2AH25K2A13Self-Checkout Kiosk

用户指南 QUICK START GUIDE F4E02 HVIN: F4E02, F4E02(B) Quick Start Guide/快速入门指南 2 3 1 6 5 5 Installation style/安装方式 283 280 1130 4-Ø10×80 S1 T1 S2 T1S1S2 1×4×4× 极简设置 更多使用帮助请阅读机内帮助APP或咨询免费400-6666-509电话。 如何下载 /使用应用 开启智能商用设备，只需几步 打开整机电源后，屏幕点亮，进入首次开机界面，按提示操作即可。 1 LAN设置 2 · 插好网线后，点击【设置】按钮，点击【有线网】，选择开启； · 若连接一个加密网络，则需要输入访问密码方可连接； · IP地址可选择自动获取IP和IP地址手动输入两种。 Wi-Fi设置 3 · 当有线连接时，Wi-Fi会自动断开； · 点击【设置】按钮，然后开启WLAN，进入WLAN搜索界面， 等待期搜索并列出可用的WLAN热点； · 点击要连接的WLAN，若选择一个加密网络，则要输入访问密码方可连接。 本机可选择2种上网模式。 本自助服务终端适用于中西餐饮服务业、 高档百货、商超、便利店、资讯站、互动多媒体等不同业 态商业客户，用于自助收银、自助点餐、咨询服务、AI识别、客流引导等多种自助服务场景。相 关应用可在互联网模式下，打开应用市场，浏览并下载应用即可完成安装。 打开主机面板 1 同时按下左右按钮，打开下翻盖面板。 打开打印机仓盖 2 向下拨动打印机拨杆，打开打印机仓盖。 4 关闭打印机仓盖，并关闭面板 按打印机仓盖两侧关闭仓盖，通电情况下打印 机自动切纸， 断电情况下需手工撕掉多余的纸； 关闭主机面板。 自助服务终端打印机装纸步骤 1 1 2 4 装入打印纸 3 放入热敏打印纸，并拉出一段于出纸口外。 3 整机电源 摄像头维护门 整机电源接口 铭牌 整机开关 系统开关 打印机 触显一体屏 人脸摄像头 提示灯 喇叭 扫码器 身份证阅读+非接(选配) 用于拍摄。 摄像头 (可选配人脸识别功能) 用于客户使用的可触摸屏幕。 触显一体屏 用于开机状态下打印单据。 打印机 用于条码识别。 扫码器 待机状态下，短按开机，再短按待机； 使用状态下，长按2-3秒，可选择关机或重启； 开机状态下，长按11秒，断电关机。 系统开关 控制整机电源通断。 整机开关 · 读取第二代身份证，支持M1\ID\CPU卡读写。 身份证阅读 +非接（选配） 自助服务终端简介 在机器内部，露出人脸摄像头结构。 摄像头维护门 在电源模块上，整机电源接口。 整机电源接口 安全警告 · 请将交流电插头插入与配件电源适配器上标识 输入相对应的交流电插座中； · 严禁在存有任何潜在爆炸性气体的场所使用； · 非专业人员不要随意打开内部模块，以免发生 危险； · 此为A级产品。在生活环境中，该产品可能会 造成无线电干扰。在这种情况下，可能需要用 户对于干扰采取切实可行的措施。 · 仅适用于海拔5000m及以下地区安全使用 · 请在温度 0°C ~ 40°C范围内使用本设备， 并在 -20°C ~ 60°C范围内存放设备及配件 关于电源请注意 · 请将插头从电源交流插座上拔下以完全断开 设备的电源连接; · 电源插座应装在设备附近，并且应当便于触 及到。 重要安全说明 · 避免在雷电期间安装或使用，否则有被雷电 电击的危险； · 当您发现有异常气味，过热或烟雾情形下， 请立刻切断电源； · 切纸刀较锋利，请勿触碰！ 建议 · 不要在靠近水或潮湿环境中使用，避免液体落 入终端中； · 不要在极端冷、热环境中使用，例如靠近火源 或点燃的香烟； · 不要摔、投掷或弯折； · 尽量在清洁无尘环境中使用，避免细小物品落 入终端中； · 在未获允许的情况下，不要在医疗设备附近使用。 声明 本公司不对以下行为负责 · 不在本指南说明的条件下使用和维护所造成的 损坏； · 对于如何因选件或耗材（非本公司提供之最初 产品或认可产品）造成的损坏或问题，本公司 将不承担任何责任。 未经本公司同意，无权进行产品修改或变动。 免责申明 由于产品的更新，此文档的某些细节可能与产品 不符，请以实物为准，此文档的解释权归本公司 所有。保留在不预先通知的情况下，修改本说明 书的权利。 注意事项 符合 “微功率短距离无线电发射设备目录和技术要求” 第一条通 用微功率设备第 3 款 C 类 设备的规定，内置环形 NFC 天线 ，1.5A/m≤磁 场强度≤7.5A/m，用户可通过“设置 - 已连 接的设备 - 连接偏好设置 -NFC”来打开和关闭 此功能 ; 不得擅自改变使用场景或使用条件、扩大发射频率范围、加大发 射功率 ( 包括额外加装射频 功率放大器 )，不得擅自更改发射天线 ; 不得对其他合法的无线电台 ( 站 ) 产生有害干扰，也不得提出免 受有害干扰保护 ; 应当承受辐射射频能量的工业、 科学及医疗 (ISM) 应用设备的 干扰或其他合法的无线电台 (站)干扰; 如对其他合法的无线电台 ( 站 ) 产生有害干扰时，应立即停止使 用，并采取措施消除干扰后 方可继续使用 ; 在航空器内和依据法律法规、国家有关规定、标准划设的射电天 文台、气象雷达站、卫星地 球站 ( 含测控、 测距、 接收、 导航站 ) 等 军民用无线电台 ( 站 )、 机场等的电磁环境保护区 域内使用微功率设 备，应当遵守电磁环境保护及相关行业主管部门的规定 ; 禁止在以机场跑道中心点为圆心、半径 5000 米的区域内使用各类 模型遥控器 ; 本产品的 NFC 功能可在常温下工作，由自带适配器供电。 (一) (二) (三) (四) (五) (六) (七) (八) 产品合格证 检验合格 制 造 商 ：上海商米科技集团股份有限公司 地 址：上海市杨浦区淞沪路388号505室 邮 箱：[email protected] 热线电话：400-6666-509 本产品有毒有害物质名称及含量标识表 部件名称 电路板组件 铅 （Pb） 汞 (Hg) 镉 (Cd) 六价铬 (Cr(VI) 多溴联苯 (PBB) 多溴二苯醚 (PBDE) 有毒有害物质或元素 壳体组件 对达到或超出环保使用年限的产品，应依据《电子信息产品控制管理办法》规定进行回收再利用， 不应随意丢弃。 表示该有毒有害物质在该部件所有均质材料中的含量均在SJ/T11363-2006规定的限量要求 以下。 ： 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出SJ/T11363-2006规定的限 量要求； ： 但是上表中打“×”的部件，其含量超出是因为目前业界还没有成熟的可替代的技术。 产品保修卡 产品名称： 产品型号： 产品编号： 购买日期： 保修期限：自购买之日起，我公司提供 天保修服务。 以下情况恕不提供免费保修： · 未经允许擅自拆卸修理的产品。 · 产品条码、易碎贴破损及保修卡涂改、残缺的。 · 未按照说明书的要求操作设备所引起的故障。 · 因进水或跌落而造成的故障、划伤或破损的人为损坏。 · 因不可抗拒因素造成的故障或损坏。 · 保修期限外。 