2AHAS-XLS71013PSmart Color Flow LED Light Strip

This equipment should be installed and operated with minimum fdistance 20cm between the radiator& your body.

This equipment should be installed and operated with minimum fdistance 20cm between the radiator& your body.

JEM ACCESSORIES INC. Add: 32 Brunswick Avenue, Edison, New Jersey, United States,08817 Tel: +1 732-339-9800 Fax: +1 732-481-0300 E-mail: [email protected] FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 We, JEM ACCESSORIES INC. hereby declare that： Product Name: Smart Color Flow LED Light Strip Model No.: XLS7-1013-ICM, XLS7-1012-ICM FCC ID: 2AHAS-XLS71013P For BT Mode: BDR(GFSK), EDR(π/4‐DQPSK ), EDR(8DPSK ) are disable by software. For Below are activated: BLE 1M Except for the manufacturer, the end user does not have any capability to modify/change the RF parameters. We acknowledge that it is the manufacturer’s responsibility to provide the radio configurations to ensure compliance with Commission’s rules. Sincerely, Signature Printed Name: Nathan Shamula Title: COO

JEM ACCESSORIES INC. Add: 32 Brunswick Avenue, Edison, New Jersey, United States,08817 Tel: +1 732-339-9800 Fax: +1 732-481-0300 E- mail: [email protected] Product Similarity Declaration FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir/Madam, We, JEM ACCESSORIES INC. hereby declare that we have a product named as Smart Color Flow LED Light Strip, ( Model No.: XLS7-1013-ICM) was tested by Bay Area Compliance Laboratories Corp. (Shenzhen), meanwhile, for our marketing purpose, we would like to list a series model No.: XLS7-1012-ICM on reports and certificate, all the models are identical in electrically, the difference as below: 1. Different Model No. 2. Different sales channels. 3. Different LED Strip: Model Difference XLS7-1013-ICM With 25ft long LED Strip XLS7-1012-ICM With 10ft long LED Strip We confirm that all information above is true, and we’ll be responsible for all the consequences. Please contact me if you have any question. Sincerely, Signature: Printed Name: Nathan Shamula Title: COO

Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601S23688E-RF-EXP Page 1 of 2 EUT EXTERNAL PHOTOGRAPHS Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601S23688E-RF-EXP Page 2 of 2

Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601S23688E-RF-INP Page 1 of 3 EUT INTERNAL PHOTOGRAPHS Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601S23688E-RF-INP Page 2 of 3 Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601S23688E-RF-INP Page 3 of 3 Antenna

Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601S23688E-RF-00 TR-EM-RF003 Page 24 of 77 Version 4.1 RF EXPOSURE EVALUATION MPE-Based Exemption Applicable Standard According to subpart 15.247 (i) and subpart 2.1091 systems operating under the provisions of this section shall be operated in a manner that ensures the public is not exposed to RF energy level in excess of the communication guidelines. According to KDB 447498 D04 v01 Interim General RF Exposure Guidance MPE-Based Exemption: General frequency and separation-distance dependent MPE-based effective radiated power(ERP) thresholds are in Table B.1 [Table 1 of § 1.1307(b)(3)(i)(C)] to support an exemptionfrom further evaluation from 300 kHz through 100 GHz. R is the minimum separation distance in meters f = frequency in MHz Result Antenna Gain#ERP Mode Frequency (MHz) Tune up conducted power # (dBm) (dBi)(dBd)(dBm)(W) Evaluation Distance (m) ERP Limit (W) BLE2402-24806.00 1.96-0.195.810.0040.20.768 Note: The tune up conducted power and antenna gain was declared by the applicant. To maintain compliance with the FCC’s RF exposure guidelines, place the equipment at least 20cm from nearby persons. Result: Compliant

