2AGEB-TCTTPMS Configuration Tool

FCC Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1)this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Shenzhen ZKC Software Technology Co., Ltd 2.911 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – EquipmentType Company name: Shenzhen ZKC Software Technology Co., Ltd Address: 1st Floor, No. 1 Block, Zhongkenuo Industry Park, Beiqi Road, Xixiang Town, Bao'an District, Shenzhen, China Product Name: TPMS Configuration Tool FCC ID: 2AGEB-TCT Model(s): TCT 2.911(d)(5)(i) EquipmentType We, [Shenzhen ZKC Software Technology Co., Ltd] (“the applicant”) certify that the equipment for which authorization is sought through certification is not: • Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules. • Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Benson Xu Date: 2024-06-20 Title and Company name: General manager /Shenzhen ZKC Software Technology Co., Ltd NOTE 1 “Covered List ”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Shenzhen ZKC Software Technology Co., Ltd 2.911 (d)(5)(ii) Applicant Attestation v1.3 Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: Shenzhen ZKC Software Technology Co., Ltd Address: 1st Floor, No. 1 Block, Zhongkenuo Industry Park, Beiqi Road, Xixiang Town, Bao'an District, Shenzhen, China Product Name: TPMS Configuration Tool FCC ID: 2AGEB-TCT Model(s): TCT 2.911(d)(5)(ii) Applicant filing We, [Shenzhen ZKC Software Technology Co., Ltd] (“the applicant”) certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 ,established pursuant to §1.50002 of this chapter,as an entity producing coveredcommunications equipment. Yours sincerely, Name: Benson Xu Date: 2024-06-20 Title and Company name: General manager /Shenzhen ZKC Software Technology Co., Ltd NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List ”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Shenzhen ZKC Software Technology Co., Ltd U.S. Agent Designation for Service of Process (Applicant and U.S. Agent are Separate Parties) TO: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 ATTENTION: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name: Baihetian Innovative Solutions FRN: 0033401605 Contact Name: Kenneth Young Street Address: 6837 Chase Rd City/Province/Zip: Dearborn, MI 48126 Telephone No: 313-395-3113 Email: [email protected] This letter is to confirm that we (“Baihetian Innovative Solutions) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. U.S. Agent Signature: Date: June 28, 2024 Signed by (Printed Name/Title): Kenneth Young/Manager The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: Shenzhen ZKC Software Technology Co., Ltd Grantee Code: 2AGEB FRN: 0025020587 FCC ID: 2AGEB-TCT Contact Name: Benson Xu Street Address: 1st Floor, No. 1 Block, Zhongkenuo Industry Park, Beiqi Road, Xixiang Town, Bao'an District City/Province/Zip: Shenzhen, China Telephone No: 0755-61173277 Email: [email protected] Applicant Signature: Date:2024-06-27 Signed by (Printed Name/Title): Benson Xu/ General manager June 2024

Shenzhen ZKC Software Technology Co., Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2024-06-20 Subject; Request for Long Term Confidentiality FCC ID: 2AGEB-TCT To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Benson Xu Title: General manager

Shenzhen ZKC Software Technology Co., Ltd 1st Floor, No. 1 Block, Zhongkenuo Industry Park, Beiqi Road, Xixiang Town, Bao'an District, Shenzhen, China Agent Authorization Com pany: Shenzhen ZKC Software Technology Co., Ltd Address: 1st Floor, No. 1 Block, Zhongkenuo Industry Park, Beiqi Road, Xixiang Town, Bao'an District, Shenzhen, China Product Name: TPMS Configuration Tool Model Number(s): TCT Product Description: TPMS Configuration Tool We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2024-06-20 Name: Benson Xu Title: General manager Company: Shenzhen ZKC Software Technology Co., Ltd

Page 1 of 4 Appendix C: Photographs of EUT Product: TPMS Configuration Tool Model: TCT External Photos Page 2 of 4 Page 3 of 4 Page 4 of 4

Label Artwork and Location Model: TCT Label: Size: L*W=44*24mm Location

Page 1 of 6 Appendix C: Photographs of EUT Product: TPMS Configuration Tool Model: TCT Internal Photos Page 2 of 6 Page 3 of 6 Page 4 of 6 BLE/WIFI ANT Page 5 of 6 RFID ANT Page 6 of 6

