2AHBN-AP47Wi-Fi 7 Wireless Access Point

Radiated PSD Appendix C.7 Sporton International Inc. Hsinchu Laboratory Page No. : 1 of 26 Test Mode: Mode 7 Summary Mode EIRP PD (dBm/RBW) 5.925-6.425GHz - 802.11be EHT20_Nss1,(MCS0)_4TX 4.96 802.11be EHT20_Nss1,(MCS0)_4TX 4.93 802.11be EHT20_Nss1,(MCS0)_4TX 4.99 802.11be EHT40_Nss1,(MCS0)_4TX 4.95 802.11be EHT40_Nss1,(MCS0)_4TX 4.91 802.11be EHT40_Nss1,(MCS0)_4TX 4.86 802.11be EHT80_Nss1,(MCS0)_4TX 4.87 802.11be EHT80_Nss1,(MCS0)_4TX 4.82 802.11be EHT80_Nss1,(MCS0)_4TX 4.96 802.11be EHT160_Nss1,(MCS0)_4TX 4.92 802.11be EHT160_Nss1,(MCS0)_4TX 4.95 802.11be EHT160_Nss1,(MCS0)_4TX 4.76 802.11be EHT320_Nss1,(MCS0)_4TX 4.79 802.11be EHT320_Nss1,(MCS0)_4TX 4.89 6.425-6.525GHz - 802.11be EHT20_Nss1,(MCS0)_4TX 4.90 802.11be EHT20_Nss1,(MCS0)_4TX 4.88 802.11be EHT20_Nss1,(MCS0)_4TX 4.78 802.11be EHT40_Nss1,(MCS0)_4TX 4.94 802.11be EHT40_Nss1,(MCS0)_4TX 4.88 802.11be EHT40_Nss1,(MCS0)_4TX 4.95 802.11be EHT80_Nss1,(MCS0)_4TX 4.70 802.11be EHT80_Nss1,(MCS0)_4TX 4.90 802.11be EHT160_Nss1,(MCS0)_4TX 4.98 802.11be EHT320_Nss1,(MCS0)_4TX 4.46 6.525-6.875GHz - 802.11be EHT20_Nss1,(MCS0)_4TX 4.89 802.11be EHT20_Nss1,(MCS0)_4TX 4.84 802.11be EHT20_Nss1,(MCS0)_4TX 4.82 802.11be EHT40_Nss1,(MCS0)_4TX 4.69 802.11be EHT40_Nss1,(MCS0)_4TX 4.88 802.11be EHT40_Nss1,(MCS0)_4TX 4.85 802.11be EHT80_Nss1,(MCS0)_4TX 4.85 802.11be EHT80_Nss1,(MCS0)_4TX 4.86 802.11be EHT80_Nss1,(MCS0)_4TX 4.94 802.11be EHT80_Nss1,(MCS0)_4TX 4.94 802.11be EHT160_Nss1,(MCS0)_4TX 4.88 802.11be EHT160_Nss1,(MCS0)_4TX 4.90 802.11be EHT320_Nss1,(MCS0)_4TX 4.99 802.11be EHT320_Nss1,(MCS0)_4TX 4.87 6.875-7.125GHz - 802.11be EHT20_Nss1,(MCS0)_4TX 4.92 802.11be EHT20_Nss1,(MCS0)_4TX 4.92 802.11be EHT20_Nss1,(MCS0)_4TX 4.93 802.11be EHT40_Nss1,(MCS0)_4TX 4.80 802.11be EHT40_Nss1,(MCS0)_4TX 4.88 802.11be EHT40_Nss1,(MCS0)_4TX 4.80 802.11be EHT80_Nss1,(MCS0)_4TX 4.90 802.11be EHT80_Nss1,(MCS0)_4TX 4.82 802.11be EHT160_Nss1,(MCS0)_4TX 4.95 RBW = 500kHz for 5.725-5.85GHz band / 1MHz for other band; Report No. : FR4O0708-01 Radiated PSD Appendix C.7 Sporton International Inc. Hsinchu Laboratory Page No. : 2 of 26 Result Mode Result EIRP PD EIRP PD Limit (dBm/RBW) (dBm/RBW) 802.11be EHT20_Nss1,(MCS0)_4TX - - - 5955MHz Pass 4.96 5.00 6195MHz Pass 4.93 5.00 6415MHz Pass 4.99 5.00 6435MHz Pass 4.90 5.00 6475MHz Pass 4.88 5.00 6515MHz Pass 4.78 5.00 6535MHz Pass 4.89 5.00 6695MHz Pass 4.84 5.00 6875MHz Straddle 6.525-6.875GHz Pass 4.82 5.00 6895MHz Pass 4.92 5.00 6995MHz Pass 4.92 5.00 7095MHz Pass 4.93 5.00 802.11be EHT40_Nss1,(MCS0)_4TX - - - 5965MHz Pass 4.95 5.00 6205MHz Pass 4.91 5.00 6405MHz Pass 4.86 5.00 6445MHz Pass 4.94 5.00 6485MHz Pass 4.88 5.00 6525MHz Straddle 6.425-6.525GHz Pass 4.95 5.00 6565MHz Pass 4.69 5.00 6685MHz Pass 4.88 5.00 6885MHz Straddle 6.525-6.875GHz Pass 4.85 5.00 6925MHz Pass 4.80 5.00 7005MHz Pass 4.88 5.00 7085MHz Pass 4.80 5.00 802.11be EHT80_Nss1,(MCS0)_4TX - - - 5985MHz Pass 4.87 5.00 6225MHz Pass 4.82 5.00 6385MHz Pass 4.96 5.00 6465MHz Pass 4.70 5.00 6545MHz Straddle 6.425-6.525GHz Pass 