2AHZG-THERMONEW433Thermo One Refrigeration Sensor

Thermo One ™ Refrigeration Sensor INSTRUCTIONS 1. Remove the battery cap screw from the bottom of the sensor enclosure. 2. Install both AA lithium batteries into the battery enclosure, noting proper polarity. 3. Install and secure the battery cap screw. The sensor will begin transmitting at 4 second intervals in order to facilitate gateway setup and positioning. 4. Determine the mounting location by considering: a. Location of cooler venting and airflow. Note: Do not install in corner of cooler. b. Minimize obstructions to gateway. c. Vertical orientation of the sensor provides best signal strength. d. Locate at least 1 inch from metal surfaces if possible. 5. Use included clip and mount into racking with zip ties or mount to side of cooler with VHB tape. Note: To remove clip slide toward base of sensor. INSTALLATION TROUBLESHOOTING It is imperative that the sensors can communicate with a OneEvent™ gateway. The number of walls, ceilings and metal objects in the signal path reduces the strength of the radio frequency (RF) signals between the sensor and the gateway. Accordingly, some sensors may have difficulties communicating to the assigned OneEvent gateway. It may be necessary to move the gateway closer to the sensor if notifications are not being received during installation testing. Installation testing begins after installing the batteries and ends by confirming the sensor reading on the OneEvent app. The test mode transmits a signal every 4 seconds for 60 minutes, after which the Thermo One™ Refrigeration sensor reverts to the default transmit cycle of 3 minutes. LIMITATIONS OF OET RF SIGNALS OneEvent™ radio communication systems are reliable and are tested to high standards. However, due to their low transmitting power and limited range (as required by regulatory bodies) there are some limitations to be considered: · Receivers may be blocked by radio signals occurring on or near their operating frequencies (i.e. signals from garage door openers). · Changes in the surrounding environment (renovations or furniture that has been moved), can disrupt radio communications between the sensor and gateway. Package Contents: Thermo One Sensor (x1) Mounting Clip (x1) L91 AA Lithium Batteries (x2) Installation Instructions (x1) 3M ™ VHB mounting tape (x1) Changes and modifications to this device not ap- proved by OneEvent ® Technologies could void the user’s authority to operate the equipment. If your sensor fails to work after you have read the previous sections, please contact your Dealer or OneEvent. If you receive a “Low Battery” alert, immediately replace them with (2) AA lithium batteries. Use of any other type will effect sensor function. TECHNICAL SPECIFICATION Operating frequency: 433 MHz Range: 100m in free air (min) Protocol: OneEvent™ RF Link Transmit interval: 3 minutes ± 15 seconds Sensor message duration: 20ms OET-100413 weight: 77 grams, including batteries 6 . Ensure the gateway is operating and connected to the OneEvent server. 7. Allow a short time to elapse for the sensor to connect to the gateway, then verify the sensor is reading in the OneEvent app. 8. Once installed, no user interaction is required. CO N TAC T U S Customer Service OneEvent ® Technologies, Inc. 505 Springdale St. Mount Horeb, WI 53572 Phone: 855.528.8324 Email: [email protected] Web : oneeventtech.com/support FCC COMPLIANCE STATEMENT This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: the grantee is not responsible for any changes or modifications not expressly approved by the party responsible for compliance. Such modifications could void the user’s authority to operate the equipment. FCC ID: 2AHZG-THERMONEW433 This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.

OneEvent Technologies, Inc. ​·​ 505 Springdale Street ​·​ Mount Horeb, WI 53572 ​· ​ Tel 715.839.2121 ​·​ oneeventtech.com Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2AHZG-THERMONEW433 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type Schematic Block Diagram Circuit Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below for 180 Days Exhibit Type Internal Photos User Manual Sincerely, Predict​ ​ ​ ·​ ​ Alert ​ ·​ ​Prevent Daniel R. Parent

OneEvent Technologies, Inc. ​·​ 505 Springdale Street ​·​ Mount Horeb, WI 53572 ​· ​ Tel 608.473.8324 ​·​ oneeventtech.com Date: February 4, 2021 Timco Engineering, Inc. 849 N.W. State Road 45 P.O. Box 370 Newberry, FL 32669 SUBJECT: Application(s) for Certification for FCC ID: 2AHZG-THERMONEW433 IC: 21362-THERMONEW433 To Whom It May Concern: We,theundersigned,herebyauthorizeSharonHoffmanatTIMCOENGINEERING,INC.onourbehalf,toapplyfor certificationonourequipmentreferencedabove.AnyandallactscarriedoutbyTIMCOENGINEERING,INC.on our behalf shall have the same effect as acts of our own. ThisistoadvisethatweareinfullcompliancewiththeAnti-DrugAbuseAct.We,theapplicant,arenotsubjecttoa denialoffederalbenefitspursuanttoSection5301oftheAnti-DrugActof1988,21USC853a,andnopartytothe application is subject to a denial of federal benefits pursuant to that section. Regards, Daniel R Parent CTO OneEvent Technologies, Inc. Predict​ ​ ​ ·​ ​ Alert ​ ·​ ​Prevent

