2AHPPAPX01Payment Terminal

User Manual V1.3 - 202301 Page 1 of 43 Payter B.V. Rozenlaan 115 3051 LP Rotterdam The Netherlands User Manual V1.3 - 202301 Page 2 of 43 Apollo terminal series User manual v1.3 (2023-01-10) Copyright © 2023 PAYTER B.V. All rights reserved. Payter reserves the right to modify specifications stated in this manual. Liability Payter B.V. accepts no liability for claims arising from improper use other than that stated in this manual of from not obeying (safety) instructions and precautions in this manual. Although considerable care has been taken to ensure a correct and suitably comprehensive description of the product, this manual may nonetheless contain errors and inaccuracies. Warranty Payter B.V. warrants to the original purchaser that this product is free from defects in material or workmanship for the period of one year from the date of purchase. This warranty does not apply to damage incurred due to misuse, incorrect handling, unapproved repairs or unapproved alterations. How to contact us If you have any comments or queries concerning any aspect related to the product, do not hesitate to contact us: Payter B.V. Rozenlaan 115 3051 LP Rotterdam t +31 (0)8 54 01 23 80 [email protected] User Manual V1.3 - 202301 Page 3 of 43 About this manual This manual is intended for professionals responsible for the integration, installation, configuration or problem solving of the Apollo and/or ApolloMax terminal. What you need to know You will have a better understanding of how the terminal works if you are familiar with: − Ethernet network technologies − The MDB protocol Reference documents Professionals responsible for configuration or installation may also refer to: − Response code and error list − Payter session protocol document − Payter Cloud Payments Service document Professionals responsible for integration of the Apollo terminal into the host machine, may also refer to: − Mechanical integration manual You can find request these additional documents at through your account representative or via [email protected] To ensure proper operation, read this manual thoroughly before using the product and retain the information for future reference. User Manual V1.3 - 202301 Page 4 of 43 Terms and abbreviations Abbreviation Description 3G/4G Third / Fourth Generation (i.e. a mobile communication system) APN Access Point Name CCI Coffee Credit Interface DC Direct Current DHCP Dynamic Host Control Protocol DNS Domain Name Server EMV Europay Mastercard Visa EVA European Vending Association GPRS General Packet Radio Service (i.e. a mobile communication system) GSM Global System for Mobile communication HSPA High Speed Packet Access (i.e. a mobile communication system) IP Internet Protocol LAN Local Area Network MDB Multidrop Bus (i.e. a communications bus standard for vending machines). ms Milliseconds NAMA National Automatic Merchandising Association NFC Near Field Communication PSP Payment Service Provider QR Quick Response PVP Payter Vending Protocol RTP Remote Terminal Protocol SDK Software Development Kit SIM Subscriber Identification Module USB Universal Serial Bus VMC Vending Machine Controller PCI Payment Card Industry Security Standards Council SRED Secure reading and exchange of data DUKPT Derived Unique Key per Transaction AES Advanced Encryption Standard TDES Triple - Data Encryption Standard RSA Rivest, Shamir, & Adleman Algorithm SHA Secure Hash Algorithm HMAC Hash-Based Message Authentication Code CMAC Cipher-Based Message Authentication Code User Manual V1.3 - 202301 Page 5 of 43 Table of Contents 1. Introduction ....................................................................................................... 7 2. Safety ................................................................................................................. 8 Safety symbols....................................................................................................................... 8 AC Adapter ............................................................................................................................ 8 Terminal ................................................................................................................................ 8 Security .................................................................................................................................. 8 3. The Apollo Terminal ........................................................................................... 9 Package contents .................................................................................................................. 9 Supported cards schemes ..................................................................................................... 9 Apollo terminal .................................................................................................................... 10 ApolloMax terminal ............................................................................................................. 11 Connections ......................................................................................................................... 12 Contactless Card Reader ..................................................................................................... 12 Power connection ............................................................................................................... 13 Dimensions Power supply ................................................................................................... 13 Accessories .......................................................................................................................... 13 Dimensions Antenna ........................................................................................................... 14 Installation ........................................................................................................................... 14 Placing the antenna .....................................…

Text truncated - open the document above for the full version.