PHY6222 Antenna test report Manufacturer：FTY Technology Co.,Ltd Add: 602, Building 1,Aidimengtuo Industrial Park, the 4 th Industrial Zone, shutianpu Community, Ma Tian Street, Guangming District, Shenzhen CHINA Website: www.phaten.com 1 FTY Technology Co.,Ltd 1. Product Description Product Name PHY6222 Antenna Type PCB antenna Maximum Gain:1.96dBi Efficiency:44.48% 2. General Description EUT Name PHY6222 Antenna Wireless type BT Antenna Type PCB antenna Dimensions Appendix A 3. Technical Information Frequency Range 2402MHz~2480MHz Test Frequency 2400,2410......2500MHz 2 FTY Technology Co.,Ltd 4. Test Standards Identity Document Title IEEE 149-1979 IEEE Standard Test Procedures for Antennas 5. Test Item Report Section Description Appendix B S11A/SWR Appendix C Gain and Efficiency Appendix D Radiation Pattern (1D and 3D) 6. Test Photo Report Section Description Appendix E Test Setup Photo 3 FTY Technology Co.,Ltd 7. Darkroom test equipment and data 5.0 Test Equipment Test system: shielded darkroom Test environment: temperature 22 °C± 3 °C , humidity 50% ± 15% Test equipment: when testing passive data, use AgilentE5071C network analyzer；When testing the active data, use the comprehensive tester CMW500 FTY Technology Co.,Ltd 4 8. Appendix A Antenna Dimension 9. Appendix B Sll/VSWR Frequency （MHz) 2400 2450 2500 VSWR 1.8 1.5 1.8 FTY Technology Co.,Ltd 5 10. Appendix C Gain and Efficiency Passive Test For D44 Freq (MHz) Effi (%) Effi (dB) Gain (dBi) Gain (dBd) UHIS (%) DHIS (%) Max (dB) Min (dB) Attenut Hor Attenut Ver 2400 40.43 -3.93 0.7 -1.45 16.061 24.371 0.7 -17.16 49.18 49.3 2410 39.54 -4.03 0.86 -1.29 15.756 23.785 0.86 -16.67 49.23 49.45 2420 40.88 -3.89 1.4 -0.75 16.635 24.243 1.4 -18.58 49.06 49.29 2430 42.5 -3.72 1.67 -0.48 17.57 24.935 1.67 -17.79 49.12 49.32 2440 44.48 -3.52 1.96 -0.19 18.796 25.689 1.96 -16.72 49.75 50.01 2450 43.2 -3.65 1.84 -0.31 18.687 24.512 1.84 -17.35 49.82 50.08 2460 41.57 -3.81 1.53 -0.62 18.485 23.085 1.53 -19.76 49.85 50.08 2470 38.01 -4.2 1.07 -1.08 17.234 20.774 1.07 -21.44 49.76 49.97 2480 38.23 -4.18 0.77 -1.38 17.723 20.511 0.77 -21.64 49.66 49.8 2490 35.02 -4.56 0.3 -1.85 16.519 18.504 0.3 -20.83 49.54 49.68 2500 28.21 -5.5 -0.77 -2.92 13.358 14.85 -0.77 -21.32 49.32 49.42 FTY Technology Co.,Ltd 6 11. Appendix D Radiation Pattern(lD and 3D) FTY Technology Co.,Ltd 7 FTY Technology Co.,Ltd 10 FTY Technology Co.,Ltd 12 12. Appendix E Test Setup Photo FTY Technology Co.,Ltd 13

