2AH9L-EVAWIFIHumidifier

Manually add Wi-Fi+Bluetooth dual-mode devices 1. If you use a Wi-Fi+Bluetooth dual-mode product, power on the device first. Then, enable Bluetooth on your mobile phone and open the app. Bluetooth and Wi-Fi+Bluetooth dual-mode devices that are ready for pairing will be displayed. 2. Select the device to be added. On the Wi-Fi setting page, enter the password for connecting to the 2.4 GHz Wi-Fi network. Wait for the device to automatically complete pairing. 3. For a Wi-Fi+Bluetooth dual-mode device, you can also perform the following steps to add the device by using Bluetooth. On the Add Manually tab, select a device type that supports Bluetooth pairing. On the page that appears, follow the detailed tutorial in the app to enable the indicator to blink quickly, select Confirm the light has flashed or breathed, and tap Next. 4. After the app detects the device, tap Add. After the device is added, tap Done. 5. When the devices are displayed in grid view, tap the small arrow in the bottom right corner of a device to access the extension functions of the device. For example, you can tap the switch icon to turn on or turn off the humidifier or drag the slider to adjust the humidity. When the devices are displayed in list view, tap the Common Functions button under the device name to quickly control the device.

Model: EVA-WiFi Page 1 of 4 Picture 1 Picture 2 Model: EVA-WiFi Page 2 of 4 Picture 3 Picture 4 Model: EVA-WiFi Page 3 of 4 Picture 5 Picture 6 Model: EVA-WiFi Page 4 of 4 Picture 7 Picture 8

Model: EVA-WiFi Page 1 of 3 Picture 1 Picture 2 Model: EVA-WiFi Page 2 of 3 Picture 3 Picture 4 Model: EVA-WiFi Page 3 of 3 Picture 5 Picture 6

Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn Page 1 of 6 TEST REPORT Reference No. .................... : WTF21F03020086W004 FCC ID ................................ : 2AH9L-EVAWIFI Applicant ............................ : Stadler Form Aktiengesellschaft Address .............................. : Chamerstrasse 1746300 Zug,Switzerland Manufacturer .................... : Foshan Shunde Esite Electrical Appliances Co.,Ltd Address .............................. : NO.4, Xingye Road, Beijiao Industrial Park,Beijiao,Shunde, Foshan, Guangdong, China Product Name .................... : Humidifier Model No. ........................... : EVA WiFi Standards........................... : FCC CFR47 Part 15 Subpart C (Section 15.247): 2019 Date of Receipt sample .... : 2021-03-15 Date of Test ....................... : 2021-05-20 Date of Issue ...................... : 2021-07-21 Test Result ......................... : Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Prepared By: Waltek Testing Group (Foshan) Co., Ltd. Address: No.13-19, 2/F., 2nd Building, Sunlink International Machinery City, Chencun, Shunde District, Foshan, Guangdong, China Tel:+86-757-23811398 Fax:+86-757-23811381 E-mail:[email protected] Compiled by: Approved by: Roy Hong / Project Engineer Danny Zhou / Manager Reference No.: WTF21F03020086W004 Page 2 of 6 Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn 1 Revision History Test Report No. Date of Issue Description Status WTF21F03020086W004 2021-07-21 Original Valid Reference No.: WTF21F03020086W004 Page 3 of 6 Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn 2 Contents Page 1 REVISION HISTORY ................................................................................................................................. 2 2 CONTENTS ............................................................................................................................................... 3 3 GENERAL INFORMATION ....................................................................................................................... 4 3.1 GENERAL DESCRIPTION OF E.U.T ................................................................................................... 4 3.2 TECHNICAL CHARACTERISTICS OF EUT ........................................................................................... 4 4 MAXIMUM PERMISSIBLE EXPOSURE (MPE) ....................................................................................... 5 4.1 STANDARD APPLICABLE................................................................................................................... 5 4.2 MPE CALCULATION METHOD........................................................................................................... 6 4.3 MPE CALCULATION RESULT ............................................................................................................ 6 Reference No.: WTF21F03020086W004 Page 4 of 6 Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn 3 General Information 3.1 General Description of E.U.T Product Name ............................... : Humidifier Model No. ..................................... : EVA WiFi Model Description ........................ : --- Rated Voltage................................ : AC 120V, 60Hz, 95W Battery Capacity ........................... : --- Power Adapter .............................. : --- 3.2 Technical Characteristics of EUT Support Standards ....................... : V4.2(BLE mode) Frequency Range ......................... : 2402-2480MHz RF Output Power .......................... : 5.04dBm (Conducted ) Modulation .................................... : GFSK Data Rate ....................................... : 2Mbps Quantity of Channels ................... : 40 Channel Separation ...................... : 2MHz Type of Antenna ........................... : PCB Printed Antenna Antenna Gain ................................ : 3dBi Lowest Oscillation ........................ : 40MHz Reference No.: WTF21F03020086W004 Page 5 of 6 Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn 4 MAXIMUM PERMISSIBLE EXPOSURE (MPE) 4.1 Standard Applicable According to §1.1307(b)(1) and KDB 447498 D01 General RF Exposure Guidance v06, system operating under the provisions of this section shall be operating in a manner that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. (a) Limits for Occupational / Controlled Exposure Frequency range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm 2 ) Averaging Times | E | 2 , | H | 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842/f 4.89/f (900/f)* 6 30-300 61.4 0.163 1.0 6 300-1500 / / F/300 6 1500-100000 / / 5 6 (b) Limits for General Population / Uncontrolled Exposure Frequency range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm 2 ) Averaging Times | E | 2 , | H | 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 / / F/1500 30 1500-100000 / / 1 30 Note: f = frequency in MHz: * = Plane-wave equivalents power density Reference No.: WTF21F03020086W004 Page 6 of 6 Waltek Testing Group (Foshan) Co., Ltd. http://www.waltek.com.cn 4.2 MPE Calculation Method S = (30*P*G) / (377*R 2 ) S = power density (in appropriate units, e.g., mw/cm 2 ) P = power input to the antenna (in appropriate units, e.g., mw) G = power gain of the antenna in the direction of interest relative to an isotropic radiator, the power gain factor is normally numeric gain. R = distance to the center of radiation of the antenna (in appropriate units, e.g., cm…
