JEM ACCESSORIES INC. Add: 32 Brunswick Avenue Edison, NJ 08817,United States Tel：908-222-7501 Fax: 908.222.7504 E-mail：[email protected] Date: 04/05/2020 Product Similarity Declaration To Whom It May Concern, We, JEM ACCESSORIES INC. hereby declare that we have a product named as Digit , (Model No: MLB7‐1035‐RGB, FCC ID: 2AHAS‐MLB71035 ) was tested by BACL, meanwhile, for our marketing purpos e, we would like to list a se ries model MLB7‐1035‐CAN, MLB7-1035-WW on reports and certificate, all the models ar e identical schematics, except for the d ifference of model No., no other changes are made to them. We confirm that all information above is true, and we’ll be responsible for all the consequences. Please contact me if you have any question. Sincerely, Signature: Printed Name: Eli Dabbah Title: Manager

EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS LED ART PANELS

EXHIBIT A - FCC ID LABEL AND LOCATION Label FCC ID Label Location Information The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

EXHIBIT C - EUT INTERNAL PHOTOGRAPHS Antenna

CIRCUIT DESCRIPTION The product is to use the MCU (TLSR 8362) and the WI-FI module TYWE3S to control the chromaticity and brightness of the colorful lamp beads and the brightness of the warm light. All operations are finally completed by the TYWE3S module to connect WIFI to the network to achieve cloud control functions. You can control the various colors and brightness of the light board through the panel buttons and mobile APP. It is mainly used in ambient lights, lighting, creative lights, warning reminders, etc. The external 12V/3A adapter provides power supply for the whole machine. (Unconstant current 3A, the actual actual current consumption is determined by the working mode of the lamp). 12V is converted to 3.3V by the internal DC/DC converter for the main control MCU. The other way is directly to the lamp board, which is converted into 5V by the lamp board DC/DC converter to supply power for the Symphony LED. This product is implemented by MCU (TLSR8362) to realize the local LED white light drive and the Symphony LED data stream, and respond to external buttons and mic signals. The module TYWE3S is responsible for linking to the network through WIFI to realize the APP control function from the smart terminal of the mobile phone issued by the cloud. And through the internal communication interconnection to realize the MCU local function response call.

Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: RSZ200425831-00 FCC Part 15.247 Page 13 of 48 FCC §15.247 (i) & §2.1091- MAXIMUM PERMISSIBLE EXPOSURE (MPE) Applicable Standard According to subpart 15.247 (i) and subpart 2.1091 systems operating under the provisions of this section shall be operated in a manner that ensures the public is not exposed to RF energy level in excess of the communication guidelines. Limits for General Population/Uncontrolled Exposure Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (Minutes) 0.3-1.34 614 1.63 *(100) 30 1.34-30 824/f 2.19/f *(180/f 2 ) 30 30-300 27.5 0.073 0.2 30 300-1500 / / f/1500 30 1500-100,000 / / 1.0 30 f = frequency in MHz * = Plane-wave equivalent power density Result Calculated Formulary: Predication of MPE limit at a given distance S = 2 4R PG  S = power density (in appropriate units, e.g. mW/cm2) P = power input to the antenna (in appropriate units, e.g., mW). G = power gain of the antenna in the direction of interest relative to an isotropic radiator, the power gain factor, is normally numeric gain. R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) Frequency (MHz) Antenna Gain Tune Up Conducted Power Evaluation Distance (cm) Power Density (mW/cm 2 ) MPE Limit (mW/cm 2 ) (dBi) (numeric) (dBm) (mW) 2412-2462 3.0 2.0 20.0 100.0 20 0.04 1.0 Note: To maintain compliance with the FCC’s RF exposure guidelines, place the equipment at least 20cm from nearby persons. Result: compliance.