联系方式： · 公司地址： · 联系电话： M05054455A Quick Setting Only several steps to enable the smart commercial device K2： Facebook：Sunmitech LinkedIn：SUNMI Technology How to download/use App LAN setting After plugging the network cable corr ectly, click “Setting” and “Wired Network” to choose Enable. Access password is required for an encrypted network connection. As for IP address, there are two options: to automatically obtain IP or to manually enter IP address. Wi-Fi setting Click “Setting” and “WLAN” to enter the WLAN search interface. Wait for the available WLAN hot spots searching and listing. Click the right WLAN to connect to the network. Access password is required for an encrypted network connection. The Self-service Kiosk is applicable for the cashier environment of commercial customers in various industries,such as Chinese and Western catering,high-end department stores,supermarkets, con- venience stores, information sites, interactive multi-media, scenic spot, etc. Please turn on the Kiosk and search & download the relevant Apps on the App market on Internet. After turning on the complete machine power supply, the screen will be lit. Then you will enter the first boot interface and just simply operate according to the instructions. There are two types of internet mode available for you. Please read the internal machine help App for more help or call 400-6666-509 for free telephone services. Open flip panel 1 Press the buttons on both side of the host at the same time to open the flip panel. Open paper storage cover 2 Toggle downward the printer driving lever to open the paper storage cover. 3 4 Close the paper storage cover and flip panel Press both sides of the paper storage cover to close it. The printer will automatically cut paper in power on state. In power off state, it is necessary to manually tear off excessive paper; Close the flip panel. 1 1 2 4 P aper Changing Steps for the Inside Printer 3 Put in paper Put in the 80mm thermal sensitive paper with a roller in it and pull out a section outside the printer exit. Camera used to shooting. Camera (optional facial recognition) Touchable screen applied for customer usage. Touch screen Used to print receipt. Printer Used to read codes. Code scanner System switch Used to control the host power supply. Host switch NFC or RF (optional) Used for NFC payment or RF quick pass. Brief Introduction of Self-Service Kiosk Camera cover Used to plug the power line. Power interface Nameplate Host switch System switch Printer Touch screen camera Indicator light Trumpet Power switch Camera cover Power interface Code scanner NFC or RF (optional) Used to cover the face camera inside the host. In standby state, short press to boot, short press again to be in standby mode; In service state, long press for 2 to 3 se conds to choose to shut-down or restart; In the state of power-on,long press for 11 seconds to shut down the host. Points for Attention Safety WarningDeclaration Important Safety InstructionsDisclaimer • Please insert the AC plug int…

