2AGPAPROITelematic Accessory with Display + RFID + Bluetooth

PRO i Installation Guide 1684567848876 - Draft - 2023-07-13 Contents Read me first.........................................................................................................3 Avoiding malfunction and damage..............................................................................................4 What’s in the box..............................................................................................................................5 Installation..............................................................................................................6 Connection overview........................................................................................................................7 Choosing the correct position.......................................................................................................8 Wiring the PRO i...............................................................................................................................9 Configuring the PRO i in Webfleet............................................................................................ 10 Configuring the PRO i in the LINK Toolkit app........................................................................11 Mounting the PRO i........................................................................................................................ 12 Attaching the PRO i using the adhesive strip...........................................................................12 Attaching the PRO i to the air vent..............................................................................................13 Support...............................................................................................................................................14 Technical data..................................................................................................................................15 Compliances......................................................................................................................................16 Addendum............................................................................................................ 17 Important safety notices and warning.......................................................................................18 CE/UK mark and Radio Equipment Directive..........................................................................19 Triman logo......................................................................................................................................20 WEEE – e-waste disposal.............................................................................................................20 FCC information for the user......................................................................................................20 Technical Specifications................................................................................................................ 21 Operating temperature................................................................................................................. 22 Model numbers................................................................................................................................22 Usable with.......................................................................................................................................22 Accessories not supplied with this device.............................................................................. 22 Accessories supplied with this device......................................................................................22 REACH statement – Webfleet..................................................................................................... 22 RoHS statement – Webfleet........................................................................................................ 23 Responsible party in the United Kingdom...............................................................................23 Responsible party in North America.........................................................................................23 Responsible party in Chile........................................................................................................... 23 Customer support contact...........................................................................................................23 Emissions information for Canada.............................................................................................23 Chile....................................................................................................................................................24 Certification for Australia.............................................................................................................24 Warning for Australia....................................................................................................................24 Notice for New Zealand................................................................................................................24 Customer support contact (Australia and New Zealand)....................................................24 Notice for South Africa.................................................................................................................25 Webfleet Telematics Service Platform......................................................................................25 How Webfleet uses your information........................................................................................25 This document.................................................................................................................................25 Terms and conditions and Limited warranty...........................................................................26 Copyright notices............................................…

Text truncated - open the document above for the full version.

Bridgestone Mobility Solutions Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 8/3/2023 U.S. Agent Designation Bridgestone Mobility Solutions B.V. acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: 2AGPAPROI): Name and company of U.S. agent: TT Telematics USA Inc. Physical U.S. address of agent: 100 Summit Drive, Burlington MA 01876 FRN of U.S. agent: No FRN is registered for TT Telematics USA Inc.. We confirm that the TT Telematics USA Inc. does no business with the FCC other than being designated as an U.S agent for service of process. Email address of U.S. agent: [email protected] TT Telematics USA Inc. acknowledges their obligation to accept service of process on behalf of Bridgestone Mobility Solutions B.V.. Bridgestone Mobility Solutions B.V. with the FRN 0025088113 accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the con- clusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Sincerely, Signature Name: Michiel Wesseling Title: CFO Bridgestone Mobility Solutions B.V. Signature Name of U.S. agent: Title of U.S. agent: TT Telematics USA Inc.

Model (EU): PROI FCC ID: 2AGPAPROI IC: 20911-PROI HVIN: PROI G0M‐2306‐2102 Model (EU): PROI FCC ID: 2AGPAPROI IC: 20911-PROI HVIN: PROI G0M‐2306‐2102 Model (EU): PROI FCC ID: 2AGPAPROI IC: 20911-PROI HVIN: PROI G0M‐2306‐2102 Model (EU): PROI FCC ID: 2AGPAPROI IC: 20911-PROI HVIN: PROI G0M‐2306‐2102 Model (EU): PROI FCC ID: 2AGPAPROI IC: 20911-PROI HVIN: PROI G0M‐2306‐2102

Model: PROI Made in Germany 4KSP .001.00 Rating:9-30Vmax 0,1A Bridgestone Mobility Solutions BV NL-1083 HK Amsterdam Beethovenstraat 503 E 1 10R-06xxxx NZ3421W00001

PROI – menu steps to retrieve FCC identifier information PROI – menu steps to retrieve ISED/IC identifier information

