2AHU2-JE3223S32 INCH DLED TV

JE3223S IMPORTANT Please observe all safety precautions when using this product. Please read this manual carefu. 32 INCH DLED TV Trademarks FCC WARNING JENSEN and JENSEN logo are trademarks or registered trademarks of ASA Electronics. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. To maintain compliance with FCC’s RF Exposure guidelines, This equipment should be installed and operated with minimum 20cm distance between the radiator and your body: Use only the supplied antenna. HDMI,the HDMI logo,and the term High Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC. 3 Contents Safety Precautions ................................................................................................... 4-6 TV Buttons And Terminal Interface ............................................................................. 7 TV Buttons .................................................................................................................... 7 Terminal Interface ......................................................................................................... 7 Accessories .................................................................................................................. 7 External device connection ......................................................................................... 7 TV Install........................................................................................................................ 8 Mounting on a Desktop................................................................................................. 8 Installation Precautions ................................................................................................ 8 Remote Control ............................................................................................................. 9 Initial Settings ........................................................................................................ 10-11 Select language ......................................................................................................... 10 Connect to the Internet .............................................................................................. 10 Terms &Conditions, Privacy Policy ............................................................................ 11 VIDAA APP Download SOP ....................................................................................... 12 Live TV .................................................................................................................... 13-15 Channel Scan ............................................................................................................. 13 Channel List................................................................................................................ 13 Favorite....................................................................................................................... 14 Connection ............................................................................................................. 16-18 Wired LAN .................................................................................................................. 16 Wireless ...................................................................................................................... 16 HDMI-CEC .................................................................................................................. 17 HDMI Device .............................................................................................................. 17 USB Device ................................................................................................................ 18 Multi-screen ................................................................................................................ 19 Screen Sharing ........................................................................................................... 19 Content Sharing.......................................................................................................... 19 Smart Functions .................................................................................................... 20-21 Media .......................................................................................................................... 20 Home .......................................................................................................................... 21 App Store ......…

Text truncated - open the document above for the full version.

ASAElectronicsShenzhenLimited (2023.02.14) EurofinsElectricalandElectronicTestingNA,Inc. 914WestPatapscoAvenue Baltimore,MD21230 RE:AttestationStatementsPart2.911(d)(5)(i)requestfor(2AHU2-JE3223S) [ ASAElectronicsShenzhenLimited ](“theapplicant”)certifiesthattheequipment forwhichauthorizationissoughtisnot“covered”equipmentprohibitedfromreceiving anequipmentauthorizationpursuanttosection2.903oftheFCCrules. Sincerely, (Applicantsignature) (Applicantprintedname)ThomasLeung ASAElectronicsShenzhenLimited (2023.02.14) EurofinsElectricalandElectronicTestingNA,Inc. 914WestPatapscoAvenue Baltimore,MD21230 RE:AttestationStatementsPart2.911(d)(5)(ii)requestfor(2AHU2-JE3223S) [ASAElectronicsShenzhenLimited](“theapplicant”)certifiesthat,asofthedateof thefilingoftheapplication,theapplicantisnotidentifiedontheCoveredListasan entityproducing“covered”equipment. Sincerely, (Applicantsignature) (Applicantprintedname)ThomasLeung

ASAElectronicsShenzhenLimited (2023.02.14) TO:FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046,USA RE:AttestationStatementsPart2.911(d)(7)requestfor(2AHU2-JE3223S) (ASAElectronicsShenzhenLimited),theundersigned,herebyauthorize(ASA Electronics)toactasourdesignatedU.S.agentforserviceofprocess,( ASAElectronics ShenzhenLimited )acceptstomaintainanagentfornolessthanoneyearafterthe granteehasterminatedallmarketingandimportationortheconclusionofany Commission-relatedproceedinginvolvingtheequipment. (ASAElectronics)acceptstheresponsibilitytoactasdesignatedU.S.agentforserviceof process,providesanagentfornolessthanoneyearafterthegranteehasterminatedall marketingandimportationortheconclusionofanyCommission-relatedproceeding involvingtheequipment. ApplicantInformation： Companyname:ASAElectronicsShenzhenLimited ContactName:ThomasLeung Address:Room503,5/F.,UnitA,SkyworthBuilding,GaoxinAvenue.1.S., NanshanDistrict,ShenZhen518057,China TelephoneNo:86-755-82793629 Email:[email protected] U.S.AgentInformation: CompanyName:ASAElectronics Address:2602MarinaDrive,Elkhart,IN-46514 ContactName:JuliaWillis TelephoneNo:800-688-3135 Email:[email protected] ApplicantSignature:AgentSignature: (iftheagentisdifferentfromtheapplicant) Applicantprintedname:ThomasLeungAgentprintedname:JuliaWillis

