2AGZG-AEEAP120001Aerial photography equipment

Remote control and Wi-Fi Repeater Description Remote control (U.S. Mode) UP UP LEFT LEFT FOR WARD FOR WARD LEFTTURN LEFTTURN TURNRIGHT TURNRIGHT RIGHT RIGHT BACK BACK DOWN DOWN Quadcopter Direction (" " indicates nose direction) 10 T aking off and Landing(Outdoors) T aking of f : Landing 1) Place Quadcopter (with full power battery) on a flat and open ground, and ensure Tail Indicator faces toward you. 2) Power on the Remote control,Wi-Fi Repeater and Quadcopter in sequence.3) Be sure the Remote control is set exactly as the figure below.4) Starting motors: toggle the left joystick to left bottom corner and toggle right joystick to right bottom corner at the mean time to start motors.5) Push the left joystick slowly, then Quadcopter take off. Please refer AEE Quadcopter User Manual for more details. Note:The motors can not be started until GPS signal is ready(Tail Indicator(green) remains on) , when the S4 is in GPS mode. 1) Slowly pull the left joystick to lower Quadcopter until it touches the ground(only on a flat and open ground).2) After landing, pull the left joystick to the lowest position and hold for more than 3 seconds until the motors stop. 3) Power off Quadcopter by sliding the switch to OFF.4) Remove the battery.5) Power off Remote control and Wi-Fi Repeater. Important: 1) Control the flight height under your control during your first flight.2) Do not toggle the left joystick to left bottom corner and toggle right joystick to right bottom corner during flight ,or it will cause the motors to stop working and the Quadcopter will drop without control. [ 1 ] Propeller [ 2 ] Motor [ 3 ] Front Indicator [ 4 ] Camera[ 5 ] Landing Gear [ 6 ] Mini USB Port [ 7 ] Micro SD Card Slot [ 8 ] 3-Axial Gimbal [ 9 ] Quadcopter Battery [ 10 ] Tail Indicator [ 11 ] Power Switch [ 12 ] Rear Indicator [ 13 ] Battery Level LCD Segment Display [ 14 ] Battery Level Check Button [ 15 ] 4XJUDI Note: The Remote Control is set to U.S. mode by default. Power SwitchCharging Port (mini USB port) Pairing Button Repeater Base Power Indicator Wi-Fi Indicator Lock Screw Disclaimer Please read this disclaimer carefully before using the product of Quadcopter . This product is not suitable for people under the age of 18. By using this product, you hereby agree to this disclaimer and signify that you have read them fully. You agree that you are responsible for your own conduct and content while using this product, and for any consequences there of. You agree to use this product only for purposes that are proper and in accordance with the terms and any applicable or guidelines AEE may make available. 1. Shenzhen AEE Aviation Technology Co.,Ltd. reserves the right of final interpretation of this disclaimer. 2. Any part of this disclaimer is subject to change without prior notice.
5IJT
EJTDMBJNFS
JT
BWBJMBCMF
JO
NVMUJQMF
MBOHVBHFT
*O
DBTF
PG
BOZ
EJTDSFQBODZ
UIF
$IJOFTF
WFSTJPO
TIBMM
QSFWBJM