Model (EU): PROI FCC ID: 2AGPAPROI IC: 20911-PROI HVIN: PROI G0M-2306-2102 Model (EU): PROI FCC ID: 2AGPAPROI IC: 20911-PROI HVIN: PROI G0M-2306-2102 Model (EU): PROI FCC ID: 2AGPAPROI IC: 20911-PROI HVIN: PROI G0M-2306-2102 RFID Antenna 13,56MHz RFID Antenna 125 kHz BT Antenna

Test Report No.: G0M-2306-2102-TFC093PE-V03 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 1 of 16 RF-EXPOSURE REPORT FCC 47 CFR Part 2.1093 RF-Exposure evaluation of portable equipment Report Reference No G0M-2306-2102-TFC093PE-V03 Testing Laboratory Eurofins Product Service GmbH Address Storkower Str. 38c 15526 Reichenwalde Germany Accreditation A2LA Accredited Testing Laboratory, Certificate No.: 1983.01 FCC Test Firm Designation Number: DE0008 Applicant Bridgestone Mobility Solutions B.V. Address Beethovenstraat 503 1083 HK Amsterdam Netherlands Test Specification According to FCC rules Standard FCC 47 CFR 2.1093 Non-Standard Test Method None Equipment under Test (EUT): Product Description Telematic Accessory with Display + RFID + Bluetooth Model(s) PROI Additional Model(s) None Brand Name(s) webfleet PRO i Hardware Version(s) 46/2022 Software Version(s) 0.0.25 FCC ID 2AGPAPROI Test Result PASSED Test Report No.: G0M-2306-2102-TFC093PE-V03 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 3 of 16 VERSION HISTORY Version History Version Issue Date Remarks Revised By 01 2023-10-18 Initial Release -- 02 2023-11-15 Replaced document: G0M-2306-2102-TFC247BT-V01 Replaced by: G0M-2306-2102-TFC247BT-V02 Replaced document: G0M-2306-2102-TFCAUT-V01 Replaced by: G0M-2306-2102-TFCAUT-V02 Reason: Correction of antenna gain by antenna pattern measurement B. Pudell 03 2023-11-28 Replaced document: G0M-2306-2102-TFC247BT-V02 Replaced by: G0M-2306-2102-TFC247BT-V03 Reason: Remove ISED part from document B. Pudell Test Report No.: G0M-2306-2102-TFC093PE-V03 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 4 of 16 ABBREVIATIONS AND ACRONYMS Acronyms Acronym Description EIRP Equivalent Isotropic Radiated Power ERP Effective Radiated Power EUT Equipment Under Test LPE Low Power Exclusion Test Report No.: G0M-2306-2102-TFC093PE-V03 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 5 of 16 REPORT INDEX 1 Equipment (Test Item) Under Test................................................................................................... 6 1.1 Reference Documents ................................................................................................................................... 7 1.2 Standalone radiation sources ........................................................................................................................ 7 1.3 Concurrent Sources ...................................................................................................................................... 7 2 Radiated Field Measurement............................................................................................................ 8 2.1 Test Conditions and Results – Electric and magnetic field strength .............................................................. 8 3 Result Summary ............................................................................................................................... 10 4 RF-Exposure classification ............................................................................................................ 11 5 RF-Exposure limits and exclusion thresholds ............................................................................ 12 5.1 SAR limits .................................................................................................................................................... 12 5.2 SAR standalone test exclusion threshold .................................................................................................... 12 5.3 SAR concurrent test exclusion threshold ..................................................................................................... 13 6 RF-Exposure Evaluation ................................................................................................................. 14 7 Single Source Evaluation Results - FCC ...................................................................................... 15 8 Concurrent Evaluation Results - FCC ........................................................................................... 16 Test Report No.: G0M-2306-2102-TFC093PE-V03 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 6 of 16 1 Equipment (Test Item) Under Test Description Telematic Accessory with Display + RFID + Bluetooth Model PROI Additional Model(s) None Brand Name(s) webfleet PRO i Serial Number(s) NZ1253W00059; NZ1253W00012 Hardware Version(s) 46/2022 Software Version(s) 0.0.25 FCC ID 2AGPAPROI Contains FCC ID None Equipment type End Product Environment General public Use case Body worn Test Report No.: G0M-2306-2102-TFC093PE-V03 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 7 of 16 1.1 Reference Documents Document Type Document No. Issued by Date Testreport G0M-2306-2102-TFC247BT-V02 Eurofins Product Service GmbH 2023-11-15 Testreport G0M-2306-2102-TFCAUT-V02 Eurofins Product Service GmbH 2023-11-15 Testreport G0M-2306-2102-TFC225RI-V01 Eurofins Product Service GmbH 2023-08-09 1.2 Standalone radiation sources Standalone radiation sources Mode Operating Frequency [MHz] Maximum conducted power [dBm] Maximum radiated power [dBm EIRP] Maximum duty cycle [%] Antenna distance to body [mm] Bluetooth 2402 1.051 3.681 78 5.0 2441 2.230 4.860 78 5.0 2480 2.467 5.097 78 5.0 RFID 13.56 MHz 13.56 -44.5 -42.3 100 5.0 RFID 125 kHz 0.125 -28.9 -31.1 100 5.0 Comment: -- 1.3 Concurrent Sources Concurrent operating conditions Bluetooth + RFID 13.56 MHz Comment: -- Test Report No.: G0M-2306-2102-TFC093PE-V03 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 8 of 16 2 Radiated Field Measurement 2.1 Test Conditions and Results – Electric and magnetic field strength 2.1.1 Information Test Information Measurement Method Radiated only Operator Azamat Ibraimov Date 2023-09…