4.90 5.00 6625MHz Pass 4.85 5.00 6705MHz Pass 4.86 5.00 6785MHz Pass 4.94 5.00 6865MHz Straddle 6.525-6.875GHz Pass 4.94 5.00 6945MHz Pass 4.90 5.00 7025MHz Pass 4.82 5.00 802.11be EHT160_Nss1,(MCS0)_4TX - - - 6025MHz Pass 4.92 5.00 6185MHz Pass 4.95 5.00 6345MHz Pass 4.76 5.00 6505MHz Straddle 6.425-6.525GHz Pass 4.98 5.00 6665MHz Pass 4.88 5.00 6825MHz Straddle 6.525-6.875GHz Pass 4.90 5.00 6985MHz Pass 4.95 5.00 802.11be EHT320_Nss1,(MCS0)_4TX - - - 6105MHz Pass 4.79 5.00 6265MHz Pass 4.89 5.00 6585MHz Straddle 6.425-6.525GHz Pass 4.46 5.00 6745MHz Straddle 6.525-6.875GHz Pass 4.99 5.00 6905MHz Straddle 6.525-6.875GHz Pass 4.87 5.00 DG = Directional Gain; RBW = 500kHz for 5.725-5.85GHz band / 1MHz for other band; PD = trace bin-by-bin of each transmits port summing can be performed maximum power density; Port X = Port X Power Density; Inf = There's no restriction for the limit. Report No. : FR4O0708-01 Radiated PSD Appendix C.7 Sporton International Inc. Hsinchu Laboratory Page No. : 3 of 26 Report No. : FR4O0708-01 Radiated PSD Appendix C.7 Sporton International Inc. Hsinchu Laboratory Page No. : 4 of 26 Report No. : FR4O0708-01 Radiated PSD Appendix C.7 Sporton International Inc. Hsinchu Laboratory Page No. : 5 of 26 Report No. : FR4O0708-01 Radiated PSD Appendix C.7 Sporton International Inc. Hsinchu Laboratory Page No. : 6 of 26 Report No. : FR4O0708-01 Radiated PSD Appendix C.7 Sporton International Inc. Hsinchu Laboratory Page No. : 7 of 26 Report No. : FR4O0708-01 Radiated PSD Appendix C.7 Sporton International Inc. Hsinchu Laboratory Page No. : 8 of 26 Report No. : FR4O0708-01 Radiated PSD Appendix C.7 Sporton International Inc. Hsinchu Laboratory Page No. : 9 of 26 Report No. : FR4O0708-01 Radiated PSD Appendix C.7 Sporton International Inc. Hsinchu Laboratory Page No. : 10 of 26 Report No. : FR4O0708-01 Radiated PSD Appendix C.7 Sporton International Inc. Hsinchu Laboratory Page No. : 11 of 26 Report No. : FR4O0708-01 Radiated PSD Appendix C.7 Sporton International Inc. Hsinchu Laboratory Page No. : 12 of 26 Report No. : FR4O0708-01 Radiated PSD Appendix C.7 Sporton International Inc. Hsinchu Laboratory Page No. : 13 of 26 Report No. : FR4O0708-01 Radiated PSD Appendix C.7 Sporton International Inc. Hsinchu Laboratory Page No. : 14 of 26 Report No. : FR4O0708-01 Radiated PSD Appendix C.7 Sporton International Inc. Hsinchu Laboratory Page No. : 15 of 26 Report No. : FR4O0708-01 Radiated PSD Appendix C.7 Sporton International Inc. Hsinchu Laboratory Page No. : 16 of 26 Report No. : FR4O0708-01 Radiated PSD Appendix C.7 Sporton International Inc. Hsinchu Laboratory Page No. : 17 of 26 Report No. : FR4O0708-01 Radiated PSD Appendix C.7 Sporton International Inc. Hsinchu Laboratory Page No. : 18 of 26 Report No. : FR4O0708-01 Radiated PSD Appendix C.7 Sporton International Inc. Hsinchu Laboratory Page No. : 19 of 26 Report No. : FR4O0708-01 Radiated PSD Appendix C.7 Sporton International Inc. Hsinchu Laboratory Page No. : 20 o…

Text truncated - open the document above for the full version.

