2AHU2JWM30AM/FM/USB/BT/AUX IN/HDMI IN RADIO

Installation and Owner's Manual MOBILE AUDIO SYSTEM JWM30 Introduction Installation Wiring Basic Operation Tuner Operation MP3/USB Operation Bluetooth Operation Remote Control Operation Care and Maintenance Troubleshooting Specifications FCC Notes JWM30 3 4 5 6 9 10 11 14 14 15 15 12 CONTENTS INTRODUCTION Packing List Precautions Features Thank you! Features of Jensen JWM30 mobile audio system include: ŸDigital AM/FM Tuner/30 Preset stations (12 AM/18 FM) ŸDual Bluetooth Ready with A2DP/AVRCP Streaming Audio ŸZone C mode individual Bluetooth selectable ŸElectronic Bass, Treble, Balance and Loudness Controls ŸHDMI Input Pass Through Rear HDMI Output with ARC/CEC ŸTime/Alarm Clock ŸDimmable Backlit LCD Control ŸRear Audio RCA Input/Outputs ŸUSB Playback of MP3 Files Ÿ3 Zone / 6 Speaker Output ŸIndependent Zone AB or Zone C Volume Control ŸWireless Remote Control Included Thank you for choosing a Jensen product. We hope you will find the instructions in this owner's manual clear and easy to follow. If you take a few minutes to look through it, you'll learn how to use all the features of your new Jensen receiver for maximum enjoyment. ŸUse the Proper Power Supply This product is designed to operate with a 12 volt DC, negative ground battery system (the standard system in a North American vehicle) ŸProtect the Disc Mechanism. Avoid inserting any foreign objects into the slot of this player. Failure to observe this may cause malfunction due to the precise mechanism of this unit. ŸUse Authorized Service Centers. Do not attempt to disassemble or adjust this precision product; contact a professional for assistance. ŸAvoid Moisture. To reduce the risk of fire or electric shock, do not expose this equipment to rain or moisture. ŸAvoid Cleaning Products. The front of this unit should only be cleaned with a slightly damp cloth. Do not use cleansers. ŸUse Recommended Accessories. TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK AND ANNOYING INTERFERENCE, USE ONLY THE RECOMMENDED ACCESSORIES. JWM30 20-PIN Speaker Wire Remote Control 3 JWM30 WHITE 10 9 7 6 16 15 14 4 3 2 1 WHITE/BLACK GRAY/BLACK GRAY BLACK RED BLUE GREEN/BLACK GREEN PINK PINK/BLACK LEFT(A) SPEAKER(+) LEFT(A) SPEAKER(-) RIGHT(A) SPEAKER(-) RIGHT(A) SPEAKER(+) GROUND +12 VDC SWITCHED LEFT(B) SPEAKER(-) 13 BROWN 11 ORANGE ORANGE/BLACK AMP REMOTE (+12VDC 100MA) LEFT(C) SPEAKER(-) LEFT(C) SPEAKER(+) RIGHT(C) SPEAKER(+) RIGHT(C) SPEAKER(-) LEFT(B) SPEAKER(+) RIGHT(B) SPEAKER(-) RIGHT(B) SPEAKER(+) 12 5 BROWN/BLACK . INSTALLATION It's a good idea to read all of the instructions before beginning the installation. We recommend having your Jensen JWM30 installed by a reputable RV dealership. NOTE: Before cutting the mounting hole, make sure the area behind the mounting location is clear of wires, fuel and vacuum or brake lines. You will need these tools and supplies to install your JWM30: Select a mounting location, taking care to avoid the following: To prevent a short circuit, be sure to turn off the ignition and remove the negative (-) battery cable prior to installation. ŸPhillips screwdriver ŸWire cutters and strippers ŸTools to remove existing radio (screwdriver, socket wrench set or other tools) ŸElectrical tape ŸCrimping tool ŸVolt meter/test light ŸCrimp connections Ÿ16 gauge wire for power connections Ÿ16-18 gauge speaker wire ŸFour M3x20mm (3/32 x 0.75") screws ŸPlaces exposed to heat-radiating appliances such as electric heaters ŸAdjacent to other equipment that radiates heat ŸPoorly-ventilated or dusty places ŸMoist or humid locations Tools and Supplies Disconnecting the Battery Selecting the Mounting Location Preparing the Opening 4 Use the mounting hole diagram ( right) to measure and cut a mounting hole, then mount the unit using four M3x20mm screws. NOTE: If the JWM30 is to be installed in a vehicle equipped with an onboard drive or navigation computer, do not disconnect the battery cable. If the cable is disconnected, the computer memory may be lost. Under these conditions, use extra caution during installation to avoid causing a short circuit. MOUNTING SCREWS M3X20 PHILIPS TYPE ROUND HEAD 4 PLACES 7.323"+0.023" - - 3 .4 6 5" +0 .0 23" JWM30 WIRING CONNECTIONS The wiring diagram depicts all the wiring connections required for proper operation of the unit. The wiring diagram depicts all the wiring connections required for proper operation of the unit. 110 1120 DETAIL A SHOWN FROM PIN VIEW WARNING: Wiring harness comes with stripped and tinned leads to aid in the installation process. Any unused speaker wires must have their exposed ends cut off or insulated individually. 10AMPFUSE 5 JWM30 WIRING HARNESS CONNECTOR AUDIO OUTPUT (FIXED) AM/FM ANTENNA SOCKET AUDIO INPUT PIN NO. WIRE COLOR DESCRIPTION 1 PINK/BLACK PINKRIGHT(C) SPEAKER (+) GREEN LEFT(C) SPEAKER (+) GREEN/BLACKLEFT(C) SPEAKER (-) BROWN/BLACK GRAYRIGHT(A) SPEAKER (+) GRAY/BLACKRIGHT(A) SPEAKER (-) N/AN/A WHITE/BLACKLEFT(A) SPEAKER (-) WHITELEFT(A) SPEAKER (+) ORANGE BLUEAMP REMOTE (+12VDC 100mA) RED+12VDC SWITCHED BLACKGROUND N/AN/A N/AN/A N/AN/A N/AN/A 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 RIGHT(C) SPEAKER (-) LEFT(B) SPEAKER (-) RIGHT(B) SPEAKER (+) ORANGE/BLACK RIGHT(B) SPEAKER (-) BROWN LEFT(B) SPEAKER (+) AUDIO OUTPUT (VARIABLE) WHITE 10 9 7 6 16 15 14 4 3 2 1 WHITE/BLACK GRAY/BLACK GRAY BLACK RED BLUE GREEN/BLACK GREEN PINK PINK/BLACK LEFT(A) SPEAKER(+) LEFT(A) SPEAKER(-) RIGHT(A) SPEAKER(-) RIGHT(A) SPEAKER(+) GROUND +12 VDC SWITCHED LEFT(B) SPEAKER(-) 13 BROWN 11 ORANGE ORANGE/BLACK AMP REMOTE (+12VDC 100MA) LEFT(C) SPEAKER(-) LEFT(C) SPEAKER(+) RIGHT(C) SPEAKER(+) RIGHT(C) SPEAKER(-) LEFT(B) SPEAKER(+) RIGHT(B) SPEAKER(-) RIGHT(B) SPEAKER(+) 12 5 BROWN/BLACK HDMI OUTPUT (ARC) BASIC OPERATION Power Zones Volume Control Audio Menu Setting Pause/Mute Liquid Crystal Display (LCD) System menu setting Press the POWER button (1) turn the unit on. The unit will resume at the last mode (Tuner, Aux, etc.) after turn on. Press and hold the POWER button (1) to enter …