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID. ............................ : 2AGEB-TCT Test Report No. ............... : TCT240607E029 Date of issue ................... : Jun. 18, 2024 Testing laboratory .......... : SHENZHEN TONGCE TESTING LAB Testing location/ address: 2101 & 2201, Zhenchang Factory Renshan Industrial Zone, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, 518103, People's Republic of China Applicant's name ............ : Shenzhen ZKC Software Technology Co., Ltd Address ........................... : 1st Floor, No. 1 Block, Zhongkenuo Industry Park, Beiqi Road, Xixiang Town, Bao'an District, Shenzhen, China Manufacturer's name ... : Shenzhen ZKC Software Technology Co., Ltd Address ........................... : 1st Floor, No. 1 Block, Zhongkenuo Industry Park, Beiqi Road, Xixiang Town, Bao'an District, Shenzhen, China Standard(s) ..................... : KDB 447498 D01 General RF Exposure Guidance v06 Product Name ................. : TPMS Configuration Tool Trade Mark ...................... : N/A Model/Type reference..... : TCT Rating(s).......................... : Rechargeable Li-ion Battery DC 3.6V Date of receipt of test item ......................................... : Jun. 07, 2024 Date (s) of performance of test ................................... : Jun. 07, 2024 ~ Jun. 18, 2024 Tested by (+signature) ... : Ronaldo LUO Check by (+signature) .... : Beryl ZHAO Approved by (+signature): Tomsin General disclaimer: This report shall not be reproduced except in full, without the written approval of SHENZHEN TONGCE TESTING LAB. This document may be altered or revised by SHENZHEN TONGCE TESTING LAB personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT240607E029 Page 2 of 7 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Table of Contents 1. General Product Information .................................................................. 3 1.1. EUT description ..................................................................................................... 3 1.2. Model(s) list ............................................................................................................ 3 2. General Information ................................................................................. 4 2.1. Test environment and mode ................................................................................. 4 2.2. Description of Support Units ................................................................................ 4 3. Facilities and Accreditations .................................................................. 5 3.1. Facilities ................................................................................................................. 5 3.2. Location ................................................................................................................. 5 4. Test Results and Measurement Data ..................................................... 6 Report No.: TCT240607E029 Page 3 of 7 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. General Product Information 1.1. EUT description Product Name ....................... : TPMS Configuration Tool Model/Type reference........... : TCT Sample Number....................: TCT240607E007-0101 Operation Frequency ........... : For BLE: 2402MHz~2480MHz For WIFI: 2412MHz~2462MHz (802.11b/802.11g/802.11n(HT20)) 2422MHz~2452MHz (802.11n(HT40)) For RFID: 125kHz Modulation Type ................... : For BLE: GFSK For WIFI: DSSS(802.11b), OFDM (802.11g/802.11n) For RFID: FSK Antenna Type ........................ : For BLE/WIFI: PCB Antenna For RFID: Internal Antenna Antenna Gain ........................ : BLE/WIFI: 0.94dBi Rating(s)................................ : Rechargeable Li-ion Battery DC 3.6V Note: The antenna gain listed in this report is provided by applicant, and the test laboratory is not responsible for this parameter. 1.2. Model(s) list None. Report No.: TCT240607E029 Page 4 of 7 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. General Information 2.1. Test environment and mode Item Normal condition Temperature +25ºC Voltage DC 3.6V Humidity 56% Atmospheric Pressure: 1008 mbar Test Mode: Engineering mode: Keep the EUT in continuous transmitting by select channel 2.2. Description of Support Units The EUT has been tested as an independent unit together with other necessary accessories or support units. The following support units or accessories were used to form a representative test configuration during the tests. Equipment Model No. Serial No. FCC ID Trade Name / / / / / Note: 1. All the equipment/cables were placed in the worst-case configuration to maximize the emission during the test. 2. Grounding was established in accordance with the manufacturer’s requirements and conditions for the intended use. 3. For conducted measurements (Output Power, 20dB Occupied Bandwidth, Carrier Frequencies Separation, Hopping Channel Number, Dwell Time, Spurious Emissions), the antenna of EUT is connected to the test equipment via temporary antenna connector, the antenna connector is soldered on the antenna port of EUT, and the temporary antenna connector is listed in the Test Instruments. Report No.: TCT240607E029 Page 5 of 7 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 3. Facilities and Accreditations 3.1. Facilities The test facility is recognized, certified, or accredited by the following organizations: ● FCC - Registration No.: 645098 SHENZHEN TONGCE TESTING LAB Designation Number: CN1205 The testing lab has been registered and fully described in a report with the (FCC) Federal Communications Commission. The acceptance letter from the FCC is maintained in our files. ● IC - Registration No.:…

Text truncated - open the document above for the full version.

