2AGY9BS-20Bluetooth soundbar speaker

1.Hold down for 3-5 seconds, then you will hear the prompt tone with the LED light flashing. Bluetooth searching mode starts automatically after power on. 2.Switch on Bluetooth searching mode on the cell phone. After pairing successfully, the device name(BS-20) will be shown connected on the cell phone, then you can open phone player and play songs. Due to different brands of mobile phone and Bluetooth versions, the searching and pairing time will be various. Under normal circumstances, it only takes 30 seconds. If the pairing password is needed, please type “0000” on the cell phone. 3.Hold down or button to volume down or up. 4.Briefly press or button to switch between songs. 5.Briefly press button to play or pause the music. User Manual BS-20 Graphic illustration Operation instruction Function Indicator Battery Charge Use the USB charging cable provided to connect the speaker to 5V USB power socket or an adaptor with USB 2.0 socket(5V/1A or over 1A) to charge the batteries. The indicator light will flash red during charging. Once the battery is fully charged, the red indicator light will go out. Attention: The speaker charging input voltage is 4.5V-5.5V, please do not exceed the safe voltage range, otherwise it will damage the speaker. Bluetooth Mode 1.Plug the TF card into the TF card reader. 2.Hold down for 3-5 seconds, then you will hear the prompt tone with the LED light flashing. Soundbar will automatically switch into TF card Mode. If it is in a different mode, switch to TF card mode by using the mode selector. 3.Hold down or button to volume down or up. 4.Briefly press or button to switch between songs. 5.Briefly press button to play or pause the music. 6.TF card insert direction is as below. TF Card Mode 1.Use a 3.5mm AUX cable to connect your cell phone / MP3 / PC and connect the cable to the AUX socket on the soundbar. 2.Hold down for 3-5 seconds, then you will hear the prompt tone with the LED light flashing. Soundbar will automatically switch into AUX Mode. If it is in a different mode, switch to AUX mode by using the mode selector. 3.Hold down or button to volume down or up. 4.Briefly press button to play or mute the music. Attention: In AUX mode, the soundbar cannot switch between songs. AUX Mode Attention: The mode of TV and soundbar should be consistent, please find the corresponding output mode to connect. Remote Control Soundbar can be connected to TV/PC/Cell Phone/Game machine/Projector/Set-top box Soundbar connected to TV Two BS-20 speakers can implement TWS true wireless speaker function. 1.Turn on speaker and enter Bluetooth mode. Hold down for 3 seconds then you can hear a tone "ding" and the LED light will flash. 2.Turn on speaker and enter Bluetooth mode. Hold down for 3 seconds then you can hear a tone "ding" and the LED light will flash. 3.Waiting for two speakers to connect to each other automatically. LED light will stay on after establishing connection and you will hear a tone “ding” . Now two speakers are ready to establish Bluetooth connection with your phone. 4.Switch on Bluetooth search mode on your phone and establish connection with the speakers. Please note the information on the Bluetooth connection method. 5.Either the buttons on speaker or remote control can control two speakers simultaneously. Attention: TWS function only works in Bluetooth mode. Numbers of connection is 2. Two speakers will become one after TWS Bluetooth connection. If two speakers are fail to establish TWS connection, please restart two speakers and try again, make sure two speakers are in Bluetooth mode. TWS True Wireless Speaker Function 1.If the soundbar cannot be turned on, please charge the battery. 2.When a low battery reminder appears, please connect the charger immediately to charge, and reduce the playback volume to 50%. It can be used while charging. 3.Cannot establish a connection even after multiple attempts? (1) Check whether the soundbar is in Bluetooth search mode. (2) If there are too many Bluetooth receivers in the vicinity, this can hamper the search process. Please turn off other Bluetooth receivers. (3) Open the Bluetooth settings on your phone, disconnect then try again to establish a connection. 4.The volume of soundbar is too low or there are distortion? Please check the volume settings of your phone and adjust the volume. 5.Is the signal being dropped when playing music? Please check whether the distance exceeds the effective range or whether there are any physical barriers between your phone and the soundbar. 6.The buttons appear to have no effect on the soundbar? Please try to use the player on phone or other players. 7.If the soundbar cannot be controlled during use, please reset it using the appropriate tool. The hardware reset button is concealed inside the AUX connection. 3.If the soundbar receives no inputs for 5 minutes, it will switch off automatically to save power. FCC Caution. (1)§ 15.19 Labelling requirements. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. § 15.21 Changes or modification warning Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. § 15.105 Information to the user. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If …

Text truncated - open the document above for the full version.

