2AHPN-BE2852Automotive Bluetooth radio transmitter

Multifunktions- Kopplungstaste LED-Anzeige PRODUKTÜBERSICHT Kopplung mit Bluetooth-Kopfhörern • Drücken Sie die Kopplungstaste am Sender, um ihn einzuschalten • Versetzen Sie den Kopfhörer in den aktiven Kopplungsmodus • Drücken Sie die Kopplungstaste am Sender, bis die LED-Anzeige abwechselnd rot und blau blinkt. Ca. 5 Sekunden Hinweis: Der Sender wechselt für die erste Kopplung automatisch in den aktiven Kopplungsmodus • Der Sender verbindet sich automatisch mit dem stärksten Bluetooth-Signal • Sobald die Bluetooth-Kopplung abgeschlossen ist, leuchtet die LED-Anzeige durchgehend blau Hinweis: Versuchen Sie nicht, mehrere Bluetooth- Geräte gleichzeitig zu verbinden. Wiederverbindung Der Sender verbindet sich automatisch mit dem stärksten Bluetooth-Signal. Es wird empfohlen, den Bluetooth-Sender vor dem Einschalten des Kopfhörers einzuschalten. Es wird davon abgeraten, denselben Kopfhörer mit mehreren Fahrzeugsendern zu koppeln. Kopplung mit weiteren Kopfhörern Der Sender kann mit bis zu acht verschiedenen Kopfhörern gekoppelt werden. Befolgen Sie die Bluetooth-Kopplungsschritte, um weitere Kopfhörer zu koppeln. Der aktive Kopplungsmodus kann durch 1-sekündiges Drücken der Kopplungstaste abgebrochen werden. Es wird davon abgeraten, denselben Kopfhörer mit mehreren Fahrzeugsendern zu koppeln. Modellbezeichnung: BTT55 Bluetooth-Sender Eingangsspannung: 12 V Gleichspannung Eingangsstrom: 1 A Frequenzgang: 10 Hz–20 kHz Belastbarkeitsgrenze: 60 mW Gewicht: 28 g Bluetooth-Version 5.0 Unterstützt: A2DP v1.3, aptX Bluetooth-Sendefrequenzbereich: 2402–2480 MHz Bluetooth-Übertragungsleistung: < 4 dBm Bluetooth-Sendemodulation: GFSK, π/4 DQPSK, 8DPSK Modulationstechnologie: BDR/EDR Übertragungsrate: Max. EDR bis zu 3 Mbit/s Anzahl der Kanäle: BT: 79 (0–78 K.) Antennentyp: PCB Die Bluetooth ® -Wortmarke und -Logos sind eingetragene Marken von Bluetooth SIG, Inc. und jegliche Nutzung dieser Marken durch HARMAN International Industries, Incorporated erfolgt in Lizenz. Andere Warenzeichen oder Handelsbezeichnungen gehören den jeweiligen Eigentümern. Modell: Harman BTT55 FCC ID: 2AHPN-BE2852 IC ID: 6434C-BE2852 Dieses Gerät erfüllt Abschnitt 15 der FCC- Bestimmungen und dem/den lizenzfreien RSS-Standard(s) von Industry Canada. Der Betrieb unterliegt den folgenden beiden Bedingungen: (1) Dieses Gerät darf keine funktechnischen Störungen verursachen; und (2) Dieses Gerät muss sämtliche Störungen aufnehmen können, darunter Störungen, die unerwünschte Funktionen des Geräts verursachen können Dieses digitale Gerät der Klasse B entspricht der kanadischen Richtlinie ICES-003. LED-AnzeigeVerbindungsstatus Durchgehend rot Keine Bluetooth- Verbindung Durchgehend blau Kopfhörer angeschlossen Abwechselnd rot und blau blinkend Aktiver Kopplungsmodus LED ausgeschaltet Sender ausgeschaltet KoppelingsknopLedlampje PRODUCTOVERZICHT Koppelen met Bluetooth-koptelefoons • Druk op de koppelingsknop op de zender om deze in te schakelen. • Zet de koptelefoon in de actieve pairingmodus. • Druk op de koppelingsknop op de zender totdat het led lampjeafwisselend rood en blauw knippert. Ongeveer 5 seconden. Opmerking: De zender gaat automatisch naar de actieve koppelingsmodus voor de eerste koppeling. • De zender maakt automatisch verbinding met het sterkste Bluetooth-signaal. • Zodra de Bluetooth-koppeling is voltooid, gaat het ledlampjecontinu blauw branden. Opmerking: Probeer niet om meerdere Bluetooth-apparaten tegelijkertijd te verbinden. Opnieuw aansluiten De zender maakt automatisch verbinding met het sterkste Bluetooth-signaal. Het wordt aanbevolen om de Bluetooth- zender AAN te zetten voordat u de koptelefoon inschakelt. Het wordt niet aanbevolen om dezelfde koptelefoon te koppelen aan meerdere voertuigzenders. Belangrijke informatie De zender maakt verbinding met het sterkste Bluetooth-signaal. Het wordt aanbevolen om de koptelefoons één voor één te koppelen. De zender ondersteunt geen afspeelfunctie voor audio, zoals PLAY, STOP, PAUZEREN, VOORUIT en ACHTERUIT SPOELEN. Het volume kan worden aangepast met de volumeknop op de koptelefoon. Modelnaam: BTT55 Bluetooth-zender Ingangsspanning: 12 V gelijkstroom Ingangsstroom 1 A Frequentierespons: 10 Hz -20 kHz Max. ingangsvermogen: 60 mW Gewicht: 28 g Bluetooth versie 5.0 Ondersteunt: A2DP v1.3, aptX Frequentiebereik Bluetooth-zender: 2402–2480MHz Bluetooth-zendervermogen: < 4 dBm Modulatie Bluetooth-zender: GFSK, π/4 DQPSK, 8DPSK Modulatietechnologie: BDR/EDR Overdrachtssnelheid: Maximaal EDR tot 3 Mbps Aantal kanalen: BT: 79 (0~78CH) Antennetype: Printplaat Het Bluetooth ® -woordmerk en de bijbehorende logo’s zijn gedeponeerde handelsmerken van Bluetooth SIG, Inc. en elk gebruik van dergelijke merken door HARMAN International Industries, Incorporated gebeurt onder licentie. Overige handelsmerken en handelsnamen zijn eigendom van de respectieve eigenaren. Model: Harman BTT55 FCC-ID: 2AHPN-BE2852 IC: 6434C-BE2852 Dit apparaat voldoet aan Deel 15 van de FCC-voorschriften en de RSS-norm(en) voor licentievrijstelling van Industry Canada. Bediening is gebonden aan de volgende twee voorwaarden: (1) dit apparaat mag geen schadelijke interferentie veroorzaken, en (2) dit apparaat moet elke ontvangen interferentie aanvaarden, waaronder interferentie die een ongewenste werking kan veroorzaken Dit digitale Klasse B-apparaat voldoet aan de Canadese norm ICES-003. LedlampjeVerbindingsstatus Ononderbroken rood Bluetoothaansluiting Ononderbroken blauw Koptelefoonaansluiting Afwisselend rood en blauw knipperend Actieve pairingmodus Led uit Zender uitgeschakeld Pulsante di accoppiamento Indicatore LED PANORAMICA DEL PRODOTTO Accoppiamento con cuffie Bluetooth • Premere il pulsante di accoppiamento sul trasmettitore per accenderlo • Mettere le cuffie in modalità di accoppiamento attivo • Premere il pulsante di accoppiamento sul trasmettitore finché la spia LED non lampeggia alternativamente con colore rosso e blu. Circa 5 secondi Nota: Il trasmettitore entra automaticamente in modalità di acco…