DongguanYafuIntelligentTechnologyCo.,Ltd Antenna specification Antenna Sample Confirmation From Name of supplier Dongguan Yafu Intelligent Technology Co., Ltd Customer name ZKC Sample name model TCT Sample size Inspection item Performance test Visual inspection Structure In the news Test results Notes QualityAudit ProjectAudit Business confirm ation Thefollowingistobecompletedbytheclient DongguanYafuIntelligentTechnologyCo.,Ltd Customer feedback Customer signature/seal date: Antenna Test Report TestUnit:ShenzhenAihuiTechnologyCo.,Ltd. Materials FPC Antenna form PIFA Polarizationmode Linear Application scenario W/G/B Workingband 2400Mhz-2500Mhz VSWR ≤2 DongguanYafuIntelligentTechnologyCo.,Ltd Power Max：2W Impedance 50Ω dBi 0.94dBi Test Equipment HPE5071C、Shielding Room、3D automatic turntable Antenna Description:： 1. Grounding processing and picture description: no 2. Need to change the motherboard to match: no  Test voltage: 3.6V, check the antenna contact is good before testing.  The RF cable of the integrated tester is kept in a natural state and can not be curled. Specification:test the specified power level, all indicators must conform to the specifications. DongguanYafuIntelligentTechnologyCo.,Ltd 1.ProjectImage 2.TestFixture 3.Antennamatchingcircuit 4.S11test 5.Antennapassiveefficiencyandgain 6.Darkroomtestequipmentanddata 7.Schematicdiagramofantennaassembly 8.Antennaenvironmenthandling 9.Antennamassproductionindex 10.Structuraldrawing DongguanYafuIntelligentTechnologyCo.,Ltd  1. ProjectImage  The final verification antenna performance prototype in our company for at least one year, easy to analyze and solve the problem of antenna mass production, to ensure the quality of antenna shipment 2. TestFixture  Objective: to test the passive parameters of antenna as accurately as possible. Making Method: the handset is made of a 50 ohm coaxial cable, one end of which is connected to the test point of the back end of the matching circuit of the handset motherboard (front end of the RF test hole) , and the other end is connected to the SMA joint. The diagram is as follows: 3、Antennamatchingcircuit    Modify DongguanYafuIntelligentTechnologyCo.,Ltd E01 E02 E03 No No No Note:Thematchisunmodified.      4.S11test 4.0 4.0s11 test method description of test equipment: Network Analyzer (E5071C) test method: a 50 ohm CABLE is used to export from the instrument test port. The SMA connector for connecting the handset is calibrated using a calibration piece, record the echo loss and standing wave ratio corresponding to the relevant frequency points. The test schematic is as follows: DongguanYafuIntelligentTechnologyCo.,Ltd Darkroom test equipment and data   4.Test Equipment Test system: shielded darkroom The temperature was 22 ° C ± 3 ° C and the humidity was 50% ± 15% Test equipment: when testing passive data, use the Network analyzer AGILENTE5071C to test active data, use the omnibus CMW500 DongguanYafuIntelligentTechnologyCo.,Ltd 5.Active antenna test data   测试数据：  BT 、WiFi 2400-2500Mhz  Freq(MHz)  Efficiency (%)  Gain (dBi)  2400 35.4 0.28 2410 33.6 0.36 2420 36.7 0.25 2430 38.6 0.85 2440 39.3 0.31 2450 35.6 0.94 2460 34.5 0.48 2470 33.1 0.20 2480 32.3 0.29 2490 34.5 0.88 2500 36.1 0.93  DongguanYafuIntelligentTechnologyCo.,Ltd 6.The panel matches the change schematic 7.Antenna environment handlin 8.The panel matches the change schematic 9.Antenna environment handlin DongguanYafuIntelligentTechnologyCo.,Ltd       Whentheantennaismass-produced,the standingwaveratioistakenasthe mass-producedteststandard. Basedonthedifferencesoftheprojectitself,the followingcriteriaaregiven: Frequency  Standardforvolumeproduction    2400 MHZ ‐2500MHZ   VSWR(MassProductionperformance)& LT;VSWR(recognitionperformance)0.5 8.Antennamassproductionindex DongguanYafuIntelligentTechnologyCo.,Ltd    10. Structuraldrawings