'PS
NPSF
EFUBJMFE
PS
MBUFTU
QSPEVDU
JOGPSNBUJPO
QMFBTF
WJTJ U
6TFS
.BOVBM
BOE
XXXBFFDPN
BatteryCompartment S3 S4 GPS NRM F M S1 S2 D S E                ON OFF CAM S3: Middle S1: S2: GPS S4: GPS NRM F M S3 S4 GPS NRM F M S1 S2 D S E Antenna Wi-Fi RepeaterRepeater BaseGimbal Control Switch S3 Photo Shooting & V ideo Recording Indicator Strap Hole Right Joystick V ideo Stop Button Remote Control Power Switch Smartphone Holder Remote Control Power Indicator Status Indicator Left Joystick Airborne Shutter Button Airborne V ideo Recording Button Hook Open/Close Button Hook Open/ Close Button Buzzer Hole Return Button Return Button Calibration Switch S2 Speed Switch S1 Flight Mode Switch S4 A P12 Q uadcopter 1 2 Assembling Wi-Fi Repeater and Smartphone Holder and Remove the Gimbal-bracket 3 Preparing the Remote control 4 Assembling Quadcopter Battery 5 7 Switching on the Repeater 8 9 Installing Smartphone Holder Installing Wi-Fi Repeater 1) Put the Repeater in the Remote control. 2) Fasten Wi-Fi Repeater with a screw. 1) Load four AA batteries into the battery compartment. Pay attention to positive and negative directions.2) Be sure S1 is swiched to the “E” position as below, S2 and S4 are switched to the upper-most position as below. 3) Slide power switch to ON position to power on the Remote control. Then the power indicator(red) lights up. After freguency-pairing between Remote control and Quadcopter, the Status Indicator ( blue or green ) lights up. Fix the Smartphone onto Remote control. Fix screw Remote control Smartphone Holder 0, + = Note (1) Propellers are designed to self-tighten during flight; therefore do not tighten them excessively. Do not use glue on the threads. (2) Ensure propellers are attached in the correct position. The quadcopter can not fly properly if the propellers are installed incorrectly. Wear protective gloves while installing as propellers are very thin and may cause accidental scratches. (3) Do not get close to or even touch the working motors and propellors to avoid serious injury. V0 iOS 8.0 or above AEE AP+ Android 4.0 or above Important: A continuous beeping(di didi di didi...) sound emitted from the Remote control indicates low battery voltage.Please replace batteries immediately. Make sure Quadcopter is powered off when replace the batteries of Remote control. 6 To install the AEE AP+ App onto your smartphone by scan QR code.You also can download the App from the Google Play Store or the Apple App Store. Scan QR Code above Download AEE App (iOS / Android) Quick Start Guide Assembling Propellers and Micro SD card Connecting the Camera 1) Remove the 4 warning cards from motors.2) Attach propellers with gray nuts to motor shafts without "P" mark, and attach propellers with black nuts to motor shafts with "P" mark. 3) Tighten propellers as per the appropriate locking direction. 1 Power on the Remote control and Wi-Fi Repeater. Then power on AEE Quadcopter.2) Enable Wi-Fi on your mobile device. Wait for Approximately 30 seconds (when the blue indicator blinks once per 3 s…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 Shenzhen AEE Aviation Technology Co.,Ltd. 2015-12-23 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, ____ Shenzhen AEE Aviation Technology Co.,Ltd.__ _hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product： Aerial photography equipment Trade Name： AEE Model Name： AP12 Serial Model： AP12+,AP12 Pro,AP12 A,AP12W,AP12 Plus, AP11B, AP11+, AP9+, AP10B, JP12, JP12+, JP12 Pro, JP12 A, JP12W, JP12 Plus, JP11B, JP11+, JP9+, JP10B FCC ID： 2AGZG-AEEAP120001 Sincerely, Signature Client’s name / title : Peng Liang / Engineer Contact information / address : AEE Hi-Tech Park,Tangtou Crossroads,Shiyan Town, Bao’an District Shenzhen,China

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (obsolete) 3.0 4.0 March-26-2015 Corrections to STC form. Added reference to KDB (current) 4.0 5.0 Nov 19 2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 5.0 Shenzhen AEE Aviation Technology Co.,Ltd. 2015-12-23 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AGZG-AEEAP120001 Pursuant to sections 0.457 and 0.459 of CFR 47, we respectfully request permanent confidential treatment of the following Exhibits accompanying this application as: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Signature Client’s name / title : Peng Liang / Engineer Contact information / address : AEE Hi-Tech Park,Tangtou Crossroads,Shiyan Town, Bao’an District Shenzhen,China

Shenzhen AEE Aviation Technology Co.,Ltd. Model Difference FCC ID: 2AGZG-AEEAP120001 Model : AP12, AP12+,AP12 Pro,AP12 A,AP12W,AP12 Plus,AP11B, AP11+, AP9+, AP10B, JP12, JP12+,JP12 Pro, JP12 A, JP12W, JP12 Plus, JP11B, JP11+, JP9+, JP10B All the model are the same circuit and RF module, except the model name and colour. Regards, Client’s signature Signature Client’s name / title : Peng Liang / Engineer Contact information / address : AEE Hi-Tech Park,Tangtou Crossroads,Shiyan To w n , Bao’an District Shenzhen,China

