2AGROLK-BH015Wireless headphone

160g / / + - M 2. Function instruction 1) .TF card player 2) .FM radio(87.5~108) 3) .Bluetooth function 4) .Card reader function 5) .PC headphone 3. Power on/off: Power on: long press " " button to open The headset. The player will enter into Bluetooth mode automatically while you turn on. Power off: Long press " " button to close The headset. 4. Mode shift 1) .No insert TF card: press and hold “ ” to shift between FM and Bluetooth. 2) .Inserting TF card before turning on player: press “ ” to shift, and the shift Sequence is BLUETOOTH-TF CARD MODE-FM. 3) .Inserting TF card after turning on player: when you turn on player, it’ll enter Bluetooth status automatically. And if you want to shift to other mode TF card player or FM), then press “M” to shift, and the shift Sequence is BLUETOOTH- TF CARD MODE-FM . 5. TF CARD PLAYER 1) .To play music: When you insert the TF card (micro SD card) with MP3 or WAV format music into the card slot, turn on the player, then you can enjoy the music. The LED indicator will be in green and will flash per 0.5 second while playing music. 2) .To change the volume: press and hold “ ” to increasing the volume; press and hold “ ” to decreasing the volume. 3) .To choose next or previous song: press “ ” to the previous song; press “ ” to choose next song. 6. FM radio 1) .Auto search channel: when you shift the player into FM radio mode, press “ ” again, then player will search FM frequency automatically. The indicator will be in green and flash fast at this moment. It’ll save all the frequencies it searches while there is Micro SD memory card plug in TF card slot. And it’ll play the first frequency searched after finishing searching automatically. The indicator will be in green at this moment. 2) .To change the volume: under FM mode, press and hold “ ” to increasing the volume; press and hold “ ” to decreasing the volume. 3) .To choose next or previous channel: under FM mod, press “ ” to the previous channel saved; press “ ” to choose next channel saved. 7. Bluetooth function 1) .Bluetooth mode: When you turn on the player, it’ll enter Bluetooth mode automatically. And if it’s under FM mode or TF card player mode, then you just press and hold “ ” to enter Bluetooth mode again (the shift Sequence is BLUETOOTH-TF CARD MODE-FM). 2) .Bluetooth pairing: turn on the headphone and enter Bluetooth mode (the indication light will be green and flash per 2 seconds), then use your mobile or other electronic equipment which have Bluetooth function to search the headphone, its display name is “BH-35”, and your mobile will pop-up dialogue (only first time your mobile connect the player), then you just choose YES to connect, then the player have the voice reminder: the device connected. Then your mobile (or any other Bluetooth equipment) finish connection with the player. 3) .Bluetooth re-pairing: any electronic equipment which you have paired the Bluetooth with this headphone will connect the headphone automatically as soon as they are in the same place and keep 10m in the range, and only the two with Bluetooth are under turn on status. 4) .Listen music: under Bluetooth mode, you just play the music on mobile or any other equipment paired, and then you can enjoy the music by the headphone. Pause/Play music: under Bluetooth status, you can press “ ” or your mobile or any other Bluetooth media player’s PAUSE/PLAY button to pause, and you can press “ ” or your mobile (or any other Bluetooth media player’s PAUSE /PLAY button to back to play music. To change the volume: under playing music by Bluetooth mode, press and hold “ + ” to increasing the volume; press and hold “ - ” to decreasing the volume. Or you can adjust the volume on your mobile or any other Bluetooth media player. To choose next or previous song: press “ + ” to choose the previous song; press “ - ” to choose next song. Or you can choose the song on your mobile or any other Bluetooth media player. 5) .Talking phone: a) Receiving calling: when you enjoy the music under Bluetooth mode, or the headphone Bluetooth standby, the headphone will receive calling automatically. And you just press “ ” to get the calling. b) Hang up the phone: Press “ ” again to hang up the phone while you are speaking on phone. The headphone will transfer to play the music automatically as soon as the caller hangs up the phone if your headphone base on playing Bluetooth music case. c) To change the volume: while talking on phone by Bluetooth, press and hold “ ” to increasing the volume; press and hold “ ” to decreasing the volume. d) Redial/replay music: Whether you are listening music (under Bluetooth status) or the player is under Bluetooth standby, you press “ ” one time to control pause or replay music, you press “ ” 2 times continuously, then you can redial the phone number you have dialed last time. 8. PC headphone function Please keep headphone on power off, and connect the headphone to computer by AV cable, then you can use the headphone as a PC headphone. The indicator will be in red at this moment. 11. Specification 12. Trouble shooting 9. Card reader function Please keep the headphone on turning on, and connect the headphone to computer by USB cable, then you can use the headphone as the card reader to load or copy data to memory card from computer. The indicator will be in red at this moment. 10. Recharge When you use off the power of player, It’ll take around 4 hours to recharge the power. The LED indicator will be in red while charging and the LED indicator will be slaked as soon as the power is full. Product Size 170*160*80mm Supporting Music Format <100mAh 300mAh MODEL NO.:BH-35 Mode play/Pause Next/V+ Prvious/v- M / / + / M / M / M / + / / + / / + / / / + / M / M / M / + / / M / M / This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may caus…

Text truncated - open the document above for the full version.