Document Version 1.1 2020-10-30 LONG-TERM CONFIDENTIALITY REQUEST for Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 TO WHOM IT M AY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we request Long-Term Confidentiality for the following product: For the product stated above, we request Long-Term Confidentiality for exhibits which contain Block Diagram, Operational Description, Parts List/Tune Up Info, Schematics, SDR Software/Security Info. The above exhibits contain ou r trade secrets and proprietary information that could be of benefit to o ur competitors. This information will not be publicly available. If you have any questions, please feel free to contact us at the address shown below. Sincerely, Company Name: Phone: Company Address: Fax: E-mail: Contact Name: Signature: Signature Date: Check your GC here. Click Grantee Search. FCC I D: Grantee Code Equipment Product Code

Annex A No.1-1467/20-04-01_Annex_A External photos of the Device Under Test This document is electronically signed and valid without handwritten signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Document authorized: Hans-Joachim Wolsdorfer Lab Manager Radio Communications CTC advanced GmbHUntertuerkheimer Str. 6-10 66117 Saarbruecken / Germany Phone: +49 681 5 98 - 0 Fax: +49 681 5 98 - 9075 web: ctcadvanced.com e-mail: [email protected] Photos Annex A Photo 1 Photo 2 2022-01-20Document 1-1467/20-04-01_Annex_A2/6 Photo 3 Photo 4 2022-01-20Document 1-1467/20-04-01_Annex_A3/6 Photo 5 Photo 6 2022-01-20Document 1-1467/20-04-01_Annex_A4/6 Photo 7 Photo 8 2022-01-20Document 1-1467/20-04-01_Annex_A5/6 Photo 9 - END OF DOCUMENT - 2022-01-20Document 1-1467/20-04-01_Annex_A6/6

Agency Label APOnn.cc.acc V1-1 APMnn.cc.acc V1-0 with: -nn = Variants not related to colour -cc = Colour Code, e.g. BL for black, WH for White -acc = (optional) Artwork customization code if applicable, e.g. different silkscreen logo Serial Label S/N Barcode: PPPYYYYWWNNNNN S/N printed text: PPPYYYYWWNNNNN-CC with: -ppp = APO (Apollo) APM (ApolloMax) -yyyy = year of production -ww = production week (work week of the year) -nnnnn = consecutive number -CC = Checksum Location Backside: Agency Label Serial Label Electronic Label The electronic label is accessible from the main menu by tapping the screen 5 times within 15 seconds.

Annex B 1-1467/20-04-01_AnnexB Internal photos of the Equipment Under Test This addendum is electronically signed and valid without handwritten signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Document authorized: Hans-Joachim Wolsdorfer Lab Manager Radio Communications CTC advanced GmbHUntertuerkheimer Str. 6-10 66117 Saarbruecken / Germany Phone: +49 681 5 98 - 0 Fax: +49 681 5 98 - 9075 web: ctcadvanced.com e-mail: [email protected] Photos Photo 1 Photo 2 2023-01-06Document No. 1-1467/20-04-01_AnnexB2/7 Photo 3 Photo 4 2023-01-06Document No. 1-1467/20-04-01_AnnexB3/7 Photo 5 Photo 6 2023-01-06Document No. 1-1467/20-04-01_AnnexB4/7 Photo 7 Photo 8 2023-01-06Document No. 1-1467/20-04-01_AnnexB5/7 Photo 9 2023-01-06Document No. 1-1467/20-04-01_AnnexB6/7 Document history VersionApplied changesDate of release initial release2023-01-06 - END OF DOCUMENT - 2023-01-06Document No. 1-1467/20-04-01_AnnexB7/7