Zhongshan World Team Electronics Co., Ltd. Model differences We: Zhongshan World Team Electronics Co., Ltd.Statement that All the model“BS-20, BS -28E, BS-41A, BS-10A, BS-20A, BS-18A, BS-18C, WS-005,BS-18D,BS-20B, BS-13, BS-1 5, BS-16, BS-17, BS-19, BS-27, BS-29, BS-31, BS-33, BS-35” All model’s the function, software and electric circuit are the same, only with a product color and model named different. Name: Fanny LuoDate: 2021.06.25 Title: Manager Signature of applicant:

C5266091_X8_Ed.1 1/1 LetterofAuthorization <ZhongshanWorldTeamElectronicsCo.,Ltd.> Company:ZhongshanWorldTeamElectronicsCo.,Ltd. Address:3rdfloor,No.132QiWanNorthRoad,EastArea,Zhongshan city,Guangdongprovince,China ProductName:Bluetoothsoundbarspeaker ModelNumber:BS-20 FCCIdentifier:2AGY9BS-20 WeauthorizeLGAITechnologicalCenterS.A.,RondadelaFontdelCarme,s/n, 08193Bellaterra,Spain,toactonourbehalfonallmattersconcerningthe abovenamedequipment. AnyindividualwithinLGAITechnologicalCenterS.A.isauthorizedtoactonour behalfandtakeactionontheapplication. WedeclarethatauthorizeLGAITechnologicalCenterS.A.,RondadelaFontdel Carme,s/n,08193Bellaterra,Spain,isallowedtoforwardallinformation relatedtotheapprovalprojecttotheFederalCommunicationCommissionand todiscussanyissuesconcerningtheapprovalapplication.Anyandallacts carriedoutbyLGAITechnologicalCenterS.A.onourbehalfshallhavethe sameeffectasactsofourown. Name:FannyLuoDate:2021.06.25 Title:Manager Signatureofapplicant:

C5266091_X10_Ed.1 1/1 ZhongshanWorldTeamElectronicsCo.,Ltd. 3rdfloor,No.132QiWanNorthRoad,EastArea,Zhongshancity,Guangdongprovince, China Date:2021.06.25 Subject:RequestforConfidentiality FCCID:2AGY9BS-20 ToWhomItMayConcern, PursuanttotheprovisionsofSections0.457and0.459ofCommission'srules (47CFR0.457,0.459),wearerequestingtheCommissiontowithholdthefollowing attachment(s)asconfidentialdocumentfrompublicdisclosure. ExhibitsLong-Term Confidentiality Short-Term Confidentiality IDLabel/LocationNoNo AttestationStatementNoNo ExternalPhotosNo BlockDiagram Schematics TestReportNoNo TestSetupPhotosNo User’sManual InternalPhotos PartsList/TuneUp RFExposureInfo OperationalDescription CoverLetter(s)NoNo SDRSoftware/SecurityInfoNo Abovementioneddocumentcontainsdetailedsystemandequipmentdescriptionare consideredasproprietaryinformationinoperationoftheequipment.Thepublic disclosureofabovedocumentsmightbeharmfultoourcompanyandwouldgive competitoranunfairadvantageinthemarket. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondentduringcertificationreviewprocesscannotbegrantedasconfidential documentsandthoseinformationwillbeavailableforpublicreviewoncethegrantof equipmentauthorizationisissued. Sincerely, Name:FannyLuoDate:2021.06.25 Title:Manager Signatureofapplicant:

FCCID:2AGY9BS-20 EUT

FCCIDLABELINGANDLOCATION FCCIDLabel FCCIDLabelLocation Thelabelshownshallbepermanentlyaffixedataconspicuouslocationonthedeviceandbe readilyvisibletotheuseratthetimepurchase(Labelingrequirementsper2.925) Bluetoothsoundbarspeaker FCCID:2AGY9BS-20

