2AHN6-AUBE218True Wireless Stereo Earphones

INSTRUCTION MANUAL Product Overview 1. 2. 3. 4. 5. 6. 1. Indicator/Microphone 2. Touch Area 3. Silicone Ear-tips 4. Earphones Charging Contacts 5. Charging Case Indicator 6. USB-C Charging Port -1- Thank you for purchasing your new true wireless earbuds. W e recommend that you spend some time reading this instruction manual in order to fully understand all the operational features it oers. Read all the safety instructions carefully before use and keep this instruction manual for future reference. Safety Rules 1. Charge the earbuds and the charging case at least once every 6 months. 2. Do not store the product in extreme temperature (below 0 or above 45 3. Do not use chemicals or detergents to clean the product. 4. Do not drop or knock the product on hard surfaces. 5. Do not scrape the surface of product with sharp objects. 6. Do not try to take the product apart. Specification Battery capacity Bluetooth version V5.1 BT profiles support SPP/HFP/A2DP/AVCTP/HID 50mAh for each earbuds 400mAh for charging case Charging time Around 1.2 hour Playing time Around 5 hours Up to 20 hours with charging case Talk time 3-5 hours Earbuds weight 5g each Case weight 10g Power ON/OFF Power ON 1. Take the earbuds out of the charging case the earbuds will power on automatically. 2. Long press the left and right touch area of the earbuds for three seconds, the earbuds indicator light flashes red and blue, and the earbuds powered on. Power OFF 1. Put the earbuds into the charging case, the earbuds will power o automatically. 2. Long press the left and right touch area of the earbuds for eight seconds, the earbuds indicator light turn o, and the earbuds powered o. Pairing 1. When using PT-30 True Wireless Earbuds the first time. Take the earbuds out of the charging case, the earbuds indicator lights flash red and blue the “pairing mode” is on. 2. Turn on Bluetooth on your mobile device. 3. Search and select “PT-30”. 4. When successfully connected, the blue LEDs flash every 5 seconds. Remark: Earbuds power o when they stay out of range for over two minutes. Find Your Fit Choose the size of silicone ear-tips that you feel the most comfortable with. Wireless Earbuds Portable Charging Case Type-C Charging Cable User manual Ear-Tips x 4 (S/M/L) In the Box Charging 1. Fully charge both the earbuds and the charging case before the first use. 2. To prevent damage, use the provided USB-C cable. 3. Fully dry o the earbuds and the USB port before charging. 4. Charging takes around 1.2 hours. 5. When fully charged, all LEDs will stay on. Bluetooth range 10 m / 33 ft Frequency response 20 Hz - 20 kHz Multi Functions Pause/Play Previous Song Next Song Volume Down Volume Up Active Siri/Google Assitant Answer/End a call Refuse the call Single tap L/R Double tap R Double tap L Long press L Long press R Triple tap L/R Tap L/R Long press L/R -2- -3- -4- -5- -6- Factory reset 1. Ensure L&R disconnect to any device. (trun o the bluetooth device connected before) 2. Triple tap the touch area of the left and right earbud. 3. When hear the prompt tone, The earbuds is ready to pair with your device now. WARNING 1. Listening to earbuds at high volume levels, particularly over extended periods of time, may damage your hearing. 2. Supervise children when using equipment. This product is not a toy. 3. The small parts included with this product can be a choking hazard. This product is not intended for use by small children and should be kept away from children under 3 years of age. MADE IN CHINA True Wireless Earbuds Model NO.: HM-AU-BE-218 -7- EARBUDS Red LED No LED Charging Fully Charged CHARGING CASE Blue LED blinks Four Blue LED Charging Fully Charged PT-30 FCC Warning This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any inte rference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does ause harmful interferenceto radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: · Reorient or relocate the receiving antenna. · Increase the separation between the equipment and receiver. · Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. · Consult the dealer or an experienced radio/TV technician for help. Radiation Exposure Statement The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

Bytech NY Inc. Agent Authorization Company: Bytech NY Inc. Address: 2585 West 13th Street,Brooklyn NY 11223,NewYork,United States Product Name: True Wireless Stereo Earphones Trade Mark: iHome Model Number(s): HM-AU-BE-218 FCC ID: 2AHN6-AUBE218 We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2021-07-06 Name: Soli Mizrahi Title: Manager Company: Bytech NY Inc.