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6

FCC ID LABELING AND LOCATION FCC ID Label Aerial photography equipment Model NO.: AP12 FCC ID: 2AGZG-AEEAP120001 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 5G ANT Photo 5 Photo 6 Photo 7 Photo 8 Photo 9 Photo 10 Photo 11 Photo 12 Photo 13 Photo 14 Photo 15 Photo 16 Photo 17 Photo 18 2.4G WIFI ANT Photo 19 Photo 20 Photo 21 Photo 22 Photo 23 Photo 24 Photo 25 Photo 26 Photo 27 Photo 28 Photo 29 Photo 30 Photo 31 Photo 32

FCC ID: 2AGZG-AEEAP120001 FCC §15.247 (i), §2.1091 – RF Exposure FCC ID:2AGZG-AEEAP120001 Applied procedures / limit According to FCC §15.247(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 Note: ƒ is frequency in MHz * = Power density limit is applicable at frequencies greater than 100 MHz Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz * = Plane-wave equivalent power density MPE PREDICTION Predication of MPE limit at a given distance, Equation from OET Bulletin 65, Edition 97-01 Where: S = power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna TEST RESULTS FCC ID: 2AGZG-AEEAP120001 Power TX 802.11b Mode Te s t Channe Frequency Maximum Peak Conducted Output Power（PK） Maximum Peak Conducted Output Power（AV） LIMIT (MHz) (dBm) (dBm) dBm CH01 2412 12.66 9.45 30 CH06 2437 12.35 9.38 30 CH11 2462 11.78 9.52 30 TX 802.11g Mode CH01 2412 11.62 8.49 30 CH06 2437 11.58 8.45 30 CH11 2462 11.54 8.41 30 TX 802.11n(20) Mode CH01 2412 10.58 8.35 30 CH06 2437 10.49 8.26 30 CH11 2462 10.39 8.16 30 Test Channe Frequency Maximum output power. Antenna port LIMIT (PK) (AV) (MHz) (dBm) (dBm) dBm TX 5G Mode CH01 5728 12.75 8.36 30 CH09 5757 12.63 8.89 30 CH16 5803 12.12 8.21 30 Te s t Channel Range Maximum peak output power (dBm) Output power (mW) Antenna Gain (numeric) Power Density (S) (mW/ cm 2 ) Limit of Power Density (S) (mW/ cm 2 ) Result 802.11b 11~13 13 19.95 1.5(1.41) 0.0056 1 Pass 802.11g 10~12 12 15.85 1.5(1.41) 0.0044 1 Pass 802.11n-HT20 10~12 12 15.85 1.5(1.41) 0.0044 1 Pass CH01 11~13 13 19.95 1.5(1.41) 0.0056 1 Pass CH09 11~13 13 19.95 1.5(1.41) 0.0056 1 Pass CH16 11~13 13 19.95 1.5(1.41) 0.0056 1 Pass Note：This device 5GHz and 2.4GHz can not transmit simultaneously，don't have to assess exposure when transmit simultaneously.

