2AHAS-MLB72059LED strip light

JEM ACCESSORIES INC. Add: 32 Brunswick Avenue, Edison, New Jersey, United States 08817 Tel: 908-222-7501 Fax: 908.222.7504 E-mail: [email protected] Date: 2022-12-06 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: Our product LED strip light, Model: MLB7-2059-RGB, MLB7-2058-RGB, FCC ID: 2AHAS-MLB72059, for use in America and this product only support 2.4G Wi-Fi (2412-2462MHz, 802.11b/g/n20/n40 Mode) and BLE 1M. The other functions and bands were disabled to use by manufacture in the software, the end user has no capability to activate it. Sincerely, Signature: Printed Name: Eli Dabbah Title: Manager

JEM ACCESSORIES INC. Add: 32 Brunswick Avenue, Edison, New Jersey, United States,08817 ： Tel 908-222-7501 Fax: 908.222.7504 E- ： mail [email protected] CFR 47 §2.911(d)(5)(i) Attestation Letter Attestation Letter Date: 02/17/2023 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(5)(i) Filing FCC ID: 2AHAS-MLB72059 JEM ACCESSORIES INC. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Signature Contact Person: Eli Dabbah Title: Manager C ompany Name: JEM ACCESSORIES INC. Company Address: 32 Brunswick Avenue, Edison, New Jersey, United States,08817

JEM ACCESSORIES INC. Add: 32 Brunswick Avenue, Edison, New Jersey, United States,08817 ： Tel 908-222-7501 Fax: 908.222.7504 E- ： mail [email protected] CFR 47 §2.911 (d)(5)(ii) Attestation Letter QA-FR-1007-A RC 02-08-2023 Attestation Letter Date: 02/17/2023 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(5)(ii) Filing FCC ID: 2AHAS-MLB72059 JEM ACCESSORIES INC. (“the applicant”) certifies that as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Signature Contact Person: Eli Dabbah Title: Manager C ompany Name: JEM ACCESSORIES INC. Company Address: 32 Brunswick Avenue, Edison, New Jersey, United States,08817

U.S. AGENT LETTER OF ATTESTATION Date: 2023-02-17 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(7) Filing FCC ID: 2AHAS-MLB72059 JEM ACCESSORIES INC. certifies that, as of the date of the filing of the application, JEM ACCESSORIES INC.. is our designated U.S. agent for service of process for the above referenced FCC ID. JEM ACCESSORIES INC. accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. JEM ACCESSORIES INC. accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent and Applicant Information: Name: JEM ACCESSORIES INC. Address: 32 Brunswick Avenue, Edison, New Jersey, United States, 08817 FRN: 0025209164 Tel.: 908-222-7501 Email: [email protected] Signed by (printed name): Eli Dabbah Signature:

BLOCK DIAGRAM 12V POWER DC 3.3V CBU BK7231N MIC Press button LED strip light Crystal: 26MHz Antenna: WIFI:2412-2462MHz BLE:2402-2480MHz

JEM ACCESSORIES INC. Add: 32 Brunswick Avenue, Edison, New Jersey, United States 08817 Tel：908-222-7501 Fax: 908.222.7504 E-mail：[email protected] FCC Authorization 2022/12/06 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We, JEM ACCESSORIES INC. the undersigned, hereby authorize Shenzhen Accurate Technology Co.,Ltd to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by Shenzhen Accurate Technology Co.,Ltd on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. Sincerely Yours, Signature: Printed Name: Eli Dabbah Title: Manager QA-FR-170-B JEM ACCESSORIES INC. Add: 32 Brunswick Avenue, Edison, New Jersey, United States,08817 Tel：908-222-7501 Fax: 908.222.7504 E-mail：[email protected] FCC Non-Confidential Authorization 2022/12/06 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Non-Confidentiality Request regarding application for certification of FCC ID: 2AHAS-MLB72058 To: whom it may concern, We, JEM ACCESSORIES INC. confirm that all the information accompanying this application is permitted to release to the public. Sincerely Yours, Signature: Printed Name: Eli Dabbah Title: Manager JEM ACCESSORIES INC. Add: 32 Brunswick Avenue, Edison, New Jersey, United States,08817 Tel：908-222-7501 Fax: 908.222.7504 E-mail：[email protected] 2022/12/6 To: Bay Area Compliance Laboratories Corp. 1274 Anvilwood Avenue Sunnyvale, CA 94089 Dear Sir/Madam, Re: Project Authorization Letter We, JEM ACCESSORIES INC. hereby authorize Shenzhen Accurate Technology Co.,Ltd to act as a laboratory for testing and test report generation for the following project(s): (Product Name: LED strip light / FCC ID: 2AHAS-MLB72059) We affirm that between Shenzhen Accurate Technology Co.,Ltd and (JEM ACCESSORIES INC.), any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Signature: Printed Name: Eli Dabbah Title: Manager QA-FR-169-B