© cetecom advanced GmbH Page 1 of 8 BNetzA - CAB - 02/21 - 102 Maximum Permissible Exposure (MPE) & Exposure evaluation Report identification number: 1-1467/20-04-09 Exemption / MPE (FCC) Certification numbers and labeling requirements FCC ID 2AHPPAPX01 This test report is electronically signed and valid without handwritten signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Document authorised: Alexander Hnatovskiy Marco Scigliano Lab Manager Testing Manager Radio Communications & EMC Radio Communications & EMC Report no.: 1-1467/20-04-09 © cetecom advanced GmbH Page 2 of 8 1. EUT technologies Min. Max. Max Rated EIRP LTE Band 2 1850 1910 24.0 30.0 30.0 A, B LTE Band 4 1710 1755 24.0 30.0 30.0 A, B LTE Band 5 824 849 24.0 30.0 30.0 A, B LTE Band 7 2500 2570 24.0 30.0 30.0 A, B LTE Band 12 699 716 24.0 30.0 30.0 A, B LTE Band 13 777 787 24.0 30.0 30.0 A, B LTE Band 14 788 798 24.0 30.0 30.0 A, B LTE Band 25 1850 1915 24.0 30.0 30.0 A, B LTE Band 26 814 849 24.0 30.0 30.0 A, B LTE Band 66 1710 1780 24.0 30.0 30.0 A, B LTE Band 71 663 698 24.0 30.0 30.0 A, B Referenced Document Corrected EIRP for RF Exposure [dBm] Cellular Technology Frequency Band [MHz] Output Power [dBm] Referenced Documents: # Results from: A RC7611 Module MPE Evaluation (Module’s MPE, FCC ID: N7NRC76B) B airprime_wp76xx_product_technical_specification_rev11_0.pdf provided by customer Min.Max.ERPEIRP Bluetooth Classic 24022480N/A8.28.2C Bluetooth LE 24022480N/A6.66.6D WLAN 2.4 GHz 24122462N/A23.823.8E SRD Technology Frequency Band [MHz] EIRP for RF Exposure [dBm] Referenced Document Output Power Radiated (Average) Referenced Documents: # Results from: C Test Report 1-1467_20-04-05 (CTC) D Test Report 1-1467_20-04-06 (CTC) E MPE SA151228C18B (taken from original module with FCC ID: VPYLB1DX) Report no.: 1-1467/20-04-09 © cetecom advanced GmbH Page 3 of 8 Min.Max.Cond.EIRP RFID 13.56 MHz 13.5613.5619.7-29.619.7F SRD Technology Frequency Band [MHz] Output Power [dBm] Power for RF Exposure [dBm] Referenced Document Note: - According to section 4.3 of 447498 D01 v06 SAR test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel. - Conducted output power provided by customer (see Annex A): P = U I = 3.1 V x 30 mA = 19.7 dBm - Radiated output power measured in lab (see Annex B, C): 55.22 dBμV @ 10 m Referenced Documents: # Results from: F Test Report 1-1467_20-04-02 2. MPE at given distance (KDB 447498 D01 General RF Exposure Guidance v06) Equation from page 18 of OET Bulletin 65, Edition 97-01 S = PG / 4π R 2 where: S = Power density P = Power input to the antenna G = Antenna gain R = Distance to the center of radiation of the antenna PG = Output Power including antenna gain The table below is excerpted from Table 1B of 47 CFR 1.1310 titled “Limits for Maximum Permissible Exposure (MPE), Limits for General Population/Uncontrolled Exposure” Frequency Range (MHz) Power Density (mW/cm 2 ) Averaging Time (minutes) 