AFC DUT TEST HARNESS REPORT Report No. : F34O0708-01 TEL : 886-3-656-9065 Page Number : 2 of 36 FAX : 886-3-656-9085 Issued Date : Oct. 08, 2025 Report Template No.: CB-A12_7 Ver2.0 Report Version : 01 Table of Contents 1 General Description .......................................................................................................................................... 6 1.1 Product Feature of Equipment Under Test ......................................................................................................... 6 1.2 Antenna Information ............................................................................................................................................ 7 1.3 Table for Multiple Listing ................................................................................................................................... 16 1.4 Table for Radio Function ................................................................................................................................... 17 1.5 Table for Permissive Change ............................................................................................................................ 19 1.6 Accessories ....................................................................................................................................................... 19 1.7 Support Equipment ........................................................................................................................................... 19 1.8 Applicable Standards ........................................................................................................................................ 19 1.9 Testing Location ................................................................................................................................................ 20 2 Measurement Environment ............................................................................................................................ 21 2.1 AFCD General Capabilities Declaration ............................................................................................................ 21 2.2 Test Configuration ............................................................................................................................................. 25 3 Protocol Test Results ..................................................................................................................................... 27 3.1 Successful Registration and Spectrum Access Request .................................................................................. 27 3.2 Unsuccessful Spectrum Access Request ......................................................................................................... 29 3.3 Successful Spectrum Access Update ............................................................................................................... 30 3.4 Unsuccessful Spectrum Access Update ........................................................................................................... 32 3.5 Unsuccessful Server Validation ........................................................................................................................ 34 4 Test Equipment and Calibration Data ........................................................................................................... 35 5 Measurement Uncertainty .............................................................................................................................. 36 Appendix A. Tools Report Appendix B. DUT Spectrum Inquiry Request/Response Logs Appendix C. RF Measurement Plots Photographs of EUT v01 AFC DUT TEST HARNESS REPORT Report No. : F34O0708-01 TEL : 886-3-656-9065 Page Number : 3 of 36 FAX : 886-3-656-9085 Issued Date : Oct. 08, 2025 Report Template No.: CB-A12_7 Ver2.0 Report Version : 01 History of this test report Report No. Version Description Issued Date F34O0708-01 01 Initial issue of report Oct. 08, 2025 AFC DUT TEST HARNESS REPORT Report No. : F34O0708-01 TEL : 886-3-656-9065 Page Number : 4 of 36 FAX : 886-3-656-9085 Issued Date : Oct. 08, 2025 Report Template No.: CB-A12_7 Ver2.0 Report Version : 01 Summary of Test Result Report Clause Ref Std. Clause Test Case Name Result (PASS/FAIL) Remark AFC capability - Inquired Frequency Test Group: Inquired Frequency - Always - 3.1.4 CT_AFC_SP_AP_AFCDRSA31_Frequency_20MHz_10611_1 N/A - - 3.1.4 CT_AFC_SP_AP_AFCDRSA31_Frequency_40MHz_10612_1 N/A - - 3.1.4 CT_AFC_SP_AP_AFCDRSA31_Frequency_80MHz_10613_1 N/A - - 3.1.4 CT_AFC_SP_AP_AFCDRSA31_Frequency_160MHz_10614_1 N/A - - 3.2.4 CT_AFC_SP_AP_AFCDUSA32_Frequency_10615_1 N/A - - 3.3.4 CT_AFC_SP_AP_AFCDSAU33_Frequency_10616_1 N/A - - 3.4.4 CT_AFC_SP_AP_AFCDUAU34_Frequency_10617_1 N/A - - 3.1.4 CT_AFC_SP_AP_AFCDRSA31_Frequency_320MHz_10713_1 N/A - AFC capability - Inquired Channel Test Group: Inquired Channel - Always - 3.1.4 CT_AFC_SP_AP_AFCDRSA31_Channel_20MHz_10618_1 N/A - - 3.1.4 CT_AFC_SP_AP_AFCDRSA31_Channel_40MHz_10619_1 N/A - - 3.1.4 CT_AFC_SP_AP_AFCDRSA31_Channel_80MHz_10620_1 N/A - - 3.1.4 CT_AFC_SP_AP_AFCDRSA31_Channel_160MHz_10621_1 N/A - - 3.2.4 CT_AFC_SP_AP_AFCDUSA32_Channel_10622_1 N/A - - 3.3.4 CT_AFC_SP_AP_AFCDSAU33_Channel_10623_1 N/A - - 3.4.4 CT_AFC_SP_AP_AFCDUAU34_Channel_10624_1 N/A - - 3.1.4 CT_AFC_SP_AP_AFCDRSA31_Channel_320MHz_10714_1 N/A - AFC capability - Inquired Frequency & Channel Test Group: Inquired Frequency and Channel - Always 3.1 3.1.4 CT_AFC_SP_AP_AFCDRSA31_FrequencyChannel_20MHz_10625_1 PASS - 3.1 3.1.4 CT_AFC_SP_AP_AFCDRSA31_FrequencyChannel_40MHz_10626_1 PASS - 3.1 3.1.4 CT_AFC_SP_AP_AFCDRSA31_FrequencyChannel_80MHz_10627_1 PASS - 3.1 3.1.4 CT_AFC_SP_AP_AFCDRSA31_FrequencyChannel_160MHz_10628_1 PASS - 3.2 3.2.4 CT_AFC_SP_AP_AFCDUSA32_FrequencyChannel_10629_1 PASS - 3.3 3.3.4 CT_AFC_SP_AP_AFCDSAU33_FrequencyChannel_10630_1 PASS - 3.4 3.4.4 CT_AFC_SP_AP_AFCDUAU34_FrequencyChannel_10631_1 PASS - 3.1 3.1.4 CT_AFC_SP_AP_AFCDRS…

Text truncated - open the document above for the full version.