Note: The information marked # is provided by the applicant, the laboratory is not responsible for its authenticity and this information can affect the validity of the result in the test report. Customer model name, addresses, names, trademarks etc. are included. This report cannot be reproduced except in full, without prior written approval of the Company. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. This report must not be used by the customer to claim product certification, approval, or endorsement by NVLAP or any agency of the U.S. Government. This report may contain data that are not covered by the NVLAP accreditation and are marked with an asterisk “▼”. Bay Area Compliance Laboratories Corp. (Shenzhen) 5F(B-West) , 6F, 7F, the 3rd Phase of Wan Li Industrial Building D, Shihua Rd, FuTian Free Trade Zone, Shenzhen, China Tel: +86-755-33320018 Fax: +86-755-33320008 www.baclcorp.com.cn TR-EM-RF003 Page 1 of 77 Version 4.1 TEST REPORT Applicant Name:JEM ACCESSORIES INC. Address:32 Brunswick Avenue, Edison, New Jersey, United States, 08817 Report Number:2601S23688E-RF-00 FCC ID:2AHAS-XLS71013P Test Standard (s) FCC PART 15.247 Sample Description Product Type:Smart Color Flow LED Light Strip Model No.:XLS7-1013-ICM Multiple Model(s) No.:XLS7-1012-ICM Trade Mark: Date Received:2026-04-09 Issue Date:2026-06-02 Test Result:Pass ▲ ▲ In the configuration tested, the EUT complied with the standards above. Prepared and Checked By:Approved By: Navilite CaiJimmy Xiao RF EngineerEMC Manager Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601S23688E-RF-00 TR-EM-RF003 Page 2 of 77 Version 4.1 TABLE OF CONTENTS DOCUMENT REVISION HISTORY ..........................................................................................................................3 GENERAL INFORMATION ........................................................................................................................................4 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT)......................................................................................4 OBJECTIVE ....................................................................................................................................................................4 TEST METHODOLOGY....................................................................................................................................................4 MEASUREMENT UNCERTAINTY .....................................................................................................................................5 TEST FACILITY ..............................................................................................................................................................5 SYSTEM TEST CONFIGURATION ...........................................................................................................................6 SUMMARY OF TEST RESULTS ................................................................................................................................9 TEST EQUIPMENT LIST ..........................................................................................................................................10 REQUIREMENTS AND TEST PROCEDURES ......................................................................................................12 AC LINE CONDUCTED EMISSIONS...............................................................................................................................12 UNWANTED EMISSION FREQUENCIES AND RESTRICTED BANDS .................................................................................14 6 DB EMISSION BANDWIDTH & 99% OCCUPIED BANDWIDTH....................................................................................17 PEAK OUTPUT POWER MEASUREMENT .......................................................................................................................19 POWER SPECTRAL DENSITY ........................................................................................................................................20 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE....................................................................................................21 CONDUCTED SPURIOUS EMISSION...............................................................................................................................22 DUTY CYCLE ...............................................................................................................................................................23 RF EXPOSURE EVALUATION ................................................................................................................................24 ANTENNA REQUIREMENT .....................................................................................................................................25 TEST DATA AND RESULTS .....................................................................................................................................26 AC LINE CONDUCTED EMISSIONS...............................................................................................................................26 UNWANTED EMISSION FREQUENCIES AND RESTRICTED BANDS .................................................................................31 6DB EMISSION BANDWIDTH........................................................................................................................................57 99% OCCUPIED BANDWIDTH ......................................................................................................................................60 MAXIMUM CONDUCTED OUTPUT POWER ..............................................................................................................…

Text truncated - open the document above for the full version.

Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601S23688E-RF-TSP Page 1 of 5 TEST SETUP PHOTOGRAPHS For Model: XLS7-1013-ICM Conducted Emissions - Front View Conducted Emissions - Side View Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601S23688E-RF-TSP Page 2 of 5 Radiated Emissions View (Below 30MHz) Radiated Emissions View (Below 1 GHz) Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601S23688E-RF-TSP Page 3 of 5 Radiated Emissions View (1-18 GHz) Radiated Emissions View (18-25 GHz) Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601S23688E-RF-TSP Page 4 of 5 For Model: XLS7-1012-ICM Conducted Emissions - Front View Conducted Emissions - Side View Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2601S23688E-RF-TSP Page 5 of 5 Radiated Emissions View (Below 30MHz) Radiated Emissions View (Below 1 GHz)