Text truncated - open the document above for the full version.

UNITED STATES DESIGNATED AGENT LETTER Date: 2023-02-13 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 U.S. designated agent Company Name: Sunmi Technology US Inc. FRN： 0033401969 Contact Name: Elliot Chen Address: 13010 Morris Road, Suite 600 Alpharetta, GA 30004 Telephone: +1-6027894117 Fax: N/A Applicant Company Name: Grantee Code: FRN: Contact Name: Address: Telephone: Fax: Email: Shanghai Sunmi Technology Co.,Ltd. 2AH25 0025501644 Fang Lu Room 505,No.388,Song Hu Road, Yang Pu District, Shanghai, China +8618501703215 +862161480325 [email protected] Email: [email protected] Ref: Attestation Statements Part 2.911(d)(7) Filing ATTN: Director of Certification: We, < Shanghai Sunmi Technology Co.,Ltd.> and < Sunmi Technology US Inc.> understand and acknowledge the applicants consent and the designated agent’s obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and e- mail of the designated agent listed above. We, < Shanghai Sunmi Technology Co.,Ltd.> and < Sunmi Technology US Inc.> acknowledge the applicant’s acceptance of its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Applicant U.S. designated agent Name (Printed): Fang Lu Name (Printed): Elliot Chen Title: Certification Manager Title: Sr. Technical Manager Signature: Signature:

