2AGCW701Wireless charger

Wireless Charger OEXH701 Manual 1. Product function 1.1 Instruction of wireless charging function The product could achieve short-range radio transmission by magnetic induction, applicable to charging for digital products of 5V 0.9A, communications, furniture, fire protection ,water proof and other digital products, this product meets Qi wireless charging standard. It could be wireless charging with all the Qi standard receiver. 1.2 3 coils design make sure 100% charging precision Put the phone with wireless charging function on the OEXH701 transmitter correctly, the phone will be wireless charging. 1.3 USB input function OEXH701 Micro USB OEXH701 can wireless charging by connect to safety adapter or Micro USB wire connect to computer 1.3 Transmitter pad indicator light working description Power on: After 2 seconds of green and blue indicator light flash alternately. indicator light will be turn green for a long time then enter into standby mode. Standby: Indicator light will be turn green for a long time Charging: Indicator light will be turn blue for a long time, remove the receiver, the indicator light will turn green, enter into standby mode. 2. Automatic protection function When the transmitter detected its connector’s load current is too large (current exceeds the rated output), the transmitter will shut off with the mobile receiver connection automatically, safety protection automatically. Put the mobile phone in correct position again after move the mobile 5 seconds later. It will re-enter charging status when the connection is successful. FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 Hang Zhou Joye Technology Co., Ltd. 2015/10/29 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, Hang Zhou Joye Technology Co., Ltd. hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product description: Wireless charger model name: OEXH701 OEXH702, OEXH703, OEXH705, OEXH706 Trademark: N/A FCC ID: 2AGCW701 Sincerely, Client’s signature Client’s name / title : Hu Sunyue / Manager Contact informations: No.1218,Wenyi Road,Yu Hang District,Hangzhou, China

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (current) 3.0 4.0 March-26-2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 4.0 Hang Zhou Joye Technology Co., Ltd. 2015/10/29 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AGCW701 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Client’s name / title : Hu Sunyue / Manager Contact informations: No.1218,Wenyi Road,Yu Hang District,Hangzhou, China

Hang Zhou Joye Technology Co., Ltd. Family letter FCC ID: 2AGCW701 Product Name: Wireless charger Brand Name: N/A The main test model ： OEXH701 Additional models for：OEXH702, OEXH703, OEXH705, OEXH706 Primary check model and additional model at the same electrical principle, PCB shape and structure, is different for outlook color, model name, Ring size. Client’s name / title : Hu Sunyue / Manager Contact informations: No.1218,Wenyi Road,Yu Hang District,Hangzhou, China

M/N: OEXH701 FCC ID: 2AGCW701 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Hang Zhou Joye Technology Co., Ltd. Label location