Bytech NY Inc. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2021-07-06 Subject; Request for Confidentiality FCC ID: 2AHN6-AUBE218 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Soli Mizrahi Title: Manager

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 4 External Photos of the EUT Fig.1 Fig.2 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 4 Fig.3 Fig.4 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 3 of 4 Fig.5 Fig.6 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 4 of 4 Fig.7 Fig.8

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 _____________________________________________________________________________________________________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 1 of 1 LABEL AND LOCATION (Size: L2.0cm x 0.5cm) Mater ial: Tagboard Glue: adhesive sticker Font color: Blue Label color: White Label Location True Wireless Stereo Earphones Model No.: HM-AU-BE-218 FCC ID: 2AHN6-AUBE218

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 4 Internal Photos of the EUT Fig.1 Fig.2 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 4 Fig.3 Fig.4 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 3 of 4 Fig.5 Fig.6 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 4 of 4 Fig.7 Fig.8 ANT

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6‐AUBE218 ________________________________________________________________________ ___ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 1 FCC RF Exposure Evaluation 1. Product Information FCC ID : 2AHN6‐AUBE218 Product name : True Wireless Stereo Earphones Test Model : HM‐AU‐BE‐218 Power Supply : Headset: Input: DC 5V, 43mA DC 3.7V by Li‐ion Battery(50mAh) Charging Case: Input: DC 5V, 500mA DC 3.7V By Li‐ion Battery(320mAh) Hardware Version : / Software Version : / Bluetooth : 2402‐2480MHz Channel Number : 79 channels for Bluetooth V5.1(DSS) Channel Spacing : 1MHz for Bluetooth V5.1(DSS) Modulation Type : GFSK , π/4‐DQPSK, 8‐DPSK for Bluetooth V5.1(DSS) Bluetooth Version : V5.1 Antenna Type : Internal Antenna Antenna Gain : 2dBi Exposure category : General population/uncontrolled environment EUT Type : Production Unit Device Type : Portable Device 2. Evaluation method and Limit According to KDB447498 D01 General RF Exposure Guidance v06 Section 4.3.1 Standalone SAR test exclusion considerations: “Unless specifically required by the published RF exposure KDB procedures, standalone 1‐g head or body and 10‐g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied. These test exclusion conditions are based on source‐based time‐averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune‐up tolerance, and the minimum test separation distance required for the exposure conditions.22 The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander (see 5) of section 4.1). To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, typically in the SAR measurement or SAR analysis report, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting is required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for the SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions; for example, handheld PTT two‐way radios, handsets, laptops & tablets etc.“ [(max. power of channel, including tune‐up tolerance, mW)/ (min. test separaƟon distance, mm)] · [√f (GHz)] ≤ 3.0 for 1‐g SAR and ≤ 7.5 for 10‐g extremity SAR, where: • f (GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6‐AUBE218 ________________________________________________________________________ ___ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 2 transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to f) in section 4.1 is applied to determine SAR test exclusion. When one of the following test exclusion conditions is satisfied for all combinations of simultaneous transmission configurations, further equipment approval is not required to incorporate transmitter modules in host devices that operate in the mixed mobile and portable host platform exposure conditions. The grantee is responsible for documenting this according to Class I permissive change requirements. Antennas that qualify for standalone SAR test exclusion must apply the estimated standalone SAR to determine simultaneous transmission test exclusion. a) The [∑ of (the highest measured or estimated SAR for each standalone antenna configuration, adjusted for maximum tune‐up tolerance) / 1.6 W/kg] + [∑ of MPE ratios] is ≤ 1.0. b)The SAR to peak location separation ratios of all simultaneously transmitting antenna pairs operating in portable device exposure conditions are all ≤ 0.04, and the [∑ of MPE ratios] is ≤ 1.0. 3. Refer Evaluation Method ANSI C95.1–1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. FCC KDB publication 447498 D01 General RF Exposure Guidance v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies. FCC CFR 47 part1 1.1310: Radiofrequency radiation exposure limits. FCC CFR 47 part2 2.1093: Radiofrequency radiation exposure evaluation: portable devices 4. Conducted Power Results <BT Classics> Mode Channel Frequency (MHz)Peak Conducted Output Power (dBm) GFSK 0 24026.759 39 24418.287 78 24806.673 π/4DQPSK 0 24025.594 39 24416.949 78 24805.406 8DPSK 0 24025.697 39 24416.930 78 24805.428 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6‐AUBE218 ________________________________________________________________________ ___ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 3 of 3 5. Manufacturing Tolerance <BT Classics> GFSK (Peak) Channel Channel 0Channel 39Channel 78 Target (dBm) 6.08.06.0 Tolerance ±(dB)1.01.01.0 π/4DQPSK (Peak) Cha…