7/65 /0 24 31 ;7 0 1 7(67 /(' % / X+ 1 *1' 1 9 1 1 2 2 4 5 6 73 MIC2 MIC4013 13 24 67$1'%< KEYB 1 TXD0 2 RXD0 3 GPIO5 4 GPIO4 5 GPIO0 6 GPIO2 7 GPIO15 8 GND 16 RST 15 ADC 14 EN 13 GPIO16 12 GPIO14 11 GPIO12 10 GPIO13 9 VCC TUYA1 TYWE3S 123456 181716151413 19 20 21 22 23 24 12 11 10 9 8 7 8 5 EN 3 IN 6 BST 2 SW 4 FB 1 GND 8 MP1470 1 VOUTA 2 VINA- 3 VINA+ 4 VSS 5 VINB+ 6 VINB- 7 VOUTB 8 VDD U3 C1 22uF/16V R1. & 22uF/16V 5 . R3 . 5 . 5N 5 &  &  5 N 5 N 5 . 5 100K &  5 0 5 N &  123 6:6 SIP-3 ' 796Y 5 5 12340 CN1 SIP-5 55 &  &  &  13 24 02'( KEYB 13 24 /0 KEYB 13 24 &2/25 KEYB 13 24 /0 KEYB &  &  &  &  +3.3V +3.3V AUDIO +3.3V DOUT +12V 3:0 AUDIO TX RX 7; 5; +3.3V 11 22 33 44 D D C C B B A A GND GND GND 12 ANT GND 3.3V GND GPIO16 NRST GPIO14 GPIO12 GPIO13 GPIO15 GPIO2 GPIO0 GPIO4 SD_D2SD_D3SD_CMDSD_CLKSD_D0SD_D1GPIO5 RXD0 TXD0 GND GND GND GND SD_D2 SD_D3SD_CMD SD_CLK SD_D0 SD_D1 GND GND GND GND CHIP_EN GND GND 1 GND 2 S1shield GND 1 3 Y126MHz CS 1 DO 2 WP 3 GND 4 DI 5 CLK 6 HLOD 7 VCC 8 U2GD25Q80CSIG 3.3V 3.3V 3.3V 3.3VNRST ADC ADC CHIP_EN GPIO16GPIO14GPIO12GPIO13 RST 1 ADC 2 EN 3 IO16 4 IO14 5 IO12 6 IO13 7 VCC 8 GND 9 IO15 10 IO2 11 IO0 12 IO4 13 IO5 14 RXD 15 TXD 16 P1 GPIO15GPIO2GPIO0GPIO4GPIO5RXD0TXD0 T 73 TP1 auto test GND GND C310uF/6.3V C100.1uF/16V L1 2.2pF/50V L2 2.7pF/50V C52.4nH C7 0.1uF/16V C91uF/6.3V C8 0.1uF/16V R212K/1% R112K/1% C1 4.3pF/50V C24.3pF/50V R4200R/5% C40.1uF/16V VDDA 1 LNA 2 VDD3P3 3 VDD3P3 4 VDD_RTC 5 TOUT 6 CHIP_EN 7 XPD_DCDC 8 MTMS 9 MTDI 10 VDDPST 11 MTCK 12 MTDO 13 GPIO2 14 GPIO0 15 GPIO4 16 VDDPST 17 SD_DATA_2 18 SD_DATA_3 19 SD_CMD 20 SD_CLK 21 SD_DATA_0 22 SD_DATA_1 23 GPIO5 24 U0RXD 25 U0TXD 26 XTAL_OUT 27 XTAL_IN 28 VDDD 29 VDDA 30 RES12K 31 EXT_RSTB 32 GND 33 U1ESP8266EX R312K/1% C6 10uF/6.3V AH1950

Note: This report must not be used by the customer to claim product certification, approval, or endorsement by A2LA* or any agency of the Federal Government. This report may contain data that are not covered by the A2LA accreditation and are marked with an asterisk “★”. BACL is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with an asterisk ’*’. Customer model name, addresses, names, trademarks etc. are not considered data. This report cannot be reproduced except in full, without prior written approval of the Company. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. FCC PART 15.247 TEST REPORT For JEM ACCESSORIES INC. 32 Brunswick Avenue, Edison, New Jersey 08817, United States FCC ID: 2AHAS-MLB71035 Report Type: Original Report Product Type: Digit Re port Number: RSZ200425831-00 Re port Date: 2020-05-26 Reviewed B y: Jimmy Xiao RF En gineer Prepared By: Bay Area Compliance Laboratories Corp. (Shenzhen) 6/F., West Wing, Third Phase of Wanli Industrial Building, Shihua Road, Futian Free Trade Zone, Shenzhen, Guangdong, China Tel: +86-755-33320018 Fax: +86-755-33320008 www.baclcorp.com.cn Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: RSZ200425831-00 FCC Part 15.247 Page 2 of 48 TABLE OF CONTENTS GENERAL INFORMATION ....................................................................................................................................... 4 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................................... 4 OBJECTIVE ................................................................................................................................................................... 4 RELATED SUBMITTAL(S)/GRANT(S) ............................................................................................................................. 4 TEST METHODOLOGY .................................................................................................................................................. 4 MEASUREMENT UNCERTAINTY .................................................................................................................................... 5 SYSTEM TEST CONFIGURATION .......................................................................................................................... 6 DESCRIPTION OF TEST CONFIGURATION ...................................................................................................................... 6 EQUIPMENT MODIFICATIONS ....................................................................................................................................... 6 EUT EXERCISE SOFTWARE .......................................................................................................................................... 6 DUTY CYCLE ................................................................................................................................................................ 7 SUPPORT EQUIPMENT LIST AND DETAILS .................................................................................................................... 8 EXTERNAL I/O CABLE .................................................................................................................................................. 8 BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................ 9 SUMMARY OF TEST RESULTS ............................................................................................................................. 10 TEST EQUIPMENT LIST ......................................................................................................................................... 11 FCC §15.247 (i) & §2.1091- MAXIMUM PERMISSIBLE EXPOSURE (MPE) ........................................................ 13 APPLICABLE STANDARD ............................................................................................................................................ 13 RESULT ...................................................................................................................................................................... 13 FCC §15.203 - ANTENNA REQUIREMENT ........................................................................................................... 14 APPLICABLE STANDARD ............................................................................................................................................ 14 ANTENNA CONNECTOR CONSTRUCTION .................................................................................................................... 14 FCC §15.207 (a) – AC LINE CONDUCTED EMISSIONS ..................................................................................... 15 APPLICABLE STANDARD ............................................................................................................................................ 15 EUT SETUP ................................................................................................................................................................ 15 EMI TEST RECEIVER SETUP ....................................................................................................................................... 15 TEST PROCEDURE ...................................................................................................................................................... 15 CORRECTED FACTOR & MARGIN CALCULATION ....................................................................................................... 16 TEST RESULTS SUMMARY ...................…

Text truncated - open the document above for the full version.

EXHIBIT D - TEST SETUP PHOTOGRAPHS Conducted Emissions - Front View Conducted Emissions - Side View Radiated Emissions View (Below 1 GHz) Radiated Emissions View (Above 1 GHz)