FCCID:2AGY9BS-20 PCBAntenna RFCHIP

Project No.: ZKT-210624L2878E Page 1 of 32 FCC TEST REPORT FCC ID:2AGY9BS-20 Report Number. ................................ : ZKT-210624L2878E Date of Test ........................................ June. 08, 2021 to June. 16, 2021 Date of issue .................................... : June. 24, 2021 Total number of pages ...................... 32 Test Result ..................................... : PASS Testing Laboratory. ........................... : Shenzhen ZKT Technology Co., Ltd. Address .......................................... : 1/F, No. 101, Building B, No. 6, Tangwei Community Industrial A venue, Fuhai Street, Bao'an District, Shenzhen, China Applicant's name ............................ : Zhongshan World Team Electronics Co., Ltd. Address .......................................... : 3 rd floor, No.132 Qi Wan North Road, East Area, Zhongshan city, Guangdong province, China Manufacturer's name ..................... : Zhongshan World Team Electronics Co., Ltd. Address .......................................... : 3 rd floor, No.132 Qi Wan North Road, East Area, Zhongshan city, Guangdong province, China Test specification: Standard ........................................... : FCC CFR Title 47 Part 15 Subpart C Section 15.249 ANSI C63.10:2013 Test procedure ................................. : / Non-standard test method ............. : N/A Test Report Form No. .................... : TRF-EL-111_V0 Test Report Form(s) Originator .... : ZKT Testing Master TRF .................................... : Dated: 2020-01-06 This device described above has been tested by ZKT, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of ZKT, this document may be altered or revised by ZKT, personal only, and shall be noted in the revision of the document. Product name ................................... : Bluetooth soundbar speaker Trademark ...................................... : N/A Model/Type reference ...................... : BS-20, BS-28E, BS-41A, BS-10A, BS-20A, BS-18A, BS-18C, WS-005,BS-18D,BS-20B, BS-13, BS-15, BS-16, BS-17, BS-19, BS-27, BS-29, BS-31, BS-33, BS-35 Ratings ............................................. : DC 5V Project No.: ZKT-210624L2878E Page 2 of 32 Testing procedure and testing location: Testing Laboratory ................................... : Shenzhen ZKT Technology Co., Ltd. Address ...................................................... :1/F, No. 101, Building B, No. 6, Tangwei Community Industrial Avenue, Fuhai Street, Bao'an District, Shenzhen, China Alen He Tested by (name + signature) .................... : Joe Liu Reviewer (name + signature) ..................... : Lake Xie Approved (name + signature) .................... : Project No.: ZKT-210624L2878E Page 3 of 32 Table of Contents Page 1.VERSION 5 2.SUMMARY OF TEST RESULTS 6 2.1 TEST FACILITY 7 2.2 MEASUREMENT UNCERTAINTY 7 3. GENERAL INFORMATION 8 3.1 GENERAL DESCRIPTION OF EUT 8 3.2 DESCRIPTION OF TEST MODES 9 3.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 3.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 10 3.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 11 4. EMC EMISSION TEST 12 4.1 CONDUCTED EMISSION MEASUREMENT 12 4.1.1 1POWER LINE CONDUCTED EMISSION LIMITS 12 4.1.2 TEST PROCEDURE 12 4.1.3 DEVIATION FROM TEST STANDARD 12 4.1.4 TEST SETUP 13 4.1.5 EUT OPERATING CONDITIONS 13 4.1.6 TEST RESULTS 14 4.2 RADIATED EMISSION MEASUREMENT 16 4.2.1 RADIATED EMISSION LIMITS 16 4.2.2 TEST PROCEDURE 17 4.2.3 DEVIATION FROM TEST STANDARD 17 4.2.4 TEST SETUP 17 4.2.5 EUT OPERATING CONDITIONS 18 5. BANDWIDTH OF FREQUENCY BAND EDGE 24 5.1 TEST REQUIREMENT: 24 5.2 TEST PROCEDURE 24 5.3 DEVIATION FROM TEST STANDARD 24 5.4 TEST SETUP 24 5.5 EUT OPERATING CONDITIONS 25 5.6 TEST RESULT 26 6. CHANNEL BANDWIDTH 28 7.1 APPLIED PROCEDURES / LIMIT 28 7.2 TEST PROCEDURE 28 7.3 DEVIATION FROM STANDARD 28 7.4 TEST SETUP 28 Project No.: ZKT-210624L2878E Page 4 of 32 Table of Contents Page 7.5 EUT OPERATION CONDITIONS 28 7.6 TEST RESULTS 29 8.ANTENNA REQUIREMENT 31 9. TEST SETUP PHOTO 32 10. EUT CONSTRUCTIONAL DETAILS 32 Project No.: ZKT-210624L2878E Page 5 of 32 1.VERSION Report No. Version Description Approved ZKT-210624L2878E Rev.01 Initial issue of report June. 24, 2021 Project No.: ZKT-210624L2878E Page 6 of 32 2.1SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.249) , Subpart C Standard Section Test Item Judgment Remark FCC part 15.203 Antenna requirement PASS FCC part 15.207 AC Power Line Conducted Emission PASS FCC part 15.249 Fundamental &Radiated Spurious Emission Measurement PASS FCC part 15.249 (a)(2)20dB Channel Bandwidth PASS FCC part 15.205 Band Edge PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Project No.: ZKT-210624L2878E Page 7 of 32 2.11.1 TEST FACILITY Shenzhen ZKT Technology Co., Ltd. Add. : 1/F, No. 101, Building B, No. 6, Tangwei Community Industrial Avenue, Fuhai Street, Bao'an District, Shenzhen, China FCC Test Firm Registration Number: 692225 Designation Number: CN1299 IC Registered No.: 27033 2.21.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power conducted ±0.16dB 3 Spurious emissions conducted ±0.21dB 4 All emissions radiated(<1G) ±4.68dB 5 All emissions radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Project No.: ZKT-210624L2878E Page 8 of 32 3. GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT Product Name: Bluetooth soundbar speaker Model No.: BS-20, BS-28E, BS-41A, BS-10A, BS-20A, BS-18A, BS-18C, WS-005, BS-18D, BS-20B, BS-13, BS-15, BS-16, BS-17, BS-19, BS-27, BS-29, BS-31, BS-3…

Text truncated - open the document above for the full version.

FCCID:2AGY9BS-20
