2AHN6-AUBE245TWS earphone

G101F TWS earphone User Manual FCCID: 2AHN6-AUBE245 Warning Special Note: Before using the earphone for the first time, please put the earphone into the ordinary charging case once and then remove it. Only then can touch be effective. Please read the warnings below carefully. Store this manual with product packaging. The safety precaution manual reduce the risk of fire or injury when correctly complied to To reduce the risk of injury : Keep batteries out of reach of children. Do not heat, open, or dispose of battery pack in fire. Do not allow metal objects to touch the battery on the device. Do not expose battery pack to excessive heat. Do not use a high current charger, or the charging line will burn out. Please Charging with a DC 5V adapter (not included in the package). Paring 1: Auto Pairing Taking the earphones out of the charging case, and then the earphones will automatically turn on, sync together and enter pairing mode. 2: Syncing your earphones.. When earphones do not sync together or enter disconnected state during use. 1): Turn off both earphones and turn back on. 2): If that does not work, placing both earphones back into case, closing the charging case and then open the charging case again. 3): While earphones is out of the charging case. Press and hold both earphones for 3 seconds. This will force the earphones to turn off and on again and sync with each other. 3: Open up Bluetooth setting on your smart device and scan for XXXX. Operation 1: Power on/off . （长按3秒开机，长按5秒关机） 1.) Take the earphones out of the charging case, automatically turn on; Put the earphones back to the charging case, automatically turn off; 2.) Long press 3 seconds to turn on Long press 5 seconds to turn off. 2: Play/Pause music. （ 单击播放暂停） When listening to music. Tap left/right earphones once to play or pause the music. 3: Previous /Next Song （双击上下曲，左耳上一曲，右耳下一曲） When listening to music. Quick double tap left earphones to go to previous song. Quick double tap right earphones to go to next song. 4: Volume -/+ （三击加减音量. 左耳音量减，右耳音量加） Quick tap left earphones 3 times to decrease the volume. Quick tap right earphones 3 times to increase the volume. 5: Answer/Hang up （单击接挂） When there is an incoming call. Tap left or right earphones once to answer the call. Tap left or right earphones again to end the call. 6: Reject （长按2秒拒接） When there is an incoming call. Long press left or right earphones for 2 seconds to reject the call. 7: Voice assistant （长按左/右耳 2秒 开启语音助手） Long press left or right earphones for 2 seconds Charging Function Fully charge the case and earphones before using for the first time. 1: Charging the charging case 仓充电时，屏幕显示数字，满电后显示100%。 When the charging case is charging, the screen will show the capacity, when it is full, show 100% LR亮着表示耳机也在充，LR灭了表示耳机满了。 2:Earphone charging 耳机在仓里充电时，红灯亮。满电后熄灭。 When battery is low, each 5s flash once for left and right side red light at the same time,you will listen to a warning sign or tone. It will turn off when the earphones completely out of battery. (a) Place the earphones into the charging case. (b) red light on the earphones turn on when charging has begun. The light will turn off when charging is complete. This device has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This device generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this device does cause harmful interference to radio or television reception, which can be determined by turning the device off and on, the user is encouraged to try to correct the interference by one or more of the following measures: --Reorient or relocate the receiving antenna. --Increase the separation between the device and receiver. --Connect the device into an outlet on a circuit different from that to which the receiver is connected. --Consult the dealer or an experienced radio/TV technician for help Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation.

