2AHAS-XCA21013Basic Wireless Keyboard

-1- Product Specifications KEYBOARD MODEL NO. : XCA2-1013-BLK -2- Keyboard Table Contents Table Contents -2- 1.0 General Specifications 1.1. Appearance 1.2. Outline Dimensions and Material -3- -3- -3- 2.0 Environmental 2.1. Working temperature 2.2. Working humidity 2.3. Storage temperature 2.4. Storage humidity -4- -4- -4- -4- -4- 3.0 Mechanical 3.1. Push button 3.2. Maximum use life -4- -4- -4- 4.0 Cable 4.1. Working Voltage 4.2. Working Current 4.3. Working Distance 4.4. Working Frequency -4- -4- -4- -4- -4- 5.0 Electrical 5.1. Inter face MIN USB 5.1.2. Power requirements -4- -4- -4- 6.0 Working condition for compatible PC -5- -3- Keyboard 1.0 General Specifications 1-1 Appearance There should be no notice liable scratches, contamination, or welding etc. That affects the appearance. (product inspect specification standard Doc. No.) There is case to make a limited sample to conform color between manufacturer and customer. 1-2 Outline, Dimensions and Material Outline, Dimensions and Material shall be shown on the individual drawing. Length 443mm Width 153mm Height 25mm Weight 412 g ± 10 g Keys 104 PCS Body Color Black Operation system environment Win2000/Win XP/WINME/Vista/Win7/Win8/Android/Linux/Apple. -4- 2.0 Environmental 2-1 Working temperature -6 °C ~ +46 °C 2-2 Working humidity 10 % ~ 80%RH 2-3 Storage temperature -20 °C ~ +60 °C 2-4 Storage humidity -20°C-60°C 3.0 Mechanical 3-1 Pushbutton Items Condition Specifications Operation force Operating on the center of Button Operating point ∮6.5mm 44±10g Max. Operating stroke 5.0±0.3 mm 3-2 Maximum use life Items Condition Specifications Maximum use life Normal 10000000 cycles Max. 4.0 RF 2.4G 4.1 Working Voltage 1.5V 4.2 Working Current 25mA 4.3 Working Distance is 8-10 meters 4.4 Working Frequency 2.4GHz Keyboard 5.0 Electrical 5-1 Interface 2.4G 5-1-2 Power requirements 1.5.V DC 25mA Max. 6.0 Working condition for compatible PC PC Win2000/Win XP/WINME/Vista/Win7/Win8/Android/Linux/Apple. -5- FCC Caution: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. IMPORTANT NOTE: Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment .

blockdiagram NT2012-SE65K RF HS6200 2402MHz—2480MHz KeyScan LEDindication 16 MHz PowerManager

JEM ACCESSORIES INC. Add: 32 Brunswick Avenue Edison, NJ 08817,United States Tel：908-222-7501 Fax: 908.222.7504 E-mail：[email protected] FCC Authorization 2020/09/14 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We, JEM ACCESSORIES INC. the undersigned, hereby authorize Bay Area Compliance Laboratories Corporation to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by Bay Area Compliance Laboratory Corporation on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. Sincerely Yours, Signature: Printed Name: Eli Dabbah Title: Manager QA-FR-170-B

JEM ACCESSORIES INC. Add: 32 Brunswick Avenue Edison, NJ 08817,United States Tel：908-222-7501 Fax: 908.222.7504 E-mail：[email protected] Date: 2020/09/14 Product Similarity Declaration To Whom It May Concern, We, JEM ACCESSORIES INC. hereby declare that we have a product named as Basic Wireless Keyboard (Model No: XCA2‐1013‐BLK) ,FCC ID: 2AHAS‐XCA21013,was tested by BACL, meanwhile, for our marketing purpose, we would like to list a series model 12484, 12485 on reports and certificate, all the models are identical schematics, except for the difference of model No., And no other changes are made to them. We confirm that all information above is true, and we’ll be responsible for all the consequences. Please contact me if you have any question. Sincerely, Signature: Printed Name: Eli Dabbah Title: Manager

Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ200822830-RF Page 1 of 3 EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ200822830-RF Page 2 of 3 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ200822830-RF Page 3 of 3

Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ200822830-RF EXHIBIT A - FCC ID LABEL AND LOCATION FCC ID Label FCC ID Label Location Information The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ200822830-RF Page 1 of 3 EXHIBIT C - EUT INTERNAL PHOTOGRAPHS Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ200822830-RF Page 2 of 3 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: RSZ200822830-RF Page 3 of 3 Antenna

OperationalPrinciple 1.CPU,NT2012-SE65Khavean8-bitmicroprocessordesignedand developed withlow-powerandhigh-speedCMOStechnology. Opration frequencyis3.5MHzwithinternalRCoscillator.,This chipis responsibletocontrolRF-BasebandTransceiver(HS6200). 2.Matrix,8*18matrixwitheightinputlineandeighteenoutputline. 3.2.4GHzISMBandTransceiver/Framer,HS6200whichisa low-cost,fullyinegratedCMOSradiofrequency(RF)transceiver block,combinedwitha64-bytebufferedframerblock.Itcontains transmit,receive,VCOandPLLfunctions,includinganon-chip channelfilterandresonator.Itneedsanexternal16MHzcrystalfor referencefrequency; 4.ANTENNA,Theantennaistypicallyfedfromtheendofthe monopolesectionbyaplatedthrough-holeviawhichisinturn connectedtotheRFoutputonthe2.4GHzband.

1 2 34 ABCD 4 3 2 1 DCBA 08 RF Circuit Main Circuit 1234567891011121314151617192021222324252618 J1 PIN26 C0C1C2C3C4C5C6C7C8C9C10C11C12C13C14C15R0R1R2R3R4R5R6R7 OSCI 25 VSS 26 VPP 27 VCC 28 P4.1 29 P4.2 30 P0.0 31 P0.1 32 P0.2 33 P0.6 37 P0.7 38 P1.0 39 P1.1 40 P1.2 41 P1.3 1 P1.4 2 P1.5 3 P1.6 4 P1.7 5 VSS 6 P2.0 7 P2.1 8 P2.2 9 P2.3 10 P2.4 11 P2.5 12 P3.0 13 P3.1 14 P3.2 15 P3.3 16 P3.4 17 P3.5 18 P3.6 19 P3.7 20 P2.6 21 P2.7 22 P4.0 23 OSCO 24 P0.3 34 P0.4 35 P0.5 36 U1NT2012-SE65K C14C13C12C11C15C10C8C9C0C16C17 R0 R1 R2 R3 R4 R5 R6 R7 Num Lock C1 C2 VCC C3 C4 C5 C6 C7 R51K NUM LED VCC C16C17 LED Display Power Circuit  1  *    2  C9  X5R  3  X1  2* 6  3* 8  49 S  !"#$% : 16MHz+/-20ppm(  +/-1 0ppm),12pF & C4  C5  '() 4  R5 *+,-./ &01() ANT12.4G TVCC ANT Matching Circuit VCC Y1 16MHZ+/-20PPM 12pF CE 1 CSN 2 SCK 3 MOSI 4 MISO 5 DVSS 20 CDVDD 19 DVDD 18 VSS 17 VREF 16 AVCC 15 AVSS 14 RFP 13 RFN 12 VCC 11 IRQ 6 AVCC 7 AVSS 8 XTALN 9 XTALP 10 U2HS6200 RF MISO RFCS RF MOSIRF SCK IRQ TVCC TVCC ANT TVCC C14100nF TVCC RF MISO RF SCK RF MOSI RFCS IRQCap Lock C29 22uF C10 0.1uF VCC BAT1 1*1.5V Num Lock LVD CF1NC LVD Scroll Lock 12345 J2 RF MISORF MOSI VCC VPP VPP TVCC