Text truncated - open the document above for the full version.

Test Report No.: G0M-2306-2102-TFC247BT-V02 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 1 of 114 RADIO REPORT FCC 47 CFR Part 15C ISED Canada RSS-247 Frequency hopping systems operating within the 2400.0 MHz - 2483.5 MHz MHz band Report Reference No G0M-2306-2102-TFC247BT-V02 Testing Laboratory Eurofins Product Service GmbH Address Storkower Str. 38c 15526 Reichenwalde Germany Accreditation DAkkS - Registration number : D-PL-12092-01-03 (ISED) ISED Testing Laboratory site: 3470A DAkkS - Registration number : D-PL-12092-01-04 (FCC) FCC Filed Test Laboratory, Reg.-No.: 96970 Applicant Bridgestone Mobility Solutions B.V. Address Beethovenstraat 503 1083 HK Amsterdam Netherlands Test Specification 47 CFR Part 15C RSS-247, Issue 3, 2023-08 RSS-Gen, Issue 5, Amendment 2, 2021-02 Non-Standard Test Method None Equipment under Test (EUT): Product Description Telematic Accessory with Display + RFID + Bluetooth Model(s) PROI Additional Model(s) None Brand Name(s) webfleet PRO i Hardware Version(s) 46/2022 Software Version(s) 0.0.25 FCC ID 2AGPAPROI IC 20911-PROI Test Result PASSED Test Report No.: G0M-2306-2102-TFC247BT-V02 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 3 of 114 VERSION HISTORY Version History Version Issue Date Remarks Revised By 01 2023-10-19 Initial Release -- 02 2023-11-15 Replaced document: G0M-2306-2102-TFC247BT-V01 Replaced by: G0M-2306-2102-TFC247BT-V02 Reason: Correction of antenna gain by antenna pattern measurement Burkhard Pudell Test Report No.: G0M-2306-2102-TFC247BT-V02 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 4 of 114 ABBREVIATIONS AND ACRONYMS Acronyms Acronym Description BR Basic Rate (Bluetooth) EDR Enhanced Data Rate (Bluetooth) EUT Equipment Under Test FCC Federal Communications Commission ISED Innovation, Science and Economic Development Canada RBW Resolution bandwidth RMS Root mean square VBW Video bandwidth V NOM Nominal supply voltage Test Report No.: G0M-2306-2102-TFC247BT-V02 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 5 of 114 REPORT INDEX 1 Equipment (Test Item) Under Test................................................................................................... 6 1.1 Photos – Equipment External ........................................................................................................................ 7 1.2 Photos – Equipment Internal ......................................................................................................................... 9 1.3 Support Equipment ...................................................................................................................................... 11 1.4 Test Modes ................................................................................................................................................. 11 1.5 Test Frequencies ......................................................................................................................................... 11 1.6 Sample emission level calculation ............................................................................................................... 12 2 Result Summary ............................................................................................................................... 13 3 Test Conditions and Results .......................................................................................................... 14 3.1 Test Conditions and Results - Occupied bandwidth .................................................................................... 14 3.2 Test Conditions and Results - 20 dB bandwidth .......................................................................................... 25 3.3 Test Conditions and Results - Number of hopping frequencies .................................................................. 36 3.4 Test Conditions and Results - Frequency hopping channel separation....................................................... 38 3.5 Test Conditions and Results - Time of occupancy (Dwell time) .................................................................. 43 3.6 Test Conditions and Results - Maximum peak conducted output power ..................................................... 46 3.7 Test Conditions and Results - Band-edge compliance ................................................................................ 57 3.8 Test Conditions and Results - Conducted spurious emissions .................................................................... 71 3.9 Test Conditions and Results - Transmitter radiated emissions ................................................................... 82 3.10 Test Conditions and Results - Receiver radiated emissions ....................................................................... 89 ANNEX A Transmitter spurious emissions ....................................................................................................... 94 ANNEX B Receiver spurious emissions ......................................................................................................... 111 Test Report No.: G0M-2306-2102-TFC247BT-V02 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 6 of 114 1 Equipment (Test Item) Under Test Description Telematic Accessory with Display + RFID + Bluetooth Model PROI Additional Model(s) None Brand Name(s) webfleet PRO i Serial Number(s) NZ1253W00059 / NZ1253W00012 Test Sample Id(s) Radiated: 44644 / Conducted: 44649 Hardware Version(s) 46/2022 Software Version(s) 0.0.25 PMN webfleet PRO i HVIN PROI FVIN 0.0.25 HMN n/a FCC ID 2AGPAPROI IC 20911-PROI Equipment type End Product Radio type Transceiver Assigned frequency bands 2400.0 MHz - 2483.5 MHz Radio technology Bluetooth Classic Power Class 2 (2.5 mW / +4 dBm) Modulation GFSK, PI/4-DQPSK, 8-DPSK Number of antenna ports 1 Antenna Type integral Model PCB trace ant…