ApplicantDeclaration QSF27-14-04Rev1.1Jan17,2024Page 1 of 1 OriginalIssue:Jan.4,2021 SGSNorthAmericaInc. 620OldPeachtreeRoad SUITE100 Suwanee,Georgia30024 UnitedStates ApplicantLegalBusinessName ShanghaiSunmiTechnologyCo.,Ltd. Address Room505,No.388SongHuRoad,YangPuDistrict,Shanghai,China FRN 0025501644 GranteeCode 2AH25 FCCID 2AH25K2A13 AuthorizedContactName FangLu ContactEmail [email protected] ContactPhone +8618501703215 I,theundersigned,certifythatIamanauthorizedsignatoryfortheApplicantandthereforedeclare; a)inaccordancewith47CFR2.911(d),allofthestatementshereinandtheexhibitsattachedheretoaretrueandcorrecttothebestofmy knowledgeandbelief. b)inacceptingaGrantofEquipmentAuthorizationissuedbyaTCB,undertheauthorityoftheFCC,asaresultoftherepresentationsmadein thisapplication,theApplicantisresponsiblefor: (1)labelingtheequipmentwiththeexactFCCIDasspecifiedinthisapplication, (2)compliancestatementlabelingpursuanttotheapplicablerules, (3)complianceoftheequipmentwiththeapplicabletechnicalrules, c)iftheApplicantisnottheactualmanufactureroftheequipment,appropriatearrangementshavebeenmadewiththemanufacturertoensure thatproductionunitsofthisequipmentwillcontinuetocomplywiththeFCC’stechnicalrequirements. d)inaccordancewith47CFR2.909andKDB394321,theApplicanthasread,understoodandagreestoacceptthattheyaretheresponsible partyandagreetoabidebytheirresponsibilitiesasspecifiedunder47CFR2.909andKDB394321. e)inaccordancewithISO17065,FCCKDB641163,FCCKDB610077,KDB394321andRSP-100,theApplicanthasread,understood,accepts andagreestoabidebythepostmarketsurveillancerequirements. (1)theApplicantunderstands,acceptsandagreesthatasamplemayberequestedforsurveillancetesting. (2)theApplicantshallmakeprovisionstoalwayshaveaproductionsampleavailableuponrequestbySGS,FCCand/orISED. (3)theApplicantshall,uponrequestbySGS,attheApplicant’sexpense,provideaproductionsampleoftherequestedproducttoSGS, FCCand/orISEDasinstructed.Thesampleshallincludeallsupportdevices,cables,software,accessoriesorotherhardwareor softwarerequiredforevaluation,review,certificationandauditsurveillanceofproductscertifiedbySGS. f)neithertheApplicantnoranypartytotheapplicationissubjecttoadenialofFederalbenefits,thatincludesFCCbenefits,pursuanttoSection 5301oftheAnti-DrugAbuseActof1988,21U.S.C.§862becauseofaconvictionforpossessionordistributionofacontrolledsubstance.See 47CFR1.2002(b)forthedefinitionofa“party”forthesepurposes. g)theApplicanthasread,understood,acceptsandagreestoabidebytheSGSNorthAmerica,Inc.(TCB)termsandconditions. LinktoCFRs:https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 LinktoKDBs:https://apps.fcc.gov/oetcf/kdb/index.cfm LinktoRSP-100:https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html LinktotheCoveredList:CoveredList [ShanghaiSunmiTechnologyCo.,Ltd.](“theapplicant”)certifiesthattheequipmentforwhichauthorizationissoughtisnot“covered” equipmentprohibitedfromreceivinganequipmentauthorizationpursuanttosection2.903oftheFCCrules. [ShanghaiSunmiTechnologyCo.,Ltd.](“theapplicant”)certifiesthat,asofthedateofthefilingoftheapplication,theapplicant[isnot] identifiedontheCoveredlist,establishedpursuantto§1.50002,asanentityproducing“covered”equipment. ApplicantSignature: Date:2024-08-28 PrintName: FangLu Title: CertificationManager *NOTE:ThisdeclarationcannotbesignedbyanAgent,itshallbesignedbyanauthorizedpersonlistedintheFCCdatabase

Shanghai Sunmi Technology Co.,Ltd. Current Date 2024-09-03 To: Compliance Certification Services (Kunshan) Inc. No.10 Weiye Rd, Innovation park, Eco&Tec, Development Zone, Kunshan City, Jiangsu, China. Dear Sir/Madam, Subject: Declaration Letter about Identity of Products *WE Shanghai Sunmi Technology Co.,Ltd., HEREBY DECLARED THAT Product Description: Self-Checkout Kiosk Model No.: F4E02 HVIN: F4E02, F4E02(B) Manufacturer’s Name: Shanghai Sunmi Technology Co.,Ltd. Manufacturer’s Address: Room 505, No.388, Song Hu Road, Yang Pu District, Shanghai, China This product is divided into two configurations (SKU1, SKU2), their differences as below: SKU1: Large scan code window, the HVIN is F4E02(B) SKU2: Small scan code window, the HVIN is F4E02 Except for the above differences, they are identical in electrical and electronic characters. After Pre-scan test, only SKU2(HVIN: F4E02) was tested since their differences. SKU1-HVIN: F4E02(B) SKU2-HVIN: F4E02 Large scan code window Small scan code window Shanghai Sunmi Technology Co.,Ltd. Note: The definition of identical should be “electrically identical”. A device will be considered to be electrically identical if no changes are made to the devices’ schematics, board layouts, component layouts, chip sets, resistors and all other electrical aspects of the device are identical. Sincerely, Signature: Printed Name : Fang Lu Position/Title : Certification Manager Contact Number: +8618501703215

