2AGFEDYE-U-BLSpeaker with Bluetooth

Instruction: DYE-U-BL speaker with Bluetooth uses USB plug DC input, able to connect to a power bank for DC input. 1. Insert USB plug into a power bank, “enter to bluetooth” sound means DC input connected. 2. Switch Bluetooth function of cell phone then pair the Bluetooth of the speaker. 3. Once Bluetooth paired and “bluetooth connected” sound, play the music from the cell phone then music comes out from the speaker. 4. Stop the music, switch off the DC input and unplug the USB. Rating: Power supply : DC5V Output power : 3W (1KHz, TGD10%) Frequency : 200Hz - 20KHZ Signal & noise ratio : 85dB Impedance : 8Ω Speaker Unit : 57mm Case Material : PP Accessories : USB charging cable FCC Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1)this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation

Babyboom Consumer Products Inc. Tuckers Distribution Center, 250 Passaic Street, Newark, NJ 07104, U.S.A. TEL: +1-973-483-5015 FAX +1-973-483-5015 USB Port Statement FCC ID: 2AGFEDYE-U-BL Date: Nov.11, 2015 To whom it may concern: We, the undersigned, state that the device's (Model: DYE-U-BL) USB port only used for charge or discharge, no any data transfer to PC. Sincerely, Chris NG/Manager

Babyboom Consumer Products Inc. Tuckers Distribution Center, 250 Passaic Street, Newark, NJ 07104, U.S.A. TEL: +1-973-483-5015 FAX +1-973-483-5015 DATE 11-11-2015 FCC ID: 2AGFEDYE-U-BL Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint BZT Testing Technology Co., Ltd. (Jack Kang) at 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen P.R. China to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by MiCOM Labs Inc, still resides with Babyboom Consumer Products Inc. at Tuckers Distribution Center, 250 Passaic Street, Newark,NJ 07104, U.S.A.. Dated this 11-11-2015 Agency agreement expiration date: 11-10-2016 By: Chris NG Signature Printed Title: Manager On behalf of : Babyboom Consumer Products Inc. Telephone: +1-973-483-5015

Babyboom Consumer Products Inc. Tuckers Distribution Center, 250 Passaic Street, Newark, NJ 07104, U.S.A. TEL: +1-973-483-5015 FAX +1-973-483-5015 DATE 11-11-2015 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AGFEDYE-U-BL Product Name: Speaker with Bluetooth Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...)  Schematics  Block diagram  Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 11-11-2015 By: Chris NG Signature Printed Title: Manager On behalf of : Babyboom Consumer Products Inc. Telephone: +1-973-483-5015

FCC ID Label Information 1. Label location: 2. FCC ID Label: Model: DYE-U-BL FCC ID: 2AGFEDYE-U-BL FCCID Label Location