Text truncated - open the document above for the full version.

HARMAN 30001 Cabot Drive Novi, Ml 48377 USA \. + 1.248.785.2361 • + 1.248.994.2703 Agent's Authorization Letter � HARMAN �GCOMPANY 4-March-2020 I, an officer of Harman, do hereby authorize, until further notice, Bureau Veritas Consumer Products Services Inc., One Distribution Center Circle, #1, Littleton, MA 01460, to act on our behalf in dealings before the Federal Communications Commission with respect to all matters relating to equipment authorizations under 4 7 CFR. This authorization includes, but is not limited to, the signing of Form 731. I certify that no party (as defined in 47 CFR 1.2002) to this application, including myself, is subject to a denial of federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C., 853A. Certified By: 94--- Jason Rennon Sr. Manager, NA HW Validation & Cert. 4-March-2020

HARMAN 3000 I Cabot Drive Novi, Ml 48377 USA \. + 1.248.785.2361 W + 1.248.994.2703 04-March-2020 Subject: FCC Signature Authorization Dear Sirs/Madams, � HARMAN � I, Jason Rennon of Harman International Industries, Incorporated, headquartered 30001 Cabot Drive, Novi, Ml 48337 USA, with Grantee Code 2AHPN, as the approved grantee with the FCC, authorize the signature of Mark Bowman to be an approved signature. Best Regards, Jason Rennon Sr. Manager, NA HW Validation & Cert.