ShanghaiSunmiTechnologyCo.,Ltd. Date:2024-08-28 TO:FederalCommunicationCommission EquipmentAuthorizationBranch 7435OaklandMillsRoad Columbia,MID21046 Regarding:FCCID:2AH25K2A13 Towhomitmayconcern: We,theundersigned,herebyauthorizeParlamZhantoactonourbehalfinallmannersrelatingto applicationforequipmentauthorizationwithrespecttotheFCCIDabove,includingsigningofall documentsrelatingtothesematters.Anyandallactscarriedoutbytheagentonourbehalfshallhave thesameeffectasactsofourown. We,theundersigned,herebycertifythatwearenotsubjecttoadenialoffederalbenefits,thatincludes FCCbenefits,pursuanttoSection5301oftheAnti-DrugAbuseActof1988,21U.S.C.853(a). Whereouragentsignstheapplicationforcertificationonourbehalf,Iacknowledgethatallresponsibility forcomplyingwiththetermsandconditionsforCertification,asspecifiedbySGSNorthAmerica,Inc.,still resideswithShanghaiSunmiTechnologyCo.,Ltd. Thisauthorizationisvaliduntilfurtherwrittennoticefromtheapplicant. Name (Printed) :FangLuTitle:CertificationManager Signature: OnbehalfofCompany:ShanghaiSunmiTechnologyCo.,Ltd. Telephone:+8618501703215

ShanghaiSunmiTechnologyCo.,Ltd. 2024-08-28 To:SGSNorthAmericaInc. 620OldPeachtreeRoad SUITE100 Suwanee,Georgia UnitedStates From:ShanghaiSunmiTechnologyCo.,Ltd. Room505,No.388,SongHuRoad,YangPuDistrict,Shanghai,China Regarding:ConfidentialityRequestregardingapplicationforFCCID:2AH25K2A13 LONGTERMCONFIDENTIALITY Pursuantto47CFRSection0.459and0.457ofthecommission’srules,theapplicantherebyrequest confidentialtreatmentofthedocumentslistedbelow,associatedwiththecertificationapplication referencedabove. Schematic(s) BlockDiagrams OperationalDescriptions NIISoftwareSecurityInfo BOM Tuneup Thedocumentsabovecontainproprietaryinformationnotreleasedtothepublic.Publicdisclosureofthis informationmayproveharmfultothebusinessoftheapplicant. Signature: PrintedName:FangLu Title:CertificationManager CompanyName:ShanghaiSunmiTechnologyCo.,Ltd.

Compliance Certification Services (Kunshan) Inc. Page: 1 of 3 External Photos for KSCR2407001236AT Test Model No.: F4E02 Compliance Certification Services (Kunshan) Inc. Page: 2 of 3 EUT Constructional Details (EUT Photos) SKU1-HVIN: F4E02(B) Compliance Certification Services (Kunshan) Inc. Page: 3 of 3 SKU2-HVIN: F4E02

粘贴位置 SN: XXXXXXXXXXXXX K2 智能自助终端 Smart Kiosk Terminal 型号/Model: F4E02 品名/Name: 自助服务终端/Self-Checkout Kiosk 输入电源/Input: 100-120V~1.5A 50/60Hz 200-240V~1.5A 50/60Hz FCC ID : 2AH25K2A13 IC : 22621-K2A13 上海商米科技集团股份有限公司 Shanghai Sunmi Technology Co., Ltd.Made in China 中国制造 CMIIT ID: XXXXXXXXXXXX This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 主机标签 HVIN: F4E02(B) SN: XXXXXXXXXXXXX K2 智能自助终端 Smart Kiosk Terminal 200-240V~1.5A 50/60Hz FCC ID : 2AH25K2A13 IC : 22621-K2A13 上海商米科技集团股份有限公司 Shanghai Sunmi Technology Co., Ltd.Made in China 中国制造 CMIIT ID: XXXXXXXXXXXX This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 型号/Model: F4E02 HVIN: F4E02 品名/Name: 自助服务终端 /Self-Checkout Kiosk 输入电源/Input: 100-120V~1.5A 50/60Hz