Bytech NY Inc. Covered Equipment Certification Attestation Letter 8/5/2024 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: 2AHN6-AUBE245 Bytech NY Inc. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. Bytech NY Inc. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Signed: Printed name: Soli Mizrahi Title: Company Name: Bytech NY Inc. Date: 8/5/2024

Bytech NY Inc. * the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. U.S. Agent Designation for Service of Process - Certification Attestation Letter 8/5/2024 TO: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 ATTN.: Reviewing Engineer FCC ID: 2AHN6-AUBE245 FRN of applicant: 0025388125 Per section 2.911(d)(7) of the FCC rules, S Bytech NY Inc. (“the applicant”) certifies that the equipment for which authorization is sought is designated to the following U.S. agent* for service of process: Company Name: Bytech NY Inc. FCC Registration Number (FRN): 0025388125 Physical U.S. Company Address: 2585 West 13th Street Brooklyn NY 11223 USA Contact Person: Soli Mizrahi Agent Email Address: [email protected] The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Agent Signed (if different from Applicant): Signed: Printed name: Soli Mizrahi Title: Click here to enter text. Company Name: Bytech NY Inc. Date: 8/5/2024 Signed: Printed name: Title: Click here to enter text. Company Name: Date:

Declaration TWS earphone Model Number: HM-AU-BE-245, XT-63, G101F FCC ID: 2AHN6-AUBE245 The device has left and right earphones, the left and right earphones are electrically identical. <Signature>： Name：Soli Mizrahi Title： Applicant Company：Bytech NY Inc.

August 05, 2024 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Shenzhen Timeway Testing Laboratories/ Zone C, 1st Floor, Zone C, 1st Floor, Block B, Jun Xiang Da Building, Zhongshan Park Road West, Tong Le Village, Nanshan District, Shenzhen, China (Name of Agent company name and address) to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with Bytech NY Inc./ 2585 West 13th Street,Brooklyn NY 11223, United States <Signature>： Name：Soli Mizrahi Title： Applicant Company：Bytech NY Inc.

August 05, 2024 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AHN6-AUBE245 Product Name: TWS earphone Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: • Schematics • Block diagram • Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature>： Name：Soli Mizrahi Title： Applicant Company：Bytech NY Inc.

Bytech NY Inc. Statement We Bytech NY Inc. Hereby Declare that The product TWS earphone, models no. HM-AU-BE-245, XT-63, G101F are all identical in interior structure, electrical circuits and components, and just the model names are different for the marketing requirement. Your assistance on this matter is highly appreciated. Yours sincerely, Signature: Name：Soli Mizrahi Title： Applicant Company：Bytech NY Inc.

charger base Left earphone Right earphone

FCC ID: 2AHN6-AUBE245

Label Location

Left earphone Right earphone

RF Exposure evaluation According to 447498 D04 Interim General RF Exposure Guidance v01 eirp = pt x gt = (EXd) 2 /30 where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, --- 10 ((dBuV/m)/20) /10 6 d = measurement distance in meters (m)---3m Sopt = (EXd) 2 /30 x gt Ant gain =-0.58dBi so Ant numeric gain= 0.875 Field strength =90.18dBμV/m @3m@2402MHz So Pt={ [10 (90.18/20) /10 6 x3] 2 /(30x0.875)}x1000 mW =0.357mW <2.72 mW Then SAR evaluation is not required

InvertedFAntennaSpecification Summary ITEMANTSPEC ModelName 2.4GANT Center Frequency HorizontalVertical 2400MHz2400MHz2500MHz2400MHz2400MHz2500MHz -1.26 -0.76-0.58 -5.25 -2.46-1.86 MAX.Gain -0.58dB PolarizationHorizontalandVertical AzimuthBeam Pattern Omni-directional Impedance 50Ohm AntennaLength 38.20mm AntennaPhoto&Length(mm) Horizontal:2400MHz2450MHz2500MHz Power(dBm) Max:0Min:-40Scale:5/div Frequency (MHz) Gain(dB) Max MinAvg 2400 -1.26174 -30.0801-7.18716 2450-0.765802-36.5604-7.48023 2500-0.585582 -22.0315 -6.59127 Vertical:2400MHz2450MHz2500MHz Power(dBm) Max:0Min:-30Scale:5/div Frequency (MHz) Gain(dB) Max MinAvg 2400-5.2537 -22.1424-12.4294 2450 -2.4652-24.5837 -10.4702 2500 -1.86120 -29.5214-9.20432 ANTTestLabs：AttestationofGlobalComplianceCo.,Ltd.