Text truncated - open the document above for the full version.

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 Report No.: LCS210607107AEA Page 1 of 47 Appendix A RF Test Data for BT V5.0(DSS) (Conducted Measurement) Product Name: True Wireless Stereo Earphones Trade Mark: iHome Test Model: HM-AU-BE-218 Environmental Conditions Temperature: 21.5°C Relative Humidity: 52.7°C ATM Pressure: 100.0 kPa Test Engineer: Jay Li Supervised by: Li Huan A.1 Maxmum Conducted Peak Output Power Mode Channel. Maximum Peak Output Power [dBm]Limit [dBm] Verdict GFSK LCH 6.759 21 PASS MCH 8.287 21 PASS HCH 6.673 21 PASS π/4DQPSK LCH 5.594 21 PASS MCH 6.949 21 PASS HCH 5.406 21 PASS 8DPSK LCH 5.697 21 PASS MCH 6.930 21 PASS HCH 5.428 21 PASS SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 Report No.: LCS210607107AEA Page 2 of 47 Test Graphs GFSK/LCH GFSK/MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 Report No.: LCS210607107AEA Page 3 of 47 GFSK/HCH π/4DQPSK/LCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 Report No.: LCS210607107AEA Page 4 of 47 π/4DQPSK/MCH π/4DQPSK/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 Report No.: LCS210607107AEA Page 5 of 47 8DPSK/LCH 8DPSK/MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 Report No.: LCS210607107AEA Page 6 of 47 8DPSK/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 Report No.: LCS210607107AEA Page 7 of 47 A.2 20dB Bandwidth Mode Channel. 20dB Bandwidth [MHz] Limit [MHz] Verdict GFSK LCH 1.060 Not Specified PASS MCH 1.053 Not Specified PASS HCH 1.053 Not Specified PASS π/4DQPSK LCH 1.289 Not Specified PASS MCH 1.289 Not Specified PASS HCH 1.288 Not Specified PASS 8DPSK LCH 1.290 Not Specified PASS MCH 1.204 Not Specified PASS HCH 1.206 Not Specified PASS Test Graphs GFSK/LCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 Report No.: LCS210607107AEA Page 8 of 47 GFSK/MCH GFSK/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 Report No.: LCS210607107AEA Page 9 of 47 π/4DQPSK/LCH π/4DQPSK/MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 Report No.: LCS210607107AEA Page 10 of 47 π/4DQPSK/HCH 8DPSK/LCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 Report No.: LCS210607107AEA Page 11 of 47 8DPSK/MCH 8DPSK/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 Report No.: LCS210607107AEA Page 12 of 47 A.3 Carrier Frequency Separation Mode Channel. Carrier Frequency Separation [MHz] Limit [MHz] Verdict GFSK LCH 0.999 0.707 PASS MCH 1.178 0.707 PASS HCH 1.216 0.707 PASS π/4DQPSK LCH 1.146 0.859 PASS MCH 1.178 0.859 PASS HCH 1.250 0.859 PASS 8DPSK LCH 0.998 0.860 PASS MCH 1.074 0.860 PASS HCH 1.190 0.860 PASS Test Graphs GFSK/LCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 Report No.: LCS210607107AEA Page 13 of 47 GFSK/MCH GFSK/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 