DUT Spectrum Inquiry Request/Response Logs_EUT 3_Radio 1 Appendix B.5 Sporton International Inc. Hsinchu Laboratory Page No. : 165 of 174 "globalOperatingClass": 132, "maxEirp": [ 30.2, 32.2, 25.9, 26.8, 26.0, 25.2, 27.7, 25.5 ] }, { "channelCfi": [ 7, 23, 39, 55 ], "globalOperatingClass": 133, "maxEirp": [ 33.2, 28.9, 28.2, 28.5 ] }, { "channelCfi": [ 15, 47 ], "globalOperatingClass": 134, "maxEirp": [ 31.9, 31.2 ] Report No. : F34O0708-01 DUT Spectrum Inquiry Request/Response Logs_EUT 3_Radio 1 Appendix B.5 Sporton International Inc. Hsinchu Laboratory Page No. : 166 of 174 }, { "channelCfi": [ 31 ], "globalOperatingClass": 137, "maxEirp": [ 34.3 ] } ], "requestId": "04cdc020d953", "availabilityExpireTime": "2025-09-25T14:32:19Z", "rulesetId": "US_47_CFR_PART_15_SUBPART_E" } ], "version": "1.4" } ########################### 2025-09-24T14:37:31Z ########################### { "headers": { "Host": "testserver.wfatestorg.org", "User-Agent": "Go-http-client/1.1", "Accept": "*/*", "Content-Type": "application/json", "Accept-Encoding": "gzip", "X-Forwarded-For": "54.215.237.20", "X-Forwarded-Host": "testserver.wfatestorg.org", "X-Forwarded-Server": "testserver.wfatestorg.org", "Content-Length": "727", "Connection": "Keep-Alive" }, "body": { "version": "1.4", "availableSpectrumInquiryRequests": [ { Report No. : F34O0708-01 DUT Spectrum Inquiry Request/Response Logs_EUT 3_Radio 1 Appendix B.5 Sporton International Inc. Hsinchu Laboratory Page No. : 167 of 174 "requestId": "04cdc020d953", "deviceDescriptor": { "serialNumber": "04cdc020d953", "certificationId": [ { "id": "2AHBN-AP47", "rulesetId": "US_47_CFR_PART_15_SUBPART_E" } ] }, "location": { "elevation": { "height": 9.699999809265137, "heightType": "AGL", "verticalUncertainty": 0 }, "ellipse": { "center": { "longitude": 121.01973724365234, "latitude": 24.84480571746826 }, "majorAxis": 0, "minorAxis": 0, "orientation": 45 }, "indoorDeployment": 1 }, "inquiredFrequencyRange": [ { "lowFrequency": 5925, "highFrequency": 7115 } ], "inquiredChannels": [ { "globalOperatingClass": 131 }, Report No. : F34O0708-01 DUT Spectrum Inquiry Request/Response Logs_EUT 3_Radio 1 Appendix B.5 Sporton International Inc. Hsinchu Laboratory Page No. : 168 of 174 { "globalOperatingClass": 132 }, { "globalOperatingClass": 133 }, { "globalOperatingClass": 134 }, { "globalOperatingClass": 136 }, { "globalOperatingClass": 137 } ] } ] } } ########################### 2025-09-24T14:37:31Z ########################### { "availableSpectrumInquiryResponses": [ { "response": { "responseCode": 0, "shortDescription": "SUCCESS" }, "availableFrequencyInfo": [ { "frequencyRange": { "highFrequency": 6125, "lowFrequency": 6105 }, "maxPsd": 3.5 }, Report No. : F34O0708-01 DUT Spectrum Inquiry Request/Response Logs_EUT 3_Radio 1 Appendix B.5 Sporton International Inc. Hsinchu Laboratory Page No. : 169 of 174 { "frequencyRange": { "highFrequency": 6145, "lowFrequency": 6125 }, "maxPsd": 5.2 }, { "frequencyRange": { "highFrequency": 6165, "lowFrequency": 6145 }, "maxPsd": 6.6 }, { "frequencyRange": { "highFrequency": 6185, "lowFrequency": 6165 }, "maxPsd": 5.7 }, { "frequencyRange": { "highFrequency": 6205, "lowFrequency": 6185 }, "maxPsd": 9.6 }, { "frequencyRange": { "highFrequency": 6225, "lowFrequency": 6205 }, "maxPsd": 12.8 }, { "frequencyRange": { Report No. : F34O0708-01 DUT Spectrum Inquiry Request/Response Logs_EUT 3_Radio 1 Appendix B.5 Sporton International Inc. Hsinchu Laboratory Page No. : 170 of 174 "highFrequency": 6245, "lowFrequency": 6225 }, "maxPsd": 2.5 }, { "frequencyRange": { "highFrequency": 6265, "lowFrequency": 6245 }, "maxPsd": 8.1 }, { "frequencyRange": { "highFrequency": 6285, "lowFrequency": 6265 }, "maxPsd": 2.6 }, { "frequencyRange": { "highFrequency": 6305, "lowFrequency": 6285 }, "maxPsd": -1.6 }, { "frequencyRange": { "highFrequency": 6325, "lowFrequency": 6305 }, "maxPsd": 8.9 }, { "frequencyRange": { "highFrequency": 6345, "lowFrequency": 6325 Report No. : F34O0708-01 DUT Spectrum Inquiry Request/Response Logs_EUT 3_Radio 1 Appendix