Shenzhen BCTC Technology Co., Ltd. BCTC-151012783 RF EXPOSURE REPORT For FCC ID: 2AGCW701 Product Name: Wireless charger Trademark: N/A Model Number: OEXH701 OEXH702, OEXH703, OEXH705, OEXH706 Prepared For : Hang Zhou Joye Technology Co., Ltd. Address : No.1218,Wenyi Road,Yu Hang District,Hangzhou, China Prepared By : Shenzhen BCTC Technology Co., Ltd. Address : No.101,Yousong Road,Longhua New District, Shenzhen,China Nanshan District, Shenzhen, China Report No.: BCTC-151012783 Shenzhen BCTC Technology Co., Ltd. BCTC-151012783 Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 2 of 8 TEST RESULT CERTIFICATION Applicant’s name .......... Hang Zhou Joye Technology Co., Ltd. Address ........................... No.1218,Wenyi Road,Yu Hang District,Hangzhou, China Manufacture's Name ..... Hang Zhou Joye Technology Co., Ltd. Address ........................... No.1218,Wenyi Road,Yu Hang District,Hangzhou, China Product description Product name .................... Wireless charger Trademark ..................... N/A Model and/or type reference : OEXH701 OEXH702, OEXH703, OEXH705, OEXH706 Standards ....................... FCC CFR 47 part1, 1.1307(b), 1.1310 Test Date: Oct. 18 - Oct. 25, 2015 Date of Report : Oct. 29, 2015 This device described above has been tested by BCTC, and the test results show that the equipment under And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BCTC, this document may be altered or revised by BCTC, personal only, and shall be noted in the revision of the document. Prepared by(Engineer): Reviewer(Quality Manager): Approved & Authorized Signer(Manager): Shenzhen BCTC Technology Co., Ltd. BCTC-151012783 Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 3 of 8 Table of Contents Page 1 . GENERAL INFORMATION 4 1.1 . Independent Operation Mode 4 1.2 . Test Supporting System 4 2 .LIST OF TEST AND MEASUREMENT INSTRUMENTS 5 2.1 . For conducted emission at the mains terminals test 5 3. METHOD OF MEASUREMENT 6 3. 1.Applicable Standard 6 4. TEST RESULT 6 4.1. Conducted Emission at the Mains Terminals Test 6 4.2. Equipment Approval Considerations: 7 4.3. E and H field Strength 7 5. PHOTOGRAPHS OF TEST SET-UP 8 Shenzhen BCTC Technology Co., Ltd. BCTC-151012783 Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 4 of 8 1. GENERAL INFORMATION 1.1. Independent Operation Mode The basic operation mode is: Final Test Mode Description Mode 1 TX Low Channel 110kHz Mode 2 TX High channel 205kHz Mode 3 RX Mode Mode 4 Transfer mode(Battery's electric quantity was0%,50%,90%) we pretest all mode, the report only show the worst mode. 1.2. Test Supporting System Adapter Description : Switching Adapter Model No. : K05050-2 Power Input : AC 100-240V~50/60Hz 0.15A Output : DC 5.0V/ 500mA USB Line : Unshielded, Detachable 0.5m Mobile phone Model No. : A1530 Battery model: A1530B Shenzhen BCTC Technology Co., Ltd. BCTC-151012783 Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 5 of 8 2.LIST OF TEST AND MEASUREMENT INSTRUMENTS 2.1. For conducted emission at the mains terminals test Equipment Manufacturer Model No. Serial No. Last Cal. Next Cal. Exposure Level Tester Narda ELT-400 N-0231 Aug. 08,15 Aug. 07,16 Magnetic field probe 100cm2 Narda B-Field Probe 100cm2 M0675 Aug. 08,15 Aug. 07,16 843 Chamber ETS 843 84301 Aug. 02,15 Aug. 01,16 Shenzhen BCTC Technology Co., Ltd. BCTC-151012783 Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 6 of 8 3. METHOD OF MEASUREMENT 3. 1.Applicable Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1093 RF exposure is calculated. According KDB680106 D01v02: RF Exposure Wireless Charging Apps v02. 4. TEST RESULT 4.1. Conducted Emission at the Mains Terminals Test Test Procedure: a) The RF exposure test was performed on 360 degree turn table in anechoic chamber. b) The measurement probe was placed at test distance (10cm) which is between the edge of the charger and the geometric centre of probe. c) The turn table was rotated 360d degree to search of highest strength. d) The highest emission level was recorded and compared with limit as soon as measurement of each points (A, B, C, D, E) were completed. e) The EUT were measured according to the dictates of KDB 680106D01v02. Shenzhen BCTC Technology Co., Ltd. BCTC-151012783 Tel: 400-788-9558 0755-33019988 Web:Http//www.bctc-lab.com Page 7 of 8 4.2. Equipment Approval Considerations: The EUT does comply with item 5.2 of KDB 680106 D01v02 a) Power transfer frequency is less than 1MHz Yes; the device operate in the frequency range from 110 KHz to 205 KHz b)Output power from each primary coil is less than 5 watts Yes; the maximum output power of the primary coil is 4.9W<5W. c) The transfer system includes only single primary and secondary coils. This includes charging systems that may have multiple primary coils and clients that able to detect and allow coupling onlybetween individual pair of coils. Yes; the transfer system includes only single primary and secondary coils. d) Client device is inserted in or placed directly in contact with the transmitter. Yes; Client device is placed directly in contact with the transmitter. e) The maximum coupling surface area of the transmit (charging) device: Yes; The EUT coupling surface area was 86.25 cm 2 (Dimensions: 11.5 cm x7.5 cm)L x W f) Aggregate leakage fields at 10cm surrounding the device from all simultaneous transmitting coilsare demonstrated to be less than 30% of the MPE limit. Yes; The EUT field strength levels are 30% x MPE limit. 4.3. E and H field Strength E-Filed Strength at 10 cm from the edges surrounding the EUT (V/m) Frequency Range (MHz) Test Position A Test Position B Test Positio…