Report No.: LCS210607107AEA Page 14 of 47 π/4DQPSK/LCH π/4DQPSK/MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 Report No.: LCS210607107AEA Page 15 of 47 π/4DQPSK/HCH 8DPSK/LCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 Report No.: LCS210607107AEA Page 16 of 47 8DPSK/MCH 8DPSK/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 Report No.: LCS210607107AEA Page 17 of 47 A.4 Hopping Channel Number Mode Channel. Number of Hopping Channel [N]Limit [N] Verdict GFSK Hop 79 >=15 PASS π/4DQPSK Hop 79 >=15 PASS 8DPSK Hop 79 >=15 PASS Test Graphs GFSK/Hop π/4DQPSK/Hop SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 Report No.: LCS210607107AEA Page 18 of 47 8DPSK/Hop SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 Report No.: LCS210607107AEA Page 19 of 47 A.5 Dwell Time Mode Packet Channel Burst Width [ms/hop/ch] Total Hops[hop*ch] Dwell Time[s] Limit [s]Verdict GFSK DH5 LCH 3.09 106.7 0.33 0.4 PASS DH5 MCH 3.08 106.7 0.329 0.4 PASS DH5 HCH 3.08 106.7 0.329 0.4 PASS π/4DQPSK 2DH5 LCH 3.09 106.7 0.307 0.4 PASS 2DH5 MCH 3.08 106.7 0.307 0.4 PASS 2DH5 HCH 3.08 106.7 0.307 0.4 PASS 8DPSK 3DH5 LCH 3.09 106.7 0.308 0.4 PASS 3DH5 MCH 3.08 106.7 0.308 0.4 PASS 3DH5 HCH 3.08 106.7 0.308 0.4 PASS Test Graphs GFSK_DH5/LCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 Report No.: LCS210607107AEA Page 20 of 47 GFSK_DH5/MCH GFSK_DH5/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 Report No.: LCS210607107AEA Page 21 of 47 π/4DQPSK _2DH5/LCH π/4DQPSK _2DH5/MCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 Report No.: LCS210607107AEA Page 22 of 47 π/4DQPSK _2DH5/HCH 8DPSK _3DH5/LCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 Report No.: LCS210607107AEA Page 23 of 47 8DPSK _3DH5/MCH 8DPSK _3DH5/HCH SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 Report No.: LCS210607107AEA Page 24 of 47 A.6 RF Conducted Spurious Emissions Mode Channel Pref [dBm] Max. Level [dBm] Limit [dBm] Verdict GFSK LCH 6.083 -38.498 -13.917 PASS MCH 7.241 -37.744 -12.759 PASS HCH 5.949 -38.109 -14.051 PASS π/4DQPSK LCH 4.492 -37.224 -15.508 PASS MCH 5.207 -37.113 -14.793 PASS HCH 4.278 -37.851 -15.722 PASS 8DPSK LCH 4.348 -37.086 -15.652 PASS MCH 5.976 -37.956 -14.024 PASS HCH 4.495 -38.031 -15.505 PASS GFSK_LCH_Graphs Pref SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 Report No.: LCS210607107AEA Page 25 of 47 Puw SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 Report No.: LCS210607107AEA Page 26 of 47 GFSK_MCH_Graphs Pref Puw SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 Report No.: LCS210607107AEA Page 27 of 47 GFSK_HCH_Graphs Pref Puw SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 Report No.: LCS210607107AEA Page 28 of 47 π/4DQPSK_LCH_Graphs Pref Puw SHENZ…

Text truncated - open the document above for the full version.