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID. ............................ : 2AGEB-TCT Test Report No. ............... : TCT240607E007 Date of issue ................... : Jun. 18, 2024 Testing laboratory .......... : SHENZHEN TONGCE TESTING LAB Testing location/ address: 2101 & 2201, Zhenchang Factory Renshan Industrial Zone, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, 518103, People's Republic of China Applicant's name ............ : Shenzhen ZKC Software Technology Co., Ltd Address ........................... : 1st Floor, No. 1 Block, Zhongkenuo Industry Park, Beiqi Road, Xixiang Town, Bao'an District, Shenzhen, China Manufacturer's name ... : Shenzhen ZKC Software Technology Co., Ltd Address ........................... : 1st Floor, No. 1 Block, Zhongkenuo Industry Park, Beiqi Road, Xixiang Town, Bao'an District, Shenzhen, China Standard(s) ..................... : FCC CFR Title 47 Part 15 Subpart C Section 15.247 FCC KDB 558074 D01 15.247 Meas Guidance v05r02 ANSI C63.10:2013 Product Name ................. : TPMS Configuration Tool Trade Mark ...................... : N/A Model/Type reference..... : TCT Rating(s).......................... : Rechargeable Li-ion Battery DC 3.6V Date of receipt of test item ......................................... : Jun. 07, 2024 Date (s) of performance of test ................................... : Jun. 07, 2024 ~ Jun. 18, 2024 Tested by (+signature) ... : Ronaldo LUO Check by (+signature) .... : Beryl ZHAO Approved by (+signature): Tomsin General disclaimer: This report shall not be reproduced except in full, without the written approval of SHENZHEN TONGCE TESTING LAB. This document may be altered or revised by SHENZHEN TONGCE TESTING LAB personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT240607E007 Page 2 of 67 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Table of Contents 1. General Product Information .................................................................. 3 1.1. EUT description ..................................................................................................... 3 1.2. Model(s) list ............................................................................................................ 3 1.3. Operation Frequency ............................................................................................ 3 2. Test Result Summary .............................................................................. 4 3. General Information ................................................................................. 5 3.1. Test environment and mode ................................................................................. 5 3.2. Description of Support Units ................................................................................ 5 4. Facilities and Accreditations .................................................................. 6 4.1. Facilities ................................................................................................................. 6 4.2. Location ................................................................................................................. 6 4.3. Measurement Uncertainty ..................................................................................... 6 5. Test Results and Measurement Data ..................................................... 7 5.1. Antenna requirement ............................................................................................ 7 5.2. Conducted Emission ............................................................................................. 8 5.3. Conducted Output Power ................................................................................... 12 5.4. Emission Bandwidth ........................................................................................... 13 5.5. Power Spectral Density ....................................................................................... 14 5.6. Conducted Band Edge and Spurious Emission Measurement ....................... 15 5.7. Radiated Spurious Emission Measurement ...................................................... 17 Appendix A: Test Result of Conducted Test Appendix B: Photographs of Test Setup Appendix C: Photographs of EUT Report No.: TCT240607E007 Page 3 of 67 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. General Product Information 1.1. EUT description Product Name ....................... : TPMS Configuration Tool Model/Type reference........... : TCT Sample Number....................: TCT240607E007-0101 Bluetooth Version ................ : V5.0 Operation Frequency ........... : 2402MHz~2480MHz Channel Separation ............. : 2MHz Data Rate............................... : LE 1M PHY, LE 2M PHY Number of Channel .............. : 40 Modulation Type ................... : GFSK Antenna Type ........................ : PCB Antenna Antenna Gain ........................ : 0.94dBi Rating(s)................................ : Rechargeable Li-ion Battery DC 3.6V Note: The antenna gain listed in this report is provided by applicant, and the test laboratory is not responsible for this parameter. 1.2. Model(s) list None. 1.3. Operation Frequency Channel Frequency Channel Frequency Channel Frequency Channel Frequency 0 2402MHz 10 2422MHz 20 2442MHz 30 2462MHz 1 2404MHz 11 2424MHz 21 2444MHz 31 2464MHz ... ... ... ... ... ... ... ... 8 2418MHz 18 2438MHz 28 2458MHz 38 2478MHz 9 2420MHz 19 2440MHz 29 2460MHz 39 2480MHz Remark: Channel 0, 19 & 39 have been tested. Report No.: TCT240607E007 Page 4 of 67 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. Test Result Summary Requirement CFR 47 Section Result Antenna requirement §15.203/§15.247 (c) PASS AC Power Line Conducted Emission §…