Text truncated - open the document above for the full version.

Test Report No.: G0M-2306-2102-TFCAUT-V02 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 1 of 20 ANTENNA TEST REPORT Antenna operating within the 2400.0 MHz - 2483.5 MHz band Report Reference No G0M-2306-2102-TFCAUT-V02 Testing Laboratory Eurofins Product Service GmbH Address Storkower Str. 38c 15526 Reichenwalde Germany Applicant Bridgestone Mobility Solutions B.V. Address Beethovenstraat 503 1083 HK Amsterdam Netherlands Equipment under Test (EUT): Product Description Telematic Accessory with Display + RFID + Bluetooth Model(s) PROI Additional Model(s) None Brand Name(s) webfleet PRO i Hardware Version(s) 46/2022 Software Version(s) 0.0.25 FCC ID 2AGPAPROI Test Report No.: G0M-2306-2102-TFCAUT-V02 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 3 of 20 VERSION HISTORY Version History Version Issue Date Remarks Revised By 01 2023-10-19 Initial Release - 02 2023-11-15 Replaced document: G0M-2306-2102-TFCAUT-V01 Replaced by: G0M-2306-2102-TFCAUT-V02 Reason: Antenna Measurements for 2402 MHz and 2480 MHz added. R. Jaafar Test Report No.: G0M-2306-2102-TFCAUT-V02 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 4 of 20 ABBREVIATIONS AND ACRONYMS Acronyms Acronym Description EUT Equipment Under Test FCC Federal Communications Commission V NOM Nominal supply voltage Test Report No.: G0M-2306-2102-TFCAUT-V02 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 5 of 20 REPORT INDEX 1 Equipment (Test Item) Under Test................................................................................................... 6 1.1 Photos ........................................................................................................................................................... 7 1.2 Photos – Equipment Internal ......................................................................................................................... 9 1.3 Support Equipment ...................................................................................................................................... 11 1.4 Test Modes ................................................................................................................................................. 12 1.5 Test Frequencies ......................................................................................................................................... 12 2 Test Conditions and Results .......................................................................................................... 13 2.1 Test Conditions and Results – Antenna pattern .......................................................................................... 13 ANNEX A Antenna patterns .............................................................................................................................. 