JEM ACCESSORIES INC. Add: 32 Brunswick Avenue, Edison, New Jersey, United States 08817 Tel：908-222-7501 Fax: 908.222.7504 E-mail：[email protected] FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Date: 2022/12/06 Product Similarity Declaration To Whom It May Concern, We, JEM ACCESSORIES INC. hereby declare that we have a product named as LED strip light, (Model No.: MLB7‐2059‐RGB, FCC ID: 2AHAS‐MLB72059) was tested by ATC (Shenzhen), meanwhile, for our marketing purpose, we would like to list a series model No.: MLB7‐2058‐RGB on rep orts and certifica te, all the models are identical schematics, except below, And no other changes are made to them. LED strip light MLB7‐2059‐RGB With 12V/2A Adapter LED strip light MLB7‐2058‐RGB With 12V/1A Adapter We confirm that all information above is true, and we’ll be responsible for all the consequences. Please contact me if you have any question. Sincerely, Signature: Printed Name: Eli Dabbah Title: Manager 2 PCS 5meter LED strip 1 PCS 5meter LED strip

Shenzhen Accurate Technology Co., Ltd. Project No.: RA221124-56504E-RF External Photos Page 1 of 11 External photos MLB7-2059-RGB Shenzhen Accurate Technology Co., Ltd. Project No.: RA221124-56504E-RF External Photos Page 2 of 11 Shenzhen Accurate Technology Co., Ltd. Project No.: RA221124-56504E-RF External Photos Page 3 of 11 Shenzhen Accurate Technology Co., Ltd. Project No.: RA221124-56504E-RF External Photos Page 4 of 11 Shenzhen Accurate Technology Co., Ltd. Project No.: RA221124-56504E-RF External Photos Page 5 of 11 Adapter Shenzhen Accurate Technology Co., Ltd. Project No.: RA221124-56504E-RF External Photos Page 6 of 11 MLB7-2058-RGB Shenzhen Accurate Technology Co., Ltd. Project No.: RA221124-56504E-RF External Photos Page 7 of 11 Shenzhen Accurate Technology Co., Ltd. Project No.: RA221124-56504E-RF External Photos Page 8 of 11 Shenzhen Accurate Technology Co., Ltd. Project No.: RA221124-56504E-RF External Photos Page 9 of 11 Shenzhen Accurate Technology Co., Ltd. Project No.: RA221124-56504E-RF External Photos Page 10 of 11 Adapter Shenzhen Accurate Technology Co., Ltd. Project No.: RA221124-56504E-RF External Photos Page 11 of 11

Shenzhen Accurate Technology Co., Ltd. Project No.: RA221124-56504E-RF LABEL AND LOCATION Page 1 of 1 FCC ID Label FCC ID Label Location Information The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

Shenzhen Accurate Technology Co., Ltd. Project No.: RA221124-56504E-RF Internal Photos Page 1 of 6 Internal photos MLB7-2059-RGB Shenzhen Accurate Technology Co., Ltd. Project No.: RA221124-56504E-RF Internal Photos Page 2 of 6 Shenzhen Accurate Technology Co., Ltd. Project No.: RA221124-56504E-RF Internal Photos Page 3 of 6 Antenna Shenzhen Accurate Technology Co., Ltd. Project No.: RA221124-56504E-RF Internal Photos Page 4 of 6 MLB7-2058-RGB Shenzhen Accurate Technology Co., Ltd. Project No.: RA221124-56504E-RF Internal Photos Page 5 of 6 Shenzhen Accurate Technology Co., Ltd. Project No.: RA221124-56504E-RF Internal Photos Page 6 of 6 Antenna

Operational Description Product Name: LED strip light Model Name: MLB7-2059-RGB Frequency Range: Wi-Fi: 2412-2462MHz,BLE:2402-2480MHz 1.After the product has been connected to DC 3.3V, product will start to work through XTAL 26M Hz vibration. During transmitting, transceiver (U1) will output low‐ power signals to the PA (Power Amplifier), and then radiate signals to the space through Antenna network. During receiving signal, antenna will send electromagnetic wave signal to the Low Noise Amplifier for enlarging, and then signal will be sent to transceiver to demodulate. 2.RF Module: CBU, RF Chip: BK7231N 3 .Modulation Type: Wi-Fi: DSSS, OFDM,BLE: GFSK 4.Voltage Range: DC12V from adapter

