1 www.PyleUSA.com www.PyleUSA.com 2 3 FEATURES: t Versatile High-Powered Mobile Cabinet Speaker System t Rugged, Durable & Reliable Sound t Bluetooth Wireless Music Streaming Ability t Speaker System PPHP1241WMU: 12'' Woofer, 1'' Tweeter PPHP1541WMU: 15'' Woofer, 1'' Tweeter t Compression Driver with Titanium Diaphragm t Built-in Rechargeable Battery t 2-Way Full Range Audio Projection tt
RCA (L/R) Stereo Line Input Connectors t RCA (L/R) Stereo Line Output Connectors t Connect & Stream Audio from External Devices t USB Flash Drive & SD Memory Card Readers t USB Reader Doubles as Device Charging Port t FM Radio with Digital LCD Display t ID3 Tag Song Readout Info: LCD Displays Song Title/Song Artist t Rear Panel Rotary Dial & Button Control Center t Master Volume, Mic Volume, Echo, Treble, Bass Setting t (2) 1/4'' Microphone Inputs t Convenient Carry Handles t 35mm Speaker Stand Mount t Engineered Heavy Duty ABS Housing BLUETOOTH WIRELESS STREAMING: t Instantly Stream Music from Your Bluetooth Devices t Works with All Your Favorite Bluetooth Devices t (iPhone, Android, Smartphone, iPad, Tablet, PC, etc.) t Bluetooth Version: 4.2 t Bluetooth Network Name: 'Pyle' t Wireless Range: 100'+ Feet WHAT'S IN THE BOX: t PA Speaker t Wireless Handheld Microphone t Headset Microphone t Beltpack Transmitter t Remote Control t Power Cable t (4) x 'AA' Batteries WARNING RECHARGEABLE BATTERY INSIDE CHARGE THE BATTERY EVERY 30DAYS EVEN IF NOT USE CHARGE THE BATTERY STOP CHARGING IMMEDIATELY 5(' *5((1 1. LCD screen2. Mp3 controlMODE : USB/SD/BT/FM/LINE(AUX) convertor : Play / PauseSCAN : Long press to auto search under FM radio : Long press 3 seconds to enter the folder option function mode (press the previous/ next songs button to choose the folder) : Repeat one / Repeat all / Random : PRE/NEXT under FM modeLong hold to search lower/higher station manually : Short press to tune to saved station : Previous SongLong press for fast rewind : Next SongLong press for fast forward3. USB input4. SD Card input5. IR Remote control receiver6. MIC level control7. Echo control8. Bass control for low frequencies9. Treble control for high frequencies 10. Master volume11. MP3 level control12. Guitar level control 13. 6.35 microphone line input14. Guitar line input15. Aux input16. Mic Priority voice switch17. RCA (R+L)line input18. RCA MIX output19. FM antenna20. Charge indicatorBattery low indicatorBattery full indicator21. A channel volume control Wireless microphone Achannel indicator22. B channel volume control Wireless microphone Bchannel indicator23. Wireless power indicatorWireless mic power switch24. Main power switch25. Battery charge switch26. DC power interface 27. IEC main inlet 32:(5 %$77(5<&+$5*( - DC 12V + $&9+] &+$5*( /2: )8// )0$17 0,&/(9(/ %$66 0,& 0$67(592/ 75(%/( (&+2 0,1 0$; 0,1 0$; ,5 86% 6'FDUG 6&$1 )2/  )2/  )2/ 03/(9(/ /,1( ,1387 0,;287 0,1 0$; *8,7$5/(9(/ *8,7$5 0,&35, $8;,1 21 2)) 0,1 0$; 0,1 0$; 0,1 0$; 0,1 0$; 03&21752/',*,7$/',63/$< MIC.A MIC.B POWER POWER SWITCH ON OFF 0,&$/(9(/ 0,1 0$; 0,1 0$; 0,&%/(9(/ 8+):,5(/(660,&523+21(6 27 34 1 2 5 6 9 1011 8 12 14 15 16 13 7 18 17 24 25 26 20 19 21 22 23 USD SCAN UHF Wireless Microphone & Portable Bluetooth PA Speaker System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