2/23/21 Rev2 Thermo One Probe External Pictures

APPLICANT: OneEvent Technologies, Inc. FCC ID: 2AHZG-THERMONEW433 IC: 21362-THERMONEW433 LABEL SAMPLE AND LOCATION

Antenna Thermo One Probe Internal Pictures

Timco Test Report # TR_0275-21_FCC_15.321_2 Revision: 2 Issue Date: 1/25/2021 Final Test Date: 1/25/2021 An IIA Company Te s t Report – FCC 15.231 Momentary Transmitter Prepared For: oneEvent Technologies, Inc. Approved for Release By: Signature: Name & Title: Bruno Clavier, General Manager Date of Signature 1/25/2021 This test report shall not be reproduced except in full without the written and signed permission of Timco Engineering Inc. (IIA). This test report relates only to the items tested as identified and is not valid for any subsequent changes or modifications made to the equipment under test. Timco Engineering, Inc., an IIA Company 849 NW State Road 45, Newberry, Florida 32669 (352) 472-5500 / [email protected] Page 2 of 22 This test report shall not be reproduced except in full without the written and signed permission of Timco Engineering Inc. (IIA). Table of Contents 1. CUSTOMER INFORMATION ........................................................................................................................................................................... 3 1.1 TEST RESULT SUMMARY ............................................................................................................................................................................................ 3 2. LOCATION OF TESTING ................................................................................................................................................................................. 4 2.1 TEST LABORATORY ....................................................................................................................................................................................................4 2.2 TESTING WAS PERFORMED, REVIEWED BY ................................................................................................................................................................ 5 3. TEST SAMPLE(S) (EUT/DUT) ........................................................................................................................................................................... 6 3.1 DESCRIPTION OF THE EUT ........................................................................................................................................................................................ 6 3.2 CONFIGURATION OF EUT ......................................................................................................................................................................................... 7 3.3 TEST SETUP OF EUT .................................................................................................................................................................................................. 7 4. TEST METHODS & APPLICABLE REGULATORY LIMITS ............................................................................................................................ 8 4.1 TEST METHODS/STANDARDS/GUIDANCE ................................................................................................................................................................ 8 5. MEASUREMENT UNCERTAINTY .................................................................................................................................................................... 8 6. ENVIRONMENTAL CONDITIONS ................................................................................................................................................................. 8 7. LIST OF TEST EQUIPMENT AND TEST FACILITY ........................................................................................................................................ 9 8. TEST RESULTS ................................................................................................................................................................................................. 10 8.1 PERIODIC OPERATION ...................................................................................................................................................................................... 11 8.1.1 Declaration Provided by Applicant .................................................................................................................................................... 11 8.1.2 Test Data: 5 Second Turn-Off Period Plot ....................................................................................................................................... 12 8.2 DUTY CYCLE ......................................................................................................................................................................................................... 13 8.2.1 Test Data: Duty Cycle Calculation Table ......................................................................................................................................... 13 8.2.2 Test Data: Subpulse 1 Activity in 100 ms Plot ................................................................................................................................. 14 8.2.1 Test Data: Subpulse 1 Duration.......................................................................................................................................................... 15 8.2.2 Test Data: Subpulse 2 Duration ......................................................................................................................................................... 16 8.3 OCCUPIED BANDWIDTH ................................................................................................................................................................................. 17 8.3.1 Test Data: Occupied Bandwidth Measurement Table ................................................................................................................. 17 8.3.2 Test Data: 20 dB Occupied Bandwidth Measurement Plot ...............................................................…

Text truncated - open the document above for the full version.

ANNEX B – Test Setup Photograph Exhibit Matrix Product Development Model: 100413 FCC ID: 2AHZG-THERMONEW433 IC: 21362-THERMONEW433 Radiated Testing, Table Setup Radiated Testing, Below 1 GHz Radiated Testing, Above 1 GHz