Shenzhen Accurate Technology Co., Ltd. Report No.: RA221124-56504E-RF-00 Version 12: 2021-11-09 Page 13 of 78 FCC- BLE&2.4G Wi-Fi FCC §15.247 (i) & §1.1307 (b) (3) & §2.1091- MAXIMUM PERMISSIBLE EXPOSURE (MPE) Applicable Standard According to subpart 15.247 (i) and subpart 2.1091 systems operating under the provisions of this section shall be operated in a manner that ensures the public is not exposed to RF energy level in excess of the communication guidelines. According to KDB 447498 D04 Interim General RF Exposure Guidance MPE-Based Exemption: General frequency and separation-distance dependent MPE-based effective radiated power(ERP) thresholds are in Table B.1 [Table 1 of § 1.1307(b)(1)(i)(C)] to support an exemptionfrom further evaluation from 300 kHz through 100 GHz. Ris the minimum separation distance in meters f = frequency in MHz For multiple RF sources: Multiple RF sources are exempt if: in the case of fixed RF sources operating in the same time-averaging period, or of multiple mobile or portable RF sources within a device operating in the same time averaging period, if the sum of the fractional contributions to the applicable thresholds is less than or equal to 1 as indicated in the following equation: Shenzhen Accurate Technology Co., Ltd. Report No.: RA221124-56504E-RF-00 Version 12: 2021-11-09 Page 14 of 78 FCC- BLE&2.4G Wi-Fi Result Mode Frequency (MHz) Tune up conducted power Antenna Gain ERP Evaluation Distance (m) ERP Limit (mW) (dBm) (dBi)(dBd)(dBm)(mW) BLE 2402-2480 8.0 0 -2.15 5.85 3.85 0.2 768 2.4G Wi-Fi 2412-2462 18.5 0 -2.15 16.35 43.15 0.2 768 Note: 1. The tune up conducted power and antenna gain was declared by the applicant. 2. The BLE and 2.4G Wi-Fi cannot Simultaneous transmitting 3. 0dBd=2.15dBi To maintain compliance with the FCC’s RF exposure guidelines, place the equipment at least 20cm from nearby persons. Result: Compliant.