B.5 Sporton International Inc. Hsinchu Laboratory Page No. : 171 of 174 }, "maxPsd": 4.3 }, { "frequencyRange": { "highFrequency": 6365, "lowFrequency": 6345 }, "maxPsd": 4.9 }, { "frequencyRange": { "highFrequency": 6385, "lowFrequency": 6365 }, "maxPsd": 11.1 }, { "frequencyRange": { "highFrequency": 6405, "lowFrequency": 6385 }, "maxPsd": -0.7 }, { "frequencyRange": { "highFrequency": 6425, "lowFrequency": 6405 }, "maxPsd": 9.2 } ], "availableChannelInfo": [ { "channelCfi": [ 33, 37, Report No. : F34O0708-01 DUT Spectrum Inquiry Request/Response Logs_EUT 3_Radio 1 Appendix B.5 Sporton International Inc. Hsinchu Laboratory Page No. : 172 of 174 41, 45, 49, 53, 57, 61, 65, 69, 73, 77, 81, 85, 89, 93 ], "globalOperatingClass": 131, "maxEirp": [ 16.5, 18.2, 19.6, 18.7, 22.6, 25.8, 15.5, 21.1, 15.6, 11.4, 21.9, 17.3, 17.9, 24.1, 12.3, 22.2 ] }, { "channelCfi": [ Report No. : F34O0708-01 DUT Spectrum Inquiry Request/Response Logs_EUT 3_Radio 1 Appendix B.5 Sporton International Inc. Hsinchu Laboratory Page No. : 173 of 174 35, 43, 51, 59, 67, 75, 83, 91 ], "globalOperatingClass": 132, "maxEirp": [ 19.5, 21.7, 25.6, 18.5, 14.4, 20.3, 20.9, 15.3 ] }, { "channelCfi": [ 39, 55, 71, 87 ], "globalOperatingClass": 133, "maxEirp": [ 22.5, 21.5, 17.4, 18.3 ] }, { Report No. : F34O0708-01 DUT Spectrum Inquiry Request/Response Logs_EUT 3_Radio 1 Appendix B.5 Sporton International Inc. Hsinchu Laboratory Page No. : 174 of 174 "channelCfi": [ 47, 79 ], "globalOperatingClass": 134, "maxEirp": [ 24.5, 20.4 ] }, { "channelCfi": [ 63 ], "globalOperatingClass": 137, "maxEirp": [ 23.5 ] } ], "requestId": "04cdc020d953", "availabilityExpireTime": "2025-09-25T14:37:31Z", "rulesetId": "US_47_CFR_PART_15_SUBPART_E" } ], "version": "1.4" } Report No. : F34O0708-01 DUT Spectrum Inquiry Request/Response Logs_EUT 3_Radio 3 Appendix B.6 Sporton International Inc. Hsinchu Laboratory Page No. : 1 of 151 AFC capability - Inquired Frequency & Channel CT_AF…

Text truncated - open the document above for the full version.

Report No. : AP4O0708 Antenna Composite Gain Test Report Sporton International Inc. Hsinchu Laboratory Page No. : 1 of 29 TEL : 886-3-656-9065 Issued Date : Feb. 07, 2025 FAX : 886-3-656-9085 Report Version : 01 Report Template No.: CB-H1_3 Ver1.0 Antenna Composite Gain Test Report FCC ID 2AHBN-AP47 Equipment Wi-Fi 7 Wireless Access Point Brand Name Juniper Model Name AP47, AP47D Applicant Juniper Networks, Inc. 1133 Innovation Way Sunnyvale, California 94089 USA Manufacturer Juniper Networks, Inc. 1133 Innovation Way Sunnyvale, California 94089 USA Standard KDB662911 D03 v01 Sample Received Oct. 15, 2024 Start Test Date Oct. 15, 2024 Final Test Date Oct. 18, 2024 ___________________________________________ Approved by: Sam Chen Sporton International Inc. Hsinchu Laboratory No.8, Ln. 724, Bo’ai St., Zhubei City, Hsinchu County 302010, Taiwan (R.O.C.) Report No. : AP4O0708 Antenna Composite Gain Test Report Sporton International Inc. Hsinchu Laboratory Page No. : 2 of 29 TEL : 886-3-656-9065 Issued Date : Feb. 07, 2025 FAX : 886-3-656-9085 Report Version : 01 Report Template No.: CB-H1_3 Ver1.0 Table of Contents History of this test report ................................................................................................................................. 3 1. Operation Mode and Antenna Information ........................................................................................ 4 2. Table for Multiple Listing ..................................................................................................................... 6 3. Table for Radio Function ..................................................................................................................... 6 4. Test Frequency ..................................................................................................................................... 7 5. Testing Location ................................................................................................................................... 