FCC RADIO TEST REPORT FCC ID: 2AGFEDYE-U-BL Product： Speaker with Bluetooth Trade Name： N/A Model Number： DYE-U-BL Report No.： POCE15072230NRRF Prepared for Babyboom Consumer Products Inc. Tuckers Distribution Center, 250 Passaic Street, Newark, NJ 07104, U.S.A. Prepared by Shenzhen POCE Technology Co.,Ltd. Room 502, Bldg. 1, Xinghua Garden, Baoan Road Xixiang, Baoan District, Shenzhen, China V1.0 Page 2 of 30 Report No.: POCE15072230NRRF TEST RESULT CERTIFICATION Applicant’s name...................... Babyboom Consumer Products Inc. Address....................................... Tuckers Distribution Center, 250 Passaic Street, Newark, NJ 07104, U.S.A. Manufacture's Name................. Babyboom Consumer Products Inc. Address....................................... Tuckers Distribution Center, 250 Passaic Street, Newark, NJ 07104, U.S.A. Product description Product name.............................. Speaker with Bluetooth Model and/or type reference .................................................... DYE-U-BL Ratings DC 5V from USB Standards................................ FCC Part15.249 Test procedure ............................... ANSI C63.10-2010 This device described above has been tested by POCE, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of POCE, this document may be altered or revised by POCE, personal only, and shall be noted in the revision of the document. Date of Test................................................... Date (s) of performance of tests.................... Nov. 01, 2015 ~ Nov. 06, 2015 Date of Issue.................................................. Nov. 06, 2015 Test Result..................................................... Pass Testing Engineer : (Lynn Chen) Technical Manager : (Carlen Liu) Authorized Signatory : (Tommy zhang) The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. V1.0 Page 3 of 30 Report No.: POCE15072230NRRF Contents 1 . T E S T S T A N D A RD S. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..4 2 . S U M M A R Y. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . .5 2.1. Equipment Under Test 5 2.2. Description of the Equipment under Test (EUT) 5 2.3. EUT operation mode 6 2.4. EUT configuration 6 2.5. Related Submittal(s) / Grant (s) 6 2.6. Modifications 6 3 . T ES T E N V I R O N M EN T. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 3.1. Address of the test laboratory 7 3.2. Test Facility 7 3.3. Environmental conditions 7 3.4. Configuration of Tested System 7 3.5. Statement of the measurement uncertainty 8 3.6. Equipments Used during the Test 9 4 . T E S T C O N D I T I O N S A N D R E S U L T S. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . .1 0 4.1. Conducted Emissions Test 10 4.2. Transmitter Radiated Unwanted Emissions and Bandedge 14 4.3. Occupied Bandwidth Measurement 20 5 . A N T E N N A R E Q U I R E M E N T. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . .2 5 6 . T E S T S E T U P P H O T O S O F T H E EU T. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . .2 6 7 . E X T E R N A L A N D I N T E R N AL P H O T O S O F T H E E U T. . . . . . . . . . . . . . . . . . . . . .2 7 V1.0 Page 4 of 30 Report No.: POCE15072230NRRF 1 . T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.249: Operation within the bands 902 - 928 MHz, 2400 - 2483.5 MHz, 5725 - 5875 MHz, and 24.0 - 24.25 GHz. ANSI C63.10-2013 ANSI C63.4-2014 V1.0 Page 5 of 30 Report No.: POCE15072230NRRF 2 . S U M M A R Y 2.1. Equipment Under Test Power supply system utilised Power supply voltage : o 120V / 60 Hz o 115V / 60Hz o 12 V DC o 24 V DC ● Other (specified in blank below) DC 5V from USB 2.2. Description of the Equipment under Test (EUT) The EUT ( Speaker with Bluetooth ) support Bluetooth function. Name of EUT Speaker with Bluetooth Model Number DYE-U-BL Antenna Type Internal BT CE Operation frequency 2402MHz-2480MHz BT Modulation Type GFSK,8DPSK,π/4DQPSK(BT V2.1+EDR) Bluetooth BT V2.1+EDR Antenna Gain 0dBi Channel List: Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 00 2402 27 2429 54 2456 01 2403 28 2430 55 2457 02 2404 29 2431 56 2458 03 2405 30 2432 57 2459 04 2406 31 2433 58 2460 05 2407 32 2434 59 2461 06 2408 33 2435 60 2462 07 2409 34 2436 61 2463 08 2410 35 2437 62 2464 09 2411 36 2438 63 2465 10 2412 37 2439 64 2466 11 2413 38 2440 65 2467 12 2414 39 2441 66 2468 13 2415 40 2442 67 2469 14 2416 41 2443 68 2470 15 2417 42 2444 69 2471 16 2418 43 2445 70 2472 17 2419 44 2446 71 2473 18 2420 45 2447 72 2474 19 2421 46 2448 73 2475 20 2422 47 2449 74 2476 21 2423 48 2450 75 2477 22 2424 49 2451 76 2478 23 2425 50 2452 77 2479 24 2426 51 2453 78 2480 25 2427 52 2454 26 2428 53 2455 For more details, refer to the user’s manual of the EUT. Serial number: Prototype V1.0 Page 6 of 30 Report No.: POCE15072230NRRF 2.3. EUT operation mode Test Mode(TM) Description Remark TM1 Bottom Channel Transmitting / TM2 Middle Channel Transmitting / TM3 Top Channel Transmitting / TM4 Charging and keeping TX power by USB The field strength of radiation emission was measured in the following position: EUT stand-up position (Y axis), lie-down position (X, Z axis). The following data show only with the worst case setup. The worst case of Y axis was reported. Based on client request, all normal using modes of the normal function …