ASA Electronics Shenzhen Limited (2023.02.15) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize (Shenzhen CTB Testing Technology Co., Ltd.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Signature: Name: Thomas Leung Title: Manager

ASA Electronics Shenzhen Limited (2023.02.15) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (32 INCH DLED TV / JE3223S / FCC ID: 2AHU2-JE3223S) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☐ Internal Photos ☐ NOTE 1 ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No required to be submitted with this application be permanently withheld from public review. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. Please contact me if there is any information you may need. Sincerely, Signature: Name: Thomas Leung Title: Manager

External Photos

Label Location: 79 0 -0.3 39 0 -0.2 45° 3 旧底图总号 底图总号 日期 签名 更 改 标 记 1 1 2023-2-2 JE3223S后铭牌 PC 黑 底银字 5001417 62368-1 62368-1 32 INCH DLED TV AC 120V~ 60Hz, 40W JE3223S FCC ID: 2AHU2-JE3223S

Internal Photos ANT1 ANT2

FCC §15.247 (i), §2.1091 – RF Exposure FCC ID: 2AHU2-JE3223S Applied procedures / limit According to FCC §15.247(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 Note: ƒ is frequency in MHz * = Power density limit is applicable at frequencies greater than 100 MHz Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm 2 ) Averaging Time |E| 2 ,|H| 2 or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz * = Plane-wave equivalent power density MPE PREDICTION Predication of MPE limit at a given distance, Equation from OET Bulletin 65, Edition 97-01 Where: S = power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna,R=20cm Test Result of RF Exposure Evaluation Modes& Channel Freq. (MHz) Tune up Produce power Maximu m peak output power (dBm) Output power to antenna (mW) Antenna Gain (numeric) Power Density (S) (mW/ cm2) Limit (mW / cm2 ) Result 2.4G WIFI ANT1 802.11b&2 437 14±1 15 31.6228 1.2359 (0.92dBi) 0.00778 1 Pass 2.4G WIFI ANT2 802.11b&2 462 14±1 15 31.6228 1.2359 (0.92dBi) 0.00778 1 Pass Tech nolo gy Tune up Produce power(dBm) Maximum Tune-up (dBm) Antenna Gain(ANT 1/ANT 2) (numeric) Power Density (S) (mW/ cm2) MPE Limit (mW/ cm2) ∑ MPE Ratio ∑ MPE Ratio Limit Result ANT 1 ANT 2 ANT 1 ANT 2 ANT 1 ANT 2 2.4G WIFI MIM O 14 ±1 14 ±1 15 15 1.2359 (0.92dBi) 0.0077 8 0.0077 8 1 0.0155 6 1 Pass

Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB230130021RF Report Tel: 4008-707- 283Web: http://www.ctb-lab.net Page 1 of 82 TEST REPORT Compiled by: Reviewed by: Approved by: Chen Zheng Arron Liu Bin Mei / Director Note: If there is any objection to the inspection results in this report, please submit a written report to the company within 15 days from the date of receiving the report. The test report is effective only with both signature and specialized stamp. This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen CTB Testing Technology Co., Ltd. this report can’t be reproduced except in full. The tested sample(s) and the sample information are provided by the client. “*” indicates the testing items were ful filled by subcontracted lab. “#” indicates the items are not in CNAS accreditation scope. Product Name: 32 INCH DLED TV FCC ID: 2AHU2-JE3223S Trademark: JENSEN Model Number: JE3223S Prepared For: ASA Electronics Shenzhen Limited Address: Room 503, 5/F., Unit A, Skyworth Building, Gaoxin Avenue.1.S., Nanshan District, Shen Zhen 518057, China Manufacturer: ASA Electronics Shenzhen Limited Address: Room 503, 5/F., Unit A, Skyworth Building, Gaoxin Avenue.1.S., Nanshan District, Shen Zhen 518057, China Prepared By: Shenzhen CTB Testing Technology Co., Ltd. Address: 1&2/F., Bui lding A, No.26, Xinhe Road, Xinqiao, Xinqiao Street, Bao'an District, Shenzhen, Guangdong, China Sample Received Date: Jan . 12 , 202 3 Sample tested Date: Jan . 12 , 202 3 to Feb . 07, 2023 Issue Date: Feb . 07, 2023 Report No.: CTB230130021RF Test Standards FCC Part15.247 ANSI C63.10:2013 Test Results PASS Remark: This is WIFI-2.4GHz band radio test report. Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB230130021RF Report Tel: 4008-707- 283 Web: http://www.ctb-lab.net Page 2 of 82 TABLE OF CONTENT Test Report Declaration Page 1. VERSION .......................................................................... 3 2. TEST SUMMARY ................................................................... 4 3. MEASUREMENT UNCERTAINTY ..................................................... 5 4. PRODUCT INFORMATION AND TEST SETUP .......................................... 6 4.1 Product Information .................................................................... 6 4.2 Test Setup Configuration ............................................................... 6 4.3 Support Equipment .................................................................... 6 4.4 Channel List .......................................................................... 6 4.5 Test Mode ............................................................................ 7 4.6 Test Environment ...................................................................... 7 5. TEST FACILITY AND TEST INSTRUMENT USED ....................................... 8 5.1 Test Facility ........................................................................... 8 5.2 Test Instrument Used .................................................................. 8 6. AC POWER LINE CONDUCTED EMISSION ............................................ 10 6.1 Block Diagram Of Test Setup .......................................................... 10 6.2 Limit ................................................................................ 10 6.3 Test procedure ....................................................................... 10 6.4 Test Result .......................................................................... 12 7. RADIATED SPURIOUS EMISSION ................................................... 14 7.1 Block Diagram Of Test Setup .......................................................... 14 7.2 Limit ................................................................................ 14 7.3 Test procedure ....................................................................... 15 7.4 Test Result .......................................................................... 16 8. BAND EDGE AND RF COUNDUCTED SPURIOUS EMISSIONS .......................... 38 8.1 Block Diagram Of Test Setup .......................................................... 38 8.2 Limit ................................................................................ 38 8.3 Test procedure ....................................................................... 38 8.4 Test Result .......................................................................... 39 9. COUDUCTED OUTPUT POWER ..................................................... 56 9.1 Block Diagram Of Test Setup .......................................................... 56 9.2 Limit ................................................................................ 56 9.3 Test procedure ....................................................................... 56 9.4 Test Result .......................................................................... 57 10. 6DB OCCUPIED BANDWIDTH ....................................................... 58 10.1 Block Diagram Of Test Setup ......................................................... 58 10.2 Limit ............................................................................... 58 10.3 Test procedure ...................................................................... 58 10.4 Test Result ......................................................................... 59 11. POWER SPECTRAL DENSITY ...................................................... 69 11.1 Block Diagram Of Test Setup ......................................................... 69 11.2 Limit ............................................................................... 69 11.3 Test procedure ...................................................................... 69 11.4 Test Result ......................................................................... 70 12. ANTENNA REQUIREMENT ......................................................... 79 13. EUT PHOTOGRAPHS ..................................................…

Text truncated - open the document above for the full version.

Antenna Specification Specifications Summary ITEMSPEC. Model NameIBM 2.4 GHz Center Frequency 2400MHz 2450MHz 2500MHz 0.92 dBi 0.62 dBi 0.90 dBi MAX. GAIN 0.92 dBi PolarizationHorizontal Azimuth Beam Pattern Omni-directional Impedance50Ω Antenna Length 6.5cm Antenna Photo Test Date 2023-01-02 Test Instrument vector network analyzer - R&S ZVB20 1. Main antenna : 2400 MHz 1.1 Horizontal Antenna Polarity:Horizontal Frequency(MHZ): 2400 Maximum Value(dBi): 0. 92 Average Gain(dBi) : -5.48 Minimum Gain(dBi): -55.1 8 1.2 Vertical Antenna Polarity:Vertical Frequency(MHZ): 2400 Maximum Value(dBi): -6.31 Average Gain(dBi) : -11.17 Minimum Gain(dBi): -62.3 2. Main antenna : 2450 MHz 2.1 Horizontal Antenna Polarity:Horizontal Frequency(MHZ): 2450 Maximum Value(dBi): 0.62 Average Gain(dBi) : -5.57 Minimum Gain (dBi): -66.98 2.2 Vertical Antenna Polarity:VerticalFrequency(MHZ): 2450 Maximum Value(dBi): -4.57 Average Gain(dBi) : -9.81 Minimum Gain(dBi): -51.4 2. Main antenna : 25 00 MHz 2.1 Horizontal Antenna Polarity:Horizontal Frequency(MHZ): 2500 Maximum Value(dBi): 0.90 Average Gain(dBi) : -5.34 Minimum Gain(dBi): -53.4 2.2 Vertical Antenna Polarity:VerticalFrequency(MHZ): 2500 Maximum Value(dBi): -5.23 Average Gain(dBi) : -11.06 Minimum Gain(dBi): -60.00

Radiated Emission Below 1G Above 1G Conducted emissions