Differences Description We Move&Groove Limited state: Product name: Wireless headphone Model: LK-BH015, JY-35, Rock-N-Grv, BH-35 All model’s the function, software and electric circuit are the same, only different in Model Name. Signature: 2015-12-10 Name Adam Prideaux Position Manager Company Name Move&Groove Limited Address Room 1203, 12/F, Tower 3 China Hong Kong City, 33 Canton Road, Tsimshatsui, Kowloon, Hong Kong China Te l + 852 2157 8788 Fax + 852 2157 8788 Email [email protected]

Dec.-10-15 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AGROLK-BH015_ Product Name: Wireless headphone Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: • Schematics Long-term confidential • Block diagram Long-term confidential • Operation description Long-term confidential These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Signature: Name Adam Prideaux Position Manager Company Name Move&Groove Limited Address Room 1203, 12/F, Tower 3 China Hong Kong City, 33 Canton Road, Tsimshatsui, Kowloon, Hong Kong China Tel + 852 2157 8788 Fax + 852 2157 8788 Email [email protected]

Label 20mm 10mm Label FCC ID: 2AGROLK-BH015 Move&Groove Limited Model name: Wireless headphone Model No.: LK‐BH015

FCCID:2AGROLKBH015    RFExposureevaluation According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances İ50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] g[Ĝf(GHz)]İ3.0 for 1-g SAR and İ7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Worse case is as below: [2402MHz 4.48(2.805mW) output power] (2.805mW /5mm) g[Ĝ2.402(GHz)]= 0.869 <3.0 for 1-g SAR ThenSARevaluationisnotrequired Worse caseis as below: [2402MHz4.48dBm

Shenzhen Alpha Product Testing Co., Ltd. TEST REPORT FCC ID: 2AGROLK-BH015 Applicant : Move&Groove Limited Address : Room 1203, 12/F, Tower 3 China Hong Kong City, 33 Canton Road, Tsimshatsui, Kowloon, Hong Kong China Equipment Under Test (EUT): Name : Wireless headphone Model : LK-BH015, JY-35, Rock-N-Grv, BH-35 Trade Name N/A Standards : FCC PART 15, SUBPART C: 2015 (Section 15.247) Report No :T1851841 01 Date of Test :December 03-10, 2015 Date of Issue :December 10, 2015 Ts e t R e s u l t : PASS In the configuration tested, the EUT complied with the standards specified above Authorized Signature (Mark Zhu) Manager The manufacture should ensure that all the products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of Shenzhen Alpha Product Testing Co., Ltd. Or test done by Shenzhen Alpha Product Testing Co., Ltd. Approvals in connection with, distribution or use of the product described in this report must be approved by Shenzhen Alpha Product Testing Co., Ltd. Approvals in writing. Page 2 of 73 Report No.: T1851841 01 Contents 1.General Information ............................................................................................................... 4 1.1.Description of Device (EUT) ...............................................................................4 1.2.Accessories of device (EUT) ...............................................................................5 1.3.Test Lab information ............................................................................................5 2.Summary of test ...................................................................................................................... 6 2.1.Summary of test result .........................................................................................6 2.2.Assistant equipment used for test .........................................................................6 2.3.Block Diagram .....................................................................................................7 2.4.Test mode .............................................................................................................7 2.5.Test Conditions .....................................................................................................8 2.6.Measurement Uncertainty (95% confidence levels, k=2) ....................................8 2.7.Test Equipment .....................................................................................................9 3.Maximum Peak Output power ............................................................................................ 10 3.1.Limit ...................................................................................................................10 3.2.Test Procedure ....................................................................................................10 3.3.Test Setup ...........................................................................................................10 3.4.Test Result ..........................................................................................................10 4.Bandwidth ............................................................................................................................. 11 4.1.Limit ................................................................................................................... 11 4.2.Test Procedure .................................................................................................... 11 4.3.Test Result .......................................................................................................... 11 5.Carrier Frequency Separation ............................................................................................. 17 5.1.Limit ...................................................................................................................17 5.2.Test Procedure ....................................................................................................17 5.3.Test Result ..........................................................................................................17 6.Number Of Hopping Channel ............................................................................................. 20 6.1.Limit ...................................................................................................................20 6.2.Test Procedure ....................................................................................................20 6.3.Test Result ..........................................................................................................20 7.Dwell Time ............................................................................................................................. 23 7.1.Test limit ............................................................................................................23 7.2.Test Procedure ....................................................................................................23 7.3.Test Results ........................................................................................................23 8.Radiated emissions ................................................................................................................ 30 8.1.Limit ...................................................................................................................30 8.2.Block Diagram of Test setup ..............................................................................31 8.3.Test Procedure ....................................................................................................32 8.4.Test Result .................................…