Ningbo Polinata Electronics Co., Ltd. Agent Authorization Company: Ningbo Polinata Electronics Co., Ltd. Address: LongXing Village WuXiang Town Yinzhou District, NingBo,China Product Name: SPEAKER BOX Model Number(s): PPHP1241WMU, PPHP108WMU, PPHP849KT, PPHP1049KT, PPHP1249KT, PPHP1541WMU, PPHP1641WMU, PPHP1538WUM, PPHP1548B, PS65ACT, PPHP155ST, PPHP1541WMU Product Description: SPEAKER BOX We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2020/04/03 Name: Jiali Fang Title: Management respresentative Company: Ningbo Polinata Electronics Co., Ltd.

Ningbo Polinata Electronics Co., Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2020/04/03 Subject; Request for Confidentiality FCC ID: 2AHU8-PPHP1241WMU To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuantto KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Jiali Fang Title: Management respresentative

Ningbo Polinata Electronics Co., Ltd. Model Difference 2020-04-03 EUT NAME: SPEAKER BOX FCC ID: 2AHU8-PPHP1241WMU MODEL : PPHP1241WMU, PPHP108WMU, PPHP849KT, PPHP1049KT, PPHP1249KT, PPHP1541WMU, PPHP1641WMU, PPHP1538WUM, PPHP1548B, PS65ACT, PPHP155ST, PPHP1541WMU All the model are the same circuit and RF module, except model names . Regards Sincerely Client’s signature Client’s name / title : Jiali Fang (Management respresentative) Contact information / address: LongXing Village WuXiang Town Yinzhou District, NingBo,China

External Photos

Model: PPHP1241WMU FCC ID: 2AHU8-PPHP1241WMU Label Location

Internal Photos ANT

Shenzhen BCTC Testing Co., Ltd. FCC ID:2AHU8-PPHP1241WMU Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB447498 D01 General RF Exposure Guidance V06 The 1-g SAR and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]·[√f(GHZ)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f(GHZ) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. BT: Modulation Channel Freq. (GHz) Conduct ed power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n SAR Exclusion threshold SAR test exclusion 2.402 -0.130.970±11.001.26<50.390233.00YES 2.4410.431.100±11.001.26<50.393383.00YES 2.480 0.661.160±11.001.26<50.396513.00YES 2.402 0.491.121±12.001.58<50.491273.00YES 2.4411.061.28 1±1 2.001.58<50.495243.00YES 2.4801.261.34 1±12.001.58<50.499183.00YES GFSK Pi/4 DQPSK Conclusion: For the max result : 0.49918W/Kg ≤ FCC Limit 3.0 for 1g SAR.