7 6. Test Facility and Configuration ........................................................................................................... 8 7. Reference Calibration .......................................................................................................................... 9 8. Test Method ........................................................................................................................................ 10 9. Measured Values and Calculation of Maximum Gain Positions .................................................... 11 10. Summary of Test Result .................................................................................................................... 19 11. Test Setup ........................................................................................................................................... 27 12. Test Equipment and Calibration Data .............................................................................................. 28 13. Test Results ........................................................................................................................................ 29 Report No. : AP4O0708 Antenna Composite Gain Test Report Sporton International Inc. Hsinchu Laboratory Page No. : 3 of 29 TEL : 886-3-656-9065 Issued Date : Feb. 07, 2025 FAX : 886-3-656-9085 Report Version : 01 Report Template No.: CB-H1_3 Ver1.0 History of this test report Report No. Version Description Issued Date AP4O0708 01 Initial issue of report Feb. 07, 2025 Report No. : AP4O0708 Antenna Composite Gain Test Report Sporton International Inc. Hsinchu Laboratory Page No. : 4 of 29 TEL : 886-3-656-9065 Issued Date : Feb. 07, 2025 FAX : 886-3-656-9085 Report Version : 01 Report Template No.: CB-H1_3 Ver1.0 1. Operation Mode and Antenna Information For EUT 1: Antenna Position Ant. RF Port Brand Name Model Name Ant. Type Connector Modes of Operation 2G5G6GAnt1 1 2 Juniper AP47 PIFA IPEX 2.4GHz, 5GHz, 6GHz 2G5G6GAnt2 2 1 Juniper AP47 PIFA IPEX 2G5G6GAnt3 3 3 Juniper AP47 PIFA IPEX 2G5G6GAnt4 4 4 Juniper AP47 PIFA IPEX 5GAnt1 5 2 Juniper AP47 Alford loop IPEX 5GHz 5GAnt2 6 1 Juniper AP47 Alford loop IPEX 5GAnt3 7 3 Juniper AP47 Alford loop IPEX 5GAnt4 8 4 Juniper AP47 Alford loop IPEX 6GAnt1 9 2 Juniper AP47 PIFA IPEX 6GHz 6GAnt2 10 1 Juniper AP47 PIFA IPEX 6GAnt3 11 3 Juniper AP47 PIFA IPEX 6GAnt4 12 4 Juniper AP47 PIFA IPEX ScanAnt1 13 2 Juniper AP47 PIFA IPEX 2.4GHz, 5GHz, 6GHz ScanAnt2 14 1 Juniper AP47 PIFA IPEX Note: For Radio 1: 6GHz Operation Mode (4TX/4RX) 6GAnt1~4 can be used as transmitting/receiving antenna. 6GAnt1~4 could transmit/receive simultaneously. For Radio 2: 5GHz Operation Mode (4TX/4RX) 5GAnt1~4 can be used as transmitting/receiving antenna. 5GAnt1~4 could transmit/receive simultaneously. For Radio 3: 2.4GHz, 5GHz and 6GHz Operation Mode (4TX/4RX) 2G5G6GAnt1~4 can be used as transmitting/receiving antenna. 2G5G6GAnt1~4 could transmit/receive simultaneously. For Radio 4: 2.4GHz, 5GHz and 6GHz Operation Mode (2TX/2RX) ScanAnt1~2 can be used as transmitting/receiving antenna. ScanAnt1~2 could transmit/receive simultaneously. Report No. : AP4O0708 Antenna Composite Gain Test Report Sporton International Inc. Hsinchu Laboratory Page No. : 5 of 29 TEL : 886-3-656-9065 Issued Date : Feb. 07, 2025 FAX : 886-3-656-9085 Report Version : 01 Report Template No.: CB-H1_3 Ver1.0 For EUT 2: Antenna Position Ant. RF Port Brand Name Model Name Ant. Type Connector Modes of Operation 2G5G6GAnt1 1 2 Juniper AP47D Dipole IPEX 2.4GHz, 5GHz, 6GHz 2G5G6Gant2 2 1 Juniper AP47D Dipole IPEX 2G5G6Gant3 3 3 Juniper AP47D Dipole IPEX 2G5G6Gant4 4 4 Juniper AP47D Dipole IPEX 5GAnt1 5 2 Juniper AP47D Patch IPEX 5GHz 5GAnt2 6 1 Juniper AP47D Patch IPEX 5GAnt3 7 3 Juniper AP47D Patch IPEX 5GAnt4 8 4 Juniper AP47D Patch IPEX 6GAnt1 9 2 Juniper AP47D Patch IPEX 6GHz 6GAnt2 10 1 Juniper AP47D Patch IPEX 6GAnt3 11 3 Juniper AP47D Patch IPEX 6GAnt4 12 4 Juniper AP47D Patc…

Text truncated - open the document above for the full version.