5 5 4 4 3 3 2 2 1 1 DD CC BB AA POWER MIC LED +3.3V 12V GNDGND GND GND GND +3.3V GND +3.3V+3.3V GND +3.3V GND GND GND +3.3V +3.3V +3.3VGND GND GND GND GND 12V GND GNDGND GND GND Title Size Document NumberRev Date:Sheet of <Doc><RevCode> <Title> B 11Tuesday, May 31, 2022 Title Size Document NumberRev Date:Sheetof <Doc><RevCode> <Title> B 11Tuesday, May 31, 2022 Title Size Document NumberRev Date:Sheetof <Doc><RevCode> <Title> B 11Tuesday, May 31, 2022 U2 RY8310 SOT23-6 EN 4 GND 2 SW 6 VIN 5 VFB 3 BS 1 33K R0402 R25 Q8 2N3904 U5 SN74LVC1G86DBVR SOT23-5 NC 1 A 2 Y 4 GND 3 VCC 5 R21NC/0R R0402 5K1_1% R0402 R18 C9 104P C0402 R284K7 R0402 L14.7uH NR3030 200K R0402 R26 C7 226P C0805 C14 226P C0805 R174K7 R0402 C4 105P C0402 T4 C1 104P C0402 0R R0402 R35 Q7 S8050 3 2 1 10K R0402 R31 470R R0402R1 1K R0402 R32 NC/0R R0402 R23 4K7 R0402 R30 200K R0402 R29 C17 102P C0402 S1 ON/OFF KEY5X5X1.5MM 1 24 3 C5 104P C0402 - + MIC1 MIC4013 MIC4013 100K R0402 R36 T20 C16 104 C0402 R225R1 R1206 C2 105P C0402 S G D N Q4 AO3400 SOT23 1 3 2 C8 102P C0402 T7 Q6 S8050 3 2 1 C24 226P C1206 CBU U1 P14 1 P16 2 P20 3 P22 4 ADC 5 RX2 6 TX2 7 3V3 14 GND 13 P24 12 P26 11 P6 10 P7 9 P8 8 TX1 15 RX1 16 P28 17 CEN 18 P9 19 P17 20 P15 21 4K7 R0402 R27 U3 IR IR IN 1 GND 2 VCC 3 C12 104 C0402 100K R0402 R20 4K7 R0402 R2 C6 104P C0402 16K_1% R0402 R19 T5 R240R/NC R0402 1K R0402 R33 1K R0402 R5 4K7 R0402 R7 D1 5.1V LL-34 12 C10 226P C0805 0R R0402 R54 C3 106P C1206 IR_IN MIC_OUT IR_IN HC P6_B/KEYP26_RP24_GP8_WP7_C P7_C C MIC_OUT MIC HC P6_B/KEY 1 1 2 2 3 3 4 4 DD CC BB AA * R F 1 TP1 R110K 3.3V P W M 2 P W M 1 P W M 0 PWM4 UART1_RXD UART1_TXD UART2_RXD UART2_TXD C2 10pF/25V_DNI C4 10pF/25V_DNI GND GND R2 18R Need Change to 18R C8 4 . 7 u F / 6 . 3 V C6 1uF/6.3V GND C3 10uF/6.3V GND 3.3V C7 4 . 7 u F / 6 . 3 V GNDGND C10 1 u F / 6 . 3 V C9 2 . 2 u F / 6 . 3 V GND PWM5 GND L1 3 . 0 n H C11 1.0pF C121.2pF/50VR30R/1% C150.5pF/50V GND C E N L2 3.6nH C5 100pF/50V TCK_F_SCK TMS_F_CSN TDI_F_SI TDO_F_SO T F_CSN1 TP T M S _ F _ C S N C10.1uF/10V GND C13 NC C14 NC GNDGND GND P17 P15 P16 P14 P28 P9 P W M 2 P W M 1 P W M 0 P W M 5 P W M 4 3 . 3 V 8 8 9 9 1 0 1 0 1 1 1 1 1 2 1 2 G N D 1 3 3 V 3 1 4 15 15 16 16 17 17 18 18 19 19 20 20 21 21 7 7 6 6 5 5 4 4 3 3 2 2 1 1 P1 Component_1 P9 P9/BT_PRIORITY/PWM3 25 P10/UART1_RXD 26 P11/UART1_TXD 27 P1/UART2_RXD/I2C2_SDA 28 P0/UART2_TXD/I2C2_SCL 29 XO 30 XI 31 VCCPLL 32 GND 33 P24/LPO_CLK/PWM4 16 P26/IRDA/PWM5 15 P17/SD_DATA0/SPI_MISO 14 P15/SD_DATA3/SPI_CSN 13 P16/SD_CMD/SPI_MOSI 12 P14/SD_CLK/SPI_SCK 11 P28/RX_EN/USBDN 10 VBAT 9 V D D A O N 8 V D D D I G 7 V S Y S 6 V C C I F 5 V C C T X 4 V C C P A 3 A N T 2 V C C R X F E 1 P 8 / B T _ A C T I V E / P W M 2 2 4 P 7 / W I F I _ A C T I V E / P W M 1 2 3 P 6 / C L K 1 3 M / P W M 0 2 2 C E N 2 1 P 2 0 / I 2 C 1 _ S C L / T C K 2 0 P 2 1 / I 2 C 1 _ S D A / T M S 1 9 P 2 2 / X H O U T / T D I 1 8 P 2 3 / A D C 3 / T D O 1 7 U1 BK7231N GND 4 XI 1 XO 3 GND 2 Y1 26MHz XTAL_4PIN GND GND GND GND XO XI XO XI 1 2 3 4 P2 WI-FI_IPEX GND R5 0Ω R6 0Ω UART2_TXD UART2_RXD TDO_F_SO UART1_TXD UART1_RXD CEN P28 P14P15 P16P17 TCK_F_SCK TDI_F_SI SCK ADC IO IO CS IO ADC RST NP NP RF 1 GND 2 ANT MOSIMISO

'TZKTTG *KYIXOHK ˖'TZKTTG *KYIXOHK 'TZKTTG -GOTJ(O ,XKW[KTI_ 8GTMK-N`-N` )UTTKIZUX :_VK*OXKIZ +^ZKXTGR <OK] *XG]OTM 6OIZ[XK UL GTZKTTG ˖ 6)( 'TZKTTG 'TZKTTG :_VK Model: 2.4G ANT ˖3KGY[XKSKTZ 8KY[RZ  8KZ[XT 2UYY 9   9SOZN )NGXZ  -GOT

★ Note: This report may contain data that are not covered by the A2LA accreditation and are marked with an asterisk “ ”. Shenzhen Accurate Technology Co., Ltd. is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with an asterisk ’*’. Customer model name, addresses, names, trademarks etc. are not considered data. This report cannot be reproduced except in full, without prior written approval of the Company. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. Shenzhen Accurate Technology Co., Ltd. 1/F., Building A, Changyuan New Material Port, Science & Industry Park, Nanshan District, Shenzhen, Guangdong, P.R. China Tel: +86 755-26503290 Fax: +86 755-26503396 Web: www.atc-lab.com Version 12: 2021-11-09 Page 1 of 78 FCC- BLE&2.4G Wi-Fi TEST REPORT Applicant Name : JEM ACCESSORIES INC. Address : 32 Brunswick Avenue,Edison,New Jersey,United States 08817 Report Number : RA221124-56504E-RF-00 FCC ID: 2AHAS-MLB72059 Test Standard (s) FCC PART 15.247 Sample Description Product Type: LED strip light Model No.: MLB7-2059-RGB Multiple Model(s) No.: MLB7-2058-RGB Trade Mark: Date Received: 2022/11/24 Report Date: 2022/12/06 Test Result: Pass* * In the configuration tested, the EUT complied with the standards above. Prepared and Checked By: Approved By: Andy Yu Candy Li EMC Engineer EMC Engineer Shenzhen Accurate Technology Co., Ltd. Report No.: RA221124-56504E-RF-00 Version 12: 2021-11-09 Page 2 of 78 FCC- BLE&2.4G Wi-Fi TABLE OF CONTENTS DOCUMENT REVISION HISTORY ......................................................................................................................... 4 GENERAL INFORMATION ....................................................................................................................................... 5 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................................... 5 OBJECTIVE ................................................................................................................................................................... 5 TEST METHODOLOGY .................................................................................................................................................. 5 MEASUREMENT UNCERTAINTY .................................................................................................................................... 6 SYSTEM TEST CONFIGURATION .......................................................................................................................... 7 DESCRIPTION OF TEST CONFIGURATION ...................................................................................................................... 7 EQUIPMENT MODIFICATIONS ....................................................................................................................................... 8 EUT EXERCISE SOFTWARE .......................................................................................................................................... 8 DUTY CYCLE ................................................................................................................................................................ 8 SUPPORT EQUIPMENT LIST AND DETAILS .................................................................................................................... 8 EXTERNAL I/O CABLE .................................................................................................................................................. 8 BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................ 9 SUMMARY OF TEST RESULTS ............................................................................................................................. 10 TEST EQUIPMENT LIST ......................................................................................................................................... 11 FCC §15.247 (I) & §1.1307 (B) (3) & §2.1091- MAXIMUM PERMISSIBLE EXPOSURE (MPE) ..................... 13 FCC §15.203 - ANTENNA REQUIREMENT ........................................................................................................... 15 APPLICABLE STANDARD ............................................................................................................................................ 15 ANTENNA CONNECTOR CONSTRUCTION .................................................................................................................... 15 FCC §15.207 (A) – AC LINE CONDUCTED EMISSIONS .................................................................................... 16 APPLICABLE STANDARD ............................................................................................................................................ 16 EUT SETUP ................................................................................................................................................................ 16 EMI TEST RECEIVER SETUP ....................................................................................................................................... 16 TEST PROCEDURE ...................................................................................................................................................... 16 TRANSD FACTOR & MARGIN CALCULATION.............................................................................................................. 17 TEST DATA ................................................................................................................................................................ 17 FCC §15.209, …

Text truncated - open the document above for the full version.

Shenzhen Accurate Technology Co., Ltd. Project No.: RA221124-56504E-RF Test Photos Page 1 of 4 Photo of Conducted Emission Measurement For Model: MLB7-2059-RGB Shenzhen Accurate Technology Co., Ltd. Project No.: RA221124-56504E-RF Test Photos Page 2 of 4 For Model: MLB7-2058-RGB Shenzhen Accurate Technology Co., Ltd. Project No.: RA221124-56504E-RF Test Photos Page 3 of 4 For Model: MLB7-2059-RGB Photo of Radiated Emission Measurement (Below 1G) Photo of Radiated Emission Measurement (Above 1G) Shenzhen Accurate Technology Co., Ltd. Project No.: RA221124-56504E-RF Test Photos Page 4 of 4 For Model: MLB7-2058-RGB Photo of Radiated Emission Measurement (Below 1G)