Text truncated - open the document above for the full version.

Page 41 of 73 Report No.: T1851841 01 1GHz—25GHz Radiated emissison Test result EUT: Wireless headphone M/N: LK-BH015 Power: DC 3.7V From Battery Test date: 2015-12-05 Test site: 3m Chamber Tested by: Eric Test mode: 8- DQPSK Tx CH1 2402MHz Antenna polarity: Vertical No Freq (MHz) Read Level (dBuV/m) Antenna Factor (dB/m) Cable loss(d B) Amp Factor (dB) Result (dBuV/m) Limit (dBuV/m) Margin (dB) Remark 1 4804 43.27 33.98 10.22 34.25 53.22 74 20.78 PK 2 4804 31.51 33.98 10.22 34.25 41.46 54 12.54 AV 3 7206 / 4 9608 / 5 12010 / Antenna Polarity: Horizontal 1 4804 42.33 33.98 10.22 34.25 52.28 74 21.72 PK 2 4804 31.74 33.98 10.22 34.25 41.69 54 12.31 AV 3 7206 / 4 9608 / 5 12010 / Note: 1, Measuring frequency from 1GHz to 25GHz 2, Spectrum Set for PK measure: RBW=1MHz, VBW=1MHz, Sweep time=Auto, Detector: PK 2, Spectrum Set for AV measure: RBW=1MHz, VBW=10Hz, Sweep time=Auto, Detector: PK 3, Result = Read level + Antenna factor + cable loss-Amp factor 4, All the other emissions not reported were too low to read and deemed to comply with FCC limit. Page 42 of 73 Report No.: T1851841 01 1GHz—25GHz Radiated emissison Test result EUT: Wireless headphone M/N: LK-BH015 Power: DC 3.7V From Battery Test date: 2015-12-05 Test site: 3m Chamber Tested by: Eric Test mode: 8- DQPSK Tx CH40 2441MHz Antenna polarity: Vertical No Freq (MHz) Read Level (dBuV/m) Antenna Factor (dB/m) Cable loss(d B) Amp Factor (dB) Result (dBuV/m) Limit (dBuV/ m) Margin (dB) Remark 1 4882 43.04 33.93 10.234.2952.88 74 21.12 PK 2 4882 34.25 33.93 10.234.2944.09 54 9.91 AV 3 7323 / 4 9764 / 5 12205 / Antenna Polarity: Horizontal 1 4882 43.05 33.93 10.234.2952.89 74 21.11 PK 2 4882 31.31 33.93 10.234.2941.15 54 12.85 AV 3 7323 / 4 9764 / 5 12205 / Note: 1, Measuring frequency from 1GHz to 25GHz 2, Spectrum Set for PK measure: RBW=1MHz, VBW=1MHz, Sweep time=Auto, Detector: PK 2, Spectrum Set for AV measure: RBW=1MHz, VBW=10Hz, Sweep time=Auto, Detector: PK 3, Result = Read level + Antenna factor + cable loss-Amp factor 4, All the other emissions not reported were too low to read and deemed to comply with FCC limit. Page 43 of 73 Report No.: T1851841 01 1GHz—25GHz Radiated emissison Test result EUT: Wireless headphone M/N: LK-BH015 Power: DC 3.7V From Battery Test date: 2015-12-05 Test site: 3m Chamber Tested by: Eric Test mode: 8- DQPSK Tx CH79 2480MHz Antenna polarity: Vertical No Freq (MHz) Read Level (dBuV/m) Antenna Factor (dB/m) Cable loss(d B) Amp Factor (dB) Result (dBuV/m) Limit (dBuV/ m) Margin (dB) Remark 1 4960 41.87 33.95 10.1834.2651.74 74 22.26 PK 2 4960 31.84 33.95 10.1834.2641.71 54 12.29 AV 3 7440 / 4 9920 / 5 12400 / Antenna Polarity: Horizontal 1 4960 43.44 33.95 10.1834.2653.31 74 20.69 PK 2 4960 32.67 33.95 10.1834.2642.54 54 11.46 AV 3 7440 / 4 9920 / 5 12400 / Note: 1, Measuring frequency from 1GHz to 25GHz 2, Spectrum Set for PK measure: RBW=1MHz, VBW=1MHz, Sweep time=Auto, Detector: PK 2, Spectrum Set for AV measure: RBW=1MHz, VBW=10Hz, Sweep time=Auto, Detector: PK 3, Result = Read level + Antenna factor + cable loss-Amp factor 4, All the other emissions not reported were too low to read and deemed to comply with FCC limit. Page 44 of 73 Report No.: T1851841 01 9. Band Edge Compliance 9.1. Block Diagram of Test Setup  9.2. Limit All the lower and upper band-edges emissions appearing within restricted frequency bands shall not exceed the limits shown in 15.209, all the other emissions outside operation shall be at least 20dB below the fundamental emissions, or comply with 15.209 limits. 9.3. Test Procedure All restriction band and non- restriction band have been tested ˈonly worse case is reported. 9.4. Test Result PASS. (See below detailed test data) Page 45 of 73 Report No.: T1851841 01 Radiated Method GFSK ( CH Low ) Band Edge Test result EUT: Wireless headphone M/N: LK-BH015 Power: DC 3.7V From battery Test date: 2015-12-05 Test site: 3m Chamber Tested by: Eric Test mode: Tx CH Low 2402MHz Antenna polarity: Vertical Freq (MHz) Read Level (dBuV/m) Antenna Factor (dB/m) Cable loss(d B) Amp Factor (dB) Result (dBuV/m) Limit (dBuV/m) Margin (dB) Remark 2390 44.96327.623.9234.9741.53374 32.467 PK 2390 --27.623.9234.97--54--AV 2400 42.0927.623.9434.9738.6874 35.32 PK 2400 --27.623.9434.97--54--AV Antenna Polarity: Horizontal 2390 44.1527.62 3.9234.9740.7274 33.28 PK 2390 --27.62 3.9234.97--54--AV 2400 40.9827.62 3.9434.9737.5774 36.43 PK 2400 --27.623.9434.97--54--AV Note: 1, Spectrum Set for PK measure: RBW=1MHz, VBW=1MHz, Sweep time=Auto, Detector: PK 2, Spectrum Set for AV measure: RBW=1MHz, VBW=10Hz, Sweep time=Auto, Detector: PK 3, Result = Read level + Antenna factor + cable loss-Amp factor 4, All the other emissions not reported were too low to read and deemed to comply with FCC limit. Page 46 of 73 Report No.: T1851841 01 GFSK (CH High) Band Edge Test result EUT: Wireless headphone M/N: LK-BH015 Power: DC 3.7V From battery Test date: 2015-12-05 Test site: 3m Chamber Tested by: Eric Test mode: Tx CH High 2480MHz Antenna polarity: Vertical Freq (MHz) Read Level (dBuV/m) Antenna Factor (dB/m) Cable loss(d B) Amp Factor (dB) Result (dBuV/m) Limit (dBuV/m) Margin (dB) Remark 2483.5 42.9627.89 434.9739.8874 34.12 PK 2483.5 --27.89 434.97 --54 --AV Antenna Polarity: Horizontal 2483.5 41.8927.89 434.9738.8174 35.19 PK 2483.5 --27.89 434.97 --54 --AV Note: 1, Spectrum Set for PK measure: RBW=1MHz, VBW=1MHz, Sweep time=Auto, Detector: PK 2, Spectrum Set for AV measure: RBW=1MHz, VBW=10Hz, Sweep time=Auto, Detector: PK 3, Result = Read level + Antenna factor + cable loss-Amp factor 4, All the other emissions not reported were too low to read and deemed to comply with FCC limit. Page 47 of 73 Report No.: T1851841 01 GFSK ( Hopping Low) Band Edge Test result EUT: Wireless headphone M/N: LK-BH015 Power: DC 3.7V From battery Test date: 2015-12-05 Test site: 3m Chamber Tested by: Eric Test mode: Tx Antenna polarity: Vertical Freq (MHz) Read Level (dBuV/m) Antenna Factor (dB/m) Cable loss(d B) Amp Factor (dB) Resu…

Text truncated - open the document above for the full version.

Photos of Radiated emission Photos of Conducted Emission test