HARMAN 30001 Cabot Drive Novi, MI 48377 USA +1.248.785.2361 +1.248.994.2703 12-February-2021 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046-1609 Bureau Veritas Consumer Products Services Inc. One Distribution Center Circle, #1 Littleton, MA 02702 Re: Confidentiality Request Gentlemen: This letter is to comply with 47 CFR 0.457(d)(2) and 0.459 pertaining to confidential material. Harman International Industries, Incorporated, requests that the following documents regarding this submission for FCC ID: 2AHPN-BE2852 be kept confidential: 1.Block Diagram 2.Schematics 3.Circuit/Technical Description 4.Parts List/Bill of Materials 5.Operational Description The material above contains technical data, which would customarily be guarded from competitors. Sincerely, Mark Bowman Regulatory Compliance Engineer 12-February-2021

HARMAN 30001 Cabot Drive Novi, MI 48377 USA +1.248.785.2361 +1.248.994.2703 12-February-2021 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046-1609 Bureau Veritas Consumer Products Services Inc. One Distribution Center Circle, #1 Littleton, MA 02702 Re: Short Term Confidentiality Request Gentlemen: Pursuant to Public Notice DA 04-1705, Harman International Industries, Incorporated, requests SHORT- TERM CONFIDENTIALITY for the following information until 180 days after the grant date of equipment authorization in order to ensure sensitive business information remains confidential until marketing of the device. FCC IDs: 2AHPN-BE2852 1.External Photos 2.Internal Photos 3.Test Setup Photos 4.User’s Manual Sincerely, Mark Bowman Regulatory Compliance Engineer 12-February-2021

Model: BTT55 External Photos Harman International Industries, Inc. 30001 Cabot Drive Novi, MI 48377 U.S.A. FRONT VIEW Top View Top View Continued Bottom View Back View

序号 1 2 面材材质 面材厚度 3面材颜色 4 5 6 印刷颜色 胶层种类 胶层厚度 7 8 9 来料方式 黏贴位置零售盒，外箱 项目规格备注 永久性可移性强粘性 卷装片装 其它 其它中粘性低粘性 初期力 3±1 # GB/T 4852 GB/T 2792 GB/T 4851 1.4±0.5（kg/25mm） 8±2（hr/kg/20mm²） 粘着力 保持力 80g C2S+PP Matt 80g C2S+PP Matt 0.08+/-0.005mm A01 white 单黑印刷 0.01+/-0.002 mm Shunli 800800012822 Certification Label GS-6011 Eason Huang 21/3/2Shunli SHEN ZHEN GRANDSUN ELECTRONIC S CO.,LTD. 深圳市冠旭电子股份有限公司 1:1 Cutline 35mm 15mm R 208-210012 Harman Model: BTT55 FCC IC: 2AHPN-BE2852 IC ID: 6434C-BE2852 CMIIT ID: XXXXXXXXXXX Made in China 10 R-06 0145 10 R-06 0145 3mm 6mm 2mm 3mm R 208-210012 Harman Model: BTT55 FCC IC: 2AHPN-BE2852 IC ID: 6434C-BE2852 CMIIT ID: XXXXXXXXXXX Made in China 10 R-06 0145

Model: BTT55 Internal Photos Harman International Industries, Inc. 30001 Cabot Drive Novi, MI 48377 U.S.A. PCB Side 1 PCB Side 1 without Shield PCB Side 2 Disassembled View