15 Test Report No.: G0M-2306-2102-TFCAUT-V02 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 6 of 20 1 Equipment (Test Item) Under Test Description Telematic Accessory with Display + RFID + Bluetooth Model PROIC Additional Model(s) None Brand Name(s) webfleet PRO i Serial Number(s) 00213E8059F6 Test Sample Id(s) 44644 Hardware Version(s) 46/2022 Software Version(s) 0.0.25 FCC ID 2AGPAPROI Equipment type End Product Radio type Transceiver Assigned frequency bands 2400.0 MHz - 2483.5 MHz Radio technology Bluetooth Classic Modulation GFSK, PI/4-DQPSK, 8-DPSK Number of antenna ports 1 Antenna Type integral Model PCB trace antenna Manufacturer Webfleet Solutions Gain 2.6 dBi (by antenna pattern measurement) Supply Voltage V NOM 12/24 VDC Operating Temperature T NOM 25 °C AC/DC-Adaptor None Manufacturer Bridgestone Mobility Solutions B.V. Beethovenstraat 503 1083 HK Amsterdam Netherlands Test Report No.: G0M-2306-2102-TFCAUT-V02 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 7 of 20 1.1 Photos EUT Overview EUT Top View Test Report No.: G0M-2306-2102-TFCAUT-V02 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 8 of 20 EUT Bottom View Test Report No.: G0M-2306-2102-TFCAUT-V02 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 9 of 20 1.2 Photos – Equipment Internal PROI PCBA Front with Display PROI PCBA Back with Display Test Report No.: G0M-2306-2102-TFCAUT-V02 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 10 of 20 PROI PCBA Back without Display Test Report No.: G0M-2306-2102-TFCAUT-V02 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 11 of 20 1.3 Support Equipment Product Type Device Manufacturer Model Comment SIM Communication Tester R&S CMW270 BT-Tester Description: AE Auxiliary Equipment SIM Simulator CBL Connecting Cable SFT Software Comment: Test Report No.: G0M-2306-2102-TFCAUT-V02 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 12 of 20 1.4 Test Modes Mode Description DH5 Single Mode = Transmit Modulation = GFSK Spreading = None Packet type = DH5 Duty cycle = 78% Comment: 1.5 Test Frequencies Designator Mode Channel Frequency [MHz] F1 Tx 0 2402 F2 Tx 39 2441 F3 Tx 79 2480 Test Report No.: G0M-2306-2102-TFCAUT-V02 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 13 of 20 2 Test Conditions and Results 2.1 Test Conditions and Results – Antenna pattern 2.1.1 Information Test Information Operator Mr. Offorji Date 2023-08-23 2.1.2 Setup Test Setup 2.1.3 Equipment Test Software Description Manufacturer Name Version Antenna pattern software Eurofins Product Service GmbH Eurofins Antenna Pattern 1.9 Test Equipment Description Manufacturer Model Identifier Cal. Date Cal. Due Anechoic chamber Frankonia AC 4 EF00200 --- --- Spectrum analyzer R&S FSU26 EF01407 2023-08 2024-08 Antenna Schwarzbeck BBHA 9120B EF01678 2021-03 2024-03 2.1.4 Procedure …

Text truncated - open the document above for the full version.

Model (EU): PROI FCC ID: 2AGPAPROI IC: 20911-PROI HVIN: PROI G0M‐2306‐2102 Model (EU): PROI FCC ID: 2AGPAPROI IC: 20911-PROI HVIN: PROI G0M‐2306‐2102 Model (EU): PROI FCC ID: 2AGPAPROI IC: 20911-PROI HVIN: PROI G0M‐2306‐2102 Model (EU): PROI FCC ID: 2AGPAPROI IC: 20911-PROI HVIN: PROI G0M‐2306‐2102 Model (EU): PROI FCC ID: 2AGPAPROI IC: 20911-PROI HVIN: PROI G0M‐2306‐2102 Model (EU): PROI FCC ID: 2AGPAPROI IC: 20911-PROI HVIN: PROI G0M‐2306‐2102 Model (EU): PROI FCC ID: 2AGPAPROI IC: 20911-PROI HVIN: PROI G0M‐2306‐2102