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 Report No.: LCS210607107AEA This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 36 FCC TEST REPORT FOR Bytech NY Inc. True Wireless Stereo Earphones Test Model: HM-AU-BE-218 Prepared for : Bytech NY Inc. Address : 2585 West 13th Street, Brooklyn NY 11223, NewYork, United States Prepared by : Shenzhen LCS Compliance Testing Laboratory Ltd. Address : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel : (+86)755-82591330 Fax : (+86)755-82591332 Web : www.LCS-cert.com Mail : [email protected] Date of receipt of test sample : June 08, 2021 Number of tested samples : 2 Sample No. : 210607107A-1, 210607107A-2 Serial number : Prototype Date of Test : June 08, 2021 ~ June 21, 2021 Date of Report : June 23, 2021 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 Report No.: LCS210607107AEA This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 36 FCC TEST REPORT FCC CFR 47 PART 15 C (15.247) Report Reference No. ................. : LCS210607107AEA Date of Issue .................................. : June 23, 2021 Testing Laboratory Name ............ : Shenzhen LCS Compliance Testing Laboratory Ltd. Address .......................................... : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Testing Location/ Procedure .......... : Full application of Harmonised standards ■ Partial application of Harmonised standards □ Other standard testing method □ Applicant’s Name ......................... : Bytech NY Inc. Address .......................................... : 2585 West 13th Street, Brooklyn NY 11223, NewYork, United States Test Specification Standard ........................................ : FCC CFR 47 PART 15 C (15.247) Test Report Form No. .................... : LCSEMC-1.0 TRF Originator ............................... : Shenzhen LCS Compliance Testing Laboratory Ltd. Master TRF .................................... : Dated 2011-03 Shenzhen LCS Compliance Testing Laboratory Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen LCS Compliance Testing Laboratory Ltd. is acknowledged as copyright owner and source of the material. Shenzhen LCS Compliance Testing Laboratory Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test Item Description. ................. : True Wireless Stereo Earphones Trade Mark ..................................... : iHome Test Model ..................................... : HM-AU-BE-218 Ratings ........................................... : Headset: Input: DC 5V, 43mA DC 3.7V by Li-ion Battery(50mAh) Charging Case: Input: DC 5V, 500mA DC 3.7V By Li-ion Battery(320mAh) Result .......................................... : Positive Tested by: Compiled by: Approved by: Ray Yang/ Administrators Jin Wang/ Technique principal Gavin Liang / Manager SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 Report No.: LCS210607107AEA This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 3 of 36 FCC -- TEST REPORT Test Result Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Test Report No. : LCS210607107AEA June 23, 2021 Date of issue Test Model.............................. : HM-AU-BE-218 EUT......................................... : True Wireless Stereo Earphones Applicant............................... : Bytech NY Inc. Address................................... : 2585 West 13th Street, Brooklyn NY 11223, NewYork, United States Telephone............................... : / Fax.......................................... : / Manufacturer......................... : DONGGUAN RDT XUNTONG TECHNOLOGY CO.LTD Address................................... : 4th floor 2#, Ruifulai Industrial, Changan, Dongguan city, Guangdong province, China Telephone............................... : / Fax.......................................... : / Factory................................... : Bytech NY Inc. Address................................... : 2585 West 13th Street, Brooklyn NY 11223, NewYork, United States Telephone............................... : / Fax.......................................... : / SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 Report No.: LCS210607107AEA This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 4 of 36 Revision History Revision Issue Date Revisions Revised By 000 June 23, 2021 Initial Issue Gavin Liang SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 Report No.: LCS210607107AEA This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 5 of 36 TABLE OF CONTENTS Description Page 1.GENERAL INFORMATION ....................................................................................................... 6 1.1 Description of Device (EUT) ............................................................................................................ 6 1.2 Support equipment List ..................................................................................................................... 7 1.3 External I/O Cable .......................................................................................................................…

Text truncated - open the document above for the full version.

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 _______________________________________________________________________________________________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 2 Test Setup Photos of the EUT Test Setup Photo(s) of Radiated Emissions Measurement Fig. 1 Fig. 2 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AHN6-AUBE218 _______________________________________________________________________________________________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 2 Test Setup Photo(s) of Conducted Emissions Measurement Fig. 3