Bureau Veritas Consumer Product Services Inc. is accredited by the American Association for Laboratory Accreditation for the specific scope of accreditation under Certificate Number 1627-01. This report may contain data which is not covered by the A2LA accreditation. ____________________________________________________________ Bureau Veritas Consumer Product Services Inc. One Distribution Center Circle, #1 • Littleton, MA • TEL (978) 486-8880 • FAX (978) page 1 of 73 Bureau Veritas Consumer Product Services Inc. Report No EV0141-3 Client Harman International Industries Inc. Mark Bowman Address 30001 Cabot Dr. Novi, MI 48377 Phone 1-248-254-7751 Items tested Automotive Bluetooth Transmitter BTT55 FCC ID 2AHPN-BE2852 IC 6434C-BE2852 Equipment Type Part 15 Spread Spectrum Transmitter FCC/IC Rule Parts 47 CFR FCC Part 15, Subpart C (Section 15.247), ISED Canada RSS- 247 Issue 2 Test Dates Jan 25,2021 – Jan 29,2021 Results As detailed within this report Prepared by Anna Vancheva – Test Engineer Authorized by Arik Zwirner– Sr. Engineer Issue Date 02/23/2020 Conditions of Issue This Test Report is issued subject to the conditions stated in the ‘Conditions of Testing’ section on page 18 of this report. Test Report for Harman International Industries Inc. • Report No. EV0141-3 February 23, 2021 ______________________________________________________________________ ____________________________________________________________ Bureau Veritas Consumer Product Services Inc. One Distribution Center Circle, #1 • Littleton, MA • TEL (978) 486-8880 • FAX (978) page 2 of 73 Contents Contents .................................................................................................................................. 2 Summary ................................................................................................................................. 3 Test Methodology .................................................................................................................... 4 Product Tested - Configuration Documentation ....................................................................... 5 Statement of Conformity .......................................................................................................... 6 Test Results ............................................................................................................................ 7 Radiated Spurious Emissions .............................................................................................. 7 AC Line Conducted Emissions ........................................................................................... 47 Measurement Uncertainty...................................................................................................... 48 Conditions Of Testing ............................................................................................................ 49 Appendix A ............................................................................................................................ 51 Report REV Sep-08-2017 - YF Test Report for Harman International Industries Inc. • Report No. EV0141-3 February 23, 2021 ______________________________________________________________________ Issue No. Reason for change Date Issued 1 Original Release February 23, 2021 _____________________________________________________________ Bureau Veritas Consumer Product Services Inc. One Distribution Center Circle, #1 • Littleton, MA • TEL (978) 486-8880 • FAX (978) page 3 of 73 Summary Between Jan 25th, 2020 and Jan 29th, 2020, we tested the BTT55 BT Transmitter. This test report supports an application for certification of a transmitter operating pursuant to: CFR Title 47 FCC Part 15.247, ISED Canada RSS-247 Issue 2 It is a frequency hopping spread spectrum transmitter that operates in the 2402 – 2480 MHz frequency range. Transfer Rate: BDR/EDR: up to 3 MB/s. Antenna Type: Non-detachable PCB trace Gain: 1.75 dBi We found that the product met the above requirements without modification. Test samples were received in good condition. Test Report for Harman International Industries Inc. • Report No. EV0141-3 February 23, 2021 ______________________________________________________________________ _____________________________________________________________ Bureau Veritas Consumer Product Services Inc. One Distribution Center Circle, #1 • Littleton, MA • TEL (978) 486-8880 • FAX (978) page 4 of 73 Test Methodology All testing was performed according to the following rules/procedures/documents; CFR Title 47 FCC Part 15.247, ISED Canada RSS-247 Issue 2, ISED Canada RSS-Gen Issue 5 and ANSI C63.10-2013, and KDB 558074 D01 15.247 Meas Guidance v05r02. Radiated emissions were maximized by rotating the EUT 3 orthogonal planes (X, Y and Z) and worst case emissions observed in Z orientation for the EUT. All the results below are for the worst case orientation only. The antenna is printed on PCB, therefore it cannot be rotated. EUT operating voltage is 13.8V DC from a vehicle battery only, therefore AC line conducted emissions requirements are not applicable. The following bandwidths were used during radiated spurious emissions testing. Frequency RBW VBW 30-1000MHz 120kHz 1MHz 1-25GHz 1MHz 3MHz Test Report for Harman International Industries Inc. • Report No. EV0141-3 February 23, 2021 ______________________________________________________________________ _____________________________________________________________ Bureau Veritas Consumer Product Services Inc. One Distribution Center Circle, #1 • Littleton, MA • TEL (978) 486-8880 • FAX (978) page 5 of 73 Product Tested - Configuration Documentation EUT Configuration Work Order: V0141 Company: Harman International Industries, Incorporated Company Address: 30001 Cabot Drive Novi, MI, 48377 Contact: Mark Bowman MN PN SN EUT: BTT55 #28 (Conducted) ,38 (EMI) EUT Description: Automotive Bluetooth Transmitter EUT Max Frequency: 2480 MHz EUT Min Frequency: 2402 MHz Support …

Text truncated - open the document above for the full version.

FCC: 2AHPN-BE2852 IC: 6434C-BE2852 FCC: 2AHPN-BE2852 IC: 6434C-BE2852 9KHz – 30MHz FCC: 2AHPN-BE2852 IC: 6434C-BE2852 30-1000MHz FCC: 2AHPN-BE2852 IC: 6434C-BE2852 FCC: 2AHPN-BE2852 IC: 6434C-BE2852 1-6GHz FCC: 2AHPN-BE2852 IC: 6434C-BE2852 FCC: 2AHPN-BE2852 IC: 6434C-BE2852 6-18GHz FCC: 2AHPN-BE2852 IC: 6434C-BE2852 18-26.5GHz FCC: 2AHPN-BE2852 IC: 6434C-BE2852 Conducted Antenna port Measurement set-up