FCC/IC RADIO TEST REPORT FCC ID:2AGZG-AEEAP120001 Product： Aerial photography equipment Trade Name： AEE Model Name： AP12 Serial Model： AP12+,AP12 Pro,AP12 A,AP12W,AP12 Plus, AP11B, AP11+, AP9+, AP10B, JP12, JP12+, JP12 Pro, JP12 A, JP12W, JP12 Plus, JP11B, JP11+, JP9+, JP10B Report No.： NTEK-2015NT1020958F1 Prepared for Shenzhen AEE Aviation Technology Co.,Ltd. AEE Hi-Tech Park,Tangtou Crossroads,Shiyan Town, Bao’an District Shenzhen,China Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 47 Report No.: NTEK-2015NT1020958F1 TEST RESULT CERTIFICATION Applicant’s name ........ Shenzhen AEE Aviation Technology Co.,Ltd. Address ........................ AEE Hi-Tech Park,Tangtou Crossroads,Shiyan Town,Bao’an District Shenzhen,China Manufacture's Name ... Shenzhen AEE Aviation Technology Co.,Ltd. Address ........................ AEE Hi-Tech Park,Tangtou Crossroads,Shiyan Town,Bao’an District Shenzhen,China Product description Product name .................Aerial photography equipment Model and/or type reference ..................... AP12 Serial Model .................... AP12+,AP12 Pro,AP12 A,AP12W,AP12 Plus,AP11B, AP11+, AP9+, AP10B, JP12, JP12+,JP12 Pro, JP12 A, JP12W, JP12 Plus, JP11B, JP11+, JP9+, JP10B Standards .................... FCC Part15.407: 01 Oct. 2015 Test procedure ................ANSI C63.10-2013 and KDB 789033 D01 v01r04 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements/ the Industry Canada requirements.. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personnel only, and shall be noted in the revision of the document. Date of Test ...................................... Date (s) of performance of tests ....... 20 Oct. 2015 ~30 Nov. 2015 Date of Issue ..................................... 30 Nov. 2015 Test Result ......................................... Pass Testing Engineer : (Allen Liu) Technical Manager : (Brown Lu) Authorized Signatory : (Sam Chen) Page 3 of 47 Report No.: NTEK-2015NT1020958F1 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 23 3.2.1 RADIATED EMISSION LIMITS 23 3.2.2 TEST PROCEDURE 24 3.2.3 DEVIATION FROM TEST STANDARD 24 3.2.4 TEST SETUP 25 3.2.5 EUT OPERATING CONDITIONS 26 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 27 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 28 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 30 4 . POWER SPECTRAL DENSITY TEST 31 4.1 APPLIED PROCEDURES / LIMIT 31 4.1.1 TEST PROCEDURE 31 4.1.2 DEVIATION FROM STANDARD 31 4.1.3 TEST SETUP 32 4.1.4 EUT OPERATION CONDITIONS 32 4.1.5 TEST RESULTS 33 5 . 6 DB & 99% EMISSION BANDWIDTH 36 5.1 APPLIED PROCEDURES / LIMIT 36 5.1.1 TEST PROCEDURE 36 Page 4 of 47 Report No.: NTEK-2015NT1020958F1 Table of Contents Page 5.1.2 EUT OPERATION CONDITIONS 36 5.1.3 TEST RESULTS 37 6 . PEAK OUTPUT POWER TEST 40 6.1 APPLIED PROCEDURES / LIMIT 40 6.1.1 TEST PROCEDURE 40 6.1.2 DEVIATION FROM STANDARD 40 6.1.3 TEST SETUP 40 6.1.4 EUT OPERATION CONDITIONS 40 6.1.5 TEST RESULTS 41 7 . OUT OF BAND EMISSIONS 42 7.1 DEVIATION FROM STANDARD 42 7.2 TEST SETUP 42 7.3 EUT OPERATION CONDITIONS 42 7.4 TEST RESULTS 43 8 . ANTENNA REQUIREMENT 45 8.1 STANDARD REQUIREMENT 45 8.2 EUT ANTENNA 45 9 . EUT TEST PHOTO 46 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 47 Report No.: NTEK-2015NT1020958F1 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.407) , Subpart E Standard Section Test Item Judgment Remark FCC §15.207 AC Power Line Conducted EmissionsN/A FCC §15.209(a), Spurious Radiated Emissions PASS FCC §15.407(a) 26 dB and 99% Emission Bandwidth PASS FCC §407(a)(3) Peak Output Power Measurement PASS FCC §2.1051, §15.407(b) Band Edges PASS FCC §15.407(a)(3) Power Spectral Density PASS FCC §2.1051, §15.407(b) Spurious Emissions at Antenna Terminals PASS FCC §15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 47 Report No.: NTEK-2015NT1020958F1 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add.:1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 47 Report No.: NTEK-2015NT1020958F1 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Aerial photography equipment Trade Name AEE Model Name AP12 Serial Model AP12+,AP12 Pro,AP12 A,AP12W,AP12 Plus,AP11B, AP11+, AP9+, AP10B, JP12, JP12+,JP12 Pro, JP12 A, JP12W, JP12 Plus, JP11B, JP11+, JP9+, JP10B Model Difference All the model are…

Text truncated - open the document above for the full version.

Page 46 of 47 Report No.: NTEK-2015NT1020958F1 9. EUT TEST PHOTO Radiated Measurement Photos Page 47 of 47 Report No.: NTEK-2015NT1020958F1 CONDUCTED EMISSION Photos