Compliance Certification Services (Kunshan) Inc. Page: 1 of 43 Internal Photos for KSCR2407001236AT Test Model No.: F4E02 Compliance Certification Services (Kunshan) Inc. Page: 2 of 43 EUT Constructional Details (EUT Photos) Antenna SKU 1-HVIN: F4E02(B) Compliance Certification Services (Kunshan) Inc. Page: 3 of 43 Compliance Certification Services (Kunshan) Inc. Page: 4 of 43 Compliance Certification Services (Kunshan) Inc. Page: 5 of 43 Compliance Certification Services (Kunshan) Inc. Page: 6 of 43 Compliance Certification Services (Kunshan) Inc. Page: 7 of 43 Compliance Certification Services (Kunshan) Inc. Page: 8 of 43 Compliance Certification Services (Kunshan) Inc. Page: 9 of 43 Compliance Certification Services (Kunshan) Inc. Page: 10 of 43 Compliance Certification Services (Kunshan) Inc. Page: 11 of 43 Compliance Certification Services (Kunshan) Inc. Page: 12 of 43 Compliance Certification Services (Kunshan) Inc. Page: 13 of 43 Compliance Certification Services (Kunshan) Inc. Page: 14 of 43 Compliance Certification Services (Kunshan) Inc. Page: 15 of 43 Compliance Certification Services (Kunshan) Inc. Page: 16 of 43 Compliance Certification Services (Kunshan) Inc. Page: 17 of 43 Compliance Certification Services (Kunshan) Inc. Page: 18 of 43 Compliance Certification Services (Kunshan) Inc. Page: 19 of 43 Compliance Certification Services (Kunshan) Inc. Page: 20 of 43 Compliance Certification Services (Kunshan) Inc. Page: 21 of 43 Compliance Certification Services (Kunshan) Inc. Page: 22 of 43

Compliance Certification Services (Kunshan) Inc. Page: 23 of 43 SKU 2-HVIN: F4E02 Compliance Certification Services (Kunshan) Inc. Page: 24 of 43 Compliance Certification Services (Kunshan) Inc. Page: 25 of 43 Compliance Certification Services (Kunshan) Inc. Page: 26 of 43 Compliance Certification Services (Kunshan) Inc. Page: 27 of 43 Compliance Certification Services (Kunshan) Inc. Page: 28 of 43 Compliance Certification Services (Kunshan) Inc. Page: 29 of 43 Compliance Certification Services (Kunshan) Inc. Page: 30 of 43 Compliance Certification Services (Kunshan) Inc. Page: 31 of 43 Compliance Certification Services (Kunshan) Inc. Page: 32 of 43 Compliance Certification Services (Kunshan) Inc. Page: 33 of 43 Compliance Certification Services (Kunshan) Inc. Page: 34 of 43 Compliance Certification Services (Kunshan) Inc. Page: 35 of 43 Compliance Certification Services (Kunshan) Inc. Page: 36 of 43 Compliance Certification Services (Kunshan) Inc. Page: 37 of 43 Compliance Certification Services (Kunshan) Inc. Page: 38 of 43 Compliance Certification Services (Kunshan) Inc. Page: 39 of 43 Compliance Certification Services (Kunshan) Inc. Page: 40 of 43 Compliance Certification Services (Kunshan) Inc. Page: 41 of 43 Compliance Certification Services (Kunshan) Inc. Page: 42 of 43 Compliance Certification Services (Kunshan) Inc. Page: 43 of 43

Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240700123607 Page: 1 of 12 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms-and-Conditions/Terms-e-Document.aspx. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 30 days only. Member of the SGS Group (SGS SA) 1 Cover Page RF Exposure Evaluation Report Application No.: KSCR2407001236AT FCC ID: 2AH25K2A13 Applicant: Shanghai Sunmi Technology Co.,Ltd. Address of Applicant: Room 505, No.388 Song Hu Road, Yang Pu District, Shanghai, China Manufacturer: Shanghai Sunmi Technology Co.,Ltd. Address of Manufacturer: Room 505, No.388 Song Hu Road, Yang Pu District, Shanghai, China Equipment Under Test (EUT): EUT Name: Self-Checkout Kiosk Model No.: HVIN : F4E02 F4E02, F4E02(B) Trade Mark: SUNMI Standard(s) : FCC Rules 47 CFR §2.1091 KDB 447498 D04 interim General RF Exposure Guidance v01 RSS-102 Issue 6 (December 15, 2023) Date of Receipt: 2024-07-03 Date of Test: 2024-08-08 to 2024-08-19 Date of Issue: 2024-08-19 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240700123607 Page: 2 of 12 Revision Record Version Description Date Remark 00 Original 2024-08-19 / Authorized for issue by: Tested By Damon Zhou /Project Engineer Approved By Terry Hou /Reviewer Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240700123607 Page: 3 of 12 2 Contents Page 1 Cover Page ........................................................................................................................................ 1 2 Contents ............................................................................................................................................ 3 3 General Information .......................................................................................................................... 4 3.1 General Description of E.U.T. .................................................................................................... 4 3.2 Technical Specifications ............................................................................................................. 4 3.3 Separation Distance ................................................................................................................... 6 3.4 Test Location .............................................................................................................................. 7 3.5 Test Facility ................................................................................................................................ 7 4 RF Exposure Test Exemptions ........................................................................................................ 8 4.1 RF Exposure Test Exemptions for single RF sources ............................................................... 8 4.2 RF Exposure Test Exemptions for Simultaneous Transmission .............................................. 10 5 IC Radiofrequency radiation exposure limits: ...................................... Error! Bookmark not defined. 6 Measurement and Calculation ....................................................................................................... 12 6.1 Maximum transmit power ......................................................................................................... 12 6.2 RF Exposure Calculation ......................................................................................................... 12 Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240700123607 Page: 4 of 12 3 General Information 3.1 General Description of E.U.T. Power supply: AC 120V/60Hz SN: K288D45N00072 Firmware Version: V 2.0 3.2 Technical Specifications BT Operation Frequency: 2402MHz to 2480MHz Modulation Type: GFSK, pi/4DQPSK, 8DPSK Number of Channels: 79 Channel Spacing: 1MHz Spectrum Spread Technology: Frequency Hopping Spread Spectrum(FHSS) Antenna Type: FPC Antenna Antenna Gain: 2.1dBi (Provided by the manufacturer) BLE Operation Frequency: 2402MHz to 2480MHz Modulation Type: GFSK Number of Channels: 40 Channel Spacing: 2MHz Antenna Type: FPC Antenna Antenna Gain: 2.1dBi (Provided by the manufacturer) 2.4GHz WiFi Operation Frequency: 802.11b/g/n(HT20)/ax(HE20): 2412MHz to 2462MHz; 802.11n(HT40)/ax(HE40): 2422MHz to 2452MHz Modulation Type: 802.11b: DSSS; 802.11g/n: OFDM; 802.11ax:OFDMA Number of Channels: 802.11b/g/n(HT20)/ax(HE20):11;802.11n(HT40)/ax(HE40):7 Channel Spacing: 5MHz Antenna Type: FPC Antenna Antenna Gain: Ant 1:2.1dBi (Provided by the manufacturer) Ant 2:2.1dBi (Provided by the manufacturer) Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.…

Text truncated - open the document above for the full version.