Radiated Composite Gain Data_Radio 2 5GHz for EUT 1 Appendix B Sporton International Inc. Hsinchu Laboratory Page No. : 11 of 14 Report No.: : AP4O0708 Θ(67.5°) -17.95/-14.28 -15.47/-16.49 -17.92/-17.59 -17.76/-16.22 -18.22/-14.11 -16.02/-17.86 -16.99/-15.02 -16.73/-14.86 -11.3/-8.47 -15.16/-13.2 -13.45/-18.75 -11.9/-8.66 -10.74/-10.45 -11.77/-13.64 -11.39/-11.79 -16.55/-17.18 -18.73/-14.49 -18.61/-19.22 -17.59/-18.42 -19.32/-16.09 -18.42/-18.14 -18.33/-18.98 -14.99/-16.8 -18.25/-17.74 Θ(75°) -18.25/-19.34 -17.84/-18.34 -18.02/-17.84 -17.91/-16.4 -17.99/-14.73 -18.72/-18.59 -18.67/-16.21 -18.76/-18.2 -13.49/-10.85 -13.5/-16.17 -10.34/-15.49 -15.69/-10.78 -15.32/-10.57 -12.74/-18.61 -15.5/-13.33 -14.46/-18.57 -18.38/-17.07 -19.3/-18.29 -17.65/-19.22 -18.05/-18.92 -18.43/-18.38 -18.59/-18.71 -16.41/-15.92 -15.94/-17.88 Θ(82.5°) -18.79/-17.67 -18.01/-18.82 -18.54/-18.71 -18.5/-18.97 -19.18/-16.12 -19.13/-17.55 -17.49/-18 -17.87/-15.86 -14.77/-15.17 -13.48/-17.07 -12.27/-18.82 -17.85/-14.67 -13.71/-13.89 -17.4/-17.5 -15.63/-14.7 -15.99/-18.82 -18.55/-17.53 -18.82/-17.94 -16.45/-18.34 -18.77/-17.66 -18.92/-18.39 -18.16/-17.97 -17.68/-17.73 -16.93/-17.91 Θ(90°) -19.31/-18.57 -19.46/-18.09 -19.01/-17.9 -19.1/-18.7 -17.54/-16.94 -19.63/-17.14 -17.27/-18 -18.63/-16.16 -16.62/-17.77 -16.04/-18.82 -17.67/-19.24 -19.09/-17.7 -15.25/-16.14 -15.65/-18.43 -18.72/-19.06 -17.8/-18.63 -17.71/-18.01 -17.67/-19.28 -18.29/-19.37 -18.74/-18.71 -18.17/-18.73 -18.05/-19.03 -18.38/-19.24 -19.18/-18.59 Θ(97.5°) -18.9/-18.03 -17.76/-18.28 -17.66/-18.37 -19.35/-18.39 -18.06/-19.02 -17.89/-18.28 -18.41/-19.05 -18.28/-17.99 -17.76/-17.89 -19.17/-18.55 -18.84/-19.24 -18.52/-17.32 -18.62/-17.13 -18.56/-18.73 -17.46/-18.23 -17.79/-19.02 -18.68/-18.49 -17.44/-18.9 -19.22/-19.49 -19.31/-18.19 -18.09/-17.88 -18.04/-18.69 -18.01/-18.72 -18.91/-17.44 Θ(105°) -18.95/-18.19 -18.92/-18.95 -19.08/-18.22 -18.49/-18.9 -19.22/-17.32 -17.42/-19.01 -18.09/-17.15 -19.29/-18.89 -19.36/-17.09 -19.09/-18.82 -18.6/-18.89 -19/-17.96 -18.15/-14.76 -18.84/-18.57 -18.14/-17.79 -17.87/-18.38 -18.01/-18.95 -17.47/-19.02 -18.44/-19.08 -17.9/-19.02 -17.69/-18.97 -18.42/-18.69 -18.86/-17.49 -18.6/-19.21 Θ(112.5°) -19.09/-18.3 -19.14/-18.35 -17.25/-18.59 -18.13/-17.59 -18.02/-18.25 -18.52/-18.87 -18.47/-18.93 -18.88/-18.23 -19.05/-19.39 -17.84/-18.42 -18.68/-18.72 -17.97/-19.03 -17.89/-17.78 -18.12/-17.31 -18.15/-17.57 -17.98/-17.32 -17.84/-18.77 -19/-18.16 -18/-18.58 -18.44/-17.84 -18.41/-18 -17.76/-18.61 -18.15/-19.02 -17.68/-19.14 Θ(120°) -17.92/-18.94 -18.4/-18.72 -18.1/-18.32 -18.55/-18.02 -18.48/-18.29 -18.94/-18.89 -18.45/-17.83 -18.61/-17.93 -18.96/-18.79 -19.14/-17.96 -17.55/-16.31 -19/-18.7 -18.2/-18.56 -16/-17.41 -17.65/-18.94 -18.86/-18.77 -18.25/-18.05 -17.5/-19.1 -18.14/-17.3 -19.03/-18.45 -18.06/-18.31 -18.54/-17.3 -18.15/-18.38 -19.11/-18.33 Θ(127.5°) -18.32/-18.49 -18.4/-18.78 -17.68/-18.12 -17.85/-19.19 -18.22/-19.3 -18.13/-18.91 -17.5/-18 -18.34/-18.02 -18.36/-18.52 -18.07/-18.65 -18.45/-18.84 -18.03/-18.04 -19.74/-14.4 -17.17/-18.17 -18.9/-18.93 -18.43/-17.27 -18.64/-18.03 -18.54/-18.4 -17.5/-17.72 -19.26/-18.55 -18.77/-19.71 -18.5/-18.92 -18.32/-18.7 -18.79/-18.56 Θ(135°) -18.07/-18.65 -19.06/-19.24 -18/-18.94 -18.46/-18.19 -18.44/-18.88 -19.19/-18.52 -17.77/-18.19 -19.07/-18.52 -17.56/-15.55 -18.49/-18.86 -18.99/-17.95 -18.74/-19.33 -18.39/-19.31 -18.74/-18.2 -18.94/-18.39 -17.92/-18.19 -18.08/-18.96 -17.91/-18.93 -18.64/-18.7 -18.81/-17.84 -18.27/-18.99 -18.59/-18.21 -18.54/-17.52 -18.94/-17.26 Θ(142.5°) -18.08/-17.06 -18.27/-18.37 -18.69/-17.08 -19.07/-18.25 -19.01/-18 -18.01/-17.94 -18.93/-18.9 -17.86/-17.06 -17.54/-18.63 -18.13/-18.28 -18.42/-18.34 -18.11/-17.96 -16.86/-19.07 -18.66/-18.29 -18.38/-18.9 -19.04/-18.19 -18.86/-18.12 -17.12/-19.04 -19.04/-18.35 -18.47/-18.97 -19.29/-17.71 -17.94/-18.23 -18.83/-18.38 -18.74/-17.78 Θ(150°) -18.93/-17.68 -18.14/-18.59 -17.43/-18.07 -18.62/-18.34 -17.84/-18.93 -18.29/-19 -18.66/-17.73 -17.82/-18.34 -18.02/-18.55 -19/-17.4 -17.98/-19.18 -17.55/-18.89 -18.81/-17.49 -18.5/-18.92 -17.74/-17.65 -18.52/-17.82 -17.9/-18.16 -18.85/-19.31 -19.27/-17.82 -18.1/-18.67 -17.34/-18.63 -17.47/-18.29 -18.31/-18.82 -18.15/-18.66 Θ(157.5°) -18.36/-17.56 -18.6/-18.46 -19.1/-16.91 -15.96/-18.39 -18.52/-17.81 -19.43/-18.32 -18.52/-18.36 -18.8/-17.67 -18.29/-17.34 -18.72/-17.39 -18.34/-19.7 -18.6/-17.57 -19.17/-18.7 -17.24/-18.18 -17.67/-17.93 -17.59/-18.5 -18.2/-18.58 -19.23/-18.1 -18.85/-18.53 -18.23/-19.2 -17.23/-18.14 -18.4/-15.66 -17.33/-19.09 -17.93/-17.73 Θ(165°) -17.46/-18.53 -17.13/-18.18 -18.42/-19.05 -18.26/-17.99 -17.82/-17.72 -17.95/-19.11 -18.89/-18.38 -17.94/-18.26 -18.21/-18.94 -18.83/-18.63 -17.36/-18.23 -18.79/-15.6 -12.87/-12.84 -14.57/-15.37 -16.82/-18.48 -18.58/-19.05 -17.8/-18.92 -17.41/-19.16 -17.51/-19.23 -18.03/-17.64 -18.9/-18.68 -18.86/-18.77 -17.2/-15.09 -13.1/-13.54 Θ(172.5°) -18.62/-17.78 -18.25/-17.32 -19.27/-17.89 -19.35/-18.03 -17.69/-18.59 -18.09/-18.11 -19.04/-17.48 -18.17/-18.49 -17.23/-19.09 -18.6/-17.76 -18.39/-18.02 -17.1/-16.38 -16.19/-15.68 -16.34/-16.18 -16.62/-18.4 -18.9/-19 -19.17/-17.98 -18.85/-18.93 -18.55/-17.64 -19.12/-18.03 -17.76/-18.05 -18.72/-19.41 -18.12/-16.6 -16.79/-17.93 Θ(180°) -15.33/-14.91 -14.46/-15.45 -17.66/-19.38 -18.22/-17.5 -18.65/-19.02 -18.72/-19.03 -18.76/-19.17 -17.84/-19.22 -17.64/-16.51 -16.99/-17.74 -18.25/-18.22 -18.69/-18.16 -17.42/-16.79 -16.6/-17.24 -18.55/-18.35 -18.11/-18.02 -18.88/-18.96 -18.06/-17.42 -18.33/-18.69 -18.96/-18.94 -19.5/-19.04 -19.39/-18.03 -18.69/-17.97 -18.18/-17.41 Freq(Hz) 5.785G/Pol. Phi/Ant. 3 -/- -/- -/- -/- -/- -/- -/- -/- -/- -/- -/- -/- -/- -/- -/- -/- -/- -/- -/- -/- -/- -/- Gain Φ(0°)/Φ(7.5°) Φ(15°)/Φ(22.5°) Φ(30°)/Φ(37.5°) Φ(45°)/Φ(52.5°) Φ(60°)/Φ(67.5°) Φ(75°)/Φ(82.5°) Φ(90°)/Φ(97.5°) Φ(105°)/Φ(112.5°) Φ(120°)/Φ(127.5°) Φ(135°)/Φ(142.5°) Φ(150°)/Φ(157.5°) Φ(165°)/Φ(172.5°) Φ(180°)/Φ(187.5°) Φ(195°)/Φ(202.5°) Φ(210°)/Φ(217.5°) Φ(225°)/Φ(232.5°) Φ(240°)/Φ(247.5°) Φ(255°)/Φ(262.5°) Φ(270°)/Φ(277.5°) …