Shenzhen BCTC Testing Co., Ltd. Report No. BCTC1912001333E FCC Part 15C Test Report FCC ID: 2AHU8-PPHP1241WMU Product Name: SPEAKER BOX Trademark: N/A Model Name : PPHP1241WMU PPHP108WMU, PPHP849KT, PPHP1049KT, PPHP1249KT, PPHP1541WMU, PPHP1641WMU, PPHP1538WUM, PPHP1548B, PS65ACT, PPHP155ST, PPHP1541WMU Prepared For : Ningbo Polinata Electronics Co., Ltd. Address : longXing Village WuXiang Town Yinzhou District, NingBo, China Prepared By : Shenzhen BCTC Testing Co., Ltd. Address : BCTC Building & 1-2F, East of B Building, Pengzhou Industrial, Fuyuan 1st Road, Qiaotou Community, Fuyong Street, Bao’an District, Shenzhen, China Test Date: Dec. 13, 2019 – Dec. 25, 2019 Date of Report : Dec. 25, 2019 Report No.: BCTC1912001333E Te s t Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-0 07 Ver.：A.0 Page 1 of 57 Shenzhen BCTC Testing Co., Ltd. Report No. BCTC1912001333E TEST RESULT CERTIFICATION Applicant’s name ............. : Ningbo Polinata Electronics Co., Ltd. Address ............................. : longXing Village WuXiang Town Yinzhou District, NingBo, China Manufacture's Name ........ : Ningbo Polinata Electronics Co., Ltd. Address ............................. : longXing Village WuXiang Town Yinzhou District, NingBo, China Product description Product name .................... : SPEAKER BOX Trademark ......................... : N/A Model and/or type reference .......................................... : PPHP1241WMU PPHP108WMU, PPHP849KT, PPHP1049KT, PPHP1249KT, PPHP1541WMU, PPHP1641WMU, PPHP1538WUM, PPHP1548B, PS65ACT, PPHP155ST, PPHP1541WMU Standards ......................... : FCC Part15.247 ANSI C63.10:2013 KDB558074 D01 15.247 Meas Guidance v05r02 This device described above has been tested by BCTC, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BCTC, this document may be altered or revised by BCTC, personal only, and shall be noted in the revision of the document. Prepared by(Engineer): Cai Fangzhong Reviewer(Supervisor): Eric Yang Approved(Manager): Zero Zhou Te s t Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-0 07 Ver.：A.0 Page 2 of 57 Shenzhen BCTC Testing Co., Ltd. Report No. BCTC1912001333E Table of Contents Test Report Declaration Page 1. TEST SUMMARY ..................................................... 5 2. TEST FACILITY ....................................................... 6 3. MEASUREMENT UNCERTAINTY ....................................... 6 4. GENERAL INFORMATION ............................................. 7 4.1 GENERAL DESCRIPTION OF EUT....................................... 7 4.2 Test Setup Configuration ................................................ 7 4.3 Support Equipment ..................................................... 8 4.4 Channel List ........................................................... 9 4.5 Test Mode ............................................................ 10 5. TEST FACILITY AND TEST INSTRUMENT USED ........................ 11 5.1 Test Facility ........................................................... 11 5.2 Test Instrument Used .................................................. 11 6. CONDUCTED EMISSIONS ............................................ 13 6.1 Block Diagram Of Test Setup ........................................... 13 6.2 Limit ................................................................. 13 6.3 Test procedure ........................................................ 13 6.4 Test Result ........................................................... 14 7. RADIATED EMISSIONS .............................................. 16 7.1 Block Diagram Of Test Setup ........................................... 16 7.2 Limit ................................................................. 17 7.3 Test procedure ........................................................ 17 7.4 Test Result ........................................................... 19 7.5 RADIATED Band EMISSION MEASUREMENT ............................ 23 8. CONDUCTED EMISSION ............................................. 25 8.1 Block Diagram Of Test Setup ........................................... 25 8.2 Limit ................................................................. 25 8.3 Test procedure ........................................................ 25 8.4 Test Result ........................................................... 26 9. 20 DB BANDWIDTH .................................................. 32 9.1 Block Diagram Of Test Setup ........................................... 32 9.2 Limit ................................................................. 32 9.3 Test procedure ........................................................ 32 9.4 Test Result ........................................................... 33 10. MAXIMUM PEAK OUTPUT POWER .................................... 37 10.1 Block Diagram Of Test Setup .......................................... 37 10.2 Limit ................................................................ 37 10.3 Test procedure ....................................................... 37 10.4 Test Result .......................................................... 38 11. HOPPING CHANNEL SEPARATION ................................... 42 11.1 Block Diagram Of Test Setup .......................................... 42 11.2 Limit ................................................................ 42 Te s t Report Tel: 400-788-9558 Web: https://www.bctc-lab.com BCTC/RF-EMC-0 07 Ver.：A.0 Page 3 of 57 Shenzhen BCTC Testing Co., Ltd. Report No. BCTC1912001333E 11.3 Test procedure ....................................................... 42 11.4 Test Result .......................................................... 43 12. NUMBER OF HOPPING FREQUENCY .................................. 47 12.1 Block Diagram Of Test Setu…