UNLESS OTHER SPECIFIED TOLERANCES ON： INPAQ TECHNOLOGY CO., LTD. X＝± X.X＝± X.XX＝± ANGLES＝± HOLEDIA＝± SCALE： UNIT：mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF INPAQ TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY：徐健 CHECKED BY：李志强 DESIGNED BY：周煜 APPROVED BY：唐龙 TITLE：NF-F-F0-R0-02-002 Specification DOCUMENT PAGE REV. NO. P1 PAGE 1 OF 2 NF-F-F0-R0-02-002 Specification 1. Applications Near Field Communication (NFC)、RFID 2. Explanation of Part Number (1) (2) (3) (4) (5) (6) (1) Product type: NF-Near Field Communication (2) Material: FPCB+Cable (3) Substrate: NONE (4) Frequency: R0-13.56MHz (5) Cable: Black (6) Suffix : 002 3. Electrical Specification Electrical Specification* Center Frequency (MHz) 13.56 Frequency Range (MHz) 12 ~15 *Single NFC antenna measurement result N F F R0 0 0 2 F 0 02 UNLESS OTHER SPECIFIED TOLERANCES ON： INPAQ TECHNOLOGY CO., LTD. X＝± X.X＝± X.XX＝± ANGLES＝± HOLEDIA＝± SCALE： UNIT：mm THIS DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF INPAQ TECHNOLOGY CO.,LTD.AND SHALL NOT BE REPRODUCED OR USED AS THE BASIS FOR THE MANUFACTURE OR SALE OF APPARATUS OR DEVICES WITHOUT PERMISSION DRAWN BY：徐健 CHECKED BY：李志强 DESIGNED BY：周煜 APPROVED BY：唐龙 TITLE：NF-F-F0-R0-02-002 Specification DOCUMENT PAGE REV. NO. P1 PAGE 2 OF 2 4. Structural Drawings 4.1 Dimensions "*" is the outgoing inspection size., "*" is important dimension TOP 78±0.15 54±0.15 背胶3M467 分割线 91.51±0.15 弯折区 域 * * 01 02 03 补强板PI 0.2+0.05背胶3M467 0.13±0.05 * 05 04 立勤 胶壳1.25-2Y,端子:1.25-T 黑双绞线 0.38±0.15 4.1±0.1 1.23±0.35 06 07 08 BOTTOM * * * 4.2 Product picture

Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240700123606 Page: 1 of 31 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms-and-Conditions/Terms-e-Document.aspx. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 30 days only. Member of the SGS Group (SGS SA) TEST REPORT Application No.: KSCR2407001236AT FCC ID: 2AH25K2A13 IC: 22621-K2A13 Applicant: Shanghai Sunmi Technology Co.,Ltd. Address of Applicant: Room 505, No.388 Song Hu Road, Yang Pu District, Shanghai, China Manufacturer: Shanghai Sunmi Technology Co.,Ltd. Address of Manufacturer: Room 505, No.388 Song Hu Road, Yang Pu District, Shanghai, China Equipment Under Test (EUT): EUT Name: Self-Checkout Kiosk Model No.: HVIN: F4E02 F4E02, F4E02(B) Trade Mark: SUNMI Standard(s) : 47 CFR Part 15, Subpart C 15.225 RSS-210 issue 10 Amendment 1 RSS-Gen Issue 5, April 2018, Amendment 2 Date of Receipt: 2024-07-03 Date of Test: 2024-08-12 Date of Issue: 2024-08-19 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240700123606 Page: 2 of 31 Revision Record Version Description Date Remark 00 Original 2024-08-19 / Authorized for issue by: Tested By Damon Zhou /Project Engineer Approved By Terry Hou /Reviewer Compliance Certification Services (Kunshan) Inc. CCSEM-TRF-001 Rev. 02 Sep 01, 2023 Report No.: KSCR240700123606 Page: 3 of 31 2 Test Summary Radio Spectrum Technical Requirement Item FCC Requirement IC Requirement Method Result Antenna Requirement 47 CFR Part 15, Subpart C 15.225 N/A RSS-210 Issue 10 Amendment (April 2020) Customer Declaration Radio Spectrum Matter Part Item FCC Requirement IC Requirement Method Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.225 RSS-210 Issue 10 Amendment (April 2020) ANSI C63.10 (2013) Section 6.2 Pass 20dB Bandwidth 47 CFR Part 15, Subpart C 15.225 RSS-210 Issue 10 Amendment (April 2020) ANSI C63.10 (2013) Section 6.9 Pass Emission Mask 47 CFR Part 15, Subpart C 15.225 RSS-210 Issue 10 Amendment (April 2020) ANSI C63.10 (2013) Section 6.4 Pass Frequency tolerance 47 CFR Part 15, Subpart C 15.225 RSS-210 Issue 10 Amendment (April 2020) ANSI C63.10 (2013) Section 6.8 Pass Radiated Emissions(9kH…

Text truncated - open the document above for the full version.
