10 4.1 Blanket 1 mW Blanket Exemption .................................................................................................... 10 4.2 MPE-based Exemption .................................................................................................................... 10 4.3 SAR-based Exemption ..................................................................................................................... 11 5 Measurement and Calculation ............................................................................................................... 14 6 EUT Constructional Details (EUT Photos) ........................................................................................... 17 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/2 Report No.: SZCR251200558710 Page: 4 of 17 3 General Information 3.1 General Description of E.U.T. Product Type: Portable device Mobile device Fixed device 3.2 Details of E.U.T. Power supply: DC5V/2A by AC/DC power adapter Adapter Manufacturer: Something High Electric(Xiamen) Company Inc. Adapter M/N:P24C050400 US Adapter Input:AC100-240V, 50/60Hz, 0.6A Adapter Output: DC5V/4A For BT: Cable Loss (for RF conducted test): 0.7dB Operation Frequency: 2402MHz to 2480MHz Modulation Type: GFSK, pi/4DQPSK, 8DPSK Number of Channels: 79 Channel Spacing: 1MHz Spectrum Spread Technology: Frequency Hopping Spread Spectrum(FHSS) Antenna Type: PIFA Antenna Antenna Gain: 2.51dBi For BLE: Cable Loss (for RF conducted test): 0.7dB Operation Frequency: 2402MHz to 2480MHz Modulation Type: GFSK Number of Channels: 40 Channel Spacing: 2MHz Antenna Type: PIFA Antenna Antenna Gain: 2.51dBi SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/2 Report No.: SZCR251200558710 Page: 5 of 17 For 2.4G WIFI: Cable Loss (for RF conducted test): 0.7dB Operation Frequency: 802.11b/g/n(HT20): 2412MHz to 2462MHz;802.11n(HT40): 2422MHz to 2452MHz Modulation Type: 802.11b: DSSS (DBPSK, DQPSK, CCK); 802.11g/n: OFDM (BPSK, QPSK, 16QAM, 64QAM) Number of Channels: 802.11b/g/n(HT20):11;802.11n(HT40):7 Channel Spacing: 5MHz Antenna Type: PIFA Antenna Antenna Gain: 2.51dBi For 5G WIFI: Operation Frequency/Number of channels (20MHz): U-NII-1: 5180-5240MHz (4 Channels); U-NII-2A: 5260-5320MHz (4 Channels); U-NII-2C: 5500-5700MHz (11 Channels); U-NII-3: 5745- 5825MHz (5 Channels) Operation Frequency/Number of channels/(40MHz): U-NII-1: 5190-5230MHz (2 Channels); U-NII-2A: 5270-5310MHz (2 Channels); U-NII-2C: 5…

Text truncated - open the document above for the full version.