300 -1500 f/1500 30 1500 - 100000 1.0 30 where f = Frequency (MHz) Declared minimum safety distance: 20 cm Report no.: 1-1467/20-04-09 © cetecom advanced GmbH Page 4 of 8 Min. Max. Caculated Limit LTE Band 2 1850 1910 20 30.0 0.20 1.00 19.90% LTE Band 4 1710 1755 20 30.0 0.20 1.00 19.90% LTE Band 5 824 849 20 30.0 0.20 0.55 36.23% LTE Band 7 2500 2570 20 30.0 0.20 1.00 19.90% LTE Band 12 699 716 20 30.0 0.20 0.47 42.71% LTE Band 13 777 787 20 30.0 0.20 0.52 38.43% LTE Band 14 788 798 20 30.0 0.20 0.53 37.89% LTE Band 25 1850 1915 20 30.0 0.20 1.00 19.90% LTE Band 26 814 849 20 30.0 0.20 0.54 36.68% LTE Band 66 1710 1780 20 30.0 0.20 1.00 19.90% LTE Band 71 663 698 20 30.0 0.20 0.44 45.03% Share of Limit [%] Power Density [mW/cm²] Cellular Technology Frequency Band [MHz] EIRP for RF Exposure [dBm] Distance [cm] Min. Max. Caculated Limit Bluetooth Classic 2402 2480 20 8.2 0.00 1.00 0.13% Bluetooth LE 2402 2480 20 6.6 0.00 1.00 0.09% WLAN 2.4 GHz 2412 2462 20 23.8 0.05 1.00 4.77% SRD Technology Frequency Band [MHz] Distance [cm] EIRP for RF Exposure [dBm] Power Density [mW/cm²] Share of Limit [%] Report no.: 1-1467/20-04-09 © cetecom advanced GmbH Page 5 of 8 3. SAR test exclusion according to KDB447498 (General RF Exposure Guidance v06) Equation from Chapter 4.3.1: Standalone SAR test exclusion considerations page 11 and ff and tables in Annex C. (c) (1) Standalone SAR test exclusion below 100 MHz at test separation distances > 50mm and < 200mm ( Threshold 100MHz > 50mm ) × (1+log(100/f)) where Threshold 1-g;10-g is 3 for 1-g; 7.5 for 10-g d seperation is the min. test separation distance ( >50mm and <200mm ) f is the RF channel transmit frequency Threshold 50mm; 100MHz < 50mm is Threshold 1-g;10-g × d / f 0.5 with f = 100MHz and d=50mm Threshold 100MHz > 50mm is (Threshold 50mm; 100MHz < 50mm ) + (d seperation -50mm ) × f / 150 with f = 100MHz The table below gives the calculated maximal power that could be used for source based time averaged conducted power, adjusted for tune up tolerance. If this is below the calculated value SAR testing is excluded. Min. Max. Caculated Limit RFID 13.56 MHz 13.56 13.56 199 19.7 93.33 1071.48 8.71% Share of Limit [%] SRD Technology Frequency Band [MHz] Distance [mm] EIRP for RF Exposure [dBm] Power [mW] Report no.: 1-1467/20-04-09 © cetecom advanced GmbH Page 6 of 8 4. Collocation overview: LTE Band 71 45.03% Bluetooth/ WLAN 2.4 GHz 4.77% RFID 13.56 MHz 8.71% Technology Share of Limit [%] Sum 58.52% This prediction demonstrates the following: The power levels for FCC at a distance of 20 cm are below the maximum levels allowed by regulations. Report no.: 1-1467/20-04-09 © cetecom advanced GmbH Page 7 of 8 Annex A: Conducted output power RFID 13.56 MHz Annex B: Pictures of the EIRP measurement for 13.56MHz with 10m distance Report no.: 1-1467/20-04-09 © cetecom advanced GmbH Page 8 of 8 LoopAntenna: EMCO 6502A (Correction factor @ 13.56MHz +9.5 dB)