Report No.: TW2407209E Applicant: Bytech NY Inc. Product: TWS earphone Model No.: HM-AU-BE-245, XT-63, G101F Trademark: Bytech, iHome Test Standards: FCC Part 15.249 Test result: It is herewith confirmed and found to comply with the requirements set up by ANSI C63.10 & FCC Part 15 Subpart C, Paragraph 15.249 regulations for the evaluation of electromagnetic compatibility Approved By Terry Tang Manager Dated: July 31, 2024 Results appearing herein relate only to the sample tested The technical reports is issued errors and omissions exempt and is subject to withdrawal at SHENZHEN TIMEWAY TESTING LABORATORIES Zone C, 1st Floor, Block B, Jun Xiang Da Building, Zhongshan Park Road West, Tong Le Village, Nanshan District, Shenzhen, China Tel (755) 83448688, Fax (755) 83442996, E-Mail:[email protected] Report No.: TW2407209E Page 2 of 59 Date: 2024-07-31 The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the SHENZHEN TIMEWAY TESTING LABORATORIES. It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the SHENZHEN TIMEWAY TESTING LABORATORIES. to his customer. Supplier or others persons directly concerned. SHENZHEN TIMEWAY TESTING LABORATORIES. will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The SHENZHEN TIMEWAY TESTING LABORATORIES. reserves the rights to withdraw it and to adopt any other remedies which may be appropriate. Special Statement： FCC-Registration No.: 744189 The EMC Laboratory has been registered and fully described in a report filed with the (FCC) Federal Communications commission. The acceptance letter from the FCC is maintained in our files. Registration No.: 744189. Industry Canada (IC) —Registration No.:5205A The EMC Laboratory has been registered by Certification and Engineering Bureau of Industry Canada for radio equipment testing with Registration No.: 5205A. A2LA (Certification Number:5013.01) The EMC Laboratory has been accredited by the American Association for Laboratory Accreditation (A2LA). Certification Number:5013.01 CAB identifier: CN0033 Report No.: TW2407209E Page 3 of 59 Date: 2024-07-31 The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the SHENZHEN TIMEWAY TESTING LABORATORIES. It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the SHENZHEN TIMEWAY TESTING LABORATORIES. to his customer. Supplier or others persons directly concerned. SHENZHEN TIMEWAY TESTING LABORATORIES. will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The SHENZHEN TIMEWAY TESTING LABORATORIES. reserves the rights to withdraw it and to adopt any other remedies which may be appropriate. Test Report Conclusion Content 1.0 General Details................................................................................................ 4 1.1 Test Lab Details................................................................................................ 4 1.2 Applicant Details.............................................................................................. 4 1.3 Description of EUT .......................................................................................... 4 1.4 Submitted Sample............................................................................................. 4 1.5 Test Duration................................................................................................... 5 1.6 Test Uncertainty................................................................................................ 5 1.7 Test By......................................................................................................... 5 2.0 List of Measurement Equipment......................................................................... 6 3.0 Technical Details............................................................................................. 7 3.1 Summary of Test Results.................................................................................... 7 3.2 Test Standards................................................................................................. 7 4.0 EUT Modification........................................................................................... 7 5.0 Power Line Conducted Emission Test.................................................................. 8 5.1 Schematics of the Test....................................................................................... 8 5.2 Test Method and Test Procedure............................................................................ 8 5.3 Configuration of the EUT.................................................................................... 8 5.4 EUT Operating Condition................................................................................... 9 5.5 Conducted Emission Limit.................................................................................. 9 5.6 Test Result..................................................................................................... 9 6.0 Radiated Emission test..................................................................................... 12 6.1 Test Method and Test Procedure............................................................................ 12 6.2 Configuration of the EUT...........................…

Text truncated - open the document above for the full version.

Conducted Emission Test Setup: Radiated Emission Test Setup:
