© 20 2 4 AVer Information Inc. All rights reserved. P/N: 300AGA20-EPH MD720UIS All-in-One PTZ Camera Quick Start Guide Package Contents Camera Power Adapter & Power Cord Remote Control Cable Fixing Plate Cable Tie (x6) M2 x 4mm Screw (x2) Quick Start Guide Optional Accessories Ceiling Mount Bracket (x2) Wall Mount Bracket *For detail on optional accessories, consult your local dealer. User Manual and Software: www.aver.com/download/MD720UIS Warranty Policy: communication.aver.com/warranty AVer Information Inc. offers a 3-year parts and labor warranty for the MD Series and a 1-year warranty for accessories. AVer Limited Warranty may vary in different countries. Please check with your local agents or resellers for details. Overview Front View 1. Privacy Indicator 2. Infrared Night Vision LED 3. Microphone Array 4. Voice Command Indicator 5. Status Indicator 6. IR Remote Control Sensor 7. Speaker Side View 8. USB 3.0 Type-A Port 9. USB 3.0 Type-C Port Back View 10. Kensington Lock 11. DC 12V Power Jack 12. USB 3.0 Type-C Port 13. HDMI Out 14. HDMI In 15. Audio In 16. Line Out 17. Wi-Fi Dongle 18. Ethernet Port 19. PoE++ Port LED Indicators Privacy Indicator Color Status Solid purple Monitoring No light Privacy mode / power off Voice Command Indicator Color Status Solid lake blue Standby Slow flashing lake blue Waiting to receive voice control Quick flashing lake blue Perform voice control Status Indicator Color Status Flashing orange Initializing Solid purple Normal Solid blue Standby Flashing blue Tracking ON Solid orange Privacy mode Flashing purple Firmware updating No light Power off Dimensions Connections Cable Fixing Plate Installation 1. Secure the cable fixing plate using the included M2 x 4mm screws. 2. Plug in the cables. 3. Secure the cables and the cable fixing plate with cable ties. Remote Control Model HB9265 Name Function 1. Power Power on or off. 2. Privacy Enter Privacy mode. The camera will turn 90 degrees downwards and microphone will be turned off. 3. Directional Pad Press the directional pad to make selections on the OSD menu. 4. OK Confirm the selection. 5. Home Press and hold for 2 seconds to go to the homepage. 6. Back Go to the previous page. 7. Menu Open Android system menu. 8. Pan-Tilt Control Press and hold for 2 seconds to switch the directional pad to pan and tilt controls. 9. Voice Control* Press to receive a voice command. 10. Volume +/- Adjust the volume. *The Voice Control function is now only available in the United States. FCC Compliance Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. FCC Radiation Exposure statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Warning: This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. Remote Control Battery Safety Information: - Store batteries in a cool and dry place. - Do not throw away used batteries in the trash. Properly dispose of used batteries through specially approved disposal methods. - Remove the batteries if they are not in use for long periods of time. Battery leakage and corrosion can damage the remote control. Dispose of batteries safely and through approved disposal methods. - Do not use old batteries with new batteries. - Do not mix and use different types of batteries: alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium). - Do not dispose of batteries in a fire. - Do not attempt to short-circuit the battery terminals. PSTI Statement of Compliance Please refer to the following website: https://www.aver.com/product-security-advisory PoE The PoE++ port is connected only to PoE networks without routing to the outside plant. COPYRIGHT © 2024 AVer Information Inc. All rights reserved. | July 5, 2024 The information contained in this documentation is subject to change without notice. Contact Information Headquarters AVer Information Inc. 8F, No.157, Da-An Rd. Tucheng Dist., New Taipei City Taiwan Tel: +886 (2) 2269 8535 USA Branch Office AVer Information Inc., Americas 44061 Nobel Drive, Fremont, CA 94538, USA Tel: +1 (408) 263 3828 Toll-free: +1 (877) 528 7824 Europe Branch Office AVer Information Europe B.V. Westblaak 134, 3012KM, Rotterdam, The Netherlands Tel: +31 (0) 10 7600 550 Japan Branch Office アバー・インフォメーション株式会社 〒160-0023 日本東京都新宿区西 新宿 3-2-26 立花新宿ビル 7 階 Tel: +81 (0) 3 5989 0290 お客様サポートセンター（固定電話 のみ…