D-PL-12076-01-03 TEST REPORT Test report no.: 1-1467/20-0 4-0 2 Testing Laboratory Applicant CTC advanced GmbH Untertuerkheimer Strasse 6 – 10 66117 Saarbruecken / Germany Phone: + 49 681 5 98 - 0 Fax: + 49 681 5 98 - 9075 Internet: https://www.ctcadvanced.com e-mail: [email protected] Accredited Testing Laboratory: The testing laboratory (area of testing) is accredited according to DIN EN ISO/IEC 17025 (2018-03) by the Deutsche Akkreditierungsstelle GmbH (DAkkS) The accreditation is valid for the scope of testing procedures as stated in the accreditation certificate with the registration number: D-PL-12076-01-03 Payter B.V. Rozenlaan 115 3051 LP Rotterdam/NETHERLANDS Phone: +31 8 54 01 23 80 Contact: Luuk de Gelder e-mail: [email protected] Manufacturer Payter B.V. Rozenlaan 115 3051 LP Rotterdam/NETHERLANDS Test Standard/s FCC - Title 47 CFR Part 15 FCC - Title 47 of the Code of Federal Regulations; Chapter I; Part 15 - Radio frequency devices RSS - 210 Issue 10 Spectrum Management and Telecommunications Radio Standards Specification - Licence-Exempt Radio Apparatus: Category I Equipment For further applied test standards please refer to section 3 of this test report. Test Item Kind of test item: Payment Terminal Model name: Apollo Max Terminal APM01 FCC ID: 2AHPPAPX01 Frequency: 13.110 MHz – 14.010 MHz Technology tested: RFID Antenna: Integrated antenna Power supply: 12V DC by external power supply Temperature range: -20°C to +55°C This test report is electronically signed and valid without handwritten signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Test report authorized: Test performed: Christoph Schneider Hans-Joachim Wolsdorfer Lab Manager Lab Manager Radio Communications Radio Communications Test report no.: 1-1467/20-04-02 © CTC advanced GmbH Page 2 of 31 1 Table of contents 1 Table of contents ............................................................................................................................................. 2 2 General Information ......................................................................................................................................... 3 2.1 Notes and disclaimer ............................................................................................................................ 3 2.2 Application details ................................................................................................................................ 3 2.3 Test Laboratories sub-contracted ........................................................................................................ 3 3 Test standard/s ................................................................................................................................................ 4 4 Reporting statements of conformity – decision rule ...................................................................................... 5 5 Test Environment ............................................................................................................................................. 5 6 Test item........................................................................................................................................................... 6 6.1 General description ............................................................................................................................... 6 6.2 Additional information .......................................................................................................................... 6 7 Description of the test setup ............................................................................................................................ 7 7.1 Shielded semi anechoic chamber ......................................................................................................... 8 7.2 Shielded fully anechoic chamber ........................................................................................................ 10 7.3 AC conducted ...................................................................................................................................... 11 7.4 Normal and extreme conditions ....................................................................................................... 12 8 Sequence of testing ....................................................................................................................................... 13 8.1 Sequence of testing radiated spurious 9 kHz to 30 MHz ................................................................... 13 8.2 Sequence of testing radiated spurious 30 MHz to 1 GHz .................................................................. 14 9 Measurement uncertainty .............................................................................................................................. 15 10 Summary of measurement results ......................................................................................................... 16 11 Additional comments .............................................................................................................................. 17 12 Measurement results .............................................................................................................................. 18 12.1 Occupied bandwidth ........................................................................................................................ 18 12.2 Field strength of the fundamental ................................................................................................... 20 12.3 Field strength of the harmonics and spurious ................................................................................ 21 12.4 Conducted limits .............................................................................................................................. 24 12.5 Frequency error..........................…

Text truncated - open the document above for the full version.

Annex D No.1-1467/20-04-01_Annex_D Setup photos of the Device Under Test This document is electronically signed and valid without handwritten signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Document authorized: Hans-Joachim Wolsdorfer Lab Manager Radio Communications CTC advanced GmbHUntertuerkheimer Str. 6-10 66117 Saarbruecken / Germany Phone: +49 681 5 98 - 0 Fax: +49 681 5 98 - 9075 web: ctcadvanced.com e-mail: [email protected] Photos Annex D Photo 1 Photo 2 2022-01-20Document 1-1467/20-04-01_Annex_D2/5 Photo 3 Photo 4 2022-01-20Document 1-1467/20-04-01_Annex_D3/5 Photo 5 Photo 6 2022-01-20Document 1-1467/20-04-01_Annex_D4/5 Photo 7 - END OF DOCUMENT - 2022-01-20Document 1-1467/20-04-01_Annex_D5/5
