2AHJSEC-4Bluetooth MIDI Controller

www.hotoneaudio.com Bluetooth MIDI Controller 技术要求： 157g铜板纸，273*124mm，四色印刷，覆哑膜，二折页 Screen DisplayGetting Started The Bluetooth indicator (the dot shown above) will flash when Ampero Control is in Bluetooth Pair Mode (hold FS 2+3). PC CC PC CC This
indicates
a
PC
message
(PC
16)
has
been
sent This
indicates
a
CC
message
(CC
112)
has
been
sent MIDI PC CC PC CC PC CC PC CC Bluetooth
not
connected Bluetooth

connected Bluetooth PC CC PC CC This
indicates
unit
bank
change
(bank
00
to
bank
01) Bank Notes: 1. You can enter offline mode if no device is found. 2. Ampero Control can only be edited by one device at a time. To use other devices, tap “Settings” icon on lower right corner of the screen, find “Connection Status” and enter, then tap “Disconnect”. Connect another device when finished. 3. The default device name is Ampero Control. You can customize your device name if needed. 1. Turn on the Bluetooth switch on your mobile device, then turn on your Ampero Control and launch the app. 2. Login your account (optional). 3. Press and hold FS 2+3 on your Ampero Control to enable Bluetooth Pair Mode. A dot will flash on the bottom right corner on the screen of your unit to indicate pairing status on. 4. When your Ampero Control appears listed on the startup page, select and tap the “Connect To The Selected Device” button on the screen. If search failed, you can retry searching by manually tap “Search Again” button. 折起朝外 3-digit LED screen: Indicates unit info (bank number, MIDI messages, etc.). Please check Screen Display section for details. EXP/CTRL 1/2: 1/4” TRS inputs, for connecting external expression pedals/momentary footswitch controllers. Perfect for Hotone Ampero Press or Ampero Switch. A B MIDI IN: Standard 5-pin MIDI input jack, for receiving MIDI messages. 1 2 3 4 USB: USB 2.0 Type-B jack, for USB MIDI control. Ampero Control can be powered by the USB port. MIDI OUT/THRU: 5-pin MIDI output jack, for sending MIDI messages. Panel Programmable Footswitch (FS) 1-4: For sending MIDI messages depending on your needs. Use Ampero Control app for detailed settings. Tap FS 1+2: Bank down Tap FS 3+4: Bank up Hold FS 2+3: Enable Bluetooth Pair Mode Hold FS 4 while powering up: Enable Expression Pedal Calibration Mode The contents of this manual are subject to change without notice. Power Supply Connection: Power supply input (9-18V DC center negative). Specifications Compatible Exp Pedal Pot Resistance: Max. 10kΩ Power Requirement: 9-18V DC center negative or 5V DC (USB) Current Consumption: Max. 100mA Dimensions: 258.5mm (W)×55.5mm (D)×49mm (H) Weight: 440g 技术要求： 157g铜板纸，273*124mm，四色印刷，覆哑膜，二折页 Thank you for purchasing a Hotone product. Scan the QR code for the full manual and app download links. 感谢您购买Hotone产品，请扫描右侧二维码获取完整说明书及配套软件下载地址。 www.hotoneaudio.com/support We recommend you update the latest firmware/software for the best possible experience. 我们建议您及时升级到最新固件/软件以获得最佳的用戶体验。 FCC regulation warning (for USA) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna transmitter. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ·Reorient or relocate the receiving antenna. ·Increase the separation between the equipment and receiver. ·Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ·Consult the dealer or an experienced radio/TV technician for help. FCC ID:2AHJSEC-